Elkay LVRCTL8 1D Series Installation manual

Page 1 1000002159 (Rev. E - 01/19)
LVRCTL8*1D
LVRCTL8S-BAC Factory Prep
Installation, Care & Use Manual

LVRCTL8*1D
Page 21000002159 (Rev. E - 01/19)
10 20
15
18
5
29
See Figure 1
16
6
See Fig. 5
See Fig. 4
25
25
34
21
19
11
36
35
43
43 9
21
28
40 (TL)
43 35 8
38 (TL)
13
37
21
3, 7, 44
29
16 16 4, 23,
30, 39
2
17
4, 23, 30, 39
15
34
41
12
FIG. 1
Uses HFC-134A refrigerant
Note: Danger! Electric shock hazard. Disconnect power before servicing unit.
See Figure 1
43
43
43

Page 3 1000002159 (Rev. E - 01/19)
LVRCTL8*1D
13 7/8"
352mm
18 3/4"
476mm
20 1/8"
511mm
25 1/8"
638mm
11/16"
18mm
3 1/2"
89mm
4 1/2"
114mm
6 1/4"
159mm
5"
127mm 2 1/2"
63mm
10"
254mm
20 3/8"
518mm
2 9/16"
65mm
7 1/4"
185mm
3/4"
18mm
4 1/2"
116mm
F
A
E
D
B
F
E
1 3/8"
35mm
5 3/4"
146mm 5 3/4"
146mm
1 3/8"
35mm
37 1/2"
952mm
O
5/16"
8mm HOLES (10)
FINISHED FLOOR
FILTER
C
8"
203mm
6 3/4"
172mm
12 5/16"
312mm
4 1/8"
105mm
27"
686mm
ADA
REQUIREMENT
31 13/16"
808mm
RIM HEIGHT
33"
838mm
ORIFICE
HEIGHT
39 9/16"
1005mm
ORIFICE
HEIGHT
HANGER
BRACKET
2 5/8"
66mm
1 1/2"
37mm
18 11/16"
474mm
FILTER
FINISHED FLOOR
6 1/2"
165mm
1 3/8"
35mm 1 3/8"
35mm
5 3/4"
146mm 5 3/4"
146mm
LEGEND/LEYENDA/LÉGENDE A = RECOMMENDED WATER SUPPLY LOCATION 3/8 O.D. UNPLATED COPPER TUBE CONNECT STUB WITH SHUT OFF (BY OTHERS) 3 IN. (76mm) MAXIMUM OUT FROM WALL
MUR
B = RECOMMENDED LOCATION FOR WASTE OUTLET 1-1/2” O.D. DRAIN STUB 2 IN. OUT FROM WALL C = 1-1/2 TRAP NOT FURNISHED D = ELECTRICAL SUPPLY (3) WIRE RECESSED BOX E = INSURE PROPER VENTILATION BY MAINTAINING 6” (152 mm) (MIN.) CLEARANCE FROM CABINET LOUVERS TO WALL. F = 7/16 BOLT HOLES FOR FASTENING UNIT TO WALL
FIG. 2
REDUCE HEIGHT BY 3” FOR INSTALLATION OF CHILDREN’S ADA COOLER
LVRCTL8

LVRCTL8*1D
Page 41000002159 (Rev. E - 01/19)
Fig. 3
Filter Installation Detail
IMPORTANT
ALL SERVICE TO BE PERFORMED BY AN
AUTHORIZED SERVICE PERSON
HANGER BRACKETS & TRAP
INSTALLATION
1) Remove hanger bracket fastened to back of
cooler by removing one (1) screw.
2) Mount the hanger bracket and trap as shown
in Figure 2.
NOTE: Hanger Bracket MUST be supported
securely. Add xture support carrier if wall will
not provide adequate support.
IMPORTANT:
• 4 1/8 in. (105mm) dimension from wall to
centerline of trap must be maintained for
proper t.
• Anchor hanger securely to wall using all ve (5)
1/4 in. dia. mounting holes.
3) Install straight valve for 3/8” O.D. tube.
INSTALLATION OF COOLER
4) Hang the cooler on the hanger bracket. Be
certain the hanger bracket is engaged properly
in the slots on the cooler back as shown in Figure
2.
5) Loosen the two (2) screws holding the lower
front panel at the bottom of cooler base and
two (2) screws at the top (Use torx bits sold
separately). Remove the front panel and set
aside.
6) Connect water inlet line--See Note 4 of General
Instructions.
7) Remove the slip nut and gasket from the
trap and install them on the cooler waste line
making sure that the end of the waste line ts
into the trap. Assemble the slip nut and gasket
to the trap and tighten securely.
START UP
Also See General Instructions
8) Stream height is factory set at 45-50 PSI. If
supply pressure varies greatly from this, adjust
screw using the access hole in the pushbutton
(insert screwdriver). CW adjustment will raise
stream and CCW adjustment will lower stream.
For best adjustment, stream should hit basin
approximately 6-1/2” (165mm) from bubbler.
Stainless Steel
PANEL COLOR
COLOR TABLE
Item No. 40
Part No.
Item No. 32
Part No.
Item No. 34
Part No.
Item No. 35
Part No.
Item No. 36
Part No.
28525C28519C 28516C 28536C22955C
Refrig. Unit
Stainless Steel
PANEL COLOR
COLOR TABLE
Item No. 38
Part No.
Item No. 32
Part No.
Item No. 33
Part No.
Item No. 34
Part No.
Item No. 35
Part No.
Item No. 37
Part No.
28539C28519C 28516C 28528C28522C 22955C
Left Unit
Fig. 4
VANDAL RESISTANT BUBBLER DETAIL
BASIN
1

