Elo TouchSystems AMM17TK User manual

AMM17TK/AMM18TK/AMM19TK 1
back of the monitor
ADAVN INTL CORP.2002
ELO is a Registered trademark of Elo TouchSystems, Inc.,
All other trademarks are the property of their reference owners.
This document is subject to change without notice.
Advan provides this information as reference only. Reference to other vendors products
does not imply any recommendation or endorsement.
Revision Control
WARNING
The title "WARNING" is used to inform the users of
possible causes that could inflict the injury, death, or
property damage to the patients.
CAUTION
The title "CAUTION" is used to inform the users of
possible causes that could inflict the patients although
it might not severe enough to cause deaths.
NOTE
The title "NOTE" is used to inform the users of items
that are of importance in terms of installation,
operation, or maintenance ofthe Equipment although
the failure does not inflict the bodily harm to the
patients.
Date Description
Document number

FCC Notice
NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, user and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment dose cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
The user manual or instruction manual for an intentional or unintentional
radiator shall caution the user that changes or modifications not expressly
approved by the party responsible for compliance could void the user’s
authority to operate the equipment.

2Users Guide
TABLE OF CONTENTS
Quick Setup................................................................................... 3~5
Product Features... 6
Unpacking .... 7
Symbol Explanations. 8
Regulatory Compliance. 8
EU Declaration of Conformity for Medical Applications......... 9
Screen Position Adjustment... 10
Cleaning lnstructions.. 11
Supported Modes..... 12
Power Management Function 13
Power Management System.. 13
Connecting the Power Cord.. 14
DDC. 14~15
Installation. 14~15
Installation for Video Play Back.......................................................16
User Controls... 17
Basic OSD Operation (VGA)... 18~20
Basic OSD Screen Section (C-Video or S-Video).... 21~23
OSD Function Description (VGA) 24
OSD Function Description (C-Video or S-Video)........... 25
Troubleshooting 26
Specification of AMM17TK......................................................... 27
Specification of AMM18TK......................................................... 28
Specification of AMM19TK......................................................... 29
Connectors... 30
Description of Warranty 31~32
Tounchscreen Users Manual ... 33~34

AMM17TK/AMM18TK/AMM19TK 3
Quick Setup (IBM/IBM Compatible under Windows 95/98/ME/2000)
Please Read Carefully When Setting Up Your New Monitor
AGM17TK/AGM18TK/AGM19TK Monitor Screen Adjustment and Resolution Setting
Procedure for IBM/IBM Compatible Computers with Windows based OS system.
Before adjusting the monitor, all the necessary drivers should be installed to your System
and resolution has to be set to manufacturers recommended preset of 1280 x 1024 @ 60Hz,
70Hz, 72Hz or 75 Hz.
To check the resolution, press the SELECT UP button on the monitor and the Information
will display under the OSD. Information will have Resolution, Horizontal and Vertical (Refresh
rate) frequency information.
To change the resolution to its factory recommended preset.
1. On a Windows 95, 98, ME or 2000, press right button on a Mouse to execute the Pop-up
menu.
2. Press Properties to execute the Display Properties
3. Press Setting and change the resolution to 1280 x 1024.
4. Press Apply or OK to select and press OK to keep the selected resolution.
5. Go back to Display Properties - Setting - Advanced properties - Adapter
6. On Adapter property, change the refresh rate to 60Hz, 70Hz, 72Hz or 75Hz. If you dont
have these options, choose Adapter Default. (60Hz recommended)
Screen Adjustment Procedure
1. Press the AUTO button.
2. If you still dont have a clear display monitor, please refer to step 3.
3. Start Shut Down in Windows 95/98/ME/2000 - It will display moire on screen
4. Press Up or Down button then the OSD menu will pop-up.
5. Adjust the Frequency under the OSD to reduce or get rid of the vertical display noise
(Jail bars). (Page 16)
6. Once the vertical display noise disappears, press adjust the Phase to reduce or get rid of
the horizontal display noise (Snowy effect). (Page 16)

