And now for something completely dierent
The karacter 500 is a box full of vibrant colors. It covers a
complete spectrum including mastering-grade saturation,
tube-inspired distortion and glorious destruction. Gone are
the days when only racks full of outboard gear could achieve
these elusive and highly desirable styles of tonal coloration...
This all-in-one solution oers two separate channels which
can be set up for dual mono, linked stereo or linked and un-
linked M/S operation. Integrated mix stages for parallel signal
processing and the unique Color Control add to its remarkable
exibility.
The entire unit is designed with discrete class-A topology,
so even the most lo- sounds will benet from the karacter’s
high-end touch. Enhance your tracks or decimate everything –
it’s a matter of karacter.
Enjoy countless hours of fun with this marvelous machine!
Compatibility ..............................................3
Installation ................................................3
Controls ...................................................4
Connectors ................................................6
Mastering-Grade Saturation ................................7
Tube-Inspired Distortion ...................................8
Glorious Destruction .......................................9
Mid/Side Processing ..................................... 10
M/S Mode ............................................... 11
Appendix................................................ 12
Deutsches Handbuch . . . 16 Manuel Français ... 30

3
Compatibility
The karacter 500 module requires installation into an API 500
series compatible rack frame (not included). It needs the pow-
er supply and the audio connectors provided by this frame,
and cannot be used for its intended purpose by itself.
The current consumption is 210 milliamperes (105 mA per
slot) at +/- 16 volts DC. This is actually more than some other
500 series modules consume as a result of the discrete class-A
design of the karacter 500’s audio path.
Most API 500 compatible racks meet this requirement with-
out problems, but there might be a limit on how many units
can be installed in a single rack. In case of doubt, please check
with the manufacturer of your specic rack.
Installation
Just follow these easy steps to install the karacter 500 module:
1. Switch your API 500 series compatible rack o and discon-
nect the power cable from mains.
2. Insert the module into two free slots of your rack. Make sure
both PCB connectors match with the rack connectors.
3. Gently push the module in place – do not use any excessive
force!
4. Tighten the front panel with four screws provided by your
rack manufacturer.
5. Connect your XLR audio cables (see page 6 for more info)
and power up your rack.
That should do it. Have lots of fun with your karacter 500!

4
Controls
Drive
Determines the overall intensity of saturation/distortion/de-
struction. Clockwise means more.
Color
Changes the harmonics-frequency relation. Middle is at; turn
left for more dub and right for more shred.
Gain
Sets the amount of output gain. This controller can both cut
(turn left) and boost (turn right) the level. Middle is at.

5
Mix
Blends the direct and the processed signal in any desired rela-
tion. Left = 100% dry, right = 100% wet.
M/S Mode
Switches from Stereo to M/S processing. The left controllers
and bottom switches control the Mid, the right controllers and
top switches process the Side.
Turbo Boost
Provides an additional kick for truly wild distortion (only avail-
able in FET Shred mode).
FET Shred
Switches from mastering-grade saturation (LED o) to tube-
inspired distortion (LED on).
Left/Right On
Activates a channel or switches to hardwire bypass.
Stereo Link
Links both channels for processing stereo sources (left con-
trollers and bottom switches become the master for both
channels). Linking the channels also works in M/S mode. It
might seem a little odd, as the behavior seems to be exactly
the same as in linked stereo mode. It can still have its benets,
though, as the inevitable divergences between left and right
channel which are caused by natural component tolerances
will be reduced in this mode, because here the side informa-
tion of both channels is processed in a single audio path.

