Emerson Leroy-Somer R220 Instruction Manual

E+ E-
0V
110
R220
VOLT
OPEN FOR 60 Hz STAB
POT 1K
A.V.R.
R220
Installation and maintenance

2
2016.05 / g
Electric Power Generation Installation and maintenance
R220
A.V.R.
4291 en -
SAFETY MEASURES
Before using your machine for the rst time,
it is important to read the whole of this
installation and maintenance manual.
All necessary operations and interventions
on this machine must be performed by a
qualied technician.
Our technical support service will be pleased
to provide any additional information you
may require.
The various operations described in this
manual are accompanied by recommen-
dations or symbols to alert the user to
potential risks of accidents. It is vital that you
understand and take notice of the following
warning symbols.
Warning symbol for an operation capable
of damaging or destroying the machine
or surrounding equipment.
Warning symbol for general danger to
personnel.
Warning symbol for electrical danger to
personnel.
All servicing or repair operations
performed on the AVR should be
undertaken by personnel trained in the
commissioning, servicing and main-
tenance of electrical and mechanical
components.
When the generator is driven at a
frequency less than 28 Hz for more than
30 seconds with an analogic regulator,
the AC power must be disconnected.
WARNING
This A.V.R. can be incorporated in a
machine marked C.E.
This manual is be given to the end user.
© - We reserve the right to modify the
characteristics of its products at any time in
order to incorporate the latest technological
developments. The informa-tion contained
in this document may therefore be changed
without notice.
This document may not be reproduced in
any form without prior authorization.
All brands and models have been registered
and patents applied for.
WARNING
This manual concerns the alternator A.V.R. which you have just purchased.
We wish to draw your attention to the contents of this maintenance manual.

3
2016.05 / g
Electric Power Generation Installation and maintenance
R220
A.V.R.
4291 en -
CONTENTS
1 - SUPPLY..............................................................................................................................4
1.1 - SHUNT excitation system ............................................................................................4
2 - R220 A.V.R. ........................................................................................................................4
2.1 - Characteristics .............................................................................................................4
2.2 - R220 AVR option ..........................................................................................................4
3 - INSTALLATION - COMMISSIONING .................................................................................5
3.1 - Electrical checks on the AVR ........................................................................................5
3.2 - Settings........................................................................................................................5
3.3 - Electrical faults.............................................................................................................6
4 - SPARE PARTS...................................................................................................................7
4.1 - Designation..................................................................................................................7
4.2 - Technical support service.............................................................................................7
Disposal and recycling instructions
WARNING
The R220 AVR cannot be used in dedicated single-phase 60 Hz.
The R220 is an IP00 product. It must be installed inside a unit so that this unit’s cover can
provide IP20 minimum total protection (it must only be installed on our alternators in the
appropriate location so that when viewed externally, it has a higher degree of protection than
IP20).

4
2016.05 / g
Electric Power Generation
124 mm
85 mm
T1 T2 T3
T4 T5 T6
5+ 6-
T7 T8 T9
T10 T11 T12
E+ E-
0V
110
R220
P1
P2
ST3
VOLT
OPEN FOR 60 Hz STAB
POT 1K
ST4
50 Hz 60 Hz
Installation and maintenance
R220
A.V.R.
4291 en -
1 - SUPPLY
1.1 - SHUNT excitation system
The alternator with Shunt excitation is self-
excited with an R220 voltage regulator.
The regulator monitors the exciter excitation
current as a function of the alternator output
voltage. Very simple in design, the alternator
with shunt excitation has no sustaining
short-circuit capacity.
2 - R220 A.V.R.
2.1 - Characteristics
- Storage : -55°C ; +85°C
- Operation : -40°C ; +65°C
- Voltage regulation: ± 0.5%.
- Voltage supply/sensing range 85 to 139 V
(50/60 Hz)
- Rapid response time (500 ms) for a
transient voltage variation amplitude of ± 20%
- Voltage setting P1
- Stability setting P2.
- Power supply protected by 8 A fuse, slow-
blow action (tolerates 10 A for 10 s)
The fuse is impregnated in the resin,
therefore it can not be replaced.
- Frequency: 50 Hz with ST3 jumper - 60 Hz
without ST3 jumper.
- The size of the screwdriver tip used to
adjust the potentiometer is 2.5 mm.
2.2 - R220 AVR option
Potentiometer for remote voltage
adjustment, 1000 Ω/ 0.5 W min: adjustment
range ± 5%.
- Remove the ST4 jumper.
For wiring up the external potentiometer;
the “earth” wires must be isolated as
well as the potentiometer terminals
(wires at the same voltage as the power).
SHUNT SYSTEM
MAIN FIELD STATOR : 12 wires (marked T1 to T12)
Armature
Field
Voltage
Option
Stability
Frequency
Potentiometer for remote
voltage adjustment
Varistor
2 x holes Ø 5.8 x 109 mm

