Point Mobile XM5 User manual

The Point Mobile name and logo are trademarks of Point Mobile Co., Ltd. in Korea and many other countries.
All rights reserved. This document and any enclosed documents contain confidential or privileged information
belonging to Point Mobile and/or its affiliates. You are hereby notified that any disclosure, copying, distribution
or the taking of any action based on the contents of this information is strictly prohibited.
Model :
XM5
Originator :
Jinny Cho
Version :
1.0
Dept.
PC/PE/ID/PM/QA
Date :
Dec 1st , 2014
XM5
User Manual
POINT MOBILE CO., LTD.
B-9F, Kabul Great Valley, 32, Digital-Ro 9Gil
Geumcheon-gu, Seoul, Korea 153-709
www.
p
ointmobile.co.kr

1
CONTENTS
1. INTRODUCTION················································································· 4
Trademarks ······························································································· 4
About the XM5 Handy Terminal ·································································· 4
Accessories ······························································································· 4
2. SAFETY REGULATIONS HW·································································· 5
2.1. General Safety Rules ········································································ 6
2.2. Power Supply·················································································· 6
2.3. Laser Safety···················································································· 6
2.4. LED Safety ····················································································· 8
2.5. FCC/ EU RF Exposure ······································································ 8
2.6. CB Scheme····················································································· 9
2.7. FCC Part 15 Regulation····································································· 9
2.8. Radio Compliance············································································ 9
2.9. WEEE Compliance··········································································10
2.10. China Compliance···········································································10
2.11. HAZARODUS Locations (USA&Canada)··············································10
2.12. ATEX Directive (Europe)···································································10
2.13. Canadian Compliance······································································10
3. GETTING STARTED··········································································· 12
3.1. Install the Battery ············································································12
3.2. Charge the Batteries········································································13
3.3. LED Indicators················································································14
3.4. Guidelines for Battery Pack Use and Disposal·······································15
3.5. Turn Your Device On ·······································································17
3.6. Desktop·························································································17
3.7. Indicator Icons················································································18
3.8. Using the Stylus··············································································18
3.9. Selecting Program···········································································19
3.10. Pop-Up Menus················································································19
3.11. Using Windows Explorer···································································19
4. GET TO KNOW YOUR DEVICE ····························································· 19
4.1. Feature of Your Device·····································································19
4.2. XM5 Handy Terminal ·······································································19
4.3. Front Panel Layout ··········································································20
4.4. Display Backlight·············································································21
4.5. Keypad Backlight ············································································20
4.6. Using Screen Protectors ···································································22
4.7. Installing Your Screen Protector ·························································23
4.8. Back Panel Layout···········································································23
4.9. Left Side Panel Layout ·····································································26
4.10. Installing Memory Cards ···································································25
4.11. Right Side Panel Layout ···································································26
4.12. Top Panel Layout············································································26

2
4.13. Bottom Panel Layout········································································27
4.14. Peripherals and Accessories······························································28
4.15. USB ActiveSync Cable ·····································································28
4.16. Li-ion Battery Packs·········································································28
4.17. Battery Power·················································································29
4.18. Main Battery Pack ···········································································29
4.19. Managing Main Battery Power····························································29
4.20. Resetting the Terminal ·····································································30
4.21. Suspend Mode ···············································································31
4.22. Memory Allocation···········································································32
4.23. Care and Cleaning of the Products······················································32
4.24. XM5 Technical Specifications ····························································32
5. USING THE KEYPAD·········································································· 33
5.1. Numeric Keypad Layout····································································34
5.2. Navigation Keys··············································································34
5.3. Basic Keys·····················································································34
5.4. Alpha/Numeric Modes······································································35
5.5. Alpha Indicators on the Numeric Keys··················································35
5.6. BLUE Key Combinations···································································36
5.7. Program Buttons·············································································36
6. USING THE IMAGE ENGINE································································ 37
6.1. Overview·······················································································38
6.2. Available Image Engines···································································38
6.3. Depth of Field·················································································38
6.4. Supported Bar Code Symbologies ······················································39
6.5. Activating the Engine ·······································································40
6.6. Using Demos··················································································40
6.7. Decoding·······················································································40
6.8. To Decode a Bar Code·····································································41
6.9. Sample Bar Codes ··········································································41
6.10. Omni-Directional Scanning Positions···················································41
6.11. Capturing Images (IT5300SR Engine Only)···········································42
7. USING THE LASER ENGINE ································································ 42
7.1. Overview·······················································································42
7.2. Available Laser Engines ···································································42
7.3. Depth of Field·················································································42
7.4. Supported Bar Code Symbologies ······················································43
7.5. Activating the Engine ·······································································43
7.6. Using Demos··················································································43
7.7. Decoding a Bar Code·······································································43
7.8. Sample Bar Code············································································43
7.9. Scanning Positions··········································································44
8. USING SCANWEDGE ········································································· 44
8.1. Overview·······················································································44
8.2. Enabling ScanWedge·······································································45

