Quick Start Guide
00825-0400-2654, Rev AF
August 2017
Rosemount™214C Sensor

August 2017
2
Quick Start Guide
NOTICE
This guide provides basic guidelines for Rosemount 214C Sensor models.
If the sensor was ordered assembled to a temperature thermowell or transmitter, see the appropriate product
literature for information on configuration and hazardous locations certifications.
Explosions could result in death or serious injury.
Installation of this sensor in an explosive environment must be in accordance with the appropriate local,
national, and international standards, codes, and practices.
Conduit/cable entries
Unless marked, the conduit/cable entries in the transmitter housing use a 1/2–14 NPT thread form. Entries
marked “M20” are M20 ⫻1.5 thread form. On devices with multiple conduit entries, all conduit entries will
have the same thread form.
When installing in a hazardous location, use only appropriately listed or Ex certified flameproof/dust plugs,
adapters, or glands in cable/conduit entries.
Only use plugs, adapters, glands, or conduit with a compatible thread form when closing these entries.
Contents
Wiring diagram for RTDs . . . . . . . . . . . . . . . . 3
Wiring diagram for thermocouples . . . . . . 4
Product certifications . . . . . . . . . . . . . . . . . . . 5
Installation drawings . . . . . . . . . . . . . . . . . . .10

Quick Start Guide
3
August 2017
1.0 Wiring diagram for RTDs
Figure 1. RTD Lead Wire Configuration per IEC 60751
Note
To configure a single element, 4-wire RTD as a 3-wire system, connect only one white lead.
Insulate or terminate the unused white lead in a manner that prevents shorting to the ground.
To configure a single element, 4-wire RTD as a 2-wire system, connect matching colored wires
first and then connect the paired wires to the terminal.
Single element, 3-wire Single element, 4-wire Dual element, 3-wire
Red
Red
White
White
Red
Red
White
Red
Red
White
Black
Black
Yellow

August 2017
4
Quick Start Guide
2.0 Wiring diagram for thermocouples
Figure 2. Thermocouple Lead Wire Configuration
Note
Dual thermocouple sensors are shipped with one pair of the wires shrink wrapped together.
Single thermocouple, 2-wire Dual thermocouple, 4-wire
IEC 60584 thermocouple colors ASTM E- 230 thermocouple colors
Type POS (+) NEG (-) POS (+) NEG (-)
JBlack White White Red
KGreen White Yellow Red
TBrown White Blue Red
( – )
( + ) ( + )
(
+
)
( – )
( – )

Quick Start Guide
5
August 2017
3.0 Product certifications
Rev 1.12
3.1 European Directive information
A copy of the EU Declaration of Conformity can be found at the end of the Quick Start Guide.
The most recent revision of the EU Declaration of Conformity can be found at
Emerson.com/Rosemount.
3.2 Ordinary Location Certification
The Rosemount 214C has been examined and tested to determine that the design meets the
basic electrical, mechanical, and fire protection requirements by a nationally recognized test
laboratory (NRTL) as accredited by the Federal Occupational Safety and Health Administration
(OSHA).
3.3 North America
The US National Electrical Code®(NEC) and the Canadian Electrical Code (CEC) permit the use
of Division marked equipment in Zones and Zone marked equipment in Divisions. The
markings must be suitable for the area classification, gas, and temperature class. This
information is clearly defined in the respective codes.
E5 Explosionproof (XP) and Dust-Ignitionproof (DIP)
Certificate: 70044744
Standards: FM 3600:2011, FM 3615:2006, UL 50E:2007, UL 61010-1:2010, ANSI/ISA
60529:2004
Markings: XP CL I, DIV 1, GP B, C, D; DIP CL II, DIV 1, GP E, F, G; CL III; T6 (–50 °C ≤Ta≤
+80 °C), T5 (–50 °C ≤Ta≤ +95 °C); Seal not required; installed per Rosemount
drawing 00214-1030; Type 4X†; Vmax 35 VDC, 750 mWmax
Special Conditions for Safe Use (X):
1. Flameproof joints are not intended for repair.
2. Cable entries must be used which maintain the ingress protection of the enclosure. Unused
cable entries must be filled with suitable blanking plugs.
N5 Division 2 (NI)
Certificate: 70044744
Standards: FM 3600:2011, FM 3611:2004, UL 50E:2007, UL 61010-1:2010, ANSI/ISA
60529:2004
Markings: NI CL I, DIV 2, GP A, B, C, D; T6 (–50 °C ≤Ta≤+80 °C),
T5 (–50 °C ≤Ta≤ +95 °C); installed per Rosemount drawing 00214-1030; Type
4X†; Vmax 35 VDC, 750 mWmax
E6 Explosionproof and Dust-Ignitionproof
Certificate: 70044744
Standards: CAN/CSA C22.2 No. 0:2010, CAN/CSA No. 25-1966,
CAN/CSA C22.2 No. 30-M1986, CAN/CSA C22.2 No. 94-M1991,
CAN/CSA C22.2 No. 61010-1:2012
Markings: Explosionproof CL I, DIV 1, GP B, C, D; Dust-Ignitionproof CL II, DIV 1,
GP E, F, G; CL III; T6 (–50 °C ≤Ta≤+80 °C), T5 (–50 °C ≤Ta≤+95 °C);
Seal not required; installed per Rosemount drawing 00214-1030; Type 4X†;
Vmax 3 5VDC, 750 mWmax

