elobau N3 Series User manual

25.05.2007
Betriebsanleitung
Neigungssensor Typ N3.../N4...
Operating instructions
Tilt sensor type N3.../N4...
D
GB

900591 / 25.05.2007
1
2

2900591 / 25.05.2007
N3xAxxx N3xDxxx N3xKxxx
N4xKxxx
N4xDxxx
N4xAxxx

900591 / 25.05.2007 11
GB
1 Technical data
1.1 Legend
On the fold-out page, the possible installation variants are depicted in the form of
technical drawings.
1 Horizontal installation
2 Vertical installation
The uniaxial tilt sensor N3... does not have a y-axis.
1.2 Terminal assignment
The terminal assignments of the models with cable connection can be found in
the corresponding datasheet. The datasheets can be requested from elobau or
downloaded at www.elobau.com.
Pin Assignment
1 Operating voltage (UB)
2GND
5, 6 Relay 1
7, 8 Relay 2
3X-OUT
4Y-OUT

12 900591 / 25.05.2007
GB
1.3 Type denomination
The following example and table are given to explain the type denomination of
the tilt sensors.
Example:
N4AK1 E1CC 0001
Nabcd efgh xxxx
Placeholder Characteristic Meaning
Na Number of axes 3 One axis
4 Two axes
b Housing/installation A Horizontal (8-pin)
B Vertical (8-pin)
C Horizontal (cable)
D Vertical (cable)
E Vertical (8-pin / Y-axis / N3)
F Vertical (cable / Y-axis / N3)
c Outputs A Analogue
D Digital
K Combined (analogue and
digital)
d Output signal
(analogue)
0 No signal
1 4-20 mA
2 0.5-4.5 V
e (*) Relay (digital) A 1 x 24 V (contact breaker)
B 2 x 24 V (contact breakers)
C 1 x 24 V (contact maker)
D 2 x 24 V (contact makers)
E 1 x 12 V (contact breaker)
F 2 x 12 V (contact breakers)
G 1 x 12 V (contact maker)
H 2 x 12 V (contact makers)

900591 / 25.05.2007 13
GB
(*) Not applicable with selection of analogue outputs (i. e. placeholder c = A).
1.4 Electrical data
On the circuit diagrams of the fold-out page, the tilt sensors are depicted in
neutral position with the operating voltage applied.
f (*) Connection type
(digital)
1 1 output = X1/X3 / Y1/Y3
2 1 output = X1/X3
1 output = Y1/Y3
3 1 output = X1/X3 / Y1/Y3
1 output = X2/X4 / Y2/Y4
4 1 output = X1/X3
1 output = X2/X4
5 1 output = X1/X3
6 1 output = X1
1 output = X3
g (*) Switch-on delay
(digital)
A No delay
B0.5s
C1s
D1.5s
E2s
h (*) Turn-off delay (digital) A No delay
B0.5s
C1s
D1.5s
E2s
x Sequence numbers Assigned by elobau
Operating voltage 10-30 V DC (analogue signal only)
12 V DC ± 15 % (12 V relay)
24 V DC ± 15 % (24 V relay)
Power consumption Typ. 22 mA
Typ. 8 mA per relay
Placeholder Characteristic Meaning

14 900591 / 25.05.2007
GB
1.5 Mechanical data
Analogue output signals Uout: 0.5-4.5 V
Iout: 4-20 mA
Load resistance at Uout Min. 10 kΩ(Ri = 100 Ω)
Load resistance at Iout Max. 500 Ω(UB > 15 V)
Max. 250 Ω(UB < 15 V)
Digital output signals Relay: 12 V / 24 V
Switching voltage: max. 48 V DC
Switching current: max. 1 A / 30 W / 30 VA
Delay time Switch-on delay (neutral position to the switching
point): selectable
Turn-off delay (switching point to the neutral
position): selectable
Resolution Inclination angle < 25°: < 0.04°
Inclination angle > 25°: < 0.14°
Linearity error Inclination angle < 25°: 1 %
Inclination angle > 25°: 2 %
Temperature drift 1.3 %
Repeat accuracy Inclination angle < 25°: 0.2°
Inclination angle > 25°: 0.5°
Vibration filter Limiting frequency selectable (typ. 40 Hz)
Signal refresh rate Approx. 100 Hz
Start-up time < 1000 ms
Housing material Housing upper part PBT GF35
Housing cover PC
Installation sockets ø 5.3 mm
Temperature range -40 °C .... +70 °C
International protection IP 67

