IMPORTANT PRODUCT INFORMATION
GFK-3003AA
May 2023
PACSystems™ RX3i IC695CPE400 and
IC695CPL410 IPI
IC695CPE400-ADBA
12
IC695CPL410-ACAN12
Firmware Version 10.85
1
Includes conformal coat and low temperature module variants, if available.
2
The last two characters of the catalog number suffix may not increment with every
firmware release beginning with IC695CPE400-ACBA and IC695CPL410-ABAN 10.30.

GFK-3003AA May 2023
i
Warnings and Caution Notes as Used in this Publication
WARNING
Warning notices are used in this publication to emphasize that hazardous voltages, currents,
temperatures, or other conditions that could cause personal injury exist in this equipment or may be
associated with its use.
In situations where inattention could cause either personal injury or damage to equipment, a Warning
notice is used.
CAUTION
Caution notices are used where equipment might be damaged if care is not taken.
Note: Notes merely call attention to information that is especially significant to understanding and operating the
equipment.
These instructions do not purport to cover all details or variations in equipment, nor to provide for every
possible contingency to be met during installation, operation, and maintenance. The information is
supplied for informational purposes only, and Emerson makes no warranty as to the accuracy of the
information included herein. Changes, modifications, and/or improvements to equipment and
specifications are made periodically and these changes may or may not be reflected herein. It is
understood that Emerson may make changes, modifications, or improvements to the equipment
referenced herein or to the document itself at any time. This document is intended for trained personnel
familiar with the Emerson products referenced herein.
Emerson may have patents or pending patent applications covering subject matter in this document. The
furnishing of this document does not provide any license whatsoever to any of these patents.
Emerson provides the following document and the information included therein as is and without warranty
of any kind, expressed or implied, including but not limited to any implied statutory warranty of
merchantability or fitness for particular purpose.

GFK-3003AA May 2023
1
Current Release Information
IC695CPE400 64MB Rackless CPU w/PACEdge + Connext and IC695CPL410 64MB Rackless CPU
w/PACEdge + WebHMI PACSystems Firmware Release 10.85 adds support for Run Mode Store (RMS) to User
Flash, SVC_REQ 63 Logic Driven Data Write to Non-Volatile Storage, three diagnostic %S bits, and Audit
Trail. PACSystems Firmware Release 10.85 resolves the issues found in the RX3i PLC: Problems Resolved in
Current Release section.
Component
Version Number
Field Upgradable Using These Upgrade Kits:
•41G2376-FW01-000-A17
•41G2617-FW01-000-A13
PACSystems
Release 10.85 Build ELTH
FPGA
02.03.00
CPLD
02.03.07
IC695ACC403 Energy Pack Base
3.03
Field Upgradable using Ubuntu Repositories
PACEdge
PACEdge 2.2.0
Not Field Upgradable
UEFI
3.15.000
RX3i PLC: New Features and Enhancements
in Current Release
New Features
Description
Run Mode Store (RMS) to User
Flash
Enables the user to make logic changes while in run mode that will be saved to both User
RAM and Flash. User RAM and User Flash equality will be maintained.
SVC_REQ 63 Logic Driven Data
Write to Non-Volatile Storage
Allows logic to write up to four regions of %R, %AI, or %AQ data to non-volatile storage
up to 24 times in a 24-hour period. The data is reloaded to the data tables on power up.
•%S53: #LG_CFG_SRC_RAM
•%S54 #DATA_SRC_RAM
•%S55: #DATA_SRC_NV
•Set to 1 if CPU logic and HWC is retrieved from User RAM at powerup.
•Set to 1 if the CPU reference data is retrieved from User RAM at powerup.
•Set to 1 if the CPU reference data is retrieved from any SVC_REQ 63 NV Storage
locations at powerup.
Audit Trail
The CPU contains a log of user actions performed on the PLC. PACAnalyzer is used to
retrieve the Audit Trail log. The log records events like web page connection,
configuration download, STOP/RUN transition, clearing of fault tables, etc.

GFK-3003AA May 2023
2
PACEdge: New Features and Enhancements
in Current Release
For a complete list of new features and enhancements, please consult GFK-3198, PACEdge Important
Product Information.
Field Upgrades
PACSystems CPU firmware version 10.85 is released to manufacturing for production and as a
downloadable upgrade kit. PACEdge 2.2.0 is released to manufacturing for production.
All production versions of the CPE400 and CPL410 are field upgradeable to this PACSystems CPU release
using the upgrades available for download on the Landing Pages found at
https://www.emerson.com/Industrial-Automation-Controls/Support.
Release in line with software license compliance requirements.
PACSystems CPU Upgrade
The RX3i firmware upgrade process may take up to four minutes to complete, depending on the contents
of the update. During the update, the RUN and OUTPUTS ENABLED LEDs blink GREEN in unison and the
CPE400 / CPL410 may automatically reset one or more times. All LEDs will be off during the automatic
reset. The IC695ACC403 Energy Pack (if present) may also be updated. The energy pack blinks all LEDs
GREEN and performs an automatic reset following its update.
Note: Do not manually power cycle the CPE400 / CPL410 or remove the energy pack (if present) or the cap
pack from the energy pack base during the updates as this may place the CPU and energy pack in an
unrecoverable and unusable state.
CPE400 PACSystems CPU Upgrade Kit
Kit Part Number: 41G2376-FW01-000-A17
Kit File Name: CPE400_FW10_85_41G2376-FW01-000-A17.zip
CPL410 PACSystems CPU Upgrade Kit
Kit Part Number: 41G2617-FW01-000-A13
Kit File Name: CPL410_FW10_85_41G2617-FW01-000-A13.zip
PACEdge Upgrade
For detailed instructions on how to upgrade PACEdge, please consult the PACEdge Important
Product Information (GFK-3198) and the PACEdge User Manual (GFK-3178).

