Emerson Micro Motion Elite Coriolis Micro Motion Elite Coriolis... User manual

Installation Manual
20002158, Rev DM
January 2018
Micro Motion® ELITE® Coriolis Flow and Density
Sensors

Safety and approval information
This Micro Motion product complies with all applicable European directives when properly installed in accordance with the
instructions in this manual. Refer to the EU declaration of conformity for directives that apply to this product. The EU declaration of
conformity, with all applicable European directives, and the complete ATEX Installation Drawings and Instructions are available on
the internet at www.emerson.com or through your local Micro Motion support center.
Information affixed to equipment that complies with the Pressure Equipment Directive, can be found on the internet at
www.emerson.com.
For hazardous installations in Europe, refer to standard EN 60079-14 if national standards do not apply.
Other information
Full product specifications can be found in the product data sheet. Troubleshooting information can be found in the configuration
manual. Product data sheets and manuals are available from the Micro Motion web site at www.emerson.com.
Return policy
Follow Micro Motion procedures when returning equipment. These procedures ensure legal compliance with government
transportation agencies and help provide a safe working environment for Micro Motion employees. Micro Motion will not accept
your returned equipment if you fail to follow Micro Motion procedures.
Return procedures and forms are available on our web support site at www.emerson.com, or by phoning the Micro Motion Customer
Service department.
Emerson Flow customer service
Email:
•Worldwide: [email protected]
•Asia-Pacific: [email protected]
Telephone:
North and South America Europe and Middle East Asia Pacific
United States 800-522-6277 U.K. 0870 240 1978 Australia 800 158 727
Canada [phone] The Netherlands [phone] New Zealand 099 128 804
Mexico [phone] France 0800 917 901 India 800 440 1468
Argentina [phone] Germany 0800 182 5347 Pakistan 888 550 2682
Brazil [phone] Italy 8008 77334 China [phone]
Central & Eastern [phone] Japan [phone]
Russia/CIS [phone] South Korea [phone]
Egypt 0800 000 0015 Singapore [phone]
Oman 800 70101 Thailand 001 800 441 6426
Qatar 431 0044 Malaysia 800 814 008
Kuwait 663 299 01
South Africa 800 991 390
Saudi Arabia 800 844 9564
UAE 800 0444 0684

Contents
Chapter 1 Planning ...........................................................................................................................1
1.1 Installation checklist .......................................................................................................................1
1.2 Best practices ................................................................................................................................. 3
1.3 Temperature limits .........................................................................................................................3
1.4 Recommendations for hygienic and self-draining applications ....................................................... 6
Chapter 2 Mounting .........................................................................................................................8
2.1 Recommendations for lifting heavy meters .................................................................................... 8
2.2 Mount the sensor ......................................................................................................................... 10
2.3 Rotate junction box or 800 core processor (optional) ................................................................... 11
2.4 Mount electronics of high-temperature sensors ........................................................................... 12
2.5 Mount a CMF010 sensor to a wall or pole ..................................................................................... 16
2.6 Mount a CMFS007, CMFS010 or CMFS015 sensor in a bracket ......................................................17
2.7 Mount a CMFS025, CMFS040 or CMFS050 sensor in a wall mount bracket ................................... 18
2.8 Secure wafer-style process connections ....................................................................................... 19
2.9 Attach extended electronics .........................................................................................................20
Chapter 3 Transmitter power and I/O wiring .................................................................................. 22
3.1 Options for wiring ........................................................................................................................ 22
3.2 Connect 4-wire cable ....................................................................................................................23
3.3 Connect the 9-wire cable ..............................................................................................................27
Chapter 4 Grounding ......................................................................................................................28
Chapter 5 Supplementary information ........................................................................................... 29
5.1 Purge the sensor case ...................................................................................................................29
5.2 Pressure relief ...............................................................................................................................32
Contents
Installation Manual i