3
9. USING CONTROL PANEL···································································· 46
9.1. System Properties···········································································45
9.2. Power properties·············································································46
9.3. Program Button properties ································································47
9.4. Backlight Properties·········································································49
9.5. Scanner Settings·············································································49
10. COMMUNICATION············································································ 52
10.1. Communication Options····································································52
10.2. Installing Additional Software ·····························································53
10.3. Connecting the USB ActiveSync Cable ················································53
10.4. ActiveSync Communication ·······························································54
10.5. Communication Type ·······································································54
10.6. Hardware Requirements for Setup ······················································54
10.7. Software Requirements for Communication ··········································55
10.8. Setting Up the Host Workstation·························································55
10.9. Communicating with the Handy Terminal··············································55
10.10. Synchronizing with the Host Workstation··············································55
10.11. Exploring the Terminal from the Workstation ·········································55
10.12. Adding Programs via ActiveSync ························································56
10.13. Wireless Radios··············································································56
10.14. Connecting the Terminal to a Wireless Network·····································57
10.15. WLAN (802.11b/g/n Radio)································································58
10.16. Adding Programs from the Internet······················································58
11. BLUETOOTH HANDLER ······································································ 58
11.1. Enabling the Bluetooth Radio·····························································59
11.2. Connecting to Other Devices ·····························································59
11.3. Pairing Bluetooth Devices ·································································59
11.4. Setting Up a Bluetooth Printer····························································59
12. SINGLE SLOT DOCKING CRADLE/SINGLE SLOT ETHERNET CRADLE DEVICE·········60
12.1. Overview·······················································································60
12.2. Battery Charging·············································································60
12.3. Power Supply·················································································60
12.4. Front Panel····················································································60
12.5. Back Panel ····················································································61
12.6. Powering the Single Slot Docking Cradle or Single Slot Ethernet Cradle Device·····62
12.7. Charging theBattery·········································································62
12.8. Technical Specifications ···································································63
13. SINGLE SLOT DOCKING CRADLE/SINGLE SLOT ETHERNET CRADLE DEVICE·········63
13.1. Overview························································································64
13.2. Power Supply·················································································64
13.3. Front Panel····················································································64
13.4. Back Panel ····················································································65
13.5.. Charging theBattery·········································································65
13.6 Technical Specifications ···································································66

