eMachines emonster Series User manual

i
......................................................................................................................................................................................................................................
.........................................................................................................................................
Important Safety Instructions
The following instructions pertain to the risk of fire, electric shock or bodily injury. Please read all of these
instructions carefully.
1Save these instructions for later use.
2Follow all of the instructions and warnings marked on this product or included in this manual.
3Do not use this computer on an unstable cart, stand or table. The product may fall, causing serious
damage to the product.
4Slots and openings in the cabinet and the back have been provided for ventilation. To ensure reliable
operation of your computer, and to protect it from overheating, do not block or cover these openings.
Don't use this product on a bed, sofa, rug or other similar surface. This product should never be placed
near or over a radiator or heat register. This product should not be placed in a built-in installation unless
proper ventilation is provided.
5Never push objects of any kind into the computer through the cabinet openings. Objects may touch
dangerous voltage points or short out parts that could result in a fire or electrical shock. Never spill
liquid of any kind on the product.
6This computer should only be connected to the AC power source indicated on your computer system's
information label. If you are not sure of the type of AC power available, consult your dealer or local
power company. Only connect this computer to a power outlet that matches the power requirements of
this computer.
7Do not allow anything to rest on the power cord. Do not locate this product where people will walk on
the cord.
8If you have to use an extension cord with this computer, make sure that the total amperage rating of all
equipment plugged into it does not exceed the amperage rating of the extension cord. Also, make sure
that the total of all products plugged into the main AC power outlet does not exceed 15 amps.
9Unplug your computer from the main electrical power outlet before cleaning. Do not use liquid cleaners
or aerosol cleaners. Use a damp cloth for cleaning.
10 Do not use this computer near water.
11 This product is eqiupped with a 3-wire grounding type plug, a plug having a third (grounding) pin. This
plug will only fit into a grounding-type power outlet. This is a safety feature. If you are unable to insert
or replace your obsolete outlet, contact your electrician to replace your obsolete outlet. Do not defeat
the purpose of the grounding-type plug.

ii
......................................................................................................................................................................................................................................
.........................................................................................................................................
Maintenance
If the product does not operate normally, adjust only those controls that are covered by the operating
instructions. Improper adjustment of other controls may result in damage and may require extensive repair
work to restore to normal operation.
Unplug this product from the main power outlet and call for service under any of the following conditions:
1If the power cord or plug is damaged or frayed.
2If liquid has been spilled into the product.
3If the product has been exposed to rain or water.
4If the product has been dropped or the cabinet has been damaged.
5If the product exhibits a distinct change in performance indicating a need for service.
Stop
If you ever have to remove the main system unit cover, observe the following precautions:
1The power supply cord must be unplugged before the main system unit cover is removed. (Separe le
cordon d'alimentation et puis enleve le couvercle.)
2Once removed, the cover must be replaced and screwed in position before the power supply cord is
plugged back in. (Apres le couvercle a enleve, visse le couvercle en place et remettre le cordon
d'alimentation.)

