Elkay Blubar Countertop Manual

Table of Contents
Declaraon of Conformity 2
Associaon 2
Recommendaons for Safeguarding the
Environment 3
Explanaon of Warning/Safety Icons 3
Introducon 4
Components Guide 5
Product Specicaons 6
Before You Begin –
Requirements for Installaon 7
Mounng Dimensions 7
Operang Environment 8
Water 8
Electrical 8
Tools You Will Need 9
Unpacking the Kit 9
What’s in the Kit 10
Installing the Machine 11
Operang the Touch Control
Keypad Fontemagna Compact Only 16
Programming the Touch Control
Keypad Fontemagna Compact Only 18
Roune Maintenance 19
Troubleshoong 22
Replacement Parts 25
NOTICE: Read the instrucons in this manual and retain for future reference.
Installaon and
Maintenance
Manual

2
Blubar Countertop and Fontemagna Compact
Installaon and Maintenance Manual
Declaraon of Conformity
D.M. 174
1
0
0
%
M
A
D
E
I
N
I
T
A
L
Y
C
E
R
T
I
F
I
C
A
T
E
I
T
P
I
rosso032 c
Materials compliant for contact with drinking water
This unit is intended for the dispensing of drinking water, and so the materials that enter into direct contact with
water meet the criteria for food-grade components pursuant to the current legislaon. In addion, the unit is
manufactured in compliance with Italian Ministerial Decrees 174 of 04/06/2004 and 25 of 02/07/2012.
Electrical safety
This water cooler is designed, manufactured and marketed in compliance with:
O the safety objecves of the Low Voltage Direcve 2006/95/EC;
O the protecon requirements of the Electromagnec Compability Direcve 2004/108/EC.
The electrical safety of the product is ensured only when it is properly connected to an ecient, legally
compliant grounding circuit.
UL standard for safety of drinking water coolers, ANSI/UL 399, Issued: 2008/08/22, Ed: 7, Rev: 2013/10/18
CSA standard for refrigeraon equipment, CSA C22.2 No. 120, Issued: 2013/03/01, Ed: 4
Associaon
D.M. 174
1
0
0
%
M
A
D
E
I
N
I
T
A
L
Y
C
E
R
T
I
F
I
C
A
T
E
I
T
P
I
rosso032 c
Internaonal Awards
2014 – BEST PROMOTION OF HEALTH AND HYDRATION
EUROPEAN AQUA AWARDS 2014, BUDAPEST
2013 – BEST PRODUCT INNOVATION
EUROPEAN AQUA AWARDS 2013, BERLIN
2012 – BEST ENVIRONMENTALLY FRIENDLY PRACTICE
EUROPEAN AQUA AWARDS 2012, ISTANBUL
2011 – BEST PRODUCT DESIGN/INNOVATION
EUROPEAN AQUA AWARDS 2011, ODESSA
2010 – BEST ENVIRONMENTALLY FRIENDLY PRACTICE
EUROPEAN AQUA AWARD 2010, PRAGUE

3
1000002474 (Rev. F - 06/2023)
Recommendaons for Safeguarding the Environment
Packaging materials
D.M. 174
1
0
0
%
M
A
D
E
I
N
I
T
A
L
Y
C
E
R
T
I
F
I
C
A
T
E
I
T
P
I
rosso032c
The packaging materials are 100% recyclable. Please follow the local guidelines on waste disposal.
For safety reasons keep the packaging material out of the reach and sight of children.
Scrappage
D.M. 174
1
0
0
%
M
A
D
E
I
N
I
T
A
L
Y
C
E
R
T
I
F
I
C
A
T
E
I
T
P
I
rosso 032 c
The Fontemagna Compact and Blubar Countertop water coolers are made using recyclable material.
These units are marked in compliance with European Direcve 2002/96/EC on Waste Electrical and
Electronic Equipment (WEEE). By ensuring that the product is scrapped correctly, you will help to
prevent potenal negave consequences for the environment and for health. This symbol indicates
that the product should not be treated as domesc waste but should be taken to a dedicated recycling
center for electrical and electronic equipment. Immediately prior to scrapping, cut o the power cable.
For more informaon on the treatment, recovery and recycling of this product, please contact
the appropriate local oce, the waste disposal service or the reseller from which the product was
purchased.
These products contain no CFCs or HFCs, which contribute to global warming.
They are the rst water coolers on the American market to use natural refrigerant.
The refrigerang system is lled with R134a: a natural gas that does not contribute to global warming
and that allows for substanal Energy Savings.
Explanaon of Warning/Safety Icons
NOTICE: Indicates an instrucon which, if not followed, could result in damage to product or property
or poor product performance.
CAUTION: Indicates an instrucon which, if not followed, could result in minor or moderate injury.
WARNING: Indicates an instrucon which, if not followed, could result in serious injury or death.

