Ellisys SerialTek Gen5 POD SSAS User manual

EDSFF Variations
Gen5 POD EDSFF Edition Assembly Reference
0004642 - R1.4
Page 1 of 9
CAUTION :
Failure to do the following may DAMAGE the interposer and VOID the warranty.
•Secure adapters as shown in this guide
•Do NOT change adapters while powered
•Do NOT hot plug
•Turn on interposer power BEFORE host power
Item Part
Number Part Description Qty
1 4631 POD Main Unit 1
24687 EDSFF Device Adaptor Base Tray 1
3 4466 SFF-TA-1006/7 Spacer Base Assembly 1
4 4702 SFF-TA-1006 Cased Spacer 1
54703 SFF-TA-1007 Uncased Spacer 1
6 4697 SFF-TA-1006 Uncased Tray 1
74464 SFF-TA-1008 Spacer Base 1
8 3736 M3x4mm Black Flat Head Screw 3
9 4991 4CM - 1CF E1 Device PCBA 1
10 4992 4CM - 1CF E3 Device PCBA 1
11 4679 Host/Device Cable Adaptor Tray 1
12 3972 HCBL-EDSFF Support Tray 1
13 4061 Hook & Loop Cable Tie 1
14 4698 SFF-TA-1007 E1.L HSA 1
15 4699 SFF-TA-1006 E1.S HSA 1
16 4700 SFF-TA-1008 E3.S HSA 1
17 4762 SFF-TA-1008 E3.L HSA 1
18 4974 PCI5-EDSFFMF 1
10
9
17
16
14
15
18
11 13 12 1
28
6
5
4
7
3

CASED OPTION (E1)
Gen5 POD EDSFF Edition Assembly Reference
0004642 - R1.4
Page 2 of 9
M3 x 4mm Flat Head Screw
SFF-TA-1006 Cased Spacer
M3 x 4mm Flat Head Screw SFF-TA-1006/7 Spacer Base Assembly
Fix the SFF-TA-1006/7 Spacer Base Assembly to the EDSFF Device
Adaptor Base Tray using three M3 x 4mm Flat Head screws.
Slide the SFF-TA-1006 Cased Spacer over the SFF-TA-1006/7
Spacer Base Assembly and secure at one end with two M3 x 4mm
Flat Head Screws
EDSFF Device Adaptor Base Tray

UNCASED OPTION (E1)
Gen5 POD EDSFF Edition Assembly Reference
0004642 - R1.4
Page 3 of 9
SFF-TA-1006 Uncased Tray
M3 x 4mm Flat Head Screw
SFF-TA-1007 Uncased Spacer
M3 x 4mm Flat Head Screw SFF-TA-1006/7 Spacer Base Assembly
Fix the SFF-TA-1006/7 Spacer Base Assembly to the EDSFF Device Adaptor
Base Tray using three M3 x 4mm Flat Head screws.
Slide the SFF-TA-1007 Uncased Spacer over the SFF-TA-1006/7 Spacer Base
Assembly and secure at one end with two M3 x 4mm Flat Head Screws.
Slide the SFF-TA-1006 Uncased Tray along runners on the Uncased Spacer
and Spacer Base Assembly .
EDSFF Device Adaptor Base Tray

SFF-TA-1008 (E3)
Gen5 POD EDSFF Edition Assembly Reference
0004642 - R1.4
Page 4 of 9
SFF-TA-1008 Spacer Base
EDSFF Device Adaptor Base
M3 x 4mm Flat Head Screw
Fix the SFF-TA-1008 Spacer Base to the EDSFF Device Adaptor
Base Tray using three M3 x 4mm Flat Head screws

Gen5 POD EDSFF Edition Assembly Reference
0004642 - R1.4
Page 5 of 9
POD Main Unit
EDSFF Device Adaptor Base Tray
M3 Captive Panel Screw
Slide the EDSFF Device Adaptor Base Tray into the slot on the DEVICE side on the
underside of the POD Main Unit at an angle of about 60~.
Rotate the EDSFF Device Adaptor Base Tray so it is horizontal and tighten the M3
Captive Panel Screws to the POD Main Unit, ensuring not to over tighten.

SFF-TA-1006/1007 (E1)
Gen5 POD EDSFF Edition Assembly Reference
0004642 - R1.4
Page 6 of 9
4CM - 1CF E1 Device PCBA
POD Main Unit
M3 Captive Screw
Raise M3 Captive Screws till it resists and screw thread clears the underside of
PCBA, then slide the 4CM - 1CF E1 Device PCBA into the connector on the
DEVICE side of the POD Unit and secure in position on the SFF-TA-1006-7
Spacer Base Assembly with M3 Captive Screws.
EDSFF Device Adaptor Base Tray
SFF-TA-1006-7 Spacer Base Assembly

SFF-TA-1008 (E3)
Gen5 POD EDSFF Edition Assembly Reference
0004642 - R1.4
Page 7 of 9
4CM - 1CF E3 Device PCBA
M3 Captive Screw
SFF-TA-1008 Spacer Base Plate
EDSFF Device Adaptor Base Tray
Raise M3 Captive Screws till it resists and screw thread clears
the underside of PCBA, then slide the 4CM - 1CF E3 Device
PCBA into the connector on the DEVICE side of the POD Unit
and secure in position on the SFF-TA-1008 Spacer Base Plate
with M3 Captive Screws.
POD Main Unit

Gen5 POD EDSFF Edition Assembly Reference
0004642 - R1.4
Page 8 of 9
POD Main Unit
Host/Device Cable Adaptor Tray
M3 Captive Panel Screw
Slide the Host/Device Cable Adaptor Tray into the slot on the HOST side
on the underside of the POD Main Unit at an angle of about 60~.
Rotate the Cable Adaptor Tray so it is horizontal and tighten the M3
Captive Panel Screws to the POD Main Unit, ensuring not to over tighten.

Gen5 POD EDSFF Edition Assembly Reference
0004642 - R1.4
Page 9 of 9
POD Main Unit
Hook & Loop Cable Tie Host/Device Cable Adaptor Tray
M3 Spring Loaded Screw
HCBL-EDSFF Support Tray
Ensure the PCI5 EDSFFMF Cable is in the correct orientation,
TOP label facing upwards. Slide the cable onto the
HCBL-EDSFF Support Tray and connect to the HOST side of
the POD Main Unit aligning PINs A1/B1.
Secure in position with the Hook & Loop Cable Tie.
PIN A1/B1 Position
PCI5-EDSFFMF
Raise the Caps of the M3 Spring Loaded Screws and secure the
HCBL-EDSFF Support Tray in position on the Host/Device Cable
Adaptor Tray with the M3 Spring Loaded Screws