iii
......................................................................................................................................................................................................................................
.........................................................................................................................................
Wichtige Sicherheitsvorschriften Unbedingt
Beachten
Allgemeine Sicherheit
Die nachfolgenden Anweisungen betreffen die Gefahr von Verletzungen durch elektrische Spannung, Feuer
und mechanische Einwirkung. Bitte lesen Sie diese Anweisungen sorgfältig.
1Beachten Sie alle Hinweise, die am Gerät selbst angebracht oder in den zugehörigen Handbuchrn
vermerkt sind.
2Stellen Sie das Gerät an einem sicheren, stabilen Arbeitsplatz auf.
3Am Gerät angebrachte Öffnungen (Schlitze und sonstige Öffnungen) dienen der Belüftung des Gerätes.
Um ein zuverlässiges Arbeiten des Geräts zu gewährleisten und um Überhitzung zu vermeiden, müssen
diese Öffnungen unbedingt freigehalten werden. Betreiben Sie das Gerät nie auf Betten, Sofas oder
anderen, weichen Unterlagen.
4Stecken keine Gegegenstände (Schraubenzieher, Büsroklamern etc.) in die
Öffnungen. Sie wurden damit Kurzschlüsse herbeiführen die zur Zer störung des Geräts führen, sich
der Gefahr eines Stromschlages aussetzen oder das Gerät in Brand setzen.
5Das Gerät darf nur an vorschriftmäßige Steckdosen mit der auf dem Gerät angegebenen Netzspannung
angeschlossen werden. Wenn Sie nicht sicher sind, welche Netzspannung richtig ist, wenden Sie sich an
den Lieferanten des Gerätes oder an das zuständige Elektriziträtswerk. Bitten nur an Genügend stark
abgesicherte Steckdosen anschließen, die der Leis tungsaufnahme des Gerätes entsprechen.
6Auf das Netzanschlußkabel dürfen keine Gegenstände gestellt werden. Legen sie das Netzkabel so,
daßniemand darauftreten oder darüber stolpern kann.
7Wenn Sie Verlängerungskabel benutzen, müssen Sie sicher sein, daß die gesamte Leistungsaufnahme
nicht größer ist als das Verlängerungskabel zulaßt. Der gesamte Stromverbrauch aller angeschlossenen
Geräte darf nicht mehr als 15 A betragen.
8Wenn Sie das Gerät reinigen, muß das Netzkabel aus der Steckdose gezogen werden.
9Das Gerät dürfen Sie nicht in der Näh von Wasserleitungen benutzen.

iv
......................................................................................................................................................................................................................................
.........................................................................................................................................
Wartung Des Computers
Wenn der Computer nicht ordnungsgemäß arbeitet, dürfen Sie nur die Einstellungen vornehmen, die im
Handbuch genannt werden. Andere Einstellungen oder Verän derungen können den Computer beschädigen
oder zerstören. Umfangreiche und kostspielige Reparaturen würden notwendig werden, um das Gerät
wieder betriebsfähig zu machen.
Ziehen Sie den Netzstecker aus der Steckdose und verständigen Sie den zuständigen Kundendienst bei
folgenden Storungen:
1Netzkabel ist defekt oder strak abgenutzt.
2Flüssigkeit ist in das Gerät geschüttet worden.
3Das Gerät war Regen oder Leitungswasser aus-gesetzt.
4Das Gerät ist heruntergefallen oder das Gehäuse ist beschädigt.
5Das Gerät arbeitet nicht mehr richtig.
Achtung
Wenn Sie das Gerät Öffnen müssen (Abnahme der verschraubten Haube), ist unbedingt folgendes zu
beachten:
1Das Netzkabel muß aus der Steckdose gezogen werden und zwar bevor Sie das Gerät Öffnen.
2Die Haube muß wieder monitiert und verschraubt werden. Erst dann darf das Netzkabel wieder
eingesteckt werden.
Safety Instruction
Ensure that the appropriate power cord is supplied with personal computer. If the power cord is not supplied
with personal computer, use the correct listed cord sets
as below:
Rating Type Note
125V, 10A Min. SVT MAX. 4.5m – One end terminated with molded on cord connector body.
18AWG/3 long Attachment plug cap with a nama 5-15P.
250V, 6A Min. SVT Max. 4.5m – One end terminated with molded on cord connector body.
18AWG/3 long Attachment plug cap with a nama 6-15P.

v
......................................................................................................................................................................................................................................
.........................................................................................................................................
Before You Read
The information in this user’s guide is subject to change without notice.
eMachines shall not be liable for technical or editorial errors or omissions contained herein; nor for
incidental or consequential damages resulting from the furnishing, performance, or use of this material.
NOTE
Depending on the model, your computer’s components may vary and look slightly different than those
pictured.

