Emerson FB3000 User manual

Emerson FB3000 RTU Instruction Manual
D301851X012
October 2022
Energy and Transportation Solutions
Emerson FB3000 Remote Terminal Unit (RTU)
Instruction Manual

Emerson FB3000 RTU Instruction Manual
D301851X012
October 2022
ii
Device Safety Considerations
Reading these Instructions
Before operating the device, read these instructions carefully and understand their safety implications. In some situations, improperly using
this device may result in damage or injury. Keep this manual in a convenient location for future reference. Note that these instructions may not
cover all details or variations in equipment or cover every possible situation regarding installation, operation, or maintenance. Should
problems arise that are not covered sufficiently in the text, immediately contact Customer Support for further information.
Protecting Operating Processes
A failure of this device — for whatever reason -- may leave an operating process without appropriate protection and could result in possible
damage to property or injury to persons. To protect against this, you should review the need for additional backup equipment or provide
alternate means of protection (such as alarm devices, output limiting, fail-safe valves, relief valves, emergency shutoffs, emergency switches,
etc.). Contact Energy and Transportation Solutions for additional information.
Returning Equipment
If you need to return any equipment to Energy and Transportation Solutions, it is your responsibility to ensure that the equipment has been
cleaned to safe levels, as defined and/or determined by applicable federal, state and/or local law regulations or codes. You also agree to
indemnify Energy and Transportation Solutions and hold Energy and Transportation Solutions harmless from any liability or damage which
Energy and Transportation Solutions may incur or suffer due to your failure to ensure device cleanliness.
Grounding Equipment
Ground metal enclosures and exposed metal parts of electrical instruments in accordance with relevant safety standards. For the USA, refer to
OSHA rules and regulations as specified in Design Safety Standards for Electrical Systems, 29 CFR, Part 1910, Subpart S, dated: May 16, 1981
(OSHA rulings are in agreement with the National Electrical Code). For international locations, refer to IEC 60364-4-41: PROTECTION AGAINST
ELECTRIC SHOCK. You must also ground mechanical or pneumatic instruments that include electrically operated devices such as lights,
switches, relays, alarms, or chart drives. The FB3000 includes a chassis ground lug. Unless specifically noted, the chassis ground is isolated
from ground terminals on individual modules installed in the device to prevent noise. The chassis ground lug provides a path to earth ground
for electrical safety, static discharge, and stray voltages. Do not connect the chassis ground lug directly to a lightning arrestor/lightning rod.
Important: Complying with the codes and regulations of authorities having jurisdiction is essential to ensuring personnel safety. The guidelines
and recommendations in this manual are intended to meet or exceed applicable codes and regulations. If differences occur between this
manual and the codes and regulations of authorities having jurisdiction, those codes and regulations must take precedence.
Protecting from Electrostatic Discharge (ESD)
This device contains sensitive electronic components which can be damaged by exposure to an ESD voltage. Depending on the magnitude and
duration of the ESD, it can result in erratic operation or complete failure of the equipment. Ensure that you correctly care for and handle ESD-
sensitive components.
Using Qualified Personnel
Installation, configuration, and any subsequent modifications to this device should only be performed by qualified, suitably-trained personnel.
System Training
A well-trained workforce is critical to the success of your operation. Knowing how to correctly install, configure, program, calibrate, and
trouble-shoot your Emerson equipment provides your engineers and technicians with the skills and confidence to optimize your investment.
Energy and Transportation Solutions offers a variety of ways for your personnel to acquire essential system expertise. Our full-time
professional instructors can conduct classroom training at several of our corporate offices, at your site, or even at your regional Emerson
office. You can also receive the same quality training via our live, interactive Emerson Virtual Classroom and save on travel costs. For our
complete schedule and further information, contact the Energy and Transportation Solutions Training Department at 800-338-8158 or email
us at [email protected].
Ethernet Connectivity
This automation device is intended to be used in an Ethernet network which does not have public access. The inclusion of this device in a
publicly accessible Ethernet-based network is not recommended.