August 2017
6
Quick Start Guide
Special Conditions for Safe Use (X):
1. Flameproof joints are not intended for repair.
2. Cable entries must be used which maintain the ingress protection of the enclosure. Unused
cable entries must be filled with suitable blanking plugs.
N6 Division 2
Certificate: 70044744
Standards: CAN/CSA C22.2 No. 0:2010, CAN/CSA C22.2 No. 94-M1991, CAN/CSA No.
213-M1987, CAN/CSA C22.2 No. 61010-1:2012
Markings: CL I, DIV 2, GP A, B, C, D; T6; (–50 °C ≤Ta≤+80 °C), T5 (–50 °C ≤Ta≤+95 °C);
installed per Rosemount drawing 00214-1030; Type 4X†; Vmax 35 VDC,
750 mWmax
†Spring loaded indicator has reduced ingress and dust ratings. Spring loaded sensors must be
installed in a thermowell to maintain dust and ingress ratings. Un-painted aluminum
enclosures are Type 4 rated.
3.4 Europe
E1 Flameproof
Certificate: DEMKO 16 ATEX 1677X
Standards: EN 60079-0:2012+A11 2013, EN 60079-1:2014
Markings: II 2 G Ex db IIC T6…T1 Gb
Vmax = 45 Vdc, Pmax = 750 mW
Installation Instructions:
1. Use field wiring suitable for both the minimum and maximum service temperatures.
2. These devices are provided without cable glands/conduit sealing devices/blanking
elements. Proper selection of suitable cable glands/conduit sealing/blanking elements
should occur in the field.
3. Unused apertures shall be closed with suitable blanking elements.
4. The enclosures may be provided with up to three 1/2–14 NPT, 3/4–14 NPT, or M20 x 1.5
entries, with location of the entries specified in the installation instructions document.
Special Conditions for Safe Use (X):
1. Refer to certificate for details regarding process and ambient temperature limits.
2. When the Rosemount 214C sensor is provided with an enclosure with a display cover, the
maximum ambient shall be 95 °C.
3. The non-metallic label on the device may store an electrostatic charge and become a
source of ignition in Group III atmospheres. Care shall be taken to reduce electrostatic
build-up. For example, the non-metallic label may be rubbed with a damp cloth.
4. The display covers were impacted at 4 J according to a low risk of mechanical danger. Guard
the display covers against impact energies greater than 4 J.
5. Flameproof joints are not intended for repair.
6. The stand-alone Rosemount 214C sensors without an enclosure must be assembled to a
suitable Ex certified enclosure of a volume no greater than 0.55 L to maintain the types of
protection “db” and “tb”.
7. The spring loaded sensors and DIN sensors must be installed in a thermowell to maintain
IP6X ratings.
8. Contact indicating sensors do not meet requirements for protection type “tb” and
therefore are not “tb” rated.