4Users Guide
Quick Setup (IBM/IBM Compatible under Windows NT 4.0)
Please Read Carefully When Setting Up Your New Monitor
AGM17TK/AGM18TK/AGM19TK Monitor Screen Adjustment and Resolution Setting
Procedure for IBM/IBM Compatible Computers with Windows based OS system.
Before adjusting the monitor, all the necessary drivers should be installed to your System
and resolution has to be set to manufactures recommended preset of 1280 x 1024 @ 60Hz,
70Hz, 72Hz or 75Hz.
To check the resolution, press the SELECT UP button on the monitor and the Information
will display under the OSD. Information will have Resolution, Horizontal and Vertical (Refresh
rate) frequency information.
To change the resolution to its factory recommended preset.
1. On a Windows NT 4.0, press right button on a Mouse to execute the Pop-up menu.
2. Press Properties to execute the Display Properties
3. Press Setting and change the resolution to 1280 x 1024.
4. Change Refresh Frequency to 60Hz, 70Hz, 72Hz or 75Hz. (60Hz recommended)
Screen Adjustment Procedure
1. Press the AUTO button.
2. If you still dont have a clear display monitor, please refer to step 3.
3. Start Shut Down in Windows 95/98/ME/2000 - It will display moire on screen
4. Press Up or Down button then the OSD menu will pop-up.
5. Adjust the Frequency under the OSD to reduce or get rid of the vertical display noise
(Jail bars). (Page 16)
6. Once the vertical display noise disappears, press adjust the Phase to reduce or get rid of
the horizontal display noise (Snowy effect). (Page 16)

AMM17TK/AMM18TK/AMM19TK 5
Quick Setup (Macintosh)
Please Read Carefully When Setting Up Your New Monitor
1. Set your Macintosh Adapter on pages 23 and 24.
2. Push the APPLE icon on the upper left corn and execute Control Panel->
Monitors&Sound. Select Thousands for the Color Depth, Select 1280X1024, 60Hz,
70Hz, 72Hz or 75Hz for the Resolution. (60Hz recommended)
* On some Apple G3 or newer systems, you may not need to use the Macintosh Adapter.
Screen Adjustment Procedure
1. Press the AUTO button on the monitor.

6Users Guide
INTRODUCTION
Congratulations on your purchasing of the AMM17TK/AMM18TK/AMM19TK high
performance TFT LCD monitor.
FEATURES
TheAGM17TK/AGM18TK/AGM19TK is a TFT-LCD monitor that is intelligent, microprocessor-
based and ergonomically designed display, compatible with most analog RGB (Red, Green,
Blue) display standards, including PS/V, PS/2, Apple Macintosh Centris, Quadra, and Macintosh
II family signals. The LCD monitor is capable of displaying crisp and vibrant color graphics with
VGA, SVGA, XGA, SXGA (non-interlaced), and most Macintosh compatible color video cards.
•Advanced Viewing Solution (AVS): Our sophisticated filter extends the viewing angle of
the screen image, without sacrificing contrast ratio and brightness.
•Advanced Timing Setup (ATS): Aunique technology from the One TouchAutoAdjustment.
Pressing the Auto Adjust button on the front panel, automatically optimizes position,
phase, clock, contrast and color balance. This allows the user to maximize the perfect
screen setting in the shortest amount of time.
•Advanced Mounting Solution (AMS): Improve flat panel environment, utilizing numerous
ergonomic mounting solutions to allow creative use in conjunction to product application.
•The monitor is able to properly function even in case of upgrade video cards or software
because of the wide auto-scanning compatibility range without requiring to buy a new
monitor.
•The internal microprocessor digitally controls auto-scanning. For horizontal scan
frequencies between 24.8 KHz and 60.2 KHz, and vertical scan frequencies between
56.3 Hz and 85.1 Hz. In each frequency mode, the microprocessor-based circuitry allows
the monitor to function at the precision-of a fixed frequency.
•The resident memory allows for storing factory default settings and also additional user
adjustment parameters.
•The maximum resolution achievable is SXGA (1280 x 1024), best suited for Windows
applications
•The compact and sleek cabinet design saves lot of your desk space and makes your desk
look neat and tidy.
•The monitor is compliant with VESA-DPMS power management standard. In order to
save energy, the monitor must be connected to a system compliant with the standard.
•The monitor is also compliant with the most stringent environmental scheme of TCO
95. In this scheme, no environmental harmful substances are used during the entire
manufacturing process.
The monitor is certified by UL International to medical standard UL2601-1. It is also CE
marked for sale into the European Community for integration or use with medical products. It
is certified by NEMKO according to EN60601-1 & EN60601-1-2 for sale to the medical market.

