Emerson Fisher easy-Drive 200L User manual

www.Fisher.com
Fisher™easy-Drive™200L
Contents
Introduction 1.................................
Scope of Manual 1.............................
Description 1.................................
Specifications 3...............................
Educational Services 3.........................
Installation 3..................................
Special Instructions for “Safe Use” and Installations
in Hazardous Locations 4.....................
Actuator Mounting 4..........................
Startup Overview 6............................
Configuration 11..............................
Control Method Configuration 11............
Modbus Setup 11.............................
Connecting using the Fisher easy-Drive
configuration software 12................
Initial Setup 13............................
Calibration Instructions 13..................
Operational Verification 15..................
Troubleshooting 17.............................
Maintenance 18................................
Disassembly 18................................
Parts Ordering 21...............................
Parts Kits 21...................................
Parts List 21...................................
Appendix A - Modbus 23.........................
Appendix B - Certificate of Conformance 29.........
Figure 1. Fisher easy-Drive 200L
X1520-1
Introduction
Scope of Manual
If the actuator has a RPU-100 installed refer to easy-Drive RPU-100 Instruction Manual (D104551X012).
This instruction manual provides installation, maintenance, and parts information for the easy-Drive
200L. Do not install, operate, or maintain an easy-Drive 200L without being fully trained and qualified in
valve, actuator, and accessory installation, operation, and maintenance. To avoid personal injury or
property damage, it is important to carefully read, understand, and follow all the contents of this
manual, including all safety cautions and warnings. If you have any questions about these instructions,
contact your Emerson sales office before proceeding.
Description
The easy-Drive 200L is a compact, rugged electric actuator designed primarily for high‐pressure throttling
applications. This actuator is ideal for use on pressure and flow control applications.
Instruction Manual
D104331X012
easy-Drive 200L
May 2023

Instruction Manual
D104331X012
easy-Drive 200L
May 2023
2
Table 1. Specifications
Available Actuator Configurations
Positioning
Power Requirements
11-30 VDC, minimum 4 amp power supply required
(fuse to 5 amps)
Material Temperature Capabilities
Electric Actuator Assembly:
-20C (-4F) to 70C (158F)
Maximum Current Draw
4 amps
Idle Current Draw
15 mA at 24 VDC, 25 mA at 12 VDC
Conduit Connections
Two 3/4 NPT connections
Maximum Stroke Length
19 mm (0.75 inch)
Maximum Thrust
3336 N (750 lbf)
Average Thrust
2446 N (550 lbf)
Nominal Stroke Speed(1)
3.9 mm/s (0.15 inch/s) at 24 VDC
2.2 mm/s (0.09 inch/s) at 12 VDC
Hazardous Area Approvals
CSA (C/US): ExplosionProof Class I, Division 1,
Groups C and D, T6, Ex db IIA T6, Class I, Zone 1,
AEx db IIA T6
ATEX Flameproof - Gas:
II 2 G, Ex db IIA T6 Gb
IECEx Flameproof - Gas: Ex db IIA T6 Gb
Enclosure Rating
Type 4X and IP66
Duty Cycle
50% maximum
Enclosure Material
Cast aluminum alloy with powder coat paint
Approximate Weight
9.5 kg (21 lbs)
1. 10% variation can be expected, based on temperature and pressure of application.