Contents
ii Micro Motion ELITE

1 Planning
Topics covered in this chapter:
•Installation checklist
•Best practices
•Temperature limits
•Recommendations for hygienic and self-draining applications
1.1 Installation checklist
□Make sure that the hazardous area specified on the approval tag is suitable for the
environment in which the meter will be installed.
□Verify that the local ambient and process temperatures are within the limits of the
meter.
□If your sensor has an integral transmitter, no wiring is required between the sensor
and transmitter. Follow the wiring instructions in the transmitter installation manual
for signal and power wiring.
□If your transmitter has remote-mounted electronics, follow the instructions in this
manual for wiring between the sensor and the transmitter, and then follow the
instructions in the transmitter installation manual for power and signal wiring.
Maximum lengths for Micro Motion cableTable 1-1:
Cable type To transmitter Maximum length
Micro Motion 9-wire 9739 MVD transmitter 1000 ft (300 m)
All other MVD transmit-
ters
60 ft (20 m)
Micro Motion 4-wire All 4-wire MVD transmit-
ters
-1000 ft (300 m) without Ex-approval
-500 ft (150 m) with IIC rated sensors
-1000 ft (300 m) with IIB rated sensors
Maximum lengths for user-supplied 4-wire cableTable 1-2:
Wire function Wire size Maximum length
Power (VDC) 22 AWG (0,35 mm2) 300 ft (90 m)
20 AWG (0,5 mm2) 500 ft (150 m)
18 AWG (0,8 mm2) 1000 ft (300 m)
Signal (RS-485) 22 AWG (0,35 mm2) or larger 1000 ft (300 m)
□For optimal performance, install the sensor in the preferred orientation. The sensor
will work in any orientation as long as the flow tubes remain full of process fluid.
Planning
Installation Manual 1

Preferred sensor orientationTable 1-3:
Process Preferred orienta-
tion Alternate orientations
Liquids
Gases
Slurries
□Install the meter so that the flow direction arrow on the sensor case matches the
actual forward flow of the process. (Flow direction is also software-selectable.)
Planning
2Micro Motion ELITE

1.2 Best practices
The following information can help you get the most from your sensor.
•There are no pipe run requirements for Micro Motion sensors. Straight runs of pipe
upstream or downstream are unnecessary.
•If the sensor is installed in a vertical pipeline, liquids and slurries should flow upward
through the sensor. Gases should flow downward.
•Keep the sensor tubes full of process fluid.
•For halting flow through the sensor with a single valve, install the valve downstream
from the sensor.
•Minimize bending and torsional stress on the meter. Do not use the meter to align
misaligned piping.
•The sensor does not require external supports. The flanges will support the sensor in
any orientation. (Some sensor models installed in very small, flexible pipeline have
optional installation instructions that allow for external supports.)
1.3 Temperature limits
Sensors can be used in the process and ambient temperature ranges shown in the
temperature limit graphs. For the purposes of selecting electronics options, temperature
limit graphs should be used only as a general guide. If your process conditions are close to
the gray area, consult with your Micro Motion representative.
Note
•In all cases, the electronics cannot be operated where the ambient temperature is
below –40 °F (–40 °C) or above +140 °F (+60 °C). If a sensor is to be used where the ambient
temperature is outside of the range permissible for the electronics, the electronics must be
remotely located where the ambient temperature is within the permissible range, as
indicated by the shaded areas of the temperature limit graphs.
•Temperature limits may be further restricted by hazardous area approvals. Refer to the
hazardous area approvals documentation shipped with the sensor or available at
www.emerson.com.
•The extended-mount electronics option allows the sensor case to be insulated without
covering the transmitter, core processor, or junction box, but does not affect temperature
ratings. When insulating the sensor case at elevated process temperatures (above 140 °F),
please ensure electronics are not enclosed in insulation as this may lead to electronics failure.
•For the CMFS007 sensor, the difference between the process fluid temperature and the
average temperature of the case must be less than 210°F (99°C)
Planning
Installation Manual 3

Ambient and process temperature limits for ELITE CMFS007, CMFS025–CMFS150
meters
140 (60)
–40 (–40)
113
(45)
–148 (–100)
–58 (–50) 400 (204)
140 (60)
A
B
B
Tamb
Tproc
Tamb = Ambient temperature °F (°C)
Tproc = Process temperature °F (°C)
A = All available electronic options
B= Remote mount electronics only
Ambient and process temperature limits for ELITE CMF***M/L/H/P (excludes special
order cryogenic modifications) and CMFS010-015 meters
140 (60)
–40 (–40)
113
(45)
–148 (–100)
–400
(–240)
400
(204)
140
(60)
Tamb
Tproc
A
B
B
Tamb = Ambient temperature °F (°C)
Tproc = Process temperature °F (°C)
A = All available electronic options
B= Remote mount electronics only
Planning
4Micro Motion ELITE