GFK-3003AA May 2023
3
Release History
CPE400
Catalog
Number1 2
Date
Firmware Version (Build Number)
Field Upgradeable Elements
PAC
Systems
FPGA3
CPLD
ACC403
EP Base
PACEdge/Field Agent
IC695CPE400-
ADBA
May 2023
10.85
(ELTH)
02.03.00
02.03.07
3.03
PACEdge 2.2 + Connext
IC695CPE400-
ADBA
Nov 2022
10.70
(EKPX)
02.03.00
02.03.06
3.03
PACEdge 2.2 + Connext
IC695CPE400-
ADBA
Sep 2022
10.70
(EKPX)
02.03.00
02.03.06
3.03
PACEdge 2.1 + Connext
IC695CPE400-
ADBA
Aug 2022
10.30
(EJYQ)
02.03.00
02.03.06
3.03
PACEdge 2.1 + Connext
IC695CPE400-
ACBA2
Jul 2022
10.30
(EJYQ)
02.03.00
02.03.06
3.03
PACEdge 2.1 + Connext
IC695CPE400-
ACBA
Aug 2021
10.15
(EGX2)
02.03.00
02.03.06
3.03
PACEdge 2.1 + Connext
IC695CPE400-
ACAU
May-2021
10.15
(EGX2)
02.03.00
02.03.06
3.03
Field Agent: No longer
supported starting with
firmware release 10.15
IC695CPE400-
ACAT
Jan 2021
10.10
(EG67)
02.03.00
02.03.06
3.03
2018_06_15_144951
IC695CPE400-
ACAS
Jun 2020
10.05
(EEJN)
02.03.00
02.03.06
3.03
2018_06_15_144951
IC695CPE400-
ACAR
Apr 2020
10.00
(EDNT)
02.03.00
02.03.06
3.03
2018_06_15_144951
IC695CPE400-
ACAQ
Feb 2020
9.99
(EDAL)
02.03.00
02.03.06
3.03
2018_06_15_144951
IC695CPE400-
ACAP
Dec 2019
9.97
(ECZ4)
02.03.00
02.03.06
3.03
2018_06_15_144951
IC695CPE400-
ACAN
Nov 2019
9.95
(ECNH)
02.03.00
02.03.03
3.03
2018_06_15_144951
IC695CPE400-
ACAM
Sep 2019
9.90
(EC93)
02.03.00
02.03.03
3.03
2018_06_15_144951
3
Prior to version 9.20, only the last two digits of the FPGA version were displayed on the Firmware Update Web Page. For example, if the FPGA
version were 2.2.0, the web page would display 2.00. This issue was resolved in version 9.20 and later.

GFK-3003AA May 2023
4
Catalog
Number1 2
Date
Firmware Version (Build Number)
Field Upgradeable Elements
PAC
Systems
FPGA3
CPLD
ACC403
EP Base
PACEdge/Field Agent
IC695CPE400-
ABAL
Mar 2019
9.75
(EB8A)
02.03.00
02.03.03
3.03
2018_06_15_144951
IC695CPE400-
ABAK
Dec 2018
9.70
(EAKR)
02.03.00
02.03.03
3.03
2018_06_15_144951
IC695CPE400-ABAJ
Aug 2018
9.55
(EA1Y)
02.03.00
02.03.03
3.03
2018_06_15_144951
IC695CPE400-
ABAH
Jul 2018
9.40
(E91K)
02.03.00
02.02.00
3.03
2018_06_15_144951
IC695CPE400-
ABAG
Feb 2018
9.40
(E91K)
02.03.00
02.02.00
3.03
2017_07_10_160104
IC695CPE400-
ABAF
Oct 2017
9.30
(E8JL)
02.03.00
02.02.00
3.03
2017_07_10_160104
IC695CPE400-
ABAE
Jul 2017
9.204
(E7QB)
02.02.00
02.02.00
3.03
2017_07_10_160104
IC695CPE400-
ABAC
Apr 2017
9.204
(E7QB)
02.02.00
02.02.00
3.03
2017_01_19_182114
IC695CPE400-
ABAB
Jan 2017
9.00
(E79S)
02.02.00
02.02.00
3.03
2017_01_19_182114
IC695CPE400-
AAAA
Dec 2016
9.00
(E79S)
02.02.00
02.02.00
3.03
2016_12_14_220042
4
The CPE400’s PACSystems Runtime is Achilles Level 2 certified in R9.20.