Instruction Manual
D104331X012
easy-Drive 200L
May 2023
3
Specifications
Table 1 lists specifications for the easy-Drive 200L. Some of the specifications for a given actuator as it originally comes
from the factory are stamped on a nameplate located on the lower actuator enclosure.
Educational Services
Emerson Educational Services
Phone: [phone]
E-mail: [email protected]
emerson.com/mytraining
Installation
WARNING
Always wear protective gloves, clothing, and eyewear when performing any installation operations to avoid personal
injury.
To avoid personal injury or property damage caused by bursting of pressure‐retaining parts or by uncontrolled process
fluid, be certain the service conditions do not exceed the limits shown on the valve nameplate and in table 1. Use
pressure‐relieving devices required by government or accepted industry codes and good engineering practices.
Check with your process or safety engineer for any additional measures that must be taken to protect against process
media.
If installing into an existing application, also refer to the WARNING at the beginning of the Maintenance section in this
instruction manual.
WARNING
For explosionproof applications, ensure the actuator cover is properly bolted before applying power to the actuator.
Personal injury or property damage may result from fire or explosion if power is applied to the actuator with the cover
removed in a hazardous area.
For explosion‐proof applications, install rigid metal conduit and a conduit seal no more than 457 mm (18 in) from the
actuator. Personal injury or property damage may result from explosion if the seal is not installed.
Select wiring and/or cable glands that are rated for the environment of use (such as hazardous area, ingress protection, and
temperature). Failure to use properly rated wiring and/or cable glands can result in personal injury or property damage
from fire or explosion.
Wiring connections must be in accordance with local, regional, and national codes for any given hazardous area approval.
Failure to follow the local, regional, and national codes could result in personal injury or property damage from fire or
explosion.
WARNING
Avoid personal injury or property damage caused by possible actuator failure. The use of a rigidly‐mounted support on the
actuator casing may cause additional stress on the actuator leading to premature wear and/or failure of the actuator
components.

Instruction Manual
D104331X012
easy-Drive 200L
May 2023
4
1. The easy-Drive 200L can be installed in any position, but normally the actuator is vertical above the valve. Install the
valve per the manufactuer's guidelines and per any applicable local, regional, and national piping codes.
2. For explosion-proof applications, install rigid metal conduit and seal no more than 457 mm (18 in) from the
actuator.
3. Unused conduit ports must be sealed with an explosion-proof port plug.
Note
Plastic conduit ports provided by factory are to be removed prior to operation and replaced with an explosion-proof port plug.
Special Instructions for “Safe Use” and Installations in Hazardous
Locations
WARNING
To avoid static discharge from the enclosure, do not rub or clean the enclosure with solvents. To do so could result in an
explosion. Clean with a mild detergent and water only.
The enclosure is nonconducting and may generate an ignitioncapable level of electrostatic charges under certain extreme
conditions. The user should ensure that the equipment is not installed in a location where it may be subjected to external
conditions (such as highpressure steam) which might cause a buildup of electrostatic charges on nonconducting surfaces.
Additionally, cleaning of the equipment shall only be done with a damp cloth.
To avoid damage to the enclosure, when screws are fully tightened into blind holes in enclosure walls, with no washer
fitted, at least one full thread shall remain free at the base of the hole.
Actuator Mounting
The following procedure describes how to mount an easy-Drive 200L actuator.
The actuator is shipped with the stem in the ideal coupling position; 6% off the lower actuator stop.
Note
Do not stroke the actuator prior to coupling the unit to the valve.
To reposition the actuator to the ideal coupling position calibrate the actuator as valve type “Stop-to-Stop”. Ensure the actuator is
able to travel making contact with its internal stops. Once calibration is complete command the valve to 6% open.
User designed and manufactured Mounting Kit and Stem Coupler will be needed to complete this procedure.
WARNING
To avoid personal injury or property damage, keep hands and tools out of the actuator stem travel path when moving the
actuator stem in the following steps.

Instruction Manual
D104331X012
easy-Drive 200L
May 2023
5
1. Supply a method of supporting the weight of the valve and actuator during assembly.
2. Push the valve stem down away from the actuator to the closed position for push down to close valves.
3. Mount the easy-Drive 200L to the mounting kit designed and supplied by the user.
a. Utilizing the wrench flats on the actuator yoke tighten the actuator yoke locknut to 205 NSm (151lbSft).
4. Lift or hoist the actuator and mounting assembly onto the valve and mate the mounting kit securely to the valve
following the valve manufacturer's guidelines.
Note
The valve stem must be fully in the down position.
5. Make the stem connection between the actuator and valve stems.
a. When installing the user-supplied stem connector the actuator stem’s threads should engage the threads of the
stem connector by a distance equal to or greater than the diameter of the actuator stem.
NOTICE
Incomplete engagement of the actuator stem in the stem connector can result in stripped threads or improper operation.
Be sure that the length of each stem clamped in the stem connector is equal to or greater than one diameter of that stem.
Damage to threads on either stem or in the stem connector can cause the parts to be replaced prematurely. Do not attempt
to remove the stem connector when force is applied to the stem.
6. Configure the actuator to the appropriate mode using the easy-Drive configurator tool. See Valve Type
Configuration section of this manual.
7. Calibrate the actuator. See Calibration Instructions section of this manual.

