Emerson GPC Series Installation instructions

1(3)
Emerson Automation Solutions | AVENTICS
cad_re-ass_saa-gpc-1_v02.docx
CAD Re-assembly instructions
for our neutral CAD file formats
Product: Guide cylinders, Series GPC
Parts assembled: 2 (5)
Consists of following parts: 5 pcs
Parts assembled: 2 (5)

2(3)
Emerson Automation Solutions | AVENTICS
cad_re-ass_saa-gpc-1_v02.docx
Mate instructions, step by step for easy handling
Constraint 2(3) : Insert
Constraint 3(3) : Mate
Constraint 2(3) : Insert
Constraint 3(3) : Mate
Constraint 1(2): Insert
Constraint 2(2): Mate
1 –Assembled A & B parts. Parts assembled: 2 (5)
Constraint 1(2): Insert
Constraint 2(2): Align (5.5mm)
2 –Assembled Nut.Parts assembled: 3 (5)

3(3)
Emerson Automation Solutions | AVENTICS
cad_re-ass_saa-gpc-1_v02.docx
Mate instructions, step by step for easy handling
1. Assemble C part.
No of parts assembled: 4 (5)
Constraint 2(2): Mate
Constraint 1(2): Insert
Constraint 1(3): Mate
Constraint 2(3): Align (5.7mm)
Constraint 3(3): Align (0.5mm)
3 –Assembled Stroke adj kit- A part. Parts assembled: 4 (5)
4 –Assembled Stroke adj kit- B part. Parts assembled: 5 (5)
