elsner elektronik WS1000 Style Owner's manual

WS1 Style
Control System for Buildings and for Conservatories
Installation and Operation
EN
WS1000 Style
Control System for Buildings and for Conservatories
including WS1Style-PF and WS1000Style-PF
WS1 Style 60180-60184 (white), 60185-60189 (black). WS1 Style-4 PF 60194 (white)
WS1000 Style 60201-60204 (white), 60206-60209 (black). WS1000 Style-10 PF 60214 (white)
Elsner Elektronik GmbH Control and AutomationTechnology
Sohlengrund 16
75395 Ostelsheim Phone [phone] [e-mail]
Germany Fax [phone] www.elsner-elektronik.de
Technical support: +49 (0) 70 33 / 30 945-250