Instruction Manual
D104331X012
easy-Drive 200L
May 2023
6
Startup Overview
Figure 2. Flowchart
PREPARE PER INSTRUCTIONS
IN INSTALLATION SECTION
POSITIONING OR
ON/OFF?
POSITIONING
ON/OFF
WIRE PER DIAGRAM FOR ON/OFF WIRE PER DIAGRAM FOR 4-20 mA
YES
NO
FIRST TIME USING
Modbus?
CONNECT USB-TO-Modbus CONVERTER
TO INTERNET CONNECTED COMPUTER
CONNECT VIA Modbus TO VALVE AND
CONFIGURED REGISTERS
FOLLOW DRIVER INSTALLATION
INSTRUCTIONS FOR YOUR DEVICE
INSTALL easy-Drive CONFIGURATION OR
Modbus MASTER SOFTWARE
UNIT IS READY FOR OPERATION

Instruction Manual
D104331X012
easy-Drive 200L
May 2023
7
Figure 3. Fisher easy-Drive 200L Wiring Diagram
FIELD WIRING CONNECTIONS
MOTOR / GEARBOX ASSY
GEN 2 CONTROLLER
GE47302-7 TOP VIEW CONTROLLER
POWER AND
CONTROL TERMINAL
Power Requirements
Ensure a stable DC power source is available, maintaining less than 5% ripple and sufficiently surge protected for the
application. A 4 amp (minimum) power supply is required.
Wiring Instructions
1. Observe local wiring requirements for hazardous location usage.
2. Conduit seals within 450 mm (18 inches) of the enclosure port are required for explosionproof installation.
3. 18 AWG (0.52 mm2) to 12 AWG (3.31 mm2) wire size required.
4. Fuse system to 5A.
5. Connect enclosure and analog signal shields.
6. Ensure power is turned off before connecting the wires.
Power
1. Connect 12 or 24 VDC reference to: –
2. Connect 12 or 24 VDC positive to: +
3. Be sure to tighten terminals sufficiently to ensure solid mechanical connection.

Instruction Manual
D104331X012
easy-Drive 200L
May 2023
8
Figure 4. Wiring - Analog Input
Figure 5. Wiring - Dual Dry Contact

Instruction Manual
D104331X012
easy-Drive 200L
May 2023
9
Figure 6. Wiring - Single Dry Contact
Figure 7. Wiring - Modbus Input

Instruction Manual
D104331X012
easy-Drive 200L
May 2023
10
Figure 8. Wiring - Auxiliary Digital I/O set to input (40080=0)
Figure 9. Wiring - Auxiliary Digital I/O set to output (40080=1)
10 V, 25 mA max

Instruction Manual
D104331X012
easy-Drive 200L
May 2023
11
Configuration
The easy-Drive 200L must be configured prior to operation.
All configuration within the actuator is done by setting values in Modbus registers. Configuration software, providing a
visual interface to the registers, is available through your Emerson sales office or at www.fisher.com/easydrive. Control
and monitoring can be done using any Modbus master (flow computer, PLC, PC).
See Appendix A for a full map of Modbus registers and their functions.
Control Method Configuration
There are two functional configurations available for the easyDrive electric actuator: On/Off and Positioning.
All available input signals are shown in table 2.
Table 2. All Available Input Signals
CONFIGURATION ON/OFF POSITIONING
Control Source Modbus Local Modbus Local
Input Signal Modbus Dual Dry Contact Single Dry Contact Modbus 4-20 mA (default)
Modbus setup
Use of a serial or USB to RS-485 device is required to connect to the actuator. Refer to manufacturer's requirements for
installation. The easyDrive 200L Modbus factory defaults are Address 1, 9600 baud, even parity, 1 stop bit, MSB.
When a connection has been achieved, the actuator may be configured as required for the application.
Figure 10. Fisher easy-Drive Configuration Software