FB3000 - CSA Approval Information
CD9411M
Issued: June 23, 2022
CSA-1
CSA Approval Information
SAFETY FIRST
Read this document carefully before installing an Emerson FB3000 RTU. Refer to the other
sections of the instruction manual for general information. In the event of a conflict between the
other sections of this manual and this document, always follow the instructions in this document.
Note
If the equipment is used in a manner not specified by the manufacturer, the protection provided by
the equipment may be impaired.
Module Part Number(s) Ordering Code
FB3000 8 Slot Chassis Assembly (Backplane) 400246-01-0, 510000-01-0 3CH08C (CSA)
3CHO8A (ATEX)
FB3000 4 Slot Chassis Assembly (Backplane) 400231-01-0, 510002-01-0 3CH04C (CSA)
3CH04A (ATEX)
FB3000 Power Module Assembly 400223-01-0, 510008-01-0 3PWBLK
FB3000 CPU Logic Module Assembly 400224-01-0, 510009-01-0 3CPU16
FB3000 CPU Personality Module Assembly 400225-01-0, 510007-01-0 3CPUSG
FB3000 8-Slot DIN Rail Assembly 510001-01-0 3DIN08
FB3000 4 Slot DIN Rail Assembly 510003-01-0 3DIN04
FB3000 12 Mixed I/O (12MIO) Logic Module
Assembly
510006-01-0
400226-01-0
3MIX12
FB3000 12 Mixed I/O (12MIO) Personality
Module Assembly
510076-01-0 3MSG12
FB3000 I/O CPU Scanner Module 510121-01-0 3IOCPU
FB3000 4 Channel HART I/O Logic Module 510114-01-0 3HRT04
FB3000 4 Channel HART I/O Personality
Module
510115-01-0 3HTSG4
FB3000 8 Channel Output (Analog/Digital)
Logic Module
400253-01-0, 510142-01-0 3AODO8 (spare)
OUT08
(configured)
FB3000 8 Channel Output (Analog/Digital)
Personality Module
400254-01-0, 510143-01-0 3OTSG8 (spare)
OUT08
(configured)
General Information:
Manufacturer: Bristol Inc. d.b.a. Remote Automation Solutions
CSA Master Contract Number: 179806

FB3000 - CSA Approval Information
CD9411M
Issued: June 23, 2022
CSA-2
SRAM Backup Battery in Power
Modules (for memory and real-time
clock)
3V coin lithium battery BT1
(Renata model CR2450HT)
(Maxell model CR2450HR)
(Panasonic model BR2450A)
(Murata model CR2450W)
Rated Capacity: 490 mAh
Operating Temperature: —40oC to +125oC
SRAM Backup Battery in CPU Module
(for memory and real-time clock)
3V coin lithium battery BT1
(Renata model CR1632).
Rated Capacity: 125 mAh
Operating Temperature: —40oC to +85oC
Protective earthing (PE) conductor
(ground wire)
#14 AWG (2.1mm2)
Fuses Littelfuse®0453010.MRSurfaceMountNano2Fuse
10Amps@125VDC
Equipment Ratings:
Mode of Operation: Continuous
Pollution Degree: 2
Installation Category: DC supplied
Altitude: 2000 m
Humidity: 95% to temperatures up to 31oc decreasing linearly to
50% r.h. at 40oc; max 80 % r.h. non-condensing
Electrical Supply Rating: Input rating: 10.5-30Vdc
Controller Circuit: Max 5A at10.5 - 30V dc
Field Circuit: Max 5A at10.5 - 30V dc
Ambient Temperature Range:
(Tamb)
-40oC to +75oC
Temperature Code: T4
Vibration: 1.0 g for 10 to 150 Hz for 30 minutes; 0.5 g for 150 to
2000 Hz for 30 minutes
Locations: The Emerson FB3000 Remote Terminal Unit (RTU) is
listed by the Canadian Standards Association (CSA) as
suitable for use in Class I, Division 2, Groups A, B, C and
D hazardous locations (when installed in a suitably-
rated enclosure), and in Class I, Zone 2, AEX/Ex ec IIC
Gc hazardous locations (when installed in an IP54
enclosure per requirements of standards CSA/UL
60079-0 and CSA/UL 60079-7).
If no suitably-rated enclosure is provided, may only be
used in non-hazardous indoor locations.
Representative Power Supplies: 24V power supply at 10A to 20A as approved to
standard UL 60950-1.

