1.Overview
The RB865io terminal is the complete modem solution for wireless m2m applications.
Based on the Telit GL865 or G30 module offers high level GSM/GPRS features in compact
aluminium housing with all the standardized interfaces and configurable I/O. Together with
its small size and wide supply voltage range, makes it easy to integrate into all kinds of
machines.
The RB865io Terminal enabling voice, data, SMS and fax communication is a
universal solution for all low-volume M2M and mobile data applications including metering,
traffic systems, transportation and logistics, security, vending machines, and facility
management.
Device can be controlled by standard AT commands or by customer's application
inside (embedded Python Script Interpreter or AppZone), thus making it the smallest,
complete SMT platform for m2m solutions.
This document contains full RB865io modem description and gives information about
installation and using it.
2.References
[1] Telit _AT_Commands_Reference_Guide.pdf
[2] Telit_G30_AT_Commands_Reference_Guide.pdf
[3] Telit_GL865-DUAL/QUAD_Hardware_User_Guide.pdf
[4] Telit_Modules_Software_User_Guide.pdf
[5] Telit_GL865-DUAL/QUAD_Product_Description.pdf
[6] Telit_Easy_Script_Python.pdf
[7] http://www.telit.com/en/products/gsm-gprs.php?p_id=12&p_ac=show&p=93
[8] http://www.python.org/
[9] Telit_AppZone_Developer_Guide.chm

Elproma Elektronika Sp. z o.o.
ul. Szymanowskiego 13
05-092 Łomianki k/Warszawy
E-mail: [e-mail]
Tel. [phone]
www.teleorigin.com
5
3.Trademarks
TELIT and the Stylized T Logo are registered in Trademark Office. All other product or service
names are the property of their respective owners.
Copyright © Telit Communications S.p.A. 2011.

Elproma Elektronika Sp. z o.o.
ul. Szymanowskiego 13
05-092 Łomianki k/Warszawy
E-mail: [e-mail]
Tel. [phone]
www.teleorigin.com
6
4.Package
4.1. Box
Original box of the product is shown in the picture below.
We can find product sticker on the box. It matches modems sticker that is placed on the
device. This proves that your modem is original product. More information about stickers in
chapter 6.3 Product sticker.

Elproma Elektronika Sp. z o.o.
ul. Szymanowskiego 13
05-092 Łomianki k/Warszawy
E-mail: [e-mail]
Tel. [phone]
www.teleorigin.com
7
5.Complete package contents
Complete package contains:
RB865io terminal (item A)
DIN handle (item B)
wall handles (items C)
antenna GSM (via SMA) (item D)
CD with software (item E)
RS232 cable (item F)

Elproma Elektronika Sp. z o.o.
ul. Szymanowskiego 13
05-092 Łomianki k/Warszawy
E-mail: [e-mail]
Tel. [phone]
www.teleorigin.com
8
6.General presentation
6.1. Description
LEDs
SMA
connector
SIM card
holder ejector
15-pin connector
Power supply
DATA
GSM
PWR
Audio
Input/Output
Extractable
SIM card
holder

Elproma Elektronika Sp. z o.o.
ul. Szymanowskiego 13
05-092 Łomianki k/Warszawy
E-mail: [e-mail]
Tel. [phone]
www.teleorigin.com
9
6.2. External connections
6.2.1. Antenna connector
SMA antenna input is used to connect external GSM antenna. To establish
connection with GSM network an external antenna must be used. Type of antenna depends
on GSM coverage. In good circumstances (level of received signal is high) use antenna
which is attached in the package. If range of GSM is low or none, an outdoor or indoor (for
instance in place where GSM range is sufficient) antenna should be used.
Note: If there is no antenna connected to SMA connector, the connection with GSM
network is impossible.
SMA connector
for antenna

Elproma Elektronika Sp. z o.o.
ul. Szymanowskiego 13
05-092 Łomianki k/Warszawy
E-mail: [e-mail]
Tel. [phone]
www.teleorigin.com
10
6.2.2. 15-pin connector (RS232)
RB865io terminal is equipped with 15-pin connector (as shown below).
Table of DB15 pins:
Pin No.
Name
Dir
Description
1
GND
-
Ground
2
GPIO (ADC)
IN/OUT
General purpose input / output.ADC range 0..3V, 10 bit resolution.
3
DTR
OUT
Data Terminal Ready. Raised by DTE when powered on. In auto-
answer mode raised only when RI arrives from DCE.
4
CTS
IN
Clear To Send. Raised by DCE in response to RTS from DTE.
5
GPIO (ADC)
IN/OUT
General purpose input / output.ADC range 0..3V, 10 bit resolution.
6
GPIO (I2C_SDA)
IN/OUT
General purpose input / output. I2C data –SDA.
7
GPIO (ADC)
IN/OUT
General purpose input / output. ADC range 0..3V, 10 bit resolution.
8
GPIO (ADC)
IN/OUT
General purpose input / output.ADC range 0..3V, 10 bit resolution.
9
RX
IN
Receive Data (a.k.a RxD, Rx).Arriving data from DCE.
10
GND
-
Ground
11
GPIO (I2C_SCL)
IN/OUT
I2C clock –SCL
12
GPIO (ADC)
IN/OUT
General purpose input / output.ADC range 0..3V, 10 bit resolution.
13
GND
-
Ground
14
RTS
OUT
Request To Send. Raised by DTE when it wishes to send. Expects
CTS from DCE.
15
TX
OUT
Transmit Data (a.k.a TxD, Tx). Sending data from DTE.
DE-15 looking into female connector
15-pin connector