Instruction Manual
D104331X012
easy-Drive 200L
May 2023
12
Connecting using the Fisher easyDrive configuration software
The Fisher easyDrive configuration software allows configuration and diagnosing of the Fisher easyDrive electric
actuator with a graphical interface. Connect a PC to the actuator using a USB or serial device to RS-485 converter using
the wiring instructions above. The USB or serial device will be visible in the drop menu under Serial Port Settings. Baud
rate and parity should be set to the Modbus settings of the actuator. Default actuator settings are address 1, 9600
baud, even parity, 1 stop bit, MSB. Press the AUTO button in the upper left corner to connect to the valve.
Use the Fisher easyDrive configuration software (figure 10) to make the desired changes, or register values may be
changed to allow different functionality.
Valve Type Configuration
D Valve Type
H 0.5” Fixed
H 0.62” Fixed
H 0.75” Fixed
H Stop-to-Stop
Figure 11. Fisher easy-Drive Configuration Software
Fixed travel settings will set the fixed travel from the valve seat (push down to close) up, i.e., 0.50” Fixed, will set the
full range of travel at 0.5 inches from the seat.
Stop-to-stop setting will set the travel using hard stops that define the full range (max 0.75 inches).

Instruction Manual
D104331X012
easy-Drive 200L
May 2023
13
Initial Setup
The control method selection determines the control signal to which the valve will respond. Only the control signal
selected will result in movement of the valve; all others will be ignored.
D Control Methods
H Dual Contact On/Off
H Single Contact On/Off
H Modbus On/Off
H Modbus Positioning
H 4-20mA Positioning
H 4-20mA Level
When using the easy-Drive Configuration Tool, clicking on the “Control Method” box will create a drop down menu as
shown. Select the desired control source; the selection will turn yellow. A box with Pending Changes will appear
showing all changes. Press “APPLY” to confirm the change(s).
Figure 12. Fisher easy-Drive Configuration Software
Calibration Instructions
WARNING
To avoid personal injury or property damage, be aware that the valve will move during the calibration cycle.
Span Calibration
It will be necessary to perform a span calibration. A span calibration is accomplished by the following method:

Instruction Manual
D104331X012
easy-Drive 200L
May 2023
14
1. Ensure the process and valve are in a safe state – the valve may move during this operation.
2. Press the “CALIBRATE SPAN” button to initiate the span calibration. The software will show a progress bar during
the calibration and display “Valve Span Calibrated” when complete.
Note
Should actual travel not equal the expected travel you will receive a span calibration failure alert. See figure 13. Ensure valve type is
selected correctly. It may be necessary to re-couple the valve actuator assembly.
Figure 13. Fisher easy-Drive Configuration Software
Span Calibration without the use of Modbus
1. Turn power to the actuator off.
2. Wait for 10 seconds to ensure all circuits have discharged.
3. Return power to the actuator and use the appropriate calibration method for your control signal. Calibration
sequence must be done within 15 seconds of power being switched on.
4. For positioning operation using 420 mA:
a. Apply a 4 mA signal between pins 4-20 mA - and 4-20 mA +. If Span is currently uncalibrated, valve plug will not
move at this time.
b. Apply a 20 mA signal between pins 4-20 mA - and 4-20 mA +. If Span is currently uncalibrated, valve plug will not
move at this time.
c. Apply a 4 mA signal between pins 4-20 mA - and 4-20 mA + – valve plug will move to the upper stop, immediately
followed by moving to the lower, closed position.
d. If calibration of the analog input is desired to improve positional accuracy, an optional operation is listed in the
next section titled Analog Input Calibration.
5. For On/Off operation using dualinput dry contact:
a. Close the contact to create a short between pins COMMON and CLOSE. If Span is currently uncalibrated, valve
plug will not move at this time.
b. Close the contact to create a short between pins COMMON and OPEN. If Span is currently uncalibrated, valve
plug will not move at this time.
c. Close the contact to create a short between pins COMMON and CLOSE – valve plug will move to the upper, open
position and then to the lower, closed position.