FB3000 - CSA Approval Information
CD9411M
Issued: June 23, 2022
CSA-3
Typical: Phoenix Contact
Quint-PS/1AC/24DC/10 or
Quint-PS/1AC/24DC/20
Extended Backplane Supported Configurations:
Voltage (Control/Loop) Max number of
12MIO/12MIO Personality
Modules installed
Max number of 12MIO/12MIO
Personality Modules with loop
power enabled
30V 31 26
24V ≤V < 30V 31 21
12V≤V < 24V 21 10
10.5V≤V < 12V 18 8
Conditions of Use:
Wiring to or from this device, which either enters or leaves the user-provided enclosure, must
adhere to wiring methods suitable for Class I, Zone 2 and Division 2 Hazardous locations, as
appropriate for the installation and is subject to the acceptance of CSA or the inspection authority
having jurisdiction.
Install this device in a user-provided enclosure that provides a minimum entry protection of IP 54,
in accordance with IEC 60079-0:11.
Install the racks in a left to right horizontal direction (wall mount on DIN-rails) inside of the end user
system enclosure. Never mount the racks in a vertical stacked direction.
When using DIN-rail mounting as the method of installation for the extended backplane
configuration, use DIN-rail end brackets at the two ends of the extended backplane to prevent side
movements of the equipment on the DIN-rail. Refer to the Emerson FB3000 RTU Instruction Manual
(D301851X012) for details.
CSA evaluates this equipment according to the following standards:
CAN/CSA C22.2 No. 213 Non-incendive Electrical Equipment for Use in Class I and II
Division 2 and Class III Division 1 and 2 Hazardous Locations

FB3000 - CSA Approval Information
CD9411M
Issued: June 23, 2022
CSA-4
ANSI/UL 121201 Non-incendive Electrical Equipment for Use in Class I and II
Division 2 and Class III Division 1 and 2 Hazardous Locations.
CAN/CSA —C22.2 No. 60079-7 Explosive atmospheres — Part 7: Equipment protection by
increased safety “e”
ANSI/UL 60079-7 Explosive atmospheres — Part 7: Equipment protection by
increased safety “e”
CAN/CSA 22.2 No. 60079-0 Explosive atmospheres — Part 0: Equipment — General
Requirements
ANSI/UL 60079-0 Explosive atmospheres — Part 0: Equipment — General
Requirements
CAN/CSA 22.2 No. 61010-1 Safety Requirements for Electrical Equipment for
Measurement, Control, and Laboratory Use, Part 1: General
Requirements
CAN/CSA 22.2 No. 61010-2-201 Safety Requirements for Electrical Equipment for
Measurement, Control, and Laboratory Use - Part 2-201:
Particular requirements for control equipment
ANSI/UL 61010-1 Safety Requirements for Electrical Equipment for
Measurement, Control, and Laboratory Use - Part 1: General
Requirements
ANSI/UL 61010-2-201 Safety Requirements for Electrical Equipment for
Measurement, Control, and Laboratory Use - Part 2-201:
Particular requirements for control equipment
WARNING
EXPLOSION HAZARD — CONNECT OR DISCONNECT ONLY IN A NON-HAZARDOUS AREA.
WARNING
EXPLOSION HAZARD — DO NOT REMOVE OR REPLACE WHILE CIRCUIT IS LIVE UNLESS THE AREA IS
FREE OF IGNITABLE CONCENTRATIONS.
WARNING
EXPLOSION HAZARD — DO NOT REMOVE OR REPLACE FUSE WHEN ENERGIZED.
DANGER
EXPLOSION HAZARD: BATTERIES MUST ONLY BE CHANGED IN AN AREA FREE OF IGNITABLE
CONCENTRATIONS
WARNING
DO NOT USE THE USB CONNECTOR UNLESS THE AREA IS KNOWN TO BE NON-HAZARDOUS.