6
Connectors
Audio outputs (+4 dBu)
Pin assignment balanced: 1ground 2hot (+) 3ground
Pin assignment unbalanced: 1ground 2hot (+) 3idle
Audio inputs (+4 dBu)
Pin assignment balanced: 1ground 2hot (+) 3cold (-)
Pin assignment unbalanced: 1ground 2hot (+) 3ground
Mono operation: Connect either one or both of the input and
output pairs 1and 2for single or dual mono channel use.
Stereo operation: Connect both inputs and outputs 1and 2–
the choice which channel is left and which is right is up to you.

h1 2 3 4 5 6 7 89 ...
Harmonics Waveform
7
Mastering-Grade Saturation
In this mode, the karacter 500 generates gentle Total
Harmonic Distortion (THD) with a soft characteristic
curve, resulting in symmetrical clipping. Your sound
gets fatter but stays intact – the perfect color for busses, stems
and complete mixes.
Stereo Link Dual Mono

h1 2 3 4 5 6 7 89 ...
Harmonics Waveform
8
Tube-Inspired Distortion
In FET Shred mode, the behavior of the karacter 500
changes drastically. The sound instantly reminds of
tube ampliers, with a wide range of asymmetrical
distortion. It’s a good idea to make extensive use of the Color
controller – there are so many nuances to discover...
Stereo Link Dual Mono

h1 2 3 4 5 6 7 89 ...
Harmonics Waveform
9
Glorious Destruction
Now, this is pushing the envelope. The Turbo Boost
option is only available in FET Shred mode and works
best at high Drive levels. It shifts the operating point
of the distortion circuit and generates even more asymmetri-
cal wave forms. Hit your samples hard!
Stereo Link Dual Mono

10
Mid/Side Processing
M/S technology is commonly known as a variant of
stereo miking.This technique uses a microphone with
cardioid pattern for the middle signal (M) and another
one with bi-directional pattern with an oset of 90° for the
side signal (S). The main advantage of this technology is its
mono compatibility. FM radio stations use M/S technology for
transmitting stereo signals exactly for this reason.
To create M/S signals, the left and right channel of the stereo
sum are added to generate the mid (M), whereas the side (S) is
created by subtracting the right from the left channel:
M = L+R S = L-R
To decode an M/S signal back into stereo again, M is added to
S for the left channel and S is subtracted from M for the right
channel:
L = M+S R = M-S
The integration of an M/S encoder and decoder into an audio
processor generates new potentials that classic stereo devices
can hardly oer. One of the main advantages is the possibil-
ity to process the middle and side signals separately. This way
you can make the center sound more solid without corrupting
the original stereo spectrum, for example.
Of course it is also possible to enhance the presence of the
side signals in an already nished mix. The stereo width can
be inuenced fast and eectively, too, and it is also possible to
process specic parts of a mix that could not be selected in a
stereo mix as precisely as it is possible in M/S mode.

11
M/S Mode
The most interesting option here is the unlinked M/S
mode, as it gives you the possibility to process the
mid and the side signals completely independent
from each other (remember left becomes mid channel and
right becomes side channel).
You can apply a high amount of saturation to the mid and
leave the sides completely untouched, or the other way
round, or anything in between... Dierent settings of the gain
controllers can be used to create subtle or signicant changes
within the stereo spectrum.
The Left On button always switches both channels in M/S mode.
Linked M/S Unliked M/S

12
Technical Details
Frequency response:
• 100 % Dry <10 Hz - 400 kHz (-3 dB)
• 100 % Wet <10 Hz - 27 kHz (-3 dB)
THD+N (100 % Dry):
• @ 0 dBu 0.013 %
• @ +10 dBu 0.024 %
THD+N (100 % Wet in Saturation Mode):
• @ 0 dBu Min Drive 0.47 %
• @ 0 dBu Max Drive 35.1 %
Noise oor 20 Hz - 20 kHz (A-weighted):
• 100% Dry -91 dBu
• 100% Wet (depending on Drive and Gain) -81 to -91 dBu
Dynamic range 20 Hz - 22 kHz: 112 dB
Maximum input level: +21 dBu
Maximum output level: +21 dBu
Input impedance: 10 kOhm
Output impedance: 68 Ohm
CE Conformity
The conformity of this device to the EU directives is
conrmed by the CE mark on the device.
This declaration becomes invalid by any unapproved modi-
cation of the device.
Nettetal, 01.11.2015 - Ruben Tilgner