Ambient and process temperature limits for special order cryogenic ELITE meters
140 (60)
–40 (–40)
–148 (–100)
–400
(–240)
176
(80)
A
B
Tamb
Tproc
Tamb = Ambient temperature °F (°C)
Tproc = Process temperature °F (°C)
A = All available electronic options
B= Remote mount electronics only
Ambient and process temperature limits for high temperature ELITE meters
140 (60)
–40 (–40)
–148 (–100)
–58
(–50)
662
(350)
A
B
Tamb
Tproc
Tamb = Ambient temperature °F (°C)
Tproc = Process temperature °F (°C)
A = All available electronic options
B= Remote mount electronics only
Planning
Installation Manual 5

Ambient and process temperature limits for Super Duplex ELITE meters
140 (60) 140 (60)
–40 (–40)
–148 (–100)
–40 (–40) 400 (204)
113
(45)
A
B
B
Tamb
Tproc
Tamb = Ambient temperature °F (°C)
Tproc = Process temperature °F (°C)
A = All available electronic options
B= Remote mount electronics only
Note
For Super Duplex models operating above 177 °C, please consult the factory before purchase.
1.4 Recommendations for hygienic and self-
draining applications
CMFS sensors are certified EHEDG TYPE EL CLASS I for hygienic applications when installed
vertically with the process fitting and gasket combinations listed in the Position Paper of
the EHEDG Test Methods Subgroup (available at http://www.ehedg.org). Other process
connections/gasket combinations may be used provided they have been evaluated and
successfully tested for in-place cleanability according to the latest edition of EHEDG
Document 2. Refer to the ELITE Product Data Sheet for further information about fitting
options.
For optimal cleanability and drainability:
•If possible, install the sensor in a vertical pipeline with the process fluid flowing
upward through the sensor.
•If the sensor must be installed in a horizontal pipeline, drainage is accomplished by
air purge evacuation of the pipeline circuit.
•For clean-in-place (CIP) applications, Micro Motion recommends using the
generally-accepted flow velocity of at least 1.5 m/s for cleaning the sensor.
•The gap between the electronics housing and sensor body should be inspected
periodically. Manually clean this gap when necessary.
Planning
6Micro Motion ELITE

Installation for self-draining applicationsFigure 1-1:
A
B
C
A. Process pipeline
B. Direction of normal process flow
C. Direction of drainage
Planning
Installation Manual 7

2 Mounting
Topics covered in this chapter:
•Recommendations for lifting heavy meters
•Mount the sensor
•Rotate junction box or 800 core processor (optional)
•Mount electronics of high-temperature sensors
•Mount a CMF010 sensor to a wall or pole
•Mount a CMFS007, CMFS010 or CMFS015 sensor in a bracket
•Mount a CMFS025, CMFS040 or CMFS050 sensor in a wall mount bracket
•Secure wafer-style process connections
•Attach extended electronics
2.1 Recommendations for lifting heavy meters
Heavy meters (those over 50 lb. [22 kg]), and even lighter meters that must be installed in
elevated or difficult-to-reach places, usually require additional consideration when
transporting or lifting them into their installation location.
•Safe handling during transportation and installation is the responsibility of the
installer – know and follow all safety practices and regulations for your facility and
for any lifting/rigging equipment being used
•A professional rigging crew with proper equipment should be used
•Typical equipment for handling heavy meters includes the following:
-Fixed hoist boom trucks or cranes
-Continuous web belt slings
-Eye to eye web belt slings
-Two leg wire rope slings
•Lift a meter by its case.
•Do not lift a meter by its electronics (junction box, transmitter, or any electrical
fittings) or by its purge fittings
•It may be useful to identify the meter center of gravity
•Protect the sealing surfaces on the process fittings with factory-installed flange
protectors or comparable field-installed protection
Mounting
8Micro Motion ELITE