900591 / 25.05.2007 15
GB
2 Appropriate use
2.1 Field of application
The tilt sensor is designed for measuring the inclination (angle from a horizontal
line) in different devices, machines etc.
The ambient conditions must be checked by the user before using the tilt sensor.
2.2 Norms and guidelines
The tilt sensor complies with the following European guideline:
2004/108/EC (EMC guideline)
2.3 Safety/Dangers
- Only operate the tilt sensor in a completely closed and undamaged housing.
- Only replace components with original spare parts which are approved for the
defined application.
- Operate the tilt sensors only in accordance with their intended use. Failure to
comply with these conditions will invalidate any warranty claims or any liability
on the part of the manufacturer.
- Ensure that all safety requirements applying to the individual machines are
observed.
- Ensure that the international and national regulations are observed.

16 900591 / 25.05.2007
GB
3 Function
3.1 Mode of operation
The tilt sensors of series N3/N4 employ the capacitive measuring method.
The sensors supply a linearised output voltage or an output current depending on
the inclination (see Electrical data).
In addition, different switching points can be defined which activate one or
several relays.
The configuration of the sensors is defined in the type denomination.
3.2 Neutral position adjustment
(optional with IR remote control)
All tilt sensors are preprogrammed with a neutral position (see the fold-out page).
The user can adjust the neutral position using the infrared remote control
"IR-NGS01" (not included in the scope of delivery), if required.
During this adjustment, the current inclination angle is defined as the neutral
position.
NOTE The neutral position can only be adjusted within a minute after the
operating voltage has been applied.
Defining the neutral position:
- Shortly press the button on the IR remote control. The remote control is
activated. LED 1 lights up briefly to indicate readiness for operation.
- Press the button for longer than 2 seconds. A data signal is transmitted to the
tilt sensor. LED 1 on the IR remote control flashes rapidly to indicate that the
transmission is in progress.
If the button is not pressed within 8 seconds, the remote control is deactivated
and will have to be reactivated by pressing the button again.
LED 2 on the tilt sensor flashes briefly three times to confirm the correct receipt
of the data signal.

900591 / 25.05.2007 17
GB
Point the IR remote control towards the sensor as shown in the figure.
4 Installation
- Ensure that the tilt sensor is only installed by specially-trained authorised
personnel.
- Install the tilt sensor on a level surface (mechanically unstressed).
- The tilt sensor must not be modified.
- Connect tilt sensor, see Technical data.

18 900591 / 25.05.2007
GB
5 Putting into operation
- Ensure that the tilt sensor is only put into operation by specially-trained
authorised personnel.
- Ensure that the electrical data is adhered to.
- Observe the operating instructions and notes provided by the manufacturer
of the device.
- Apply operating voltage and check the proper functioning of the tilt sensor
according to application.
6 Maintenance
6.1 Measures
The tilt sensor is maintenance-free.
6.2 Disposal
Dispose of used parts and unwanted packaging in accordance with the
regulations of the country in which the device is installed.

elobau
Elektrobauelemente GmbH & Co. KG
Postfach 1265
88306 Isny/Allgäu
Germany
Werk:
Zeppelinstr. 44
88299 Leutkirch
Germany
Tel.: [phone]
Fax: [phone]
E-Mail:[email protected]
Web: www.elobau.com
Artikelnummer / Article Number: 900591
Version / Version: 1.0
Datum / Date: 25.05.2007
Seiten / Pages: 20