Instruction Manual
D104331X012
easy-Drive 200L
May 2023
15
6. For On/Off operation using single dry contact:
a. Open the contact to create an open circuit between pins COMMON and OPEN. If Span is currently uncalibrated,
valve plug will not move at this time.
b. Close the contact to create a short between pins COMMON and OPEN. If Span is currently uncalibrated, valve
plug will not move at this time.
c. Open the contact to create an open circuit between pins COMMON and OPEN – valve plug will move to the
upper, open position and then to the lower, closed position.
7. The unit is now calibrated.
Analog Input Calibration
For valves using 4-20 mA as a control source, several options are available to customize control of the actuator. Use a
4-20 mA signal generator to provide the desired signal. It is possible to calibrate the 4-20 mA signal in reverse acting or
split-ranging with the method below with at least 4 mA of signal difference between the close and open values. The
example shows a valve being changed from normal to reverse acting during the calibration process.
1. With the Control Method set to 4-20 Positioning or 4-20 mA Level, enter the Calibration screen and the 4-20 mA
Signal Calibration window will be visible.
2. Click the CALIBRATE CLOSE & OPEN VALUES button. A separate window will open to guide through the process.
3. Set the 4-20 mA signal to the desired value for when the valve is to be closed.
4. Enter this value into the Calibrated mA Signal text box and press Next.
Figure 14. Fisher easy-Drive Configuration Software
5. Set the 4-20 mA signal to the desired value for when the valve is to be open.
6. Enter this value into the Commanded mA Signal text box and press Next.

Instruction Manual
D104331X012
easy-Drive 200L
May 2023
16
Figure 15. Fisher easy-Drive Configuration Software
7. If the Close and Open values are as expected, press Confirm to accept these values. If not, press Cancel to restart
the process.
Note
The value of the 4-20 mA signal must have at least 4 mA difference between the close and open signals. A differential less than
that amount will cause the actuator to reject the calibration and use the previous values.
Should the entered values vary more than 10% from the expected 4-20 mA values; the actuator will accept the calibration and a
Notification displaying “Questionable Analog Calibration” will result.
Figure 16. Fisher easy-Drive Configuration Software
Operational Verification
WARNING
To avoid personal injury or property damage, be aware that the valve will move and respond to an input signal during start
up.

Instruction Manual
D104331X012
easy-Drive 200L
May 2023
17
1. Before turning on power to the unit, be sure that a closed signal is being commanded to the unit.
D Single DryContact: contact is open.
D Dual Dry Contact: Contact closed across pins COMMON and CLOSE.
D Analog Input: signal = 4 mA.
D Modbus: position demand = 0.
2. Turn on power to the unit.
3. Apply a change in position demand to ensure unit responds properly.
D Single DryContact:
H Closed contact between pins COMMON and OPEN will open the valve.
H Dual dry contact: Closed contact between pins COMMON and OPEN will open the valve. Closed contact
between pins COMMON and CLOSE will close the valve.
D Analog Input: valve will respond to proportional demand.
D Modbus: valve will respond to positional demand in register 40001. 0 = fully closed and 1000 = fully open.
4. If the valve does not respond as expected, proceed to Troubleshooting guide on page 17.
5. Check conduit ports
D Conduit seal must be in place within 450 mm (18 in) of the enclosure.
D Unused conduit ports must be sealed with an explosion-proof port plug.
6. Replace the cover and tighten all 8 bolts to 20 Nm (15 ftlbs).
Troubleshooting
1. Unit does not move.
a. Green heartbeat LED will pulse near Modbus terminals when power is present. Verify the 12VDC to 24VDC is
present on the power terminals as shown on the cover.
b. Verify all wires are firmly attached on both ends.
c. Verify the wires are connected to the correct terminals - see Wiring in the manual.
d. Verify the configured control method matches control signal.
2. Unit does not respond to 420 mA signal
a. Green heartbeat LED will pulse near Modbus terminals when power is present. Verify the 12VDC to 24VDC is
present on the power terminals as shown on the cover.
b. Verify all wires are firmly attached on both ends.
c. Verify the wires are connected to the correct terminals - see Wiring in the manual.
d. Verify the configured control method matches control signal.