GFK-3003AA May 2023
5
CPL410
Catalog
Number12
Date
Firmware Version (Build Number)
Field Upgradeable Elements
PAC
Systems
FPGA
CPLD
ACC403
EP Base
PACEdge/Field Agent
IC695CPL410-ACAN
May 2023
10.85
(ELTH)
02.03.00
02.03.07
3.03
PACEdge 2.2 + WebHMI
IC695CPL410-ACAN
Nov 2022
10.70
(EKPX)
02.03.00
02.03.06
3.03
PACEdge 2.2 + WebHMI
IC695CPL410-ACAN
Sep 2022
10.70
(EKPX)
02.03.00
02.03.06
3.03
PACEdge 2.1 + WebHMI
IC695CPL410-ACAN
Jul 2022
10.30
(EJYQ)
02.03.00
02.03.06
3.03
PACEdge 2.1 + WebHMI
IC695CPL410-
ABAN2
Jul 2022
10.30
(EJYQ)
02.03.00
02.03.06
3.03
PACEdge 2.1 + WebHMI
IC695CPL410-ABAN
Aug 2021
10.15
(EGX2)
02.03.00
02.03.06
3.03
PACEdge 2.1 + WebHMI
IC695CPL410-
ABAM
May 2021
10.15
(EGX2)
02.03.00
02.03.06
3.03
Transitioned to PACEdge:
UBUNTU_16.04.4_4.4.0-
130-generic_20190801
IC695CPL410-ABAL
Jan 2021
10.10
(EG67)
02.03.00
02.03.06
3.03
UBUNTU_16.04.4_4.4.0-
130-generic_20190801
IC695CPL410-ABAK
June 2020
10.05
(EEJN)
02.03.00
02.03.06
3.03
UBUNTU_16.04.4_4.4.0-
130-generic_20190801
IC695CPL410-ABAJ
Apr 2020
10.00
(EDNT)
02.03.00
02.03.06
3.03
UBUNTU_16.04.4_4.4.0-
130-generic_20190801
IC695CPL410-ABAH
Feb 2020
9.99
(EDAL)
02.03.00
02.03.06
3.03
UBUNTU_16.04.4_4.4.0-
130-generic_20190801
IC695CPL410-ABAG
Dec 2019
9.97
(ECZ4)
02.03.00
02.03.06
3.03
UBUNTU_16.04.4_4.4.0-
130-generic_20190801
IC695CPL410-ABAF
Nov 2019
9.95
(ECNH)
02.03.00
02.03.03
3.03
UBUNTU_16.04.4_4.4.0-
130-generic_20190801
IC695CPL410-ABAE
Sep 2019
9.90
(EC93)
02.03.00
02.03.03
3.03
UBUNTU_16.04.4_4.4.0-
130-generic_20190801
IC695CPL410-AAAC
Mar 2019
9.75
(EB8A)
02.03.00
02.03.03
3.03
UBUNTU_16.04.4_4.4.0-
130-generic_20180710
IC695CPL410-AAAB
Dec 2018
9.70
(EAKR)
02.03.00
02.03.03
3.03
UBUNTU_16.04.4_4.4.0-
130-generic_20180710
IC695CPL410-AAAA
Aug 2018
9.55
(EA1Y)
02.03.00
02.03.03
3.03
UBUNTU_16.04.4_4.4.0-
130-generic_20180710

GFK-3003AA May 2023
6
RX3i PLC: Functional Compatibility
Compatibility Issue
Description
PAC Machine Edition
Logic Developer PLC
Programmer Version
Requirements
Feature
Minimum Version of PME Required
Run Mode Store (RMS) to
User Flash and %S53,
%S54, & %S55
PACSystems RX3i CPU firmware revision 10.85 (or later).
PAC Machine Edition 10.2 (or later) to configure Run Mode
Store (RMS) to User Flash and view the new S bits.
IC695CMM002/CMM004
Serial Module Support in
the IC695PNS001
Bxxx/PNS101 and
IC695CEP001 PROFINET
Scanners
PACSystems RX3i CPUs with firmware revision 10.30 (or
later) support IC695CMM002/CMM004 Serial Modules in
the IC695PNS001 Bxxx/PNS101 and IC695CEP001 when
configured using PAC Machine Edition 10.00. (or later)
Legacy Client/Server
Protocol Memory Access
PACSystems RX3i CPUs with firmware revision 10.30 (or
later) support Legacy Client/Server Protocol Memory
Access when configured using PAC Machine Edition 10.00.
(or later)
IC695CPL410 Increased
PROFINET Device Support
PAC Machine Edition 9.80 SIM 7 or later is required to
configure a CPL410 with up to 64 (simplex) or 32 (Hot
Standby Redundancy) PROFINET I/O devices.
OPC UA Non-Transparent
Server Redundancy
PACSystems Hot Standby Redundancy RX3i CPUs with
firmware revision 10.10 or later support OPC UA Non-
Transparent Server Redundancy when configured using
PAC Machine Edition 9.80 SIM 5 or later.
OPC UA Server Logging
PACSystems RX3i CPUs with firmware revision 10.10 or
later support OPC UA Server Logging when configured
using PAC Machine Edition 9.80 SIM 5 or later.
Sequence of Events with
IRIG-B
PAC Machine Edition Logic Developer PLC 9.80 SIM 5 or
later is required to use Sequence of Events recording with
IRIG-B time synchronization.
Produce EGD on
Redundant IP
PAC Machine Edition Logic Developer PLC 9.50 SIM 20, 9.70
SIM 2, 9.80 SIM 2, or later is required to support EGD
Production with the Redundant IP address.
DNP3 Outstation
Configuration
PAC Machine Edition Logic Developer PLC 9.70 or later is
required to support DNP3 Outstation Configuration
OPC UA Management and
Security Provisioning
PAC Machine Edition Logic Developer PLC 9.50 SIM 16 or
later is required to support OPC UA Secure (Encrypted)
Connection provisioning.

GFK-3003AA May 2023
7
Compatibility Issue
Description
Increased Program Block
Count
PAC Machine Edition Logic Developer PLC 9.50 SIM 13 and
PACSystems PLC Firmware R9.70, or later are required to
support user programs with more than 512 blocks, up to a
maximum of 768 blocks.
CPE400 Hot Standby
Redundancy with
PROFINET®IO.
PME 9.50 SIM 5, or later is required for the configuration
of Hot Standby Redundancy with PROFINET IO.
CPE400 functionality
including Embedded
Simplex PROFINET I/O
Controller
PME 9.00 SIM 8 or later is required for native configuration
support of the CPE400.
SNTP Client Configuration
PME 9.00 SIM 10, or 9.50 SIM 2, or later
CPL410 Configuration
PME 9.50 SIM 10 or later
Backward
Compatibility
To convert an existing project which uses any other PLC, use the Family Conversion
feature in PME. Be aware of the constraints involved, as will be notified in PME. For
instance, the first PROFINET Controller in an RX3i CPU320 application will be assigned to
the embedded PROFINET Controller feature of the CPE400 or CPL410.
C Toolkit Compatibility
Feature
Supported C Toolkit
Versions
Note:
The CPE400/CPL410
support 64-bit C blocks
compiled with the C Toolkit
Version 8.00 or later. All
pre-existing C blocks must
be recompiled as a 64-bit
C block before
downloading to the
CPE400 or CPL410.
8.00 or 9.00 and
higher
The Series 90 Toolkit
(IC641SWP709/719) is not
compatible with PACSystems.
The function PLCC_get_plc_version() will return a new value for the PLC_version_info-
>model when a toolkit app runs on the CPL410. It is 0x002C (44). The CPE400 will
continue to return 0x0026 (38).