Quick Start Guide
7
August 2017
I1 ATEX Intrinsic Safety
Certificate: Baseefa16ATEX0101X
Standards: EN 60079-0:2012+A11:2013, EN 60079-11:2012
Markings: II 1 G Ex ia IIC T5/T6 Ga (SEE CERTIFICATE FOR SCHEDULE)
Special Condition of Use (X):
1. The equipment must be installed in an enclosure which affords it a degree of ingress
protection of at least IP20.
N1 ATEX Type n – with enclosure
Certificate: BAS00ATEX3145
Standards: EN 60079-0:2012+A11:2013, EN 60079-15:2010
Markings: II 3 G Ex nA IIC T5 Gc T5(-40 °C≤ Ta≤ 70 °C)
ND Dust
Certificate: DEMKO 16 ATEX 1677X
Standards: EN 60079-0:2012+A11 2013, EN 60079-31:2014
Markings: II 2 D Ex tb IIIC T 130 °C Db
Vmax = 45 Vdc, Pmax = 750 mW
Installation Instructions:
1. Use field wiring suitable for both the minimum and maximum service temperatures.
2. These devices are provided without cable glands/conduit sealing devices/blanking
elements. Proper selection of suitable cable glands/conduit sealing/blanking elements
should occur in the field.
3. Unused apertures shall be closed with suitable blanking elements.
4. The enclosures may be provided with up to (3) 1/2–14 NPT, 3/4–14 NPT, or M20 ⫻1.5
entries, with location of the entries specified in the installation instructions document.
Special Conditions for Safe Use (X):
1. Refer to certificate for details regarding process and ambient temperature limits.
2. When the Rosemount 214C sensor is provided with an enclosure with a display cover, the
maximum ambient shall be 95 °C.
3. The non-metallic label on the device may store an electrostatic charge and become a
source of ignition in Group III atmospheres. Care shall be taken to reduce electrostatic
build-up. For example, the non-metallic label may be rubbed with a damp cloth.
4. The display covers were impacted at 4 J according to a low risk of mechanical danger. Guard
the display covers against impact energies greater than 4J.
5. Flameproof joints are not intended for repair.
6. The stand-alone Rosemount 214C sensors without an enclosure must be assembled to a
suitable Ex certified enclosure of a volume no greater than 0.55 L to maintain the types of
protection “db” and “tb”.
7. The spring loaded sensors and DIN sensors must be installed in a thermowell to maintain
IP6X ratings.
8. Contact indicating sensors do not meet requirements for protection type “tb” and
therefore are not “tb” rated.
Thermocouples; Pi = 500 mW T6 60 °C ≤Ta≤+70 °C
RTDs; Pi = 192 mW T6 60 °C ≤Ta≤+70 °C
RTDs; Pi = 290 mW T6 60 °C ≤Ta≤+60 °C
T5 60 °C ≤Ta≤+70 °C

August 2017
8
Quick Start Guide
3.5 International
E7 Flameproof
Certificate: IECEx UL 16.0048X
Standards: IEC 60079-0:2011, IEC 60079-1:2014
Markings: Ex db IIC T6…T1 Gb
Vmax = 45 Vdc, Pmax = 750 mW
Installation Instructions:
1. Use field wiring suitable for both the minimum and maximum service temperatures.
2. These devices are provided without cable glands/conduit sealing devices/blanking
elements. Proper selection of suitable cable glands/conduit sealing/blanking elements
should occur in the field.
3. Unused apertures shall be closed with suitable blanking elements.
4. The enclosures may be provided with up to three 1/2–14 NPT, 3/4–14 NPT, or M20 ⫻1.5
entries, with location of the entries specified in the installation instructions document.
Special Conditions for Safe Use (X):
1. Refer to certificate for details regarding process and ambient temperature limits.
2. When the Rosemount 214C sensor is provided with an enclosure with a display cover, the
maximum ambient shall be 95 °C.
3. The non-metallic label on the device may store an electrostatic charge and become a
source of ignition in Group III atmospheres. Care shall be taken to reduce electrostatic
build-up. For example, the non-metallic label may be rubbed with a damp cloth.
4. The display covers were impacted at 4 J according to a low risk of mechanical danger. Guard
the display covers against impact energies greater than 4J.
5. Flameproof joints are not intended for repair.
6. The stand-alone Rosemount 214C sensors without an enclosure must be assembled to a
suitable Ex certified enclosure of a volume no greater than 0.55 L to maintain the types of
protection “db” and “tb”.
7. The spring loaded sensors and DIN sensors must be installed in a thermowell to maintain
IP6X ratings.
8. Contact indicating sensors do not meet requirements for protection type “tb” and
therefore are not “tb” rated.
I7 IECEx Intrinsic Safety
Certificate: IECEx BAS 16.0077X
Standards: EN 60079-0:2012+A11:2013, EN 60079-11:2012
Markings: Ex ia IIC T5/T6 Ga (SEE CERTIFICATE FOR SCHEDULE)
Special Condition of Use (X):
1. The equipment must be installed in an enclosure which affords it a degree of ingress
protection of at least IP20.
N7 IECEx Type n – with enclosure
Certificate: IECEx BAS 07.0055
Standards: IEC 60079-0:2011, IEC 60079-15:2010
Markings: Ex nA IIC T5 Gc; T5(–40 °C ≤ Ta≤ +70 °C)
Thermocouples; Pi = 500 mW T6 60 °C ≤Ta≤+70 °C
RTDs; Pi = 192 mW T6 60 °C ≤Ta≤+70 °C
RTDs; Pi = 290 mW T6 60 °C ≤Ta≤+60 °C
T5 60 °C ≤Ta≤+70 °C

