Emerson CAMDEN CF3600AP User manual

Part No. F40BP73840000 Form No. BP7384
Model No.: CF3600
READ AND SAVE THESE INSTRUCTIONS
Net Weight: 15.9 Lbs.
CAMDEN™
52” Damp Location
Ceiling Fan
Owner's Manual
CF3600AP
Antique Pewter
CF3600ORH
Oil Rubbed Bronze
with Highlights
Model Numbers
BP7384 Camden, CF3600 3/12/09 12:37 PM Page 1

WARNING: To avoid fire, shock, and serious personal injury, follow these
instructions.
Safety Instructions
1. Read your owner’s manual carefully and keep it for future reference.
2. Before servicing or cleaning unit, switch power off at service panel and lock service
panel disconnecting means to prevent power from being switched on accidentally.
When the service disconnecting means cannot be locked, securely fasten a
warning device, such as a tag, to the service panel.
3. Be careful of the fan and blades when cleaning, painting, or working near the fan.
Always turn off the power to the ceiling fan before servicing.
4. Do not put anything into the fan blades while they are turning.
5. Do not operate reversing switch until fan blades have come to a complete stop.
Additional Safety Instructions for Installation
1. To avoid possible shock, be sure electricity is turned off at the fuse box before
wiring, and do not operate fan without blades.
2. The installation is to be in accordance with the National Electrical Code, ANSI/NFPA
70-1999 and Local Codes. Use the National Electrical Code if Local Codes do not
exist. The ceiling fan must be grounded as a precaution against possible electrical
shock. Electrical installation should be made or approved by a licensed electrician.
3. The outlet box and joist must be securely mounted and capable of reliably
supporting at least 50 pounds. Use only U.L. outlet boxes listed as “Acceptable for
Fan Support”, and use the mounting screws provided with the outlet box. Most
outlet boxes commonly used for support of light fixtures are not
acceptable for fan support and may need to be replaced. Consult a qualified
electrician if in doubt.
4. The downrod furnished with the fan provides the minimum recommended floor to
fan blade clearance for an 8 foot ceiling.
5. The fan must be mounted with the fan blades at least 7 feet from the floor to prevent
accidental contact with the fan blades.
6. Follow the recommended instructions for the proper method of wiring your ceiling
fan. If you do not know enough about electrical wiring, have your fan installed by a
licensed electrician.
NOTE: This fan is suitable for use with solid-state speed controls.
WARNING: This product is designed to use only those parts supplied with this
product and/or any accessories designated specifically for use with this product by
Emerson Electric Co. Substitution of parts or accessories not designated for use with
this product by Emerson Electric Co. could result in personal injury or
property damage.
WARNING: To reduce the risk of personal injury, do not bend the blade flange when
installing the blade flanges, balancing the blades or cleaning the fan. Do not insert
foreign objects in between rotating fan blades.
!WARNING
DATE CODE:
The date code of this fan may be found on the box, stamped in ink on a white label.
You should record this data above and keep it in a safe place for future use.
2Model No.: CF3600
BP7384 Camden, CF3600 3/12/09 12:37 PM Page 2