4
Blubar Countertop and Fontemagna Compact
Installaon and Maintenance Manual
Introducon
The Fontemagna Compact and Blubar Countertop coolers bring contemporary style and state-of-the-art
technology to commercial water dispensers. Fontemagna Compact combines precise pushbuon control with
a sleek, minimalist design, while Blubar Countertop puts a modern spin on the tradional appeal of the hand-
operated tap.
O Mulple dispensing opons: cold sll water, cold sparkling water, and room-temperature sll water
(Fontemagna Compact only)
O Natural materials throughout: stainless steel, aluminum, Plexiglas
O Internal components made enrely of stainless steel
O Dual cooling coil – one for cold water and one for sparkling water, with the opon for simultaneous dispensing
O High-insulaon ice bank ensures a high output of cold water, sll and sparkling
Fontemagna Compact
O Preprogrammed quanes of water to minimize overow and waste
O Electronic keypad with glass cover, easy to use and hygienic, with touch control commands
O Self-diagnosis and alarm system responds to lile or no water ow, an accidental water leak or the need for
CO2 cylinder replacement
O Energy Saving command: when selected, this feature enables standby funconality of the unit, with
consumpon reduced by 75% compared to full funconality
NOTICE: Due to rigorous tesng, product may reasonably be expected to contain traces of sanizing
soluon.

5
1000002474 (Rev. F - 06/2023)
Components Guide
Removable top cover
Lockable top cover
Touch Control
keypad
Tap – sparkling water
Tap – sll water
Drip tray
Drip tray
Ice bank inlet
Thermostat
Ice bank overow
Water inlet
Water inlet
CO2inlet
CO2inlet
Power cord
Power switch
LED alarms
No/low H20 pressure
No/low CO2 pressure
Machine stopped
Dispensing buons –
small serving
large serving
Power
buon
Energy
Saving
buon
Cold
sparkling
dispenser
Room-temperature
sll dispenser
Cold sll
dispenser
Blubar Countertop Fontemagna Compact
Fontemagna Compact
Touch Control keypad
Power cord

6
Blubar Countertop and Fontemagna Compact
Installaon and Maintenance Manual
Product Specicaons
Specicaon Blubar Countertop Fontemagna Compact
Cooling capacity gal/h (lt/h) 20 (80) 20 (80)
Connuous supply gal (lt) 12 (45) 12 (45)
Cold water temperature 37.4°F – 50°F
(3°C – 10°C)
37.4°F – 50°F
(3°C – 10°C)
Ice bank capacity gal (lt) 3.7 (14) 3.7 (14)
Ice bank lb (kg) 11 (5) 11 (5)
Cooling technology ICE BANK single stainless steel coil ICE BANK single stainless steel coil
Condensaon Forced venlaon (fan) Forced venlaon (fan)
Adjustable thermostat Yes Yes
Refrigerant gas R134a R134a
Pump Professional booster pump Professional booster pump
Inlet water pipe ø 3/8" ø 3/8"
Power 115V - 60Hz 115V - 60Hz
Power consumpon 330W - 3.2A 330W - 3.2A
Working room temperature Min 41°F – Max 107.6°F
(Min 5°C – Max 42°C)
Min 41°F – Max 107.6°F
(Min 5°C – Max 42°C)
UNIT WEIGHT lb (kg) 77
(35)
82
(45)
SHIPPING WEIGHT lb (kg) 84
(38)
110
(50)
Dimensions W x D x H in (mm) 14.2 x 22.6 x 22.4
(360 x 575 x 570)
18.1 x 23.2 x 20.1
(460 x 590 x 510)
Dispensing area height in (mm) 12.6 (320) 13.38 (310)
Packaging dimensions
W x D x H in (mm)
18.1 x 24.8 x 26.0
(460 x 630 x 660)
21.2 x 27.6 x 26.8
(540 x 700 x 680)
Dispensing Supply opon (sparkling, cold water) Supply opon (sparkling, cold and room
temperature water) with customizable
poron control system
Mechanical outlet taps HQ stainless steel
Push buons Electronic touch pad board
Energy Saving device Included, dedicated push buons
Display Alarms No/low water, No/low CO2, leakage
Materials All robust stainless steel parts,
Plexiglas front panel
All robust stainless steel and aluminum parts