AMM17TK/AMM18TK/AMM19TK 7
UNPACKING
Please check the following items are present when you unpack the box, and save the packing
materials in case you will need to ship or transport the monitor in future.
•AMM17TK/AMM18TK/AMM19TK LCD Monitor and two video cable (1) VGA
HDDB15 cable (1) DVI-D cable
•AC Power cord
•AC-Adapter
•Floppy Disk (for test pattern and set up)
•User Manual, Registration Card, and Warranty Card
•C-video(Composite Video) Cable, S-Video Cable, Audio Cable and USB Cable
5(*,675$7,21
:$55$17<
AUTO
SELECT
CAUTION
Manufacturer : Ault Korea
Model No : MW160 or MW116

8User TMs Guide
Symbol Explanations
Indicates proof of conformity to applicable European Economic
Community Council directives and to harmonized standards
published in the official journal of the European Communities
Tested and certified by UL to UL2601. If this mark appears with the
indicators "C" and "US" the product is certified for both the U.S and
Canadian markets, to the applicable U.S and Canadian standards.
Tested to comply with FCC Class B standards.
Dangerous high voltage.
Consult accompanying documents.
Tested and certified by NEMKO in accordance with EN60601-1.
Indicates protective earth ground.
For indoor use only.
DC power control switch
Regulatory Compliance
This monitor has been tested to comply with IEC/EN 60601-1 and IEC/EN60601-1-2.
Only model AGM19TK is classified according to UL2601-1 and CAN/CSA C22.2 No.601-1.
Because many medical offices are located in residential areas,this monitor,in addition to the
medical requirements,has also been tested and found to comply with the limits for FCC Class B
computing devices in a typically configured system. It is the system integrator or configurer's
responsibility to test and ensure that the entire system complies with applicable EMC laws.

8.1 User TMs Guide
Equipment is not suitable for use in the presence of flammable anesthetic mixture with air or with
oxygen or nitrous oxide.
No user serviceable parts inside, ask qualified personnel when accessing inside.
For disposal of waste product, you must follow the requirement of local code.
Electrical input rating : 12V d.c 4.5A
Classification
-Type of protection against electric shock : Class I Equipment.
-Degree of protection against the ingress of water : Ordinary
-Mode of operation : Continuous
Environmental conditions for transport and storage
-Temperature range within 20℃to 60℃
-Relative humidity range 10% to 90%
-Atmospheric pressure range within 500 to 1060hPa.
Manufacture information :
CARDIANAL INC.
205 Ace Techno Tower, 197-17
Kuro-Dong, Kuro-Gu, Seoul 152-050
Korea
Additional explanation of symbol
: Direct Current
This monitor is intended for use on Health Care Facilities.
Only the model AMM17TK, AGM19TK, AMM19TK and 240-030-900
Cleaning : Do not try to clean the LCD Monitor with a liquid or chemicals.
This device is complies with Part 15 of
the FCC Rules. Operation is subject to
the following two conditions: (1) this
device may not cause harmful
interference, and (2) this device must
accept any interference received,
including interference that may caus
e

AMM17TK/AMM18TK/AMM19TK 9
EU Declaration of Conformity for Medical Applications
ADeclaration of Conformity has been filed for this product. Asample of this
document may be found in the addendum which accompanied this manual. For a
copy of the Declaration of Conformity document, please contact ADVAN Intl
Corp. and request for AMM17TK, AGMM18TK andAMM19TK DOC.
Installation
Before you unpack your monitor, prepare a suitable workspace. You need a stable
and level surface near a grounded wall outlet in an area which is relatively free of
glare from sunlight or other sources of bright light. The monitor is cooled by natural
convection (it has no fan).
For optimum performance, do not block the cooling vents.
While unpacking the monitor, inspect it and other package contents for shipping
damage that could cause a fire or shock hazard. Immediately report any shipping
damage to the carrier or transportation company and contact customer service for
monitor in the future or in case of return.
After you unpack the monitor, make sure the following items are included
 Monitor with 1.5 meter(5ft)monitor-to computer video cable
 AC adapter with cable
CAUTION: AC Adapter must be plugged into Grounded a power outlet)
CAUTION : AC adapter
Manufacturer: Ault korea
Model No: MW160 or MW116
 Touchscreen cable if monitor has touchscreen option
 This operations manual
Note: Your system provider may offer alternative cords or cables
depending on the installation requirement and local geography issues.

10 Users Guide
SCREEN POSITION ADJUSTMENT
In order to optimize the best viewing position, you can adjust the tilt of the monitor by using
both of your hands to hold the edges of the monitor as shown in the figure below. The moni-
tor can be adjusted to 28 degrees up as indicated by arrow below.
28°

AMM17TK/AMM18TK/AMM19TK 11
SAFETY PRECAUTION
•Avoid placing the monitor, or any other heavy object, on the power cord to prevent fire or
electrical shock from damage to the power cord.
•Do not expose the monitor to rain, excessive moisture, or dust to avoid fire or shock hazard.
•Do not cover the slots or openings of the monitor for proper heat dissipation. Always put
the monitor in a place where there is adequate ventilation.
•Avoid placing the monitor against a bright background or where sunlight or other light
sources may reflect on the area of the monitor. Place the monitor just below eye level.
•Handle with care when transporting the monitor.
•Refrain from giving the shock or scratch to the screen, as screen is fragile.