Page 5 1000002159 (Rev. E - 01/19)
LVRCTL8*1D
Fig. 5
(Refrigerated side shown)
30
1
43 (8)
23
1
25
1
40 (TL)
7
31
24 36
43
43
33
34
27
27
27
27
14, 27
26
42
32
22
27
43
43
27
(Items 31 & 24 also
used on the LH unit)
1
43
43
42
39 4
44 3
15

LVRCTL8*1D
Page 61000002159 (Rev. E - 01/19)
HAC
1:4
Fig. 6
DESCRIPTION
1
2
3
4
5
6
ITEM NO. PART NO.
0000000469
0000000471
0000000484
72460104
0000000376
0000000420
Filter Head Assy.
Screw #10-16 x .50 PH
Tube - Inlet
Reducer Fitting - 3/8” x 1/4”
Filter Assy - Pure 3000 gallon
Filter Bracket
WATERSENTRY® PURE FILTER PARTS LIST
(See Fig. 6)
2
4
3
1
6
5
97446C
98777C
75588C
110868642550
1000001994
98775C
56121C
98773C
0000000238
35870C
36322C
1000001602
1000004447
98530C
45929C
56092C
27124C
98776C
66703C
98724C
70002C
55931C
600985451640
28617C
0000000966
22897C
1000001906
98778C
75524C
100147140560
28596C
See Color Table
See Color Table
See Color Table
See Color Table
See Color Table
See Color Table
See Color Table
160270508640
See Color Table
55996C
70864C
0000001190
75589C
28551C
Kit - VR Bubbler Replacement
Kit - Compressor Hardware
Nut - 1-1/4” Slip Joint
Screw - #10-24 x .75 Socket Hd.
Kit - Tee 1/4” (3 Pack)
Kit - Fan Mtr/Blade/Shroud/Screws/Nut
Elbow - Drain
KIt - Cold Control/Screws
Kit - Elect/Relay/Overload/Cover
Power Cord
Compressor Serv. Pak EMI 70
Kit - Elbow 5/16” - 1/4” (3 Pack)
Kit - Drain Tube Assy.
Kit - Regulator/Holder/Nut
Tube - Drain
Tubing - Poly (Cut To length)
Cover - Cold Control
Kit - CondenserDrier
Drier
Evaporator Replacement Assembly
Screw - #10 x 1/2” Lg. HHSM
Cover - Dispenser Bottom
Drain Plug 1-1/2
Screen - VR
Replacement Basin - Stainless Steel
Panel - Bottom Dispenser
Kit - Push Button/Sleeve/Spacer/Screw Nuts
Kit - Heat Exchanger/Drier
Clip (Front & Rear Panels)
Gasket - Drain
Panel - Screen
Panel - RH Dispenser Side
Panel - LH Dispenser Side
Panel - Dispenser Front
Panel - Front Lower
Panel - RH Rear
Panel - LH Rear
Panel - RH Rear TL
Strainer - Bright
Panel - LH Rear TL
Strainer (See “General Instructions”)
Screw - #8 x .62 Torx/Slot
Kit - #10 x .50 Pinned Torx Screws/T25-Bit
Gasket
Hanger Bracket
PART NO. DESCRIPTION
1
2
3
4
5
6
7
8
9
10
*11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
NS
ITEM NO.
115V PARTS LIST
*REPLACE WITH SAME COMPRESSOR USED
IN ORIGINAL ASSEMBLY.
NOTE: All correspondence pertaining to any of the above
water coolers or orders for repair parts MUST include Model
No. and Serial No. of cooler, name and part number of replace-
ment part.
REPAIR SERVICE INFORMATION TOLL FREE NUMBER 1.800.260.6640
FOR PARTS, CONTACT YOUR LOCAL DISTRIBUTOR OR CALL 1.800.834.4816
ELKAY MANUFACTURING COMPANY • 2222 CAMDEN COURT • OAK BROOK, IL 60523 • 630.574.8484 • www.elkay.com
PRINTED IN U.S.A.
NS = NOT SHOWN