7
1000002474 (Rev. F - 06/2023)
Before You Begin – Requirements for Installaon
Mounng Dimensions
Width
22.2"(564mm)
Width
26.1"(663mm)
Depth
26.6" (678mm)
Depth
27.2" (691mm)
Height
34.4" (874mm)
Height
34.4" (874mm)
Height
28" (711mm)
Height
12.75"
(324mm)
Depth
3.88" (99mm)
Diameter
8" (203mm)
Width
3.25" (83mm)
Footprint:
14.2” wide x 22.6" deep
363mm x 574mm
Footprint:
18.1" wide x 23.2" deep
460mm x 589mm
Blubar Countertop
Over counter (includes 4" clearance on sides and back)
Under counter
Water lter
CO2 cylinder (typical, 20 pound)
Fontemagna Compact

8
Blubar Countertop and Fontemagna Compact
Installaon and Maintenance Manual
Operang Environment
O Install the machine in a clean, dry, well-venlated room. It is designed to funcon correctly in environments
with a temperature of 16°C to 32°C – Climac Class N, (between 61°F and 90°F).
O Check that the water cooler is level, that it is on a surface that can support its weight and in an environment
suitable for its size and use.
O Do not place the machine near a source of heat.
O To guarantee adequate venlaon, leave at least 4" (100 mm) of space around the unit.
O Take care not to damage the cooling uid circuit. It is essenal to ensure that the tubes of the refrigerant
circuit are not damaged.
O The unit is not intended for use by children.
O Keep the areas surrounding the unit dry to avoid the risk of people slipping.
O The unit must not be cleaned with a water jet.
Water
O Always connect the water cooler to a water main that supplies drinking water only.
O Use of 3/8" diameter connecons is recommended.
O Turn o the main water inlet tap if the unit is not to be used for a long period.
Electrical
O Check that the voltage shown on the serial number plate corresponds to the voltage being
supplied at the installaon site.
O Do not use extension cables or mulple-power sockets. The machine must be located
close enough to a standard power socket that the supplied power cable reaches without
stretching.
O Aer installaon, check that the machine is not standing on its power supply cable.
O Ensure that it is possible to disconnect the power supply either by removing the plug or via a two-pole circuit
breaker placed upstream of the plug.
O Before any maintenance or cleaning operaon is carried out, remove the plug from the socket or disconnect
the power supply.
O If the power cable is damaged, it must be replaced by the manufacturer, by its technical support service or by
a qualied technician.
O Do not posion other electrical equipment in the immediate vicinity of the water cooler.

9
1000002474 (Rev. F - 06/2023)
Tools You Will Need
Unpacking the Kit
Remove the front panel (labeled FRONT) and cover of the
wooden packing case.
Remove the cardboard box and the internal protecve
packaging by sliding them up and over the top.
Once you have unpacked the machine, check all components
to ensure that they are not damaged. Contact the carrier
immediately if there has been any damage during shipping.
NOTICE: Ensure that your machine is installed by a
qualied technician in compliance with the
manufacturer’s instrucons and the local safety
guidelines.
NOTICE: Only qualied technicians should access the internal components of your machine, other than
to ll the ice bank.
(2) 8" adjustable wrenches
(1) 10" adjustable pliers
(1) 12" adjustable wrench
(1) universal screwdriver
(1) 12" pipe cuer
(1) wire cung pliers

10
Blubar Countertop and Fontemagna Compact
Installaon and Maintenance Manual
What’s in the Kit
NOTICE: CO2 source is not included and must be supplied separately.
(1) Blubar Countertop or Fontemagna
Compact water cooler
(1) CO2
regulator
(1) external
water lter
Top panel
keys
(2) 3/8"–quick
connect connector
(1) supply hose 1/2 ips x 3/8
tube x 12” long
(1) water
shuto valve
(1) water
pressure
regulator
(1) 10' coil CO2
tubing 1/4” OD
(natural)
(1) 3/8” x 1/4”
quick connect
connector
(1) 4” piece of
1/4” OD tubing
(1) 10' coil
water tubing
3/8” OD (blue)
PLUS