3
THIS FAN IS SUITABLE FOR DAMP LOCATIONS
SUCH AS COVERED PORCHES, COVERED PATIOS, AND COVERED
DECKS...ANYWHERE THERE IS A ROOF OVERHEAD.
This Manual is Designed to Make it as Easy as Possible for You to
Assemble, Install, Operate and Maintain Your Ceiling Fan
Do not install or use fan if any part is
damaged or missing. Call Toll-Free:
1-800-654-3545
!WARNING
This product is designed to use only
those parts supplied with this product
and/or any accessories designated
specifically for use with this product by
Emerson Electric Co. Substitution of
parts or accessories not designated for
use with this product by Emerson Electric
Co. could result in personal injury or
property damage.
!WARNING
Tools Needed for Assembly
One Phillips head screwdriver
One wire stripper
One stepladder
Materials
Wiring, outlet box and box connectors
must be of type required by the local code.
The minimum wire shall be a 3-conductor
(2-wire with ground) of the following sizes:
Installed Wire Length Wire Size A.W.G.
Up to 50 ft. 14
50-100 ft. 12
Before assembling your ceiling fan, refer
to section on proper method of wiring
your fan (Page 9). If you feel you do not
have enough wiring knowledge or
experience, have your fan installed by a
licensed electrician.
!WARNING
Unpacking Instructions
For your convenience, check-off boxes are provided next to each step. As each
step is completed, place a check mark in the box. This will insure that all steps
have been completed and will be helpful in finding your place should you be
interrupted.
NOTE: If you are uncertain of part
description, refer to exploded view
illustration.
a. Fan motor assembly
b. One motor cover
c. One coupling cover
d. One ceiling cover
e. One switch adapter plate
f. Four blade flanges
g. Four blade medallions
h. One switch cover plate
i. One hanger bracket
j. One hanger ball/downrod assembly
k. One loose parts bag containing:
1. One clevis pin
2. One hairpin clip
3. Two #8-32 x 1-1/4” threaded studs
4. Two #8 external tooth lockwashers
5. Two #8-32 knurled knobs
6. Thirteen #10-32 x 3/4” oval head
blade screws
7. Five wire connectors
8. One 3/16” hex wrench
9. One chain coupler
10. One chain pendant
11. Nine #8-32 x 5/8” flat head
flange screw
12. One 5/16-18 x 1/4” setscrew
13. Three #8-32 x 1/4” flat head screws
14. One pendant
1. Open carton containing fan. Remove
top half of styrofoam unit. Remove
parts, placing all carton contents on a
soft protective surface to prevent
scratching the painted or plated
finishes, and check to see that you
have received the following parts:
Model No.: CF3600
BP7384 Camden, CF3600 3/12/09 12:37 PM Page 3

4
2. Remove and discard the two cardboard
shipping retainers securing the motor
hub in the motor housing assembly.
3. Remove the fan motor assembly from
the protective plastic bag. Place all
carton contents on a protective
surface.
4. Position the fan motor assembly, with
the motor hub facing up, carefully on
the styrofoam for blade assembly.
A. FAN MOTOR
ASSEMBLY
I. HANGER
BRACKET K. LOOSE
PARTS BAG
C. COUPLING
COVER
D. CEILING
COVER
B. MOTOR
COVER
J. HANGER BALL/
DOWNROD ASSEMBLY
H. SWITCH COVER
PLATE
G. BLADE MEDALLION (4)
F. BLADE FLANGE (4)
E. SWITCH
ADAPTER PLATE
NOTE: Place the parts from the loose
parts bags in a small container to keep
them from being lost.
IMPORTANT
IMPORTANT
PROTECTIVE
PLASTIC BAG
CARDBOARD
SHIPPING
RETAINER (2)
Model No.: CF3600
BP7384 Camden, CF3600 3/12/09 12:37 PM Page 4