4
1. Introduction
Thank you for purchasing XM5 handy terminal.
This manual generally provides you with the safety information and basic features and operations of
the XM5 device. Please read all safety precautions and this manual carefully before using your handy
terminals and peripherals to ensure safe and proper use.
Trademarks
The official name of Windows XP is Microsoft Windows XP Operating System.
The official name of Windows Vista is Microsoft Windows Vista Operating System.
The official name of Windows 7 is Microsoft Windows 7 Operating System.
Microsoft, Windows, Windows Embedded Handheld 6.5 Pro, ActiveSync, and the brand names and
product names of other Microsoft products are trademarks of Microsoft Corporation in the US and
other countries.
Other company and product names given in this manual or displayed in this software may be the
trademarks of their respective companies.
About the XM5 Handy Terminal
The new XM5 is the latest generation handy terminal device, combining a pocket sized rugged form
factor built on Microsoft Windows Embedded Handheld 6.5 Pro operating system. The XM5 is designed
for retail warehousing and logistics applications where maximum performance and durability is
required in compact Janam device.
The XM5 handy terminal is available in different models depending on the options.
Accessories
 Cradles (including DC 5V 4A Adaptor)
CRD-P1-005U (XM5-Single Slot Cradle)
CRD-P1-005E (XM5-Single Ethernet Cradle)
 Batteries
4000mAh Battery Pack, Standard Capacity (60-BTSC)
 Power Supply
AC Adaptor, INPUT: AC100~240V 50/60Hz, OUTPUT: DC5V 1.8A with MicroUSB type
 Cables
MicroUSB ActiveSync Cable
 Others
Stylus Pen and tether
Handstrap
XM5 handy terminal contains the following items basically:

5
• Handy terminal
• MicroUSB ActiveSync Cable
• 5V/1.8A AC Adaptor with MicroUSB type
• AC Plugs
• Battery Pack
• Stylus Pen and tether
• Handstrap
• LCD Screen Protection Film
• Quick Start Guide
☞ NOTE: Keep the original packaging for use when sending products to the technical assistance center. Damage
caused by improper packaging is not covered under the warranty
☞ NOTE: Rechargeable battery packs are not initially charged or discharged. Before you begin to use, you must charge
the battery packs first. See Paragraph 3.2.
2. Safety Regulations
Symbols in this manual
In this manual, some important items are described with the symbols shown below. Be sure to read
these items before using this equipment.
WARNING Indicates a potentially hazardous situation which, if not avoided, could result in death
serious injury, or serious damage, or fire in the equipment or surrounding objects.
AVERTISSEMENT Le terme AVERTISSEMENT indique une situation potentiellement dangereuse qui, si elle n'est pas
évitée, peut entraîner la mort, des blessures graves, des dommages importants ou l'incendie d’objets et biens d’équipement
environnants.
CAUTION Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate
injury, partial damage to the equipment or surrounding objects, or loss of data.
ATTENTION Le terme ATTENTION indique une situation potentiellement dangereuse qui, si elle n'est pas évitée, peut
entraîner des blessures mineures ou modérées, des dégâts partiels à l'équipement, aux objets environnants ou la perte de
données.
☞ NOTE Indicates information to which you should pay attention when operating the equipment.
This section outlines the safety precautions associated with using XM5 handy terminal.
☞ NOTE: XM5 handy terminals meet or exceed the requirements of all applicable standards organizations for safe
operation. However, as with any electrical equipment, the best way to ensure safe operation is to read this manual
carefully before performing any type of connection to the handy terminal and operate them according to the agency
guidelines described in the manual.