GFK-3003AA May 2023
8
Compatibility Issue
Description
PROFINET IO
Compatibility
Feature
Minimum
CPE400
Version
Minimum
CPL410
Version
Minimum
3iPNS
Version
Minimum
CEP001
Version
IC695CMM002/CMM004
Serial Module Support in
the IC695PNS001-
Bxxx/PNS101 and
IC695CEP001
10.30
10.30
3.35
(-Bxxx hw
and PNS101)
2.80
Increased PROFINET
Device Support (up to
64 simplex or 32 Hot
Standby Redundancy)
N/A
10.15
N/A
N/A
SVC_REQ 20 Read
Extended IO Fault Table
with Remote Fault Record
9.40
9.40
N/A
N/A
Remote Get HART Device
Information COMMREQ
9.00
9.00
2.41
2.60
Extended PROFINET
Subslot Numbers
9.00
9.00
N/A
N/A
Redundantly controlled
PROFINET IO (20 Hot
Standby Redundancy)
9.30
9.30
2.00
N/A
32 Simplex (non-
redundantly controlled)
PROFINET IO
9.00
9.00
N/A
N/A
Hot Standby
Redundancy
CPE400 firmware release 9.30 and CPL410 release 9.55 support Hot Standby Redundancy
with PROFINET IO. Hot Standby Redundancy with Genius IO is supported using the
IC695GCG001 RX3i Genius Communications Gateway. Hot Standby Redundancy with
Ethernet Global Data (EGD) is not supported.
LAN3 restriction
LAN3 is used only to synchronize the Primary and Secondary CPUs in a Hot Standby
Redundancy configuration. No additional hardware may be attached to LAN3. Use of
both ports is recommended when used in this fashion, as this provides a redundant
synchronization link between the two CPUs.
Redundant IP Support
CPE400 firmware release 9.30 and CPL410 release 9.55 support two independent
Redundant IP addresses, one for LAN 1 and one for LAN 2. LAN 2 Redundant IP is
supported when configured for Ethernet mode only.
Redundant IP is supported by the SRTP Server, Modbus TCP Server, and EGD protocols. It
is not possible to use Redundant IP with the OPC UA Server or with the Ethernet
firmware update web page.
Ethernet AUP File
Support
The CPE400 and CPL410 do not support Advanced User Parameter (AUP) files for their
Embedded Ethernet interfaces. Instead, use PAC Machine Edition to set the Ethernet
configuration parameters for SNTP and advanced Ethernet Global Data applications.

GFK-3003AA May 2023
9
Compatibility Issue
Description
Service Request 56 & 57
Logic Driven
Read/Write to Flash
Support
The IC695ACC403 Energy Pack automatically saves user memory to nonvolatile storage
when the CPE400/CPL410 is powered off and restores it to RAM when the
CPE400/CPL410 is turned on. Consequently, the CPE400 and CPL410 do not support
Service Requests 56 & 57 Logic Driven Read/Write to Flash. The service request function
block’s ENO output returns no power flow if these service requests are executed.
Whenever an RX3i application that uses service requests 56 & 57 is being migrated to a
CPE400 or CPL410, an IC695ACC403 Energy Pack should be used to provide equivalent
functionality, since the service requests themselves will have no effect and should ideally
be removed.
HART®Pass Through
CPE400 supports HART pass-through. HART Pass Through entails the usage of PC-based
applications, RX3i Analog modules with HART functionality, and (optionally) supporting
PROFINET products. HART Pass Through operation is described in the PACSystems HART
Pass Through User Manual, GFK-2929.
Embedded PROFINET
Controller HART Pass-
Through Support
HART Pass-Through is supported on all versions of the CPE400 and CPL410 with
PACSystems HART Device Type Manager v1.1 and PACSystems HART Multiplexer v1.1.
Remote Get HART
Device Information
COMMREQ
The Remote Get HART Device Information COMMREQ is supported by these products:
•RX3i CPUs with version 8.95 or later (which includes all versions of CPE400)
•IC695PNC001 RX3i PROFINET Controller version 2.26 or later
•IC695PNS001 RX3i PROFINET Scanner version 2.41 or later
•IC695PNS001 RX3i PROFINET Scanner GSDML-V2.3-GEIP-RX3iPNS-20160602.xml
Supported Browsers for
Firmware Update
The CPE400 and CPL410 support secure firmware updates over Ethernet using a web
browser. Supported browsers are listed below along with the minimum required version:
•Chrome: 62.0.3202.94 (or later)
•Firefox: 57.0.2 (or later)
•Microsoft Edge 38.14393.1066.0 (or later)
•Safari: 11.0.2 (12604.4.7.1.6) (or later)
CIMPLICITY®
OPC UA Client
PACSystems OPC UA servers support up to five concurrent sessions with up to ten
concurrent variable subscriptions and up to 12,500 variables. The subscription limit is
shared across all available sessions.
When using CIMPLICITY OPC UA Client, ensure the total number of subscriptions does
not exceed the maximum. CIMPLICITY OPC UA Client is configured to create one
subscription for every 500 items by default. If, for example, a project contains 1000
monitored items, CIMPLICITY creates two subscriptions. The number of items per
subscription may be modified from the Device Configuration Panel / OPC UA DA
Configuration / Subscriptions / Max. Number of Monitored Items.