12 User’s Guide
PRESET MODES
To reduce the need for adjustment for different modes, the monitor has default
setting modes that are most commonly used as given in the table below. If any
these display modes are detected, the monitor automatically adjusts the picture
size and centering. When none of the mode is matched, the user can store their
preferred modes in the user modes. The monitor is capable of storing up to 7
user modes. The only condition to store as a user mode is the new display
information must 1 KHz difference for horizontal frequency or 1 Hz for vertical
frequency or the sync signal polarities are differentfrom the default modes.
Mode
Resolution
(H×V) H. Freq.
(KHz) V. Freq. (Hz) Clock Freq. (MHz)
1
640
×
350
31.5
70
25.175
2
640
×
350
37.9
85
31.5
3
640
×
400
3
1.5
70
25.175
4
640
×
400
3
7.9
85
31.5
5
720
×
350
3
1.5
70
28.322
6
720
×
4
0
0
31.5
70
25.175
7
720
×
4
0
0
3
7.9
85
35.5
8
640
×
480
3
1.5
60
25.175
9
640
×
480
37.
9
7
2
31.5
10
640
×
480
37.5
75
31.5
11
640
×
480
43.3
85
36.0
12
800
×
600
3
5.1
56
36.0
13
800
×
600
37.9
60
40.0
14
800
×
600
4
8.1
72
50.0
15
800
×
600
46.9
7
5
49.5
16
8
00
×
6
00
53.7
85
56.25
17
1024
×
768
35.5
43
44.9
18
1024
×
768
48.4
60
65.0
19
1024
×
768
56.5
70
75.0
20
1024
×
768
60
75
78.75
21
1024
×
768
68.7
85
94.5
22
1
152
×
864
6
7.5
7
5
108.0
23
1
280
×
960
6
0
60
108.0
24
1
280
×
1024
6
3.9
60
135.0
25
1
280
×
1024
79
75
157.5

AMM17TK/AMM18TK/AMM19TK 13
POWER MANAGEMENT FUNCTION
The monitor is equipped with the power management function which automatically reduce the
power consumption when not in use in three power level modes.
•Stand-by Mode
The monitor goes into stand-by mode when the horizontal sync signal is off for about 10
seconds. In this mode, the screen goes off and the power LED blinks for 3 seconds On
and 1 second Off. The screen is displayed after the horizontal sync signal is restored.
•Suspend Mode
The monitor goes into suspend mode when the vertical sync signal is off for about 10
seconds. The power consumption during this is less than 8 W. In this mode, the screen
goes off and the power LED blinks for 3 seconds On and 1 second Off. The screen is
displayed after the vertical sync signal is restored.
•Off Mode
The monitor goes into power-off mode when the vertical and horizontal sync signals are
off for about 10 seconds. In this mode, the screen goes off and the power LED blinks for
3 seconds On and 1 second Off. The screen is displayed after the vertical and horizontal
sync signals are restored.
Power Management System
TheAMM17TK/18TK/19TK Series Medical Monitor complies with the VESADPMS power
management proposal. The VESA DPMS proposal provides four phases of power-saving
modes by detecting the horizontal sync signal as shown in the table blow.
When the monitor is power saving mode or detects an incorrect timing, the screen will be
blank and power LED indicator will blink.
M ode DC Input Power
(monitor only) AC Input power (Incl. AC adapter) LED Status
On 35 W max. 60 W max. Steady Green
Standby 4.5 W max. 6 W max. Blinking Green
Supend 4.5 W max. 6 W max. Blinking Green
On 4.5 W max. 6 W max. Blinking Green

14 Users Guide
DDC
To make your installation easier, the monitor is able to Plug and Play with your system if your
system also supports DDC protocol. The DDC (Display Data Channel) is a communication
protocol through which the monitor automatically informs the host system about its
capabilities, for example, supported resolutions and corresponding timing. The monitor
supports DDC1 and DDC2B standard.
INSTALLATION
To install the monitor to your host system, please follow the steps as given below:
Steps
1. Use the VGA cable that provides D-SUB 15P connector and connect to the
15-pin connector on the VGA controller card.
2. Connect the DC power to the DC power connector on the monitor.
3. If use with USB hub, connect the loop cable between the monitor and the USB hub then
connect the DC power to the bottom of USB hub.
4. Connect one end of AC power cord into the AC Adapter and the other end to AC
power outlet. (See page 13)
5. Then turn the computer on and then the monitor.
6. If the monitor still does not function properly, please refer to the troubleshooting section
to diagnose the problem.
S-Video cable
C-Video cable
Analog signal cable
Digital signal cable (DVI)
USB cable from monitor to PC
USB DC loop cable