5
Your new ceiling fan will require a
grounded electrical supply line of 120 volts
AC, 60 Hz, 15 amp circuit.
The outlet box must be securely anchored
and capable of withstanding a load of at
least 50 pounds.
To reduce the risk of fire, electric shock,
or personal injury, mount fan to outlet box
marked “Acceptable for Fan Support”,
and use screws supplied with outlet box.
Most outlet boxes commonly used for
support of light fixtures are not
acceptable for fan support and may need
to be replaced. Consult a qualified
electrician if in doubt.
!WARNING
If your fan is to replace an existing ceiling
light fixture, turn electricity off at the main
fuse or circuit breaker box at this time and
remove the existing light fixture.
Electrical Requirements
How to Assemble Your
Ceiling Fan
Turning off wall switch is not sufficient.
To avoid possible electrical shock, be
sure electricity is turned off at the main
fuse or circuit breaker box before wiring.
All wiring must be in accordance with
National and Local codes and the ceiling
fan must be properly grounded as a
precaution against possible electrical
shock.
!WARNING
Turning off wall switch is not sufficient.
To avoid possible electrical shock, be
sure electricity is turned off at the main
fuse or circuit breaker box before wiring.
All wiring must be in accordance with
National and Local codes and the ceiling
fan must be properly grounded as a
precaution against possible electrical
shock.
!WARNING
To reduce the risk of personal injury, do
not bend the blade flange when installing
the blade flanges, balancing the blades or
cleaning the fan. Do not insert foreign
objects in between rotating fan blades.
!WARNING
Model No.: CF3600
#10-32 x 1/4" OVAL HEAD
SCREW (2 per blade
assembly)
BLADE
FLANGE
BLADE
(Sold Separately)
BLADE
MEDALLION
Figure 1
1. Position the blade medallion on top of
the blade by aligning the raised bosses
into the blade mounting holes.
Carefully position the blade flange onto
the bottom of the blade by aligning the
bosses with the blade holes. Install
three #10-32 x 1/4” oval head screws
into the mounting holes of the
medallion and tighten. Be sure the
flange and medallion are aligned with
the blade holes (Figure 1). If using
wooden blades, be very careful not to
over tighten the blade screws.
NOTE: Screws for the wooden blades
are shipped with the blades. Do not
discard the blade packaging until you
have located the screws.
NOTE: Recommend the blades screws
be checked regularly for tightness.
2. Assemble remaining three blades per
previous instructions.
NOTE: Take care not to scratch fan
blades while installing flanges.
BP7384 Camden, CF3600 3/12/09 12:37 PM Page 5

6Model No.: CF3600
FLANGE
MOTOR HUB
MOUNTING HOLE
#8-32 x 5/8" FLAT HEAD SCREW
(2 per flange/blade assembly)
BLADE
ASSEMBLY
Figure 2
Note: Be sure the flange screws on the
blade assembly are facing down for
correct installation into the motor hub.
3. Insert the blade flange into one of the
mounting holes in the motor hub
(Figure 2). Align the flange with the slot
in the motor assembly. Insert one #8-32
x 5/8” flat head screw (supplied) into
one of the flange mounting holes; do
not fully tighten. Install the second
screw in the same manner; tighten both
screws securely.
7. Securely engage the 3-pin connector
from the fan motor assembly with the
switch cover connector. The
connectors are keyed and must be
mated correctly before they can be
engaged (Figure 5).
8. Slide the pull chain through the chain
busing located on the side of the switch
cover.
9. Position the switch cover assembly
onto the fan motor switch cover adapter
plate. Align the switch cover assembly
switches with the clearance notches in
the motor assembly switch cover
adapter plate. Secure the cover using
three #8-32 x 1/4” flat head screws
(supplied).
NOTE: Do not pinch wires between the
fan motor assembly and switch cover
assembly.
NOTE: Take care not to scratch fan
housing when installing blades.
4. Repeat assembly instructions for the
remaining three blade assemblies.
PAN HEAD
SCREW (3)
MOTOR
FLANGE
Figure 3
PAN HEAD SCREW (3)
SWITCH
ADAPTER
PLATE
FAN MOTOR
ASSEMBLY
Figure 4
5. Remove and retain one of the three
pan head screws from the motor flange
(Figure 3); loosen the other two pan
head screws three or four turns.
Position the switch adapter plate on the
motor flange so that the two screws
mate with the two keyhole slots in the
adapter (Figure 4).
6. Turn the switch adapter plate clockwise
and tighten both screws (Figure 4).
Reinstall the other pan head screw in
the remaining hole in the adapter.
BP7384 Camden, CF3600 3/12/09 12:37 PM Page 6