GFK-3003AA May 2023
10
Compatibility Issue
Description
PACSystems Energy
Pack Compatibility
The only energy pack compatible with the IC695CPE400 and CPL410 is the IC695ACC403.
The CPE400 and CPL410 are not compatible with the ICRXIACCEPK01 RXi Controller
Energy Pack, the IC695ACC400 CPE305/310 Energy Pack, or the IC695ACC402 CPE330
Energy Pack.
•It is not possible to connect the CPE400/CPL410 and the IC695ACC400
CPE305/310 Energy Pack together.
•It is possible to connect the ICRXIACCCPK01A RXi Capacitor Pack to the
IC695ACC403 Energy Pack Base. If this occurs, the capacitor pack operates
normally.
•It is possible to connect the IC695ACC403 CPE400/CPL410 Energy Pack and
IC695ACC413 Capacitor Pack to an ICRXICTL000 controller. If this occurs no
errors are logged however user memory may not be preserved under all
conditions Do not use the CPE400 Energy Pack or Capacitor Pack with the
RXi Controller.
•It is physically possible to connect the IC695ACC403 CPE400/CPL410 Energy Pack
to an IC695CPE330 controller. If this occurs, no errors are logged. However, it
will not allow any future firmware updates to the ACC403 Energy Pack. Do not
use the ACC403 Energy Pack with the RX3i CPE330 Controller.
•It is physically possible to connect the IC695ACC402 CPE330 Energy Pack and
IC695ACC412 Capacitor Pack to an IC695CPE400 or CPL410 controller. If this
occurs no errors are logged. However, it will not allow any future firmware
updates to the ACC402 and the capacitors will reach their end-of-life threshold
faster than the RX3i Capacitor Pack IC695ACC413. Do not use the ACC402
Energy Pack or ACC412 Capacitor Pack with the RX3i CPE400 or CPL410
Controller.
•It is physically possible to connect the ICRXIACCEPK01A RXi Energy Pack to an
IC695CPE400 or CPL410 controller. If this occurs no errors are logged. However,
it will not allow any future firmware updates to the EPK01A and user memory
may not be preserved under all conditions. Do not use the EPK01A RXi Energy
Pack with the RX3i CPE400 or CPL410 Controller.
Ethernet Station
Manager Compatibility
Ethernet Station Manager Utility Version 1.3 Build 2 or later is recommended for use with
the CPE400 and CPL410. Earlier versions are compatible; however, they may not display
all the Ethernet parameters after issuing a parm all command. Should this issue occur,
pressing enter, or issuing another command will cause the station manager to display
the remaining parameters.
Set Temporary IP
Address not supported
Since the configured IP Addresses may be viewed using the CPE400/CPL410 OLED
display, the Set Temporary IP Address tool in PME is not required for CPE400/CPL410 and
is therefore not supported for CPE400 and CPL410.
RDSD Support
RDSD support using a USB memory stick or a micro SD card is not available with the
current release.

GFK-3003AA May 2023
11
Compatibility Issue
Description
Supported Primary and
Secondary CPUs
The Primary and Secondary CPUs in a redundant system must be the same model. For
example, two CPE400s may be paired together as the Primary and Secondary CPUs.
Likewise, two CPL410s may be paired together. Pairing CPE400 and CPL410 as Primary
and Secondary CPUs in a redundant system is not permitted.
Display Port is not
operational
The Display port, located on the underside of the CPE400 and CPL410 is not operational.
USB Ports
The CPE400’s left USB port is assigned to PACEdge. The right USB port is reserved.
The CPL410’s left USB port is assigned to PACEdge. The right USB port is reserved.
Micro SD Card
The Micro SD Card Slot is reserved and not available for use.
Serial IO Protocol
Serial IO Protocol is supported on the CPE400 effective with firmware release 9.40 and
the CPL410 effective with release 9.55.
Cimplicity and RX3i
Subscription Size
Incompatibility
The RX3i OPC UA server supports up to 10 subscriptions with up to 12,500 monitored
items each. Cimplicity OPC UA driver supports an unlimited number of subscriptions with
a default limit of 500 monitored items per subscription, and a hard limit of 32,767 bits of
data in a subscription. This means that it is not possible to subscribe to all 12,500
variables of the RX3i PLC with a Cimplicity HMI. The effective monitored item limit in
Cimplicity is dependent on the size of the data being subscribed to. Other OPC UA clients
with a larger monitored item per subscription limit can subscribe to the entire address
space of variables, such as UA Expert.
Network and Memory
Performance Monitor
PACS Analyzer
Requirements
PACSystems RX3i CPUs with firmware revision 10.05 or later support Network and
Memory Performance Monitoring when used with PACS Analyzer version 4.3 or later.
Sequence of Events
with IRIG-B
Sequence of Events recording with IRIG-B time synchronization is available when used
with these SoE-enabled components:
•Support for up to four IC695PNS101 Advanced PROFINET Scanner modules
oIC695CPE400/IC695CPL410 Release 10.10 or later
oIC695PNS101 Release 3.26 and GSDML-V2.3-IntelligentPlatformsLLC-
RX3iPNS-20191010.xml or later
•Support for up to five IC695PNS101 Advanced PROFINET Scanner modules
oIC695CPE400/IC695CPL410 Release 10.15 or later
oIC695PNS101 Release 3.30 and GSDML-V2.3-IntelligentPlatformsLLC-
RX3iPNS-20191010.xml or later
•SoE_App C Block version 1.08 or later
•Irig_Diag C Block version 1.00 or later
•UDT IRIG_DIAG_DATA.UDT (no version)
Field Agent Support
The CPE400 Embedded Field Agent is no longer supported beginning with firmware
release 10.15. The Embedded Field Agent will not function after upgrading to this
release. Downgrading a CP400 with release 10.15 to an earlier firmware version does not
re-enable Field Agent Support.