vi
......................................................................................................................................................................................................................................
.........................................................................................................................................
Blank

vii
......................................................................................................................................................................................................................................
CONTENTS
Chapter 1 Introduction
System Features ....................................................................................................... 1-1
System Overview ..................................................................................................... 1-3
Front .................................................................................................................. 1-3
Rear ................................................................................................................... 1-7
Chapter 2 Setting Up Your System
1. Selecting a Location ............................................................................................ 2-1
2. Checking the Voltage Selection........................................................................... 2-2
3. Connecting Your Peripheral Devices .................................................................. 2-3
Connecting a Monitor....................................................................................... 2-3
Connecting a Keyboard and Mouse ................................................................. 2-3
Connecting Modem Cables .............................................................................. 2-4
Connecting an Ethernet Cable (optional) ........................................................ 2-5
Connecting Audio Devices ............................................................................... 2-6
Connecting a Printer ......................................................................................... 2-7
Connecting a Serial Device .............................................................................. 2-7
Connecting the USB Devices........................................................................... 2-8
Connecting a Power Cord ................................................................................ 2-9
4. Turning the Computer On and Off .................................................................... 2-10
Turning On the Computer .............................................................................. 2-10
Turning Off the Computer.............................................................................. 2-10

viii
......................................................................................................................................................................................................................................
.........................................................................................................................................
Chapter 3 Using Your Computer
Using a Floppy Disk Drive .......................................................................................3-1
Using a CD/DVD-ROM Drive ................................................................................. 3-3
Using a CD-RW Drive ..............................................................................................3-4
Using Special Keys on the Keyboard....................................................................... 3-5
Using a Mouse .......................................................................................................... 3-6
Changing the Display Resolution and Color Depth ................................................ 3-7
Controlling the Audio Volume.................................................................................. 3-7
Chapter 4 Using the BIOS Setup Program
About the Setup Program .........................................................................................4-1
Entering the Setup Program .....................................................................................4-2
Help Window .....................................................................................................4-3
BIOS Setup Program ................................................................................................4-4
Main Menu.........................................................................................................4-4
Advanced Menu.................................................................................................4-6
Security Menu....................................................................................................4-8
Power Menu .....................................................................................................4-10
Boot Menu ....................................................................................................... 4-11
Exit Menu ........................................................................................................ 4-11
Chapter 5 Inside Your Computer
Removing the Cover ................................................................................................. 5-1
Replacing the Cover .................................................................................................5-3
Internal Components ................................................................................................ 5-4
Mainboard Overview ................................................................................................5-5
Changing the Jumpers .............................................................................................. 5-6
Connecting a Power Supply Connector ................................................................... 5-7
Connecting the Front Panel Connector Cable ......................................................... 5-8
Connecting the USB and MIDI/Game Port connector Cable ...............................5-10
Connecting the Front Panel Speaker & Microphone jacks Cable ........................ 5-11

ix
......................................................................................................................................................................................................................................
.........................................................................................................................................
Chapter 6 Installing and Removing Board Options and Drives
Installing an Expansion Card .................................................................................. 6-1
Installing and Removing Memory Modules ........................................................... 6-3
Installing a Memory Module............................................................................ 6-4
Removing a Memory Module .......................................................................... 6-4
Installing and Removing the Processor .................................................................. 6-5
Replacing a Hard Disk Drive .................................................................................. 6-7
Replacing the Battery .............................................................................................. 6-9
After Installing Options......................................................................................... 6-10
Chapter 7 Using the PowerDVD
About DVD .............................................................................................................. 7-1
Playing the PowerDVD ........................................................................................... 7-1
How to Run the PowerDVD............................................................................. 7-1
Buttons of the PowerDVD................................................................................ 7-2
Chapter 8 Using the Restore CDs
Restoring Your Original Software ........................................................................... 8-1
Installing Drivers ..................................................................................................... 8-3
Appendix A Specifications
Specifications .......................................................................................................... A-1
Appendix B Solving Common Problems
Power....................................................................................................................... B-1
Hard Disk Drive...................................................................................................... B-1
CD/DVD-ROM Drive ............................................................................................. B-2
CD-RW Drive.......................................................................................................... B-2
Audio ....................................................................................................................... B-3
Floppy Disk Drive................................................................................................... B-3
Display & Monitor.................................................................................................. B-4
Keyboard ................................................................................................................. B-7
Mouse ...................................................................................................................... B-7
Option Card............................................................................................................. B-7