6
2.1. General Safety Rules
CAUTION
 Use only the components supplied by the manufacturer for the specific XM5 being used.
 Do not attempt to disassemble the XM5 handy terminal, as it does not contain parts that can be
repaired by the user. Any tampering will invalidate the warranty.
 When replacing the battery pack or at the end of the operative life of the XM5 handy terminal,
disposal must be performed in compliance with the laws in force in your country.
 Before using the devices and the battery packs, read this manual carefully.
 Do not submerge the XM5 handy terminal in liquid products.
CAUTION
ATTENTION
Utilisez uniquement les composants fournis par le fabricant pour l’utilisation du XM5.
Ne tentez pas de démonter le XM5. Ce produit ne contient aucune pièce ne pouvant être réparée par l'utilisateur. Toute
manipulation fera perdre la garantie au produit.
Lors du remplacement de la batterie ou en fin de vie du terminal portatif XM5, l'élimination et le recyclage doit être effectuée
en conformité avec les lois en vigueur dans votre pays.
Avant d'utiliser les appareils et les batteries, lire attentivement ce manuel.
Ne pas plonger le XM5 dans des produits liquides.
2.2. Power Supply
The power supply for this device has met applicable KCC/CCC safety requirements.
Please adhere to the following safety instructions per UL guidelines:
• FAILURE TO FOLLOW THE INSTRUCTIONS OUTLINED MAY LEAD TO SERIOUS PERSONAL
INJURY AND POSSIBLE PROPERTY DAMAGE.
• IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS.
WARNING
• DANGER – TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, CAREFULLY FOLLOW THESE
INSTRUCTIONS.
WARNING
AVERTISSEMENT
DANGER - POUR RÉDUIRE LES RISQUES D'INCENDIE OU DE CHOC ÉLECTRIQUE, VEUILLEZ SUIVRE
ATTENTIVEMENT CES INSTRUCTIONS.
Use only Janam-approved power supply. Use of a non-Janam-approved power supply may be
dangerous and the warranty does not cover damage to the device caused by non-Janam-approved
power supply. The package includes international AC plugs. The AC plugs must be plugged in the
power supply before the power supply itself is plugged on the wall outlet. The power supply is intended
to be correctly oriented in a vertical or horizontal or floor mount position.
N'utilisez que l'alimentation fournie et approuvée par Janam. L'utilisation de toute autre alimentation peut être dangereuse.
La garantie ne couvre pas les dommages causés à l'appareil par une autre alimentation que celle fournie par Janam.
L’alimentation est livrée avec des adaptateurs AC pour les différentes prises Internationales. Ces prises adaptateur doivent
être installées à l'alimentation électrique avant que cette dernière soit elle-même branchée sur la prise murale. L'alimentation
est destinée à être orientée en position verticale ou horizontale.
2.3. Laser Safety
CAUTION

7
A Class 2 laser is safe because the blink reflex limit the exposure to no more than 0.25 seconds. It
only applies to visible-light lasers (400–700 nm). Class-2 lasers are limited to 1mW continuous wave,
or more if the emission time is less than 0.25 seconds or if the light is not spatially coherent. Although
staring directly at the laser beam momentarily causes no known biological damage, avoid staring at
the beam as one would with any very strong light source, such as the sun. Avoid that the laser beam
hits the eye of an observer, even though reflective surfaces such as mirrors, etc.
The laser light is visible to the human eye and is emitted from the window indicated in the figure.
ATTENTION
Un laser de classe 2 reste inoffensif pour les yeux. Le réflexe de clignement de l’œil limite l'exposition à 0,25 secondes au
plus. Ceci s’applique uniquement aux lasers de lumière visible (400-700 nm). Les Lasers de Classe 2 sont limités à 1 mW
(onde continue), ou davantage si le temps d'émission est inférieur à 0,25 secondes ou encore si la lumière n'est pas
cohérente dans l'espace. Bien que le fait de regarder directement le faisceau laser ne cause pas de dommage biologique
momentané, il est conseillé d’éviter de regarder le faisceau ainsi que n'importe quelle source de lumière très forte, comme
le soleil. Évitez également que le faisceau laser frappe l'œil d'un observateur, ainsi que toutes surfaces réfléchissantes
environnantes, telles que des miroirs, etc
La lumière laser est visible pour l'œil humain et est émise à partir de la fenêtre indiquée sur la figure.
Laser output window
Flash window
Camera window
S/N label
Laser Light Label

