Emerson AS1-FRE Series Installation instructions

1(3)
Emerson Automation Solutions | AVENTICS
cad_re-ass_as1-fre-5_v02.docx
CAD Re-assembly instructions
for our neutral CAD file formats
Product: Filter pressure regulator, Series AS1-FRE
Parts assembled: 2 (5)
Consists of following part: 5 pcs
Parts assembled: 2 (5)

2(3)
Emerson Automation Solutions | AVENTICS
cad_re-ass_as1-fre-5_v02.docx
Mate instructions, step by step for easy handling
Constraint 2(3) : Insert
Constraint 3(3) : Mate
Constraint 2(3) : Insert
Constraint 3(3) : Mate
Constraint 1(3): Mate (0.25 mm)
Constraint 2(3): Mate (0.25 mm)
Constraint 3(3): Mate
1 - Assemble Body & Pressure gauge Parts assembled: 2(5)
Constraint 1(2): Insert
Constraint 2(2): Mate
2 - Assemble Reservoir Parts assembled: 3(5)

3(3)
Emerson Automation Solutions | AVENTICS
cad_re-ass_as1-fre-5_v02.docx
Mate instructions, step by step for easy handling
Constraint 2(3) : Insert
Constraint 3(3) : Mate
Constraint 2(3) : Insert
Constraint 3(3) : Mate
Constraint 1(2): Insert
Constraint 2(2): Mate (1 mm)
3 - Assemble Drain knob Parts assembled: 4(5)
Constraint 1(3): Insert
Constraint 2(3): Mate
Constraint 3(3): Mate
4 - Assemble Protective guard Parts assembled: 5(5)