x
......................................................................................................................................................................................................................................
.........................................................................................................................................
Appendix C Approval Statements
FCC Compliance Statement ................................................................................... C-1
Battery Warning Instruction ................................................................................... C-2
Fuse Warning Instruction........................................................................................ C-2
Laser Product .......................................................................................................... C-3

Introduction 1-1
......................................................................................................................................................................................................................................
Introduction
Chapter 1Chapter 1
Chapter 1Chapter 1
Chapter 1
Introduction
This chapter describes the major features of your computer.
System Features
Your personal computer is a powerful, versatile, and high performance system that offers
exceptional speed and convenience in a compact design.
Your computer offers the following features:
●Micro ATX form factor
●Intel Coppermine FC-PGA processor
●Two DIMM sockets, expandable up to 256MB using SDRAM modules
●Math coprocessor built in the microprocessor chip
●PCI bus interface
●Two built-in Enhanced IDE controllers
●Intel FW82810 Graphics and Memory Controller Hub (GMCH)
●Intel FW82801AA I/O Controller Hub (ICH)
●Video memory using main memory
NOTES
The internal graphics device on Intel FW82810 supports Intel Dynamic Video Memory
Technology (D.V.M.T). D.V.M.T. dynamically responds to application requirements by
allocating the proper amount of display and texturing memory.
As your system has sharing memory architecture using the main memory for video memory, the
usable main memory size is less than real size when the computer is running.

1-2 Introduction
......................................................................................................................................................................................................................................
.........................................................................................................................................
●Built-in high performance audio CODEC and PCI audio interface
●IT8702F super I/O controller
●Advanced Power Management (APM) and Advanced Configuration and Power Interface
(ACPI)
●Three 32-bit PCI expansion card connectors
●System BIOS and video BIOS shadow RAM
●Password function by using BIOS
●Two USB ports
●One built-in serial port and one built-in parallel port
●A built-in PS/2 style keyboard port
●A built-in PS/2 compatible mouse port
●Three audio jacks and one MIDI/Game port connector
●Plug-and-Play (PnP) BIOS feature

Introduction 1-3
......................................................................................................................................................................................................................................
.........................................................................................................................................
System Overview
The following section describes names and functions of your system.
Front
1 Power Button ( ) & Power Indicator
The power button controls the system’s AC input power. When the computer is turned off,
pushing the button turns on the computer. The power indicator lights up when the computer is
receiving power. When the computer is on, pushing the button turns off the computer.
2 Microphone Jack
The microphone jack can be used to attach a personal computer microphone for integrating
your own voice or musical input into a sound application.
3 Speaker Jack
The Speaker jack can be used to attach most speakers with integrated amplifiers.
4 Hard Disk Drive Access Indicator ( )
The hard disk drive access indicator lights up when one of the hard-disk drives is reading data
from or writing data to the drive.
3
4
2
1
NOTE
Your CD/DVD-ROM and CD-RW drives may differ from the illustrations described in this user’s
guide.

