17A2 17" All-in-One Touchcomputer
Expanded Versatility for POS Applications
Elo TouchSystems 17A2 17" All-in-one touchcomputer
provides an attractive ultra-compact 17” touch solution
that can fit virtually anywhere in any point-of-service
environment.
Expanded versatility, bigger screen, and improved
serviceability all in a compact design
The 17A2 touchcomputer with dual video display support
includes a choice of Elo TouchSystems newest breakthrough
touch technology, Acoustic Pulse Recognition, AccuTouch
five-wire resistive, IntelliTouch surface acoustic wave or
CarrollTouch Infrared. Its 1280 X 1024 SXGA resolution
with a 5 x 4 aspect ratio displays clear, precise graphics
for improved readability. A variety of optional field-replace-
able peripherals can easily be integrated into the 17A2's
compact design including: magnetic stripe reader, vacuum
fluorescent, rear-facing customer display, biometric finger -
print recognition device, and speaker bar with/without a
built-in single or omni-directional barcode scanner.
Designed for public access
The silent, fanless, spill and tamper resistant design of the
17A2 and its compact integrated peripherals, make this
touchcomputer a preferred choice for point-of-sale, kiosk
and point-of-interest applications.
Features
■Space saving, integrated, all-in-one touchcomputer
with the footprint of a standard 17" LCD display
■Silent, fanless Intel Celeron M design-ideal for POS,
kiosk and POI applications
■Industry standard VESA mounting options—
configurable as a desktop or wall-mount
■Choice of Microsoft Windows Embedded for POS
(WEPOS), XP Professional or Microsoft Windows XP
Embedded operating systems
■Full range of “field” replaceable and serviceable POS
options such as an integrated MSR, vacuum fluorescent,
rear-facing customer display, biometric fingerprint
recognition device, and speaker bar with/without a
built in single or omni-directional barcode scanner
■Available with AccuTouch five-wire resistive, CarrollTouch
Infrared, IntelliTouch surface acoustic wave or Acoustic
Pulse Recognition (APR) touch technologies
■ Integrated (optional) wireless LAN & DVD for expanded
access and advanced media applications
■ One Ethernet, two serial, and four high-speed USB 2.0
ports for maximum expansion
■Designed for public access with cables hidden from
user's view; OSD and cable lockout function to mini-
mize public tampering

17A2 17" All-in-One Touchcomputer Specifications
Case/Bezel color Dark Gray
Processor Intel Celeron M 1G z CPU
Chipset Intel 915GME/IC 6
Video Up to 128MB sharedi
Memory (RAM) 1GB DDR2 standard on 1 of 2 slots; Expandable to 2GB maximumii
Supported Operating Systems Microsoft Windows XP Professional Service Pack 2
Microsoft Windows Embedded for Point of Service (WEPOS)
Microsoft Vista
Serial Ports 2 x RS232 serial (RJ45, 8 position); COM2 is RS232, RS422 and RS485 selectable
USB Port 4 x 2.0 high-speed USB self powered: 1 (of 4 port) is 12V USB Port (1.5A) for POS Peripherals
VGA Port 1 x VGA D-SUB
Ethernet 100/10Base-T Port 1 x LAN RJ45
Cash Drawer Port 1 x cash drawer (RJ11, 6 position)
PS/2 Port 1 x PS/2 Universal (default to Keyboard compatibility)
Audio Port 1 x 3.5mm audio-out; 1 x 3.5mm mic-in
ard Drive 1 x 2.5” 160 GB SATA hard driveiii
Compact Flash Slot 1 x Compact Flash type I (internal)
Display Size 17.0 in. diagonal; Type: Active matrix TFT LCD; Aspect Ratio: 5 x 4
Optional Touchscreens AccuTouch Five-Wire Resistive; IntelliTouch Surface Wave; CarrollTouch Infrared; Acoustic Pulse Recognition (APR)
Optional Peripherals Magnetic Stripe Reader, Serial Customer Display; (20x2 VFD), Biometric Fingerprint Reader,
Speaker Bar; Line or Omni Barcode Scanner, DVD Burner, drive (internal); Wireless Card
Useful Screen Area 337.92 mm (13.31 in.); 270.33 mm (10.65 in.)
Maximum Touchcomputer Width: 391 mm (15.40 in.)
Dimensions with Standiv eight: 380.6 mm (15.00 in.)
Depth: 239 mm (9.42 in.)
Tilt Adjust From -5° to 75°
Optimal Resolution 1280 x 1024 at 60 z (native); scalar support for 1024 x 768 or 800 x 600 at 60 z
Colors 16.7 million colors
Brightness (typical) No Touchscreen: 300 cd/m2
with AccuTouch: 240 cd/m2
with IntelliTouch: 276 cd/m2
with CarrollTouch: 276 cd/m2
with APR: 276 cd/m2
Viewing Angle (from center) orizontal (left/right): ±80° or 160° total; Vertical (up/down): ±80° or 160° total
Contrast Ratio 800:1 (typical)
Temperature Operating: 0°C to 35°C; Storage: -20°C to 60°C
umidity (non-condensing) Operating: 20% to 80%; Storage: 5% to 95%
Weight with All Options (approx.) Actual: +20 lb. (+9.09 kg); Shipping: +25 lb. (11.36 kg)
Agency Approvals UL/cUL (Recognized component), FCC, CE, VCCI, C-tick, EN60950
Warranty 3 years
Backlight Lamp Time to Minimum 50,000 hours
1/2 Brightness
MTBF (mean time between failures) 50,000 hours demonstrated
Other Features 100mm VESA mounting; removable base; threaded holes on bottom of base for secure mounting;
2 watt/channel speakers located in display head; touchscreen sealed to bezel; touchscreen sealed to LCD
Power Supply Type: External brick; Input (line) voltage: 100-240 VAC, 50-60 z; Output voltage/current: 12 V at 10.0 amps max.
i Memory supports both system and video. Accessible system memory may be up to 128 MB less than the amount stated, depending on the video mode.
ii Maximum memory using 2 slots.
iii GB equals one billion bytes when referring to storage capacity. Accessible capacity may be less. May not be applicable for XP Embedded Systems.
iv Dimensions vary with stand position and options selected.
Other restrictions and regional differences may apply. For a copy of the terms and conditions of the Elo TouchSystem's Limited Warranty, please contact
your Elo representative or reseller.
Tyco Electronics reserves the right to change or pdate, witho t notice, any information contained herein, to change,
witho t notice, the design, constr ction, materials, processing or specifications of any prod cts, and to discontin e or
limit prod ction or distrib tion of any prod cts.
Acc To ch, CarrollTo ch, Elo logo, Elo To chSystems, IntelliTo ch, TE Logo, and Tyco Electronics are trademarks.
Copyright 2009 Tyco Electronics Corporation 2/09