Acceptable lifting pointsFigure 2-1:
Center of gravity for large metersFigure 2-2:
A
A. Typical center of gravity
Note
Complete and detailed dimensional drawings, including the location of the center of gravity, can be
found through the product drawings link in our online store (www.emerson.com).
Mounting
Installation Manual 9

2.2 Mount the sensor
Use your common practices to minimize torque and bending load on process connections.
Tip
To reduce the risk of condensation problems, do not orient transmitters or sensor junction boxes
with their conduit openings pointing upward.
CAUTION!
Do not lift the sensor by the electronics or purge connections. Lifting the sensor by the
electronics or purge connections can damage the device.
Mounting the sensorFigure 2-3:
Notes
•Do not use the sensor to support the piping.
•The sensor does not require external supports. The flanges will support the sensor in any
orientation. (Some sensor models installed in very small, flexible pipeline have optional installation
instructions that allow for external supports.)
Mounting
10 Micro Motion ELITE

2.3 Rotate junction box or 800 core processor
(optional)
An integrally mounted junction box or 800 core processor can be rotated to one of eight
possible positions in 45 degree increments.
Parts for rotating the junction box or 800 core processor on the sensorFigure 2-4:
A
B
C
DE
A. Housing
B. Clamping ring
C. Clamping ring screw
D. Feedthrough
E. Alignment notches
Note
The 800 core processor is shown in this figure. The junction box has a somewhat different appearance.
Procedure
1. Loosen the clamping ring screw and remove the clamping ring.
2. Gently separate the housing from the feedthrough, but only until there is sufficient
clearance from the alignment notches to rotate the housing.
3. Rotate the housing to the desired position and in line with the alignment notches.
4. Seat the housing onto the feedthrough.
5. Replace the clamping ring and tighten the clamping ring screw.
Mounting
Installation Manual 11

2.4 Mount electronics of high-temperature sensors
The electronics of high-temperature sensors are attached to the end of a 32" (812 mm)
pre-installed flexible conduit. The electronics must be separately mounted on a wall or
instrument pole.
Components of a high-temperature sensorFigure 2-5:
B
A
C
D
A. Sensor
B. Electronics
C. Mounting bracket
D. Flexible conduit (minimum bend radius 6" [152 mm])
With some large meter sizes, the meter may ship with the electronics attached to the
sensor case. The meter cannot be operated in this configuration. Detach the electronics
bracket from the sensor case and then proceed to mount the electronics to a wall or
instrument pole as described below.
Important
Do not operate the meter while the electronics are attached to the sensor case.
Mounting
12 Micro Motion ELITE

Removing electronics from the sensor caseFigure 2-6:
A
A. Detach electronics from sensor case and mount to a wall or instrument pole
Procedure
•For wall mounting, use four 5/16" or four M8 bolts to secure the mounting bracket.
Mounting
Installation Manual 13

Wall-mount componentsFigure 2-7:
A
B
C
A. Wall or flat surface
B. Electronics (enhanced core processor shown)
C. Flexible conduit
•For mounting to an instrument pole, use a 2-inch U-bolt pipe kit to secure the
mounting bracket.
Mounting
14 Micro Motion ELITE

Pole-mount componentsFigure 2-8:
A
B
C
A. Instrument pole
B. Electronics (enhanced core processor shown)
C. Flexible conduit
Mounting
Installation Manual 15

2.5 Mount a CMF010 sensor to a wall or pole
The CMF010 sensor has an optional mounting configuration for use with small or flexible
pipeline. If the pipeline adequately supports the sensor, you can skip this procedure.
1. Locate the optional mounting holes. For sensors with a junction box, the junction
box must be rotated to the side to expose the mounting holes.
Optional mountingFigure 2-9:
A
B
C
A. Two user-supplied 5/16" (M8) bolts
B. Junction box or core processor (junction box shown)
C. Mounting surface
2. If necessary, install rigid standoffs between the sensor and the mounting surface.
3. Using two user-supplied 5/16" (M8) bolts (minimum length 2 1/4" [58 mm]), secure
the sensor case to the mounting surface.
Mounting
16 Micro Motion ELITE