5
2016.05 / g
Electric Power Generation Installation and maintenance
R220
A.V.R.
4291 en -
3 - INSTALLATION -
COMMISSIONING
3.1 - Electrical checks on the AVR
- Check that all connections have been
made properly as shown in the attached
wiring diagram.
- Check that the ST3 frequency selection
jumper is on the correct frequency setting.
- Check whether the ST4 jumper or the
remote adjustment potentiometer have
been connected.
3.2 - Settings
The machine is tested and set at the
factory. When rst used with no load,
make sure that the drive speed is correct
and stable (see the nameplate). After
operational testing, replace all access
panels or covers.
The only possible adjustments to the
machine should be made on the AVR.
3.2.1 - R220 setting (shunt system)
Initial potentiometer settings
- P1 potentiometer (AVR voltage
adjustment): fully anti-clockwise.
- Remote voltage adjustment potentiometer:
centre position.
Run the alternator at its rated speed. If the
voltage does not increase, the magnetic
circuit should be remagnetized (see section
3.3).
- Turn the AVR voltage adjustment
potentiometer P1 slowly until the output
voltage rated value is obtained.
- Adjust the stability setting using P2.
Clockwise: increase the rapidity.
Anti-clockwise: decrease the rapidity.
3.2.2 - Special type of use
Excitation circuit E+, E- must not be left
open when the machine is running : AVR
damage will occur.
3.2.2.1 - R220 eld weakening (SHUNT)
The exciter is switched off by disconnecting
the AVR power supply (1 wire - 0 or 110V).
Contact rating : 16A - 250V alt.
The power supply contactor must only be
closed when the alternator is not being
driven
3.2.2.2 - R220 eld forcing
Battery must be isolated from the earth.
Exciter eld may be at line potential.
WARNING
E+ E-
0V
110
VOLT POT 1K
Battery (B Volt)
+
-
t
(400V - 10A) Diode
E+ E-
0V
110
Exciter field

6
2016.05 / g
Electric Power Generation Installation and maintenance
R220
A.V.R.
4291 en -
3.3 - Electrical faults
Fault Action Effect Check/Cause
No voltage at
no load on
start-up
Connect a new battery
of 4 to 12 volts to
terminals E- and E+,
respecting the polarity,
for 2 to 3 seconds
The alternator builds up and its
voltage is still correct when the
battery is removed.
- Lack of residual magnetism
The alternator builds up but its
voltage does not reach the rated
value when the battery is
removed.
- Check the connection of the voltage
reference to the AVR
- Faulty diodes
- Armature short-circuit
The alternator builds up but its
voltage disappears when the
battery is removed
- Faulty AVR
- Field windings disconnected
- Main eld winding open circuit - check the
resistance
Voltage too
low
Check the drive speed
Correct speed
Check the AVR connections (AVR may be
faulty)
- Field windings short-circuited
- Rotating diodes burnt out
- Main eld winding short-circuited - Check
the resistance
Speed too low
Increase the drive speed
(Do not touch the AVR voltage pot. (P2)
before running at the correct speed)
Voltage too
high
Adjust AVR voltage
potentiometer
Adjustment ineffective Faulty AVR
Voltage
oscillations
Adjust AVR stability
potentiometer
- Check the speed : possibility of cyclic
irregularity
- Loose connections
- Faulty AVR
- Speed too low when on load (or U/F bend
set too high)
Voltage
correct at no
load and too
low when on
load (*)
Run at no load and
check the voltage
between E+ and E- on
the AVR
- Check the speed (or U/F bend set too
high)
- Faulty rotating diodes
- Short-circuit in the main eld. Check the
resistance
- Faulty exciter armature.
(*) Caution : For single-phase operation, check that the sensing wires coming from the AVR are correctly connected to the
operating terminals
Voltage
disappears
during
operation
Check the AVR, the
surge suppressor, the
rotating diodes, and
replace any defective
components
The voltage does not return to the
rated value.
- Exciter winding open circuit
- Faulty exciter armature
- Faulty AVR
- Main eld open circuit or short-circuited
Warning : after operational testing, replace all access panels or covers.