Elproma Elektronika Sp. z o.o.
ul. Szymanowskiego 13
05-092 Łomianki k/Warszawy
E-mail: [e-mail]
Tel. [phone]
www.teleorigin.com
11
6.2.3. Power supply connector
The power supply connector is a 2-pin connector for external DC power supply
connection, which can handle voltage from range 5..30 V DC, 2.5 W max. continuous
power.
No.
Signal
I/O
Description
+
V+BATTERY
I
5 V –30 V DC
-
GND
-
Ground
Attention!
An attempt to power terminal from DC source outside of 5..30 V range may result in
physical destruction of the device.
Power supply
connector

Elproma Elektronika Sp. z o.o.
ul. Szymanowskiego 13
05-092 Łomianki k/Warszawy
E-mail: [e-mail]
Tel. [phone]
www.teleorigin.com
12
6.2.4. Audio Input/Output
The RB865io modem is equipped with audio interface, which can be used for
transmitting voice communication while calling. To use this interface plug the HandsFree
headphones into it. The Audio I/O is shown in the picture below.
6.2.5. SIM card holder
SIM card holder is placed in front of RB865io terminal (as shown below) and is
accessible externally. To insert SIM card into the holder press the yellow button, eject the
little drawer, place there Your SIM card and insert drawer into the modem (You will hear
click). To operate the module in a GSM network, it is necessary to insert a SIM card
obtained from the network operator.
Extractable SIM
card holder
SIM card holder
ejector
Audio
Input/Output
Interface

Elproma Elektronika Sp. z o.o.
ul. Szymanowskiego 13
05-092 Łomianki k/Warszawy
E-mail: [e-mail]
Tel. [phone]
www.teleorigin.com
13
6.3. Product sticker
Product stickers are on the modem and on the box of the product.
Aproduction sticker includes the following information:
Product serial number (IMEI)
the CE marking
the 15-digit bar code
the model signature (RB865io)

Elproma Elektronika Sp. z o.o.
ul. Szymanowskiego 13
05-092 Łomianki k/Warszawy
E-mail: [e-mail]
Tel. [phone]
www.teleorigin.com
14
7.Basic features and services
Basic features and available services for RB865io are contained in table below.
Feature/service
Description
Standard
Supported Bands:
GSM Quad-band
850/900/1800/1900MHz
Physical:
83 x 72 x 25 mm
Weight 151g
GPRS
Multi-slot class 10 (4 Down; 2 Up; 5 Total)
Max BR Downlink 85.6 Kbps
Coding Scheme CS1-CS4
Interfaces
Connectors
Single 70 pin board to board (only terminal with G30 module)
RF MMCX
SIM Card
3.0V / 1.8V
STK 3.1
Connectivity
15-pin connector
UART: BR from 300 bps to 115.2 Kbps
Auto BR
SMS
MO / MT Text and PDU mode
Cell broadcast
Audio
Telephony
Digital audio
Differential analog audio lines
Vocoders HR/FR/EFR/AMR
DTMF support
Audio control: echo suppression; noise suppression; side tone; gain control
GSM supplementary
services
USSD phase II
Call forwarding
Call hold; waiting; multiparty
Call diverting
Missed call indicator
AOC
Call barring
CSD
Max BR 14.4 Kbps
Power supply
5V –30V DC

Elproma Elektronika Sp. z o.o.
ul. Szymanowskiego 13
05-092 Łomianki k/Warszawy
E-mail: [e-mail]
Tel. [phone]
www.teleorigin.com
15
8.Using the modem
8.1. Setting up the modem
To set up the modem, do the following steps:
Eject SIM card holder using yellow button and pull out the drawer.
Insert Your SIM card into drawer.
Verify if SIM card fits in the drawer properly (as shown).
Insert the drawer into the modem.
SIM car drawer
can be
completely
taken out
Put Your SIM card
into drawer and
insert the drawer
into modem
Eject SIM
holder using
yellow button and
pull out drawer

Elproma Elektronika Sp. z o.o.
ul. Szymanowskiego 13
05-092 Łomianki k/Warszawy
E-mail: [e-mail]
Tel. [phone]
www.teleorigin.com
16
Connect the antenna to the SMA connector
Optionally it can be connected using RS-232 cable
Plug the power supply cable to the power supply input
Plug the hands-free headphones into Audio I/O
Now the modem is ready to work.
8.2. Mounting the modem
8.2.1. On DIN bus
To mount modem on DIN bus install DIN handle as shown below
8.2.2. On the wall
To mount modem on the wall install wall handles as shown below.

