Emerson AutoSense II Inbound Standalone User manual

AutoSense™ II
Inbound Standalone
Installation Manual
Cargo Monitoring Solutions

2
Table of Contents
Page 3
Page 3
Page 4
Page 4
Equipment AutoSense
Standalone Cellular
Connectivity System
Verification
Regulatory Approvals
Technical Support
Page 5
Page 6

3
Inventory List: (Equipment may vary)
• AutoSense Standalone
• 6ft. Low Voltage Extension Cord
• Rubber Reader Antenna
• 2 Cellular Paddle Antennas
• 100-240VAC Power Supply
Installation Hardware:
• Cable Ties
• Cable Tie Mounts
• Mounting Screws
• Cable Clamps
• Test Logger
Equipment
AutoSense Standalone Installation
1. Attach the 2 cellular paddle antennas and the single rubber reader antenna.
2. Mount on wall at least 6 ft. up and in front of dock doors using one of these methods:
a. Mounting screws
b. Cable ties and cable tie mounts
3. Plug power supply into a non-switched power outlet
4. Take picture of AutoSense Standalone and send it to [email protected]
Kit Equipment

4
Cellular Connectivity
1. Angle antennas away from the wall
2. After power is applied, verify the LEDs to right
of the ethernet port are lit correctly
a. Left LED is a solid GREEN indicating system
is operational
b. Middle LED is solid GREEN indicating
connection to cellular carrier
c. Right LED is GREEN or AMBER indicating
cellular strength
System Verication
Stand at the farthest receiving
area/dock door from the
AutoSense Standalone. With the Test
Logger, press and hold the gold power
button in the right-hand corner of the
board until the LED starts ashing
GREEN. LED will ash AMBER when the
test logger has been read.
Test will verify that the system is working
properly. No further action is required.
Power Button
Green Light Green or Orange
Light Red
Light - No cell
connection

5
PakSense, Inc. Model: PSASII-03; FCC ID WPEPSASII-03; IC: 8031A-PSASII03
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Warning: Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
This equipment complies with FCC RF Exposure requirements and should be installed and
operated with a minimum distance of 20 cm between the radiator and any part of the human body.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to
the following two conditions: (1) This device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts
de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire
de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même
si le brouillage est susceptible d’en compromettre le fonctionnement.
This equipment complies with the ICES RF radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with a minimum
distance of 20 cm between the radiator and any part of the human body.
Cet équipement est conforme aux limites d’exposition aux radiations ICES définies pour un
environnement non contrôlé . Cet équipement doit être installé et utilisé à une distance minimale
de 20 cm entre le radiateur et une partie de votre corps.
Regulatory Approvals

6
Technical Support
Technical Support is available 24 hours a day, 7 days a week.
We’re with you every step of the way.
Toll Free: [phone]
Emerson.com/Cargo
[e-mail]
ASIS.UM.Rev1.0220 Emerson is a trademark of Emerson Electric Co. or one of its affiliated companies.
©2020 Emerson Electric Co. All rights reserved.