AMM17TK/AMM18TK/AMM19TK 15
DDC
To make your installation easier, the monitor is able to Plug and Play with your system if your
system also supports DDC protocol. The DDC (Display Data Channel) is a communication
protocol through which the monitor automatically informs the host system about its
capabilities, for example, supported resolutions and corresponding timing. The monitor
supports DDC1 and DDC2B standard.
Installation with sound board or sound source
To install the monitor for input/output sound, please follow the steps as given below:
Steps
1. Connect sound source (ex. sound output from sound card, sound output from CD player or
DVD player, etc.) to Audio In.
2. Connect sound source receiver (ex. sound input or Mic input from the sound card) to Mic
out.
3. At the front of the monitor there are two connection, Audio Out and Mic In. Connect any
type of sound output device (ex. speaker, earphone, etc.) to Audio Out. Mic In is for
microphone input connection.
AC power adapter
Audio Out
Mic In
Audio in cable
Mic out cable

16 Users Guide
Display for Video and Image Playback
Explains how to use our AGM17TK/AGM18TK to play VCR, view television, video game, or
digital camera images. It also show you how to connect video and other types of video
equipment to the display.
Connecting with Video Equipment
You can connect many types of video equipment to the display. The equipment must have
either Super VHS video (S-video) ports or composite video ports. To install the monitor to
your video equipment, please follow the steps as given below:
Steps
1. Make sure the video equipment has a Super VHS (S-video) or a Composite video connector.
2. Turn off the computer, display, and video equipment before any types of connection.
3. For composite video, plug one end of an RCA cable into the video out port on the video
equipment then connect the other end to the monitor video input port.
4. For S-video, plug one end of the S-video cable into the video out port on the video equipment
then connect the other end to the monitor S-video input port.
5. Connect the DC power to the DC power connector on the monitor.
6. Connect one end of AC power cord into the AC Adapter and the other end to AC
power outlet.
7. Then turn the video equipment on and then the monitor.
Connecting to a Television Signal
The display doesnt have a tuner. To view television on the display, you need to use either the
VCR or TV tuner card in your computer to change channels.
Video and Sound
This monitor does have speakers for sound. If youre using the display to play a video or view
television images, you need to connect the speakers to your television or video equipment
for sound. Please review page 13 for sound connection.
S-Video cable
C-Video cable
Analog signal cable
Digital signal cable (DVI)
USB cable from monitor to PC
USB DC loop cable

AMM17TK/AMM18TK/AMM19TK 17
USER CONTROLS
Front Panel Controls
1. Power LED: Lights up to indicate the power is turned ON.
2. Power Switch: To turn ON or OFF the power.
3. +: To increase the value of the parameter in the OSD you have selected for adjustment.
To increase the brightness directly when OSD menu is not activated.
4. -: To decrease the value of the parameter in the OSD you have selected for adjustment.
To increase the brightness directly when OSD menu is not activated.
5. Select Up: To enter OSD menu then can use as moving upward in the OSD menu.
6. Select Down: To move downward in the OSD menu.
Switch PC display to Video display and vice versa by one touch when OSD menu is not activated.
7. Auto Button: One touch Auto adjust or Exit OSD menu.
Standard OSD Operation
1. Press menu button to activate the OSD.
2. Use Select Up or Down keys to move up or down through the menu. The parameter will be highlighted wehn
selected.
3. Then use + or - to increase or decrease the value of the parameter, or make selection between different options.
4. To quit the OSD screen at any time during the operation, pressAuto button. If no keys are pressed for a time period,
the OSD automatically disappears.

18 Users Guide
OSD Scren Basic Section (VGA)
For OSD display, push Menu. For selecting Icon, push Up
or Down
Push the select button to execute the Auto
Setup function
Push Up or Down button to select between
Brightness or Contrast then push Select
Use Left or Right button to adjust
Push Up or Down button to select between
Frequency or Phase then push Select
Use Left or Right button to adjust
Push Up or Down button to select between
Horizontal or Vertical then push Select
Use Left or Right button to adjust
Push Up or Down button to select between
OSD Hor. Pos., OSD Ver. Pos., OSD
Background, or User Timeout then push Select
Use Left or Right button to adjust
Push Left or Right to select Color Temp between
5000, 6500, 7300, 9500, or User then push
Select
If User were slected, push Up or Down button to
select between Red, Green, or Blue then push
Select
Use Left or Right button to adjust