1-4 Introduction
......................................................................................................................................................................................................................................
.........................................................................................................................................
5 CD/DVD-ROM Drive
This drive is used to play music CDs, photo CDs, video CDs, or to load software package onto
the hard disk drive.
6 Disc Tray
Motorized loading system on which the CDs is placed. To eject the tray, press the Load/Eject
button.
7 Busy Indicator
The busy indicator lights during initialization and data-read operations.
8 Eject Hole
Insert a rod here to eject the tray manually only when there is no power available.
9 Load/Eject Button
Opens or closes the disc tray. To eject the tray, exit the application before you press the button.
6
78
9
5

Introduction 1-5
......................................................................................................................................................................................................................................
.........................................................................................................................................
10 CD-RW Drive & Floppy Disk Drive Access Door
Press on the lower-left of this door to access to a CD-RW drive and a floppy disk drive.
11 Floppy Disk Drive Access Indicator
The floppy disk drive access indicator lights up when the drive is reading data from or writing
data to a diskette. Wait until the access indicator turns off before removing a diskette from the
drive.
12 Eject Button
Press this button to eject any diskette in the drive.
13 Floppy Disk Drive
The floppy disk drive accepts 3.5-inch floppy diskettes.
14 CD-RW Drive
This drive is used to play music CDs, photo CDs, video CDs, or to load software package onto
the hard disk drive and makes the copying, storage, and distribution of large files on CDs
(CD-R or CD-RW media).
14
10
13
12
11
NOTE
For detailed information about using your CD-RW drive, refer to the CD-RW drive User’s
Guide.

1-6 Introduction
......................................................................................................................................................................................................................................
.........................................................................................................................................
16
17
15 USB & MIDI/Game Port Connectors Access Door
Push it to open the door for using the USB and MIDI/Game port connectors.
16 USB Connector
You can connect any USB compliant devices to the USB connector. USB devices include low-
speed peripherals such as microphone, digital joystick, and speaker.
17 MIDI/Game Port Connector
You can connect any of a number of MIDI or game input devices to the MIDI/Game port. For
example, you can connect a joystick, game pad, or steering wheel for playing computer games
rather than using the mouse as your input device.
15

Introduction 1-7
......................................................................................................................................................................................................................................
.........................................................................................................................................
Rear
NOTE
Your actual modem card may differ from the illustrations shown in this user’s guide.
1 Keyboard Connector
The PS/2 style keyboard plugs into the keyboard connector.
2 Serial Port (COM1) Connector
You can connect a serial device, such as an external modem and printer, to this serial port
connector.
3 Video Connector
The signal cable from your monitor plugs into the video connector.
4 USB Connector
You can connect any USB compliant devices to the USB connector. USB devices include low-
speed peripherals such as microphone, digital joystick, and speaker.
5 Mouse Connector
The PS/2 style mouse plugs into the mouse connector.
1
2
5
3
4

1-8 Introduction
......................................................................................................................................................................................................................................
.........................................................................................................................................
5 AC Power Receptacle
Your system power cable plugs into the AC power receptacle.
6 Voltage Selection Switch
The voltage selection switch must be set to match the AC power voltage.
10
5
7 Ethernet Card (optional)
You can use the Ethernet network by using this card.
CAUTION
Setting the voltage selection switch incorrectly will damage your computer. Verify that this
switch is set correctly for your AC power voltage before turning on your computer.
6
9
8
7
8 Option Card Slot Covers
9 Parallel Port (LPT1) Connector
You can connect a parallel device, such as a printer, to the parallel port.
10 Air Ventilation Holes
There are holes for air ventilation.
NOTE
For more information, refer to the Ethernet Card Quick Start Guide (PDF format) that came
with your system.

Introduction 1-9
......................................................................................................................................................................................................................................
.........................................................................................................................................
11 Speaker Jack
The Speaker jack can be used to attach most speakers with integrated amplifiers.
12 Line-in Jack
The Line-in jack can be used to attach a record/playback device such as a cassette player, CD
player, or VCR.
13 Phone Jack
You can connect the RJ11 phone jack cable from the telephone to this connector.
14 Wall Jack
You can connect the RJ11 wall jack cable for using faxes, e-mail, and internet access.
15 Padlock Ring
The padlock ring allows you to secure the system
cover to the chassis to prevent unauthorized access to
the inside of the computer. To use padlock ring, insert
a commercially available padlock through the ring
and then lock the padlock.
11
12
13
14
15