GFK-3003AA May 2023
12
PACEdge: Functional Compatibility
Note: For a complete list of PACEdge functional Compatibility, please consult GFK-3198, PACEdge
Important Product Information.
RX3i PLC: Problems Resolved in Current
Release
Subject
ID code
Description
Cyber Security
Updates
DE9500
DE9617
SFDC
02002236
Added security enhancements to harden the product against a malicious
actor.
Clear All clears
PLC_BAT and masks
Energy Pack failures
DE715
A Clear All operation clears the values of all %S bits. After this operation,
the PLC_BAT status bit value might not reflect the actual status of the
Energy Pack. For example, an Energy Pack in a failed state before the
Clear All operation will remain in the failed state after the Clear All
operation has completed. However, the PLC_BAT status bit will then
indicate a good state. This has been fixed.
PACEdge: Problems Resolved in Current
Release
Note: For a complete list of PACEdge Problems resolved in current release, please consult GFK-3198,
PACEdge Important Product Information.

GFK-3003AA May 2023
13
RX3i PLC: Restrictions and Open Issues
CPE400 & CPL410 CPUs & Embedded Ethernet
Open Issue
ID code
Description
Firmware Update Login
Timeout
DE196
DE205
DE2626
The CPU enforces a 2-minute login activity timeout on the Firmware Update
web page. Selecting an update package on the Firmware Update page and
pressing the Upload File button after the timer expires initiates a firmware
update. However, instead of displaying the firmware update status, one of
these scenarios may occur:
•Another login page is presented. After entering the user name and
password the update status is displayed.
•The web browser loses connection with the CPE400 and is unable
to display the update status because the CPU is automatically
resetting while applying the firmware update. After the reset
completes, pressing the refresh button in the browser shows the
installed firmware version.
•An error message is displayed indicating the firmware update was
not successful however, returning to the firmware update home
page shows that the new firmware version was installed.
These timeout issues may be avoided by having the firmware file ready so
that the firmware update can be initiated immediately after logging in.
Running applications
with fatal faults from
flash
DE86
If an application that generates a fatal fault (such as a watchdog timeout) is
stored to flash, the controller is configured to power up from flash and go
to RUN, and the RUN/STOP switch is disabled, the application may become
stuck in an endless loop. (Power-up from flash, go to RUN, watchdog
timeout, repeat.) It is recommended that users thoroughly test their
application before writing it to flash and disabling the RUN/STOP switch.
RX3i CPUs that experience this issue must be returned to Emerson
Automation Solutions for repair.
Using OEM Passwords
with Enhanced Security
Disabled
DE755
Single-character OEM passwords are not supported when enhanced
security is disabled.
PME cannot display
reference tables with
Enhanced Security
Enabled and OEM
Locked
DE781
When Enhanced Security is enabled, and OEM protection is engaged, only
reference areas specified within the Access Control List can be viewed by a
programmer, or HMI, regardless of privilege level. For example, if viewing
%R memory from words 1 to 400 then the Access Control List must include
read access to %R words 1 to 400. A custom reference view table with
smaller reference sizes may also be used.

GFK-3003AA May 2023
14
Open Issue
ID code
Description
Controller
Communication
Window Timer settings
below 10 ms are
ignored
DE845
Normal sweep allows the configuration of the Controller Communications
Window Timer for Limited operation and a time range from 0 to 255 ms
(default 10 ms). However, the system is currently ignoring settings in the
0 to 9 ms range which results in an effective window time of 10 ms for this
configuration range. This means a sweep impact of up to 10 ms may occur
for some complex Controller Communication Window operations. If this
operation is undesired then it is recommended to use a different sweep
mode, such as Constant Sweep or Constant Window.
Dual Hardware
Configuration Not
Created When
Uploading Redundant
CPE400/CPL410
Application
DE3052
A dual hardware configuration is not automatically created in PME when
uploading a redundant CPE400/CPL410 application. Before uploading the
primary application, dual hardware configuration must be manually
enabled by setting the CPE400 or CPL410’s Enable Redundancy target
property to True. The secondary application may then be uploaded.
Memory Not Preserved
After Turning
CPE400/CPL410 Off
with Power Button
DE3975
The CPE400 and CPL410 do not preserve user memory when the Power
Button is used to turn the CPU off while an energy pack is connected. At
this time, it is recommended to turn off power to the circuit powering
either the CPE400 / CPL410 or its associated Energy Pack to allow for
orderly shutdown procedures to occur.
Multibit ECC Memory
Error Causes Hardware
Watchdog
DE4181
The CPE400 and CPL410’s hardware watchdog timer expires and the CPU
reboots into STOP HALT mode if an uncorrectable (multi-bit) ECC memory
error is detected. Correctable (single-bit) errors are automatically repaired
as expected. No ECC memory faults are logged in the fault table whenever
either occurs.
Sequence Store Failure
Downloading
Redundant Hardware
Configuration
DE4254
It is possible to download a redundant hardware configuration with a non-
zero %W transfer list length to a CPE400 or CPL410 which has no %W
memory configured. The downloaded configuration is not valid since no
%W memory is configured, so none should be allowed in the transfer list.
If this occurs, the CPU enters STOP / FAULT Mode and a Sequence Store
Failure is listed in the PLC Fault Table. PAC Machine Edition’s Feedback Zone
shows Error 8097: Controller Error - Controller program reference exceeds
configured reference [0x05][0x90] [0x80310015]
This issue may be resolved by correcting the hardware configuration to
either remove %W memory from the transfer list or allocate %W memory in
the CPU corresponding to the length configured in the transfer list. Once
corrected, place the CPE400 or CPL410 into STOP / NOIO Mode by clearing
the PLC Fault Table and downloading the hardware configuration again.