Instruction Manual
D104331X012
easy-Drive 200L
May 2023
18
e. Check the value of the analog input in register 40026 If this register shows 0, the 4-20 mA may be wired
backwards. Swap wire and attempt again.
3. Diagnostics show a Motor Stall - Travel Deviation Fault.
a. If the actuator can not move to its commanded position, the actuator will stop, without damage, and issue a
Motor Stall - Travel Deviation Fault warning. When the command signal changes outside of the deadband
(Modbus register 40053), it will attempt to move again.
Maintenance
The frequency of inspection and maintenance depends on the severity of the service conditions.
WARNING
Avoid personal injury from sudden release of process pressure or bursting of parts. Before performing any maintenance
operations:
D Do not remove the actuator from the valve while the valve is still pressurized.
D Always wear protective gloves, clothing, and eyewear when performing any maintenance operations to avoid personal
injury.
D Disconnect any operating lines providing air pressure, electric power, or a control signal to the actuator. Be sure the
actuator cannot suddenly open or close the valve.
D Use bypass valves or completely shut off the process to isolate the valve from process pressure. Relieve process pressure
on both sides of the valve. Drain the process media from both sides of the valve.
D Back plug away from seat to relieve spring compression.
D Use lock‐out procedures to be sure that the above measures stay in effect while you work on the equipment.
D Check with your process or safety engineer for any additional measures that must be taken to protect against process
media.
WARNING
For explosionproof applications, ensure the actuator cover is properly bolted before applying power to the actuator.
Personal injury or property damage may result from fire or explosion if power is applied to the actuator with the cover
removed in a hazardous area.
For explosion‐proof applications, install rigid metal conduit and a conduit seal no more than 457 mm (18 in) from the
actuator. Personal injury or property damage may result from explosion if the seal is not installed.
Select wiring and/or cable glands that are rated for the environment of use (such as hazardous area, ingress protection, and
temperature). Failure to use properly rated wiring and/or cable glands can result in personal injury or property damage
from fire or explosion.
Wiring connections must be in accordance with local, regional, and national codes for any given hazardous area approval.
Failure to follow the local, regional, and national codes could result in personal injury or property damage from fire or
explosion.
Disassembly
1. Follow valve manufactur's warnings and instructions for isolating and releasing line pressure prior to disassembling
the valve.

Instruction Manual
D104331X012
easy-Drive 200L
May 2023
19
2. Move the actuator off the seat before disassembling the valve and actuator.
NOTICE
The following steps are intended to prevent damage to the valve during the removal of the yoke and actuator.
3. For Positioning Actuators
•Command the valve to anywhere between 10% and 20% travel.
•Disconnect power and signal.
•Proceed to step 4.
For On/Off Actuators
•Command the valve to open or close, and cut the power when the valve is at midstroke.
•Disconnect power and signal.
•Proceed to step 4.
4. Remove actuator and mounting kit from the valve body.
Assembly
1. Connect actuator and mounting kit to valve body.
2. Replace the top of the explosion proof enclosure (key 60) and tighten cap screws (key 64) to 20 N•m (15 lbf•ft).

Instruction Manual
D104331X012
easy-Drive 200L
May 2023
20
Figure 17. Fisher easy-Drive 200L Actuator Exploded View
APPLY LUB
GE94736-A