Quick Start Guide
9
August 2017
NK Dust
Certificate: IECEx UL 16.0048X
Standards: IEC 60079-0:2011, IEC 60079-31:2013
Markings: Ex tb IIIC T 130 °C Db
Vmax = 45 Vdc, Pmax = 750 mW
Installation Instructions:
1. Use field wiring suitable for both the minimum and maximum service temperatures.
2. These devices are provided without cable glands/conduit sealing devices/blanking
elements. Proper selection of suitable cable glands/conduit sealing/blanking elements
should occur in the field.
3. Unused apertures shall be closed with suitable blanking elements.
4. The enclosures may be provided with up to three 1/2–14 NPT, 3/4–14 NPT, or M20 ⫻1.5
entries, with location of the entries specified in the installation instructions document.
Special Conditions for Safe Use (X):
1. Refer to certificate for details regarding process and ambient temperature limits.
2. When the Rosemount 214C sensor is provided with an enclosure with a display cover, the
maximum ambient shall be 95 °C.
3. The non-metallic label on the device may store an electrostatic charge and become a
source of ignition in Group III atmospheres. Care shall be taken to reduce electrostatic
build-up. For example, the non-metallic label may be rubbed with a damp cloth.
4. The display covers were impacted at 4 J according to a low risk of mechanical danger. Guard
the display covers against impact energies greater than 4J.
5. Flameproof joints are not intended for repair.
6. The stand-alone Rosemount 214C sensors without an enclosure must be assembled to a
suitable Ex certified enclosure of a volume no greater than 0.55 L to maintain the types of
protection “db” and “tb”.
7. The spring loaded sensors and DIN sensors must be installed in a thermowell to maintain
IP6X ratings.
8. Contact indicating sensors do not meet requirements for protection type “tb” and
therefore are not “tb” rated.
3.6 Combinations
KA Combination of E1 and E6
KB Combination of E5 and E6
KC Combination of E1 and E5
KD Combination of E1, E5, and E6
KN Combination of N1, N5, N6, and N7s

August 2017
10
Quick Start Guide
4.0 Installation drawings
Figure 3. Rosemount 214C Hazardous Location (00214-1030)

Quick Start Guide
11
August 2017
Figure 4. Rosemount 214C Declaration of Conformity
EU Declaration of Conformity
No: RMD 1109 Rev. C
Page 1 of 2
We,
Rosemount, Inc.
8200 Market Boulevard
Chanhassen, MN 55317-9685
USA
declare under our sole responsibility that the product,
Rosemount™ 214C Temperature Sensor
manufactured by,
Rosemount, Inc.
8200 Market Boulevard
Chanhassen, MN 55317-9685
USA
to which this declaration relates, is in conformity with the provisions of the European Union
Directives, including the latest amendments, as shown in the attached schedule.
Assumption of conformity is based on the application of the harmonized standards and, when
applicable or required, a European Union notified body certification, as shown in the attached
schedule.
(signature)
Vice President of Global Quality
(function)
Chris LaPoint
(name)
31-July-2017
(date of issue)

August 2017
12
Quick Start Guide
EU Declaration of Conformity
No: RMD 1109 Rev. C
Page 2 of 2
ATEX Directive (2014/34/EU)
DEMKO 16ATEX1677X - Flameproof Certificate
Equipment Group II Category 2 G (Ex db IIC T6…T1 Gb)
Harmonized Standards:
EN 60079-0:2012+A11:2013, EN 60079-1:2014
DEMKO 16ATEX1677X - Dust Certificate
Equipment Group II Category 2 D (Ex tb IIIC T130°C Db)
Harmonized Standards:
EN 60079-0:2012+A11:2013, EN 60079-31:2009
BAS00ATEX3145 - Type n Certificate
Equipment Group II Category 3 G (Ex nA IIC T5 Gc)
Harmonized Standards:
EN60079-0:2012+A11:2013, EN60079-15:2010
Baseefa16ATEX0101X – Intrinsic Safety Certificate
Equipment Group II Category 1 G (Ex ia IIC T5/T6)
Harmonized Standards:
EN 60079-0:2012+A11:2013, EN 60079-11:2012
RoHS Directive (2011/65/EU)
Harmonized Standard: EN 50581:2012
ATEX Notified Bodies
UL International Demko A/S [Notified Body Number: 0539]
Borupvang 5A
2750 Ballerup
Denmark
SGS Baseefa Limited [Notified Body Number: 1180]
Rockhead Business Park
Staden Lane
Buxton Derbyshire
SK17 9RZ United Kingdom
ATEX Notified Body for Quality Assurance
SGS Baseefa Limited [Notified Body Number: 1180]
Rockhead Business Park Staden Lane
SK17 9RZ Buxton
United Kingdom