8
If the above laser light label is attached to your device, it indicates the product contains a
laser engine or laser aimer that emits the laser light. The following information is provided to
comply with the rules imposed by international authorities and refers to the correct use of
XM5 handy terminal.
Laser Safety Statement
This product has been tested in accordance with and complies with CDRH 21 CFR 1040.10 and
1040.11 and IEC 60825-1 Ed 2 (2007) except for deviations pursuant to Laser Notice No 50, dated
June 24, 2007. LASER LIGHT. DO NOT STARE INTO BEAM. CLASS 2 LASER PRODUCTS. 1 mW MAX
OUTPUT: 650nm.
For installation, use and maintenance, it is not necessary to open the device.
WARNING: Do not attempt to open or otherwise service any components in the optics cavity. Opening or servicing
any part of the optics cavity by unauthorized personnel may violate laser safety regulations. The optics system
is a factory only repair item.
AVERTISSEMENT : Ne tentez pas d'ouvrir ou d’intervenir de quelque manière que ce soit sur les composants de la
cavité optique. L'ouverture ou l'entretien d'une partie de la cavité optique par des personnes non autorisées pourrait
enfreindre les règlementations liées aux normes de sécurité laser. La réparation du système optique ne peut être
prise en charge que par le personnel qualifié du fabricant.
WARNING: Use of controls or adjustments or performance of procedures other than those specified herein may
result in exposure to hazardous visible laser light.
AVERTISSEMENT : Toute manipulation, réglage, ou l'exécution des procédures autres que ceux spécifiés ici
peuvent entraîner une exposition dangereuse à la lumière visible du laser.
WARNING:
Use of optical systems with the scanner will increase eye hazard. Optical instruments include binoculars,
microscopes, eye glasses and magnifying glasses.
AVERTISSEMENT : L'utilisation du scanner avec des systèmes optiques tels que jumelles, microscopes, lunettes
de vue et autres loupes, augmente les risques de dommages pour les yeux.
2.4. LED Safety
The LED output on this device has met IEC62471 LED safety and certified to be under the limits of a
CLASS 1 LED product.
2.5. FCC/EU RF Exposure
 Body effects
This device complies with FCC/EU RF exposure guidelines set forth for an uncontrolled environment.
For body worn operation, this device has been tested and meets the RF exposure guidelines for use
with an accessory that contains no metal and the positions the handset a minimum of 1.0 cm (0.39
inch) from the body. Use of other enhancements may not ensure compliance with RF exposure
guidelines. If you do not use a body-worn accessory and are not holding the device at the ear, position
the handset a minimum of 1.0 cm (0.39 inch) from your body when the device is switched on.
Belt-clips, holsters, and similar accessories containing metallic components from others manufacturers
should not be used.
Accessories worn close to the body, without keeping a minimum distance of 1 cm (0.39 inch) between
the user's body and the device, and that have not been tested for typical body operation, may not
comply with FCC's RF exposure limits and should be avoided.
.

9
2.6. CB Scheme
This device complies with CB Scheme IEC 60950-1
2.7. FCC Part 15 Regulation
Pursuant to part 15 of the FCC Rules, you are cautioned that changes or modifications not expressly
approved by Janam could void your authority to operate the XM5 handy terminal.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This device has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
In accordance with FCC 15.21, changes or modifications not expressly approved by the party
responsible for compliance could void the user‘s authority to operate the equipment.
The antenna(s) must not be co-located or operating in conjunction with any other antenna or
transmitter. To maintain compliance with FCC/EU RF exposure guidelines for body-worn
operation, do not use accessories that contain metallic components. .
2.8. Radio Compliance
XM5 RF terminals are in conformity with all essential requirements of the R&TTE Directive (1999/5/EC).
This device is marked with in accordance with the Class II product requirements
specified in the R&TTE Directive, 1999/5/EC. The device is intended for use throughout the European
Community; PAN European Frequency Range: 2.402 ~ 2.480 GHz.
Restrictions for use in France are as follows:
• Indoor use: maximum power (EIRP*) of 100 mW for the entire 2.400 ~ 2.4835 GHz
• Outdoor use: Maximum power (EIRP*) of 100 mW for the 2.400 ~ 2.454 GHz band and
maximum power (EIRP*) of 10 mW for the 2.454 ~ 2.483 GHz band.
The CE mark on the device indicates that the system has been tested to and confirm with the
provisions noted within the 2004/108/EC Electromagnetic Compatibility Directive and the
2006/95/EC Low Voltage Directive,
1999/5/EC (R&TTE), and 2011/65/EU (RoHS) .