7
2016.05 / g
Electric Power Generation Installation and maintenance
R220
A.V.R.
4291 en -
4 - SPARE PARTS
4.1 - Designation
Description Type Code
A.V.R. R220 AEM 110 RE 028
4.2 - Technical support service
Our technical support service will be happy
to provide any information you require.
When ordering spare parts, you should in-
dicate the complete machine type, its serial
number and the information indicated on the
nameplate.
Part numbers should be identied from the
exploded views and their description in
the parts list.
Our extensive network of «service stations»
can dispatch the necessary parts without
delay.
To ensure correct operation and the safety
of our alternators, we recommend the use of
original manufacture spare parts.
In the event of failure to comply with this ad-
vice, the manufacturer cannot be held res-
ponsible for any damage.

8
2016.05 / g
Electric Power Generation Installation and maintenance
R220
A.V.R.
4291 en -
Disposal and recycling instructions
We are committed to limit the environmental
impact of our activity. We continuously
survey our production processes, material
sourcing and products design to improve
recyclability and diminish our footprint.
These instructions are for information
purposes only. It is the user responsibility to
comply with local legislation regarding
product disposal and recycling.
Recyclable materials
Our alternators are mainly built out of iron,
steel and copper materials, which can be
reclaimed for recycling purposes.
These materials can be reclaimed through a
combination of manual dismantling,
mechanical separation and melting
processes. Our technical support depar-
tment can provide detailed directions on
products dismounting upon request.
Waste & hazardous materials
The following components and materials
need a special treatment and need to be
separated from the alternator before the
recycling process:
- electronic materials found in the terminal
box, including the Automatic Voltage
Regulator (198), Current Transformers
(176), interference suppression module
(199) and other semi-conductors.
- diode Bridge (343) and Surge suppressor
(347), found on the alternator rotor.
- major plastic components, such as the
terminal box structure on some products.
These components are usually marked with
plastic type information.
All materials listed above need special
treatment to separate waste from
reclaimable material and should be handed
to specialized disposal companies.
The oil and grease from the lubrication
systemshouldbeconsideredasahazardous
waste and has to be handled according to
local legislation.

9
2016.05 / g
Electric Power Generation Installation and maintenance
R220
A.V.R.
4291 en -

10
2016.05 / g
Electric Power Generation Installation and maintenance
R220
A.V.R.
4291 en -

Conception
Life Extension
Optimization
Start-up
Operation
•Consulting & specification
•Maintenance
contracts
•Remanufacturing
•System upgrade
•Monitoring
•System audit
•Commissioning
•Training
•Genuine spare parts
•Repair services
Our worldwide service network of over 80 facilities is at your service.
This local presence is our guarantee for fast and efcient repair, support and
maintenance services.
Trust your alternator maintenance and support to electric power generation experts.
Our eld personnel are 100% qualied and fully trained to operate in all environments
and on all machine types.
We know alternators operation inside out, providing the best value service to
optimize your cost of ownership.
Where we can help:
Contact us:
Americas: [phone]
Europe & International: [phone]
Asia Pacific: [phone]
China: [phone]
India: [phone]
[e-mail]
Scan the code or go to:
www.lrsm.co/support
Service & Support

www.emersonindustrial.comwww.emerson.com/epg
- 2016.05 / g4291 en