Elproma Elektronika Sp. z o.o.
ul. Szymanowskiego 13
05-092 Łomianki k/Warszawy
E-mail: [e-mail]
Tel. [phone]
www.teleorigin.com
17
8.3. Checking the communication with the modem
Once the modem is connected you can check communication between RB865io
terminal and the PC using Telit AT Controller available here:
http://teleorigin.com/download/Tools/Common/Telit_AT_Controller_r2_2_1.zip
Configuration of the DTE (port COM) should be as follows:
Bits per second: 115200 bps,
Data bits: 8,
Parity: None,
Stop bits: 1,
Flow control: hardware.
To communicate with modem use software such as Hyperterminal (AT commands) or
use attached GPRS Control v.2.1.0.0 software. For further information about GPRS Control,
refer to GPRS Control 3.1.0.0 User's Manual and to install refer to GPRS Control Installation
Guide.
Using a communication software such as Hyperterminal, enter the AT and push
'enter' button. The response of the terminal should be 'OK' displayed in the Hyperterminal
window.
If the connection with the modem cannot be established do the following:
Check if modem is connected with PC via RS-232 or USB.
Check the configuration of the COM port.
Examples of AT commands:
ATE1 enables modem echo function,
AT+CGMI modem answers “Telit” when connection is OK.
AT+CPIN? shows current status of SIM card
AT+CPIN=xxxx to enter PIN, where 'xxxx' are digitals
AT+CSQ to verify received signal strength
ATD<phone_number>; to initiate a voice call
ATH to hang up a voice call
For further information about AT commands and their usage, refer to [1] / [2].

Elproma Elektronika Sp. z o.o.
ul. Szymanowskiego 13
05-092 Łomianki k/Warszawy
E-mail: [e-mail]
Tel. [phone]
www.teleorigin.com
18
8.4. Status of the modem (LEDs)
The operational status of the RB865io Terminal is signalized by external LEDs placed
on the front panel of the modem.
The table below shows what is the meaning of LEDs.
LED
status
LED
name
LED colour
Status description
GPRS
blue
Lights when GPRS connection is established
on
GSM
orange
Shows the RF activity of GSM module
PWR
green
Modem is on
GPRS
none
No GPRS connection is established
off
GSM
none
Terminal has no connection with GSM
network
PWR
none
Modem is off
8.5. Disabling and enabling echo function
If echo is not displayed when entering AT command, that means:
The local echo function in software (such as Hyperterminal) is disabled
The echo function of the modem is disabled
To enable echo function of the modem enter ATE1 command.
In Machine to Machine communication it is recommended to disable echo function
(type ATE0) in order to avoid useless CPU processing.
For further information about AT commands and their usage, refer to [1] / [2].

Elproma Elektronika Sp. z o.o.
ul. Szymanowskiego 13
05-092 Łomianki k/Warszawy
E-mail: [e-mail]
Tel. [phone]
www.teleorigin.com
19
8.6. Verifying the strength of received signal
RB865io Terminal can establish connection with network if the received signal
strength is sufficiently strong.
To verify the signal strength and bit error rate, do the following:
Using software such as Hyperterminal enter AT+CSQ. This command displays the
received signal strength indication <rssi> and channel bit error rate <ber>. The modem
answers as follows:
+CSQ: <rssi>,<ber>
OK
<parameter>
Description
<rssi>
0 through 31 - covers the range of -113 dbm (or less) to -51dbm (or
greater)
<ber>
Channel bit error rate (in percent)
0–7 RXQUAL values in the GSM 05.08 table
99 Unknown or not detectable
For further information about AT commands and their usage, refer to [1] / [2].
8.7. PIN code status
To check PIN code status enter AT+CPIN? Command.
The table below shows the most interesting responses of the modem:
Answer
Description
+CPIN: SIM PIN
PIN code has not been entered
+CPIN: READY
PIN code has been entered correctly
For further information about AT commands and their usage, refer to [1] / [2].

Elproma Elektronika Sp. z o.o.
ul. Szymanowskiego 13
05-092 Łomianki k/Warszawy
E-mail: [e-mail]
Tel. [phone]
www.teleorigin.com
20
8.8. Network registration
8.8.1. GSM network registration
To check GSM network registration status enter AT+CREG? into software (for
instance Hyperterminal) Modem will answer in following format:
+CREG: <n>,<stat>[,<lac>,<ci>]
OK
The following table shows the +CREG parameters:
<parameter>
Description
<n>
0Disables the network registration unsolicited result code.
1Enables the network registration unsolicited result code +CREG: <stat>.
2Enables the network registration and location information in unsolicited
reports and Read command +CREG:<stat>[,<lac>,<ci>].
The default is 0.
<stat>
0Not registered, and the ME is not currently searching for a new operator to which to
register.
1Registered, home network.
2Not registered, but the ME is currently searching for a new operator to which to
register.
3Registration denied.*
4Unknown.
5Registered, roaming.
<lac>
Two-byte location area code in hexadecimal format
<ci>
Two-byte cell ID in hexadecimal format.
*To manage connecting to network SIM card inserted into the modem must be valid.
For further information about AT commands and their usage, refer to [1] / [2].