GFK-3003AA May 2023
15
Open Issue
ID code
Description
Run Mode Store of EGD
Causes Sequence Store
Failure & CPU Software
Event Faults
DE4130
SFDC
00406176
Performing a RUN Mode Store of a project where the total number of
variables in EGD exchanges is near the maximum of 30,000 may result in a
Controller Sequence Store Failure (Group: 137; Error Code 4) and CPU
Software Event fault. (Group: 140; Error Code 145)
If this occurs, the project may be successfully downloaded while the
controller is in STOP Mode.
SRTP and Modbus TCP
Client Retries
DE5687
SRTP and Modbus TCP Client COMMREQs may require multiple TCP retries
to establish a connection when a gateway is configured on both LAN 1 and
LAN 2. Once a TCP connection is established, client operations proceed
normally. Client communications occur without multiple retries if only one
of the LANs has a gateway configured or if there are no gateways
configured.
PLC Fault Table Empty
After Restart Due to
Fatal Error
DE6573
PAC Machine Edition may not display any faults in the PLC fault table if it is
connected to a controller when it encounters a fatal error that results in an
automatic restart. (STOP/HALT) Should this occur, the fault table is empty
and the PME Fault Table Viewer indicates zero faults out of X number of
faults displayed. (EX: Displaying 0 of 11 faults, 11 Overflowed) Closing and
re-opening the PME Fault Table View displays the faults correctly.
PLC Fault Table Faults
Not Shown in
Chronological Order
DE6574
Faults in the PLC Fault Table may not be listed in chronological
order following an automatic controller restart due to a fatal error.
PME Error Programmer
already attached
DE8016
When connected to a target, there is a field called the request timeout,
which can be up to 240s. If you are connected to PME via a LAN2 port, and
you remove the ethernet cable and then re-attach it to a LAN2 port,
reconnect to PME, and try to enter programmer mode, the operation will
fail. To enter programmer mode, you must wait for the request timeout
amount of time to be able to enter programmer mode. You will see the
following error in PME when trying to enter the programmer before the
request timeout has expired:
Error 8085: Programmer already attached [{PC name}\{user name}]
To recover, you can wait for the request timeout amount of time, or you
can restart the PLC.
To avoid this issue, make sure you press "Disconnect" before removing the
ethernet cable from the LAN2 port, or else, you will have to wait for the
configured request timeout before you can re-enter the programmer
mode.

GFK-3003AA May 2023
16
Open Issue
ID code
Description
OPC UA Server Non-
Transparent
Redundancy
ApplicationDescriptions
for Remote ServerURI
Not Available On Local
FindServers Request
DE8313
The OPC UA Server in PACSystems controllers with firmware versions 10.10
and later, on controllers that are configured for OPC UA Non-Transparent
Redundancy (IC695CPE330, IC695CPE400, and IC695CPL410) and in a
redundant server pair, do not populate the information necessary to
automatically connect to the remote OPC UA server using the built-in OPC
UA FindServers service. If configuring an OPC UA Client for Non-
Transparent Redundancy to communicate with the PACSystems OPC UA
servers on a redundant system, the DiscoveryURLs for both servers must
manually be configured into the OPC UA Client. The default method of
configuration with Cimplicity software is to manually configure both
DiscoveryURLs for local and remote redundant servers and is not impacted
by this defect. Some OPC UA clients may not offer manual configuration of
both DiscoveryURLs and will have a compatibility issue when configuring
for OPC UA Non-Transparent Redundancy with a PACSystems OPC UA
server.
Failure To Publish All
Expected Variables to
OPC UA Address Space
DE9888
SFDC02016
781
Variables with their "Publish" property set to "Internal" are incorrectly
counted against the CPU's OPC UA address space limit but not actually
published. This causes some variables with their "Publish" property set to
"External Read/Write" or "External Read-Only" to not be present the OPC
UA address space. If variables do not have their "Publish" property set to
"Internal", or if an internally published variable comes alphabetically after
any externally published variables, then this issue does not occur.
Incorrect Data for
"Application
Information" Variable
"Address Space Status"
in OPC UA Address
Space
DE9900
In the OPC UA address space folder "Application Information" the "Address
Space Status" can incorrectly state that "All Elements Published to Address
Space" when they were not. This may occur when the total number of
internal and external published variables exceeds the externally published
variable limit for the controller.
OPC UA Server Sessions
May Not Expire
Correctly When PLC
Clock Set to Date Prior
to Year 2010
DE9942
SFDC02004
019
If the PLC Clock is set to a day prior to the year 2010, the OPC UA server will
negotiate session timeouts during session creation, but if the attached OPC
UA client stops responding to the OPC UA protocol the session timeout will
not be enforced, consuming a session incorrectly. Restarting the OPC UA
server will reclaim the abandoned sessions. If the PLC clock is set to any
date in the year 2010 or later, including the correct time/date, the problem
will not occur.