10. Carefully turn partially assembled fan
over and place on top of the
styrofoam, resting on switch cover
assembly.
7
11. Remove the hanger ball by loosening
the setscrew in the hanger ball until
the ball falls freely down the downrod
(Figure 6). Remove the clevis pin from
the downrod, then remove the hanger
ball. Retain the pin and hanger ball for
reinstallation in Step 17.
12. Separate, untwist and unkink the three
80” motor leads. Route the motor lead
wires through the downrod. Align the
clevis pin holes in the downrod with
the holes in the motor coupling. Install
the clevis pin and secure with the
hairpin clip (Figure 7). The clevis pin
must go through the holes in the motor
coupling and the holes in the downrod.
Be sure to push the straight leg of the
hairpin clip through the hole near the
end of the clevis pin until the curved
portion of the hairpin clip snaps around
the clevis pin. The hairpin clip must be
PIN
HANGER
BALL
SETSCREW
DOWNROD
Figure 6
Model No.: CF3600
SWITCH COVER
ASSEMBLY
SWITCH COVER
CONNECTOR
MOTOR ASSEMBLY
CONNECTOR
SWITCH CHAIN
BUSHING
Figure 5
HAIRPIN
CLIP
CLEVIS PIN
MOTOR
COUPLING
5/16-18 x 1/4"
SETSCREW
Figure 7
properly installed to prevent the clevis
pin from working loose. Pull on the
downrod to make sure the clevis pin is
properly installed.
13. Install the 5/16-18 x 1/4” setscrew into
the threaded hole on the motor
coupling.
14. While pulling up on the downrod,
securely tighten the 5/16-18 x 1/4”
setscrew (supplied) in the motor
coupling using the 3/16” hex wrench
(supplied) (Figure 7).
NOTE: The setscrew must be properly
installed as described above, or fan
wobble could result.
15. Carefully place the motor housing
cover over the downrod the guide it
over the motor housing assembly.
Align the three mounting holes with the
corresponding threaded holes on top
of the motor. Install three #8-32 x 1/4”
pan head screws into the holes to
secure the motor cover (Figure 8).
It is critical that the clevis pin in the motor
coupling is properly installed and the
setscrew securely tightened. Failure to
verify that the pin and setscrew are
properly installed (as shown in Figure 4)
could result in the fan falling.
!WARNING
BP7384 Camden, CF3600 3/12/09 12:37 PM Page 7

It is critical that the pin in the hanger ball
is properly installed and the setscrew
securely tightened. Failure to verify that
the pin and setscrew are properly
installed could result in the fan falling.
!WARNING
17. Reinstall the hanger ball (Figure 10) on
the downrod as follows. Route the motor
leads through the downrod. Position the
pin through the two holes in the downrod
and align the ball so the pin is captured
in the groove in the top of the hanger
ball. Pull the hanger ball up tight against
the pin and securely tighten the setscrew
in the hanger ball. A loose setscrew
could create fan wobble.
18. The fan comes with blue, black and
white leads that are 80” long. Before
installing fan, measure up approx-
imately 6 to 9-inches above top of
hanger ball/downrod assembly. Cut off
excess leads and strip back insulation
1/2-inch from end of leads.
CEILING
COVER
PIN
DOWNROD
HANGER BALL
SETSCREW
Figure 10
FAN MOTOR
ASSEMBLY DOWNROD
MOTOR
COVER
#8-32 x 1/4" PAN HEAD
SCREW (4)
Figure 8
MOTOR
COVER
COUPLING
COVER
DOWNROD
GROMMET
CEILING
COVER
Figure 9
16. Make sure the grommet is properly
installed in the coupling cover then
slide the coupling cover over the
downrod until it rests on the motor
housing cover. Place the ceiling cover
over the downrod. Be sure both the
ceiling cover and the coupler cover are
oriented correctly (Figure 9).
NOTE: Be careful not to scratch the
downrod with the ceiling cover during
installation.
8Model No.: CF3600
BP7384 Camden, CF3600 3/12/09 12:37 PM Page 8