Quick Start Guide
13
August 2017
ᴹ
China RoHS
㇑᧗⢙䍘䎵䗷ᴰབྷ⎃ᓖ䲀٬Ⲵ䜘Ԧරࡇ㺘
Rosemount 214

List of Rosemount 214 Parts with China RoHS Concentration above MCVs
䜘Ԧ〠
Part Name
ᴹᇣ⢙䍘䍘Hazardous Substances
䫵
Lead
(Pb)
⊎
Mercury
(Hg)
䭹
Cadmium
(Cd)
ޝԧ䬜䬜
Hexavalent
Chromium
(Cr +6)
ཊⓤ㚄㚄㤟
Polybrominated
biphenyls
(PBB)
ཊⓤ㚄㚄㤟䟊
Polybrominated
diphenyl ethers
(PBDE)
⭥ᆀ㓴Ԧ
Electronics
Assembly
O
O
O
O
O
O
༣փ㓴Ԧ
Housing
Assembly
O
O
O
O
O
O
Րᝏಘ㓴Ԧ
Sensor
Assembly
O
O
O
O
O
O
ᵜ㺘Ṭ㌫׍ᦞ
SJ/T11364
Ⲵ㿴ᇊ㘼ࡦ֌
This table is proposed in accordance with the provision of SJ/T11364.
O:
᜿Ѫ䈕䜘ԦⲴᡰᴹ൷䍘ᶀᯉѝ䈕ᴹᇣ⢙䍘Ⲵ䟿൷վҾ
GB/T 26572
ᡰ㿴ᇊⲴ䲀䟿㾱≲
O: Indicate that said hazardous substance in all of the homogeneous materials for this part is below the limit requirement of
GB/T 26572.
X:
᜿Ѫ൘䈕䜘Ԧᡰ֯⭘Ⲵᡰᴹ൷䍘ᶀᯉ䟼ˈ㠣ቁᴹа㊫൷䍘ᶀᯉѝ䈕ᴹᇣ⢙䍘Ⲵ䟿儈Ҿ
GB/T 26572
ᡰ㿴ᇊⲴ䲀䟿㾱≲
X: Indicate that said hazardous substance contained in at least one of the homogeneous materials used for this part is above
the limit requirement of GB/T 26572.

Global Headquarters
Emerson Automation Solutions
6021 Innovation Blvd.
Shakopee, MN 55379, USA
[phone] or [phone]
[phone]
[e-mail]
North America Regional Office
Emerson Automation Solutions
8200 Market Blvd.
Chanhassen, MN 55317, USA
[phone] or [phone]
[phone]
[e-mail]
Latin America Regional Office
Emerson Automation Solutions
1300 Concord Terrace, Suite 400
Sunrise, FL 33323, USA
[phone]
[phone]
[email protected] Linkedin.com/company/Emerson-Automation-Solutions
Twitter.com/Rosemount_News
Facebook.com/Rosemount
Youtube.com/user/RosemountMeasurement
Google.com/+RosemountMeasurement
Standard Terms and Conditions of Sale can be found on the Terms
and Conditions of Sale page.
The Emerson logo is a trademark and service mark of Emerson
Electric Co.
Rosemount and Rosemount logotype are trademarks of Emerson.
National Electrical Code is a registered trademark of National Fire
Protection Association, Inc.
All other marks are the property of their respective owners.
© 2017 Emerson. All rights reserved.
Europe Regional Office
Emerson Automation Solutions
Neuhofstrasse 19a P.O. Box 1046
CH 6340 Baar
Switzerland
[phone]
[phone]
[email protected]
Asia Pacific Regional Office
Emerson Automation Solutions
1 Pandan Crescent
Singapore 128461
[phone]
[phone]
[e-mail]
Middle East and Africa Regional Office
Emerson Automation Solutions
Emerson FZE P.O. Box 17033
Jebel Ali Free Zone - South 2
Dubai, United Arab Emirates
[phone]
[phone]
[e-mail]
Quick Start Guide
00825-0400-2654, Rev AF
August 2017
*00825-0400-2654*