GFK-3003AA May 2023
17
Open Issue
ID code
Description
Ethernet COMMREQs
not always delivered on
the first logic sweep
ISS183540
In certain instances, where User Logic is of sufficient size and a COMMREQ
is issued on the first logic sweep, a race condition exists between the
determination of the CPU Run/Stop state and logic-driven issuance of a
COMRREQ which may cause the COMMREQ to be aborted before its
transmission is attempted. To the user, it would appear as if the COMMREQ
was never issued. The condition is much more observable on COMMREQs
issued from the CPU’s embedded Ethernet port. To avoid the possibility of
encountering this condition, users should avoid issuing COMMREQs on the
first logic sweep.
Ethernet Disconnect
During Word-for-Word
Change
CR-2234
If the Ethernet connection is broken during a word-for-word change, the
programmer may not allow a subsequent word-for-word change after
reconnecting since it thinks another programmer is currently attached. To
correct the issue, go offline and then back online again.
Simultaneous Clears,
Loads, and Stores Not
Supported
CR-3118
CR-3300
Currently, PACSystems CPUs do not support multiple programmers
changing CPU contents at the same time. The programming software may
generate an error during the operation. Simultaneous loads from a single
PLC are allowed.
Hardware
Configuration Not
Equal After Changing
Target Name
CR-3181
If the user stores a hardware configuration to flash that sets Logic/Config
Power-up Source to Always Flash or Conditional Flash and then subsequently
changes the name of the target in the programming software, the
hardware configuration will go Not Equal and will not Verify as equal.
PLC and IO Fault Tables
May Need to be Cleared
Twice to Clear Faulted
State
CR-3191
Both PLC and IO fault tables may need to be cleared to take the CPU out of
Stop/Fault mode. If one of the tables contains a recurring fault, the order in
which the tables are cleared may be significant. If the CPU is still in
Stop/Fault mode after both tables are cleared, try clearing the fault tables
again.
Setting Force On/Off by
Storing Initial Value
CR-3317
Once a Force On or Force Off has been stored in the PLC, the user cannot
switch from Force On to Force Off or vice-versa directly by downloading
initial values. The user can turn off the force by doing a download, and then
change the Force On or Force Off by another download.
Second programmer
can change logic while
in Test & Edit mode
CR-4223
While currently active in a Test and Edit session using Machine Edition on
one PC, Machine Edition running on another PC is not prevented from
storing new logic to the PLC.
Must have Logic if
Powering up from Flash
CR-4633
If the application will configure the CPU to retrieve the contents of flash
memory at power-up, be sure to include logic along with hardware
configuration when saving to flash memory.
Extended Memory
Types for IO Triggers
CR-5952
CR-6319
%R, %W, and %M cannot be used as IO triggers.
Possible PME inability
to connect
CR-6067
Infrequently, an attempt to connect a programmer to a PLC via Ethernet
will be unsuccessful. The normal connection retry dialog will not be
displayed. Rebooting the computer that is running the programmer will
resolve the behavior.

GFK-3003AA May 2023
18
Open Issue
ID code
Description
Do not attempt to store
logic and configuration
to a PLC from multiple
targets
CR-6450
In a system in which the hardware configuration is stored from one target
and logic is stored from a different target, powering up from flash will not
work. The observed behavior is that, following a power-up from flash, PME
reports hardware configuration and logic are not equal.
Sequence Store Failure
CR-6586
ISS176888
When downloading projects with very large hardware configurations or
which use large amounts of user memory, it is possible to encounter a PLC
Sequence Store Failure error when writing the project to flash. To work
around this error, either or both of the following actions may be helpful:
1. Perform an explicit clear of flash before performing the write.
2. Increase the operation timeout used by PME before performing
the write. This is done by expanding the Additional Configuration
in the Inspector window for the target controller and adjusting the
Request Timeout. The timeout may need to be increased to as
much as 60000 ms, depending on the amount of memory used
and the condition of the flash memory.
C Toolkit PlcMemCopy
Documentation
Incorrect
CR-7082
This routine does allow the destination and source pointers to be outside of
reference memory. If the destination points to discrete reference memory,
overrides and transitions will be honored. Note that the header for
PlcMemCopy has been updated in Release 3.50 of the C toolkit.
Logic and HWC are not
equal after the power
cycle
ISS168431
If the Hardware Config from Target 1, with Logic/Configuration Power-up
Source and Data Source both set to Always from Flash, is stored in Flash,
then Logic and Hardware Config from Target 2, with Logic/Configuration
Power-up Source both set to Always from RAM, are stored to RAM and there
is a good battery, then when power is cycled the programmer may show
that Logic and Hardware Config are not equal. The remedy is to clear Flash
and re-store the Logic and Hardware Config from Target 2.
Multiple Log Events
CR-2014
The Ethernet Interface sometimes generates multiple exception log events
and PLC Fault Table entries when a single error condition occurs. Under
repetitive error conditions, the exception log and/or PLC Fault Table can be
filled with repetitive error messages.
Spurious Ethernet Fault
CR-4104
In rare instances, after the power cycle, the Ethernet Interface may log the
following fault, Event = 28H, Entry 2 = 000eH. This fault can be safely
ignored.
Clear of large hardware
configurations may
cause log event 08/20
CR-6577
A Log event 08/20 may occur when very large hardware configurations are
cleared, and transfers are active on other Server connections. This log
event can be safely ignored.
PLC response timeout
errors (8/08) in Ethernet
exception log under
extremely heavy SRTP
traffic
ISS010006
Under extremely heavy SRTP traffic conditions, the Ethernet Interface may
log an event in the Ethernet exception log (Event 8, Entry 2 = 08H)
indicating an overload condition. This error terminates the SRTP
connection. If this event appears, either the traffic load should be reduced,
or the application should use an alternate communications method to
verify that critical data transfers were not lost due to the overload.