1. Securely attach the hanger bracket to
the outlet box using the two screws
supplied with the outlet box (Figure 12).
How to Hang
Your Ceiling Fan
The fan must be hung with at least 7' of
clearance from floor to blades (Figure 11).
!WARNING
The outlet box and joist must be securely
mounted and capable of supporting at
least 50 lbs. Use only a U.L. outlet box
listed as “Acceptable for Fan Support”.
!WARNING
To reduce the risk of fire, electric shock,
or personal injury, mount fan to outlet box
marked “Acceptable for Fan Support”,
and use screws supplied with outlet box.
Most outlet boxes commonly used for
support of light fixtures are not
acceptable for fan support and may need
to be replaced. Consult a qualified
electrician if in doubt.
!WARNING
CEILING
FLOOR
AT
LEAST
7'
Figure 11
9Model No.: CF3600
2. Carefully lift the fan and seat the
hanger ball/downrod assembly on the
hanger bracket that was just attached
to the outlet box (Figure 12). Be sure
the groove in the ball is lined up with
the tab on the hanger bracket
(Figure 13).
Hanger bracket must seat firmly against
outlet box. If the outlet box is recessed,
remove wall board until bracket contacts
box. If bracket and/or outlet box are not
securely attached, the fan could wobble
or fall.
!WARNING
Failure to seat tab in groove could cause
damage to electrical wires and possible
shock or fire hazard.
!WARNING
To avoid possible fire or shock, do not
pinch wires between the hanger
ball/downrod assembly and hanger
bracket.
!WARNING
TWO SCREWS
SUPPLIED
WITH
OUTLET BOX HANGER
BRACKET
TAB
OUTLET
BOX
NOTE: CEILING COVER, SUPPLY WIRES AND FAN
WIRES OMITTED FOR CLARITY.
OUTLET
BOX
HANGER
BRACKET
HANGER BALL/
DOWNROD ASSEMBLY
1-1/4" THREADED
STUD (2)
Figure 12
Figure 13
BP7384 Camden, CF3600 3/12/09 12:37 PM Page 9

3. Screw the two 1-1/4” threaded studs
(supplied) into the tapped holes in the
hanger bracket (Figure 13).
4. Lift the ceiling cover up to the threaded
studs and turn until the studs protrude
through the holes in the ceiling cover
(Figure 15).
5. Secure the ceiling cover in place by
sliding lockwashers (supplied) over the
threaded studs and installing the two
knurled knobs (supplied). (Figure 15).
Tighten the knurled knobs securely
until the ceiling cover fits snugly against
the ceiling.
NOTE: CEILING COVER
OMITTED FOR CLARITY.
GROUND
WIRE
LISTED
WIRE
CONNECTOR (3)
GREEN WIRE
(GROUND) FROM
HANGER BRACKET
GREEN WIRE
(GROUND) FROM
HANGER BALL
WHITE SUPPLY
(NEUTRAL)
WHITE FAN
WIRE
BLACK SUPPLY
(HOT)
BLACK AND BLUE
FAN WIRES
Figure 14
Check to see that all connections are
tight, including ground, and that no bare
wire is visible at the wire connectors,
except for the ground wire. Do not
operate fan until blades are in place.
Noise and fan damage could result.
!WARNING
Model No.: CF3600
10
1. Connect the green grounding lead from
the hanger ball and the green
grounding lead from the hanger bracket
to the grounding conductor of supply
(this may be a bare wire or wire with
green colored insulation). Securely
connect wires with wire connectors
supplied. (Figure 14.)
2. Securely connect the fan motor white
wire to the supply white (neutral) wire
using wire connector supplied (Figure
14). Securely connect the fan motor
black wire and blue wire to the supply
black (hot) wire using wire connector
supplied (Figure 14). After connections
have been made, turn leads upward
and carefully push leads into the outlet
box, with the white and green leads on
one side of the outlet box and the black
and blue leads on the other side of the
outlet box.
How to Wire
Your Ceiling Fan
Turning off wall switch is not sufficient.
To avoid possible electrical shock, be
sure electricity is turned off at the main
fuse box before wiring. All wiring must be
in accordance with National and Local
codes and the ceiling fan must be
properly grounded as a precaution
against possible electrical shock.
!WARNING
If you feel that you do not have enough
electrical wiring knowledge or
experience, have your fan installed by a
licensed electrician.
This product is designed to use only
those parts supplied with this product
and/or any accessories designated
specifically for use with this product by
Emerson Electric Co. Substitution of
parts or accessories not designated for
use with this product by Emerson Electric
Co. could result in personal injury or
property damage.
!WARNING
BP7384 Camden, CF3600 3/12/09 12:37 PM Page 10