FB3000 - CSA Approval Information
CD9411M
Issued: June 23, 2022
CSA-5

Emerson FB3000 RTU Instruction Manual
D301851X012
October 2022
Contents iii
Contents
Chapter 1.Introduction 1
1.1Safety Labels .........................................................................................................................2
1.2Features................................................................................................................................2
1.3FB3000 RTU Chassis ..............................................................................................................3
1.4Central Processing Unit (CPU) ...............................................................................................3
1.5Memory ................................................................................................................................4
1.6I/O ........................................................................................................................................4
1.6.1Example — 12 Channel Mixed I/O Module (3MIX12/3MSG12).....................................4
1.7Power ...................................................................................................................................5
1.8Communications ..................................................................................................................5
1.9Software Tools ......................................................................................................................6
1.10RoHS Compliance.................................................................................................................6
1.11Secure Gateway....................................................................................................................6
Chapter 2.Installation 7
2.1Hazardous Locations .............................................................................................................7
2.2Required Tools ......................................................................................................................7
2.3Site Considerations ...............................................................................................................8
2.3.1Connecting Extension Chassis .................................................................................10
2.4General Wiring Guidelines...................................................................................................12
2.5Grounding ..........................................................................................................................13
2.5.1Chassis Ground Lug.................................................................................................13
2.5.2Internal System Bus Ground ....................................................................................14
2.5.3Isolated Ground on 3MIX12/3MSG12 Module .........................................................14
2.5.424V Loop Ground on 3MIX12/3MSG12 Module .......................................................15
2.6Mounting the Chassis..........................................................................................................15
2.6.1Panel or Wall Mounting the Chassis.........................................................................17
2.7Removing Battery Saver Tabs ..............................................................................................20
2.8Connecting Power...............................................................................................................21
2.8.1Connecting External Power .....................................................................................21
2.8.2Power Planning .......................................................................................................22
2.9Removing/Replacing the I/O Cover .....................................................................................24
2.10Connecting Communication Ports......................................................................................24
2.10.1Connecting to COM1 ............................................................................................26
2.10.2Connecting to COM2 ............................................................................................29
2.10.3Connecting to COM3 ............................................................................................32
2.10.4Connecting to COM4 ............................................................................................34
2.10.5Ethernet and Micro USB Port .................................................................................36
Chapter 3.I/O Configuration and Wiring 37
3.112-Channel Mixed I/O Module Configuration (3MIX12/3MSG12/MIO12).............................37
3.1.1Analog Inputs (3MIX12/3MSG12)............................................................................38
3.1.2Analog Outputs (3MIX12/3MSG12).........................................................................40
3.1.3Digital Inputs (3MIX12/3MSG12) ............................................................................42

Emerson FB3000 RTU Instruction Manual
D301851X012
October 2022
iv Contents
3.1.4Digital Outputs (3MIX12/3MSG12)......................................................................... 43
3.1.5Pulse Inputs (3MIX12/3MSG12).............................................................................. 48
3.2HART®Input/Output Channels (3HRT04/3HRTSG4/HRT04) ............................................... 49
3.2.1Point-to-Point Mode............................................................................................... 50
3.2.2Multi-Drop Mode.................................................................................................... 52
3.2.3Analog Input Mode (HART Communication Disabled)............................................. 54
3.2.4Analog Output Mode (HART Communication Disabled).......................................... 55
3.2.5Software Configuration .......................................................................................... 55
3.38-Channel Output Module Configuration (3AODO8/3OTSG8/OUT08)................................ 57
3.3.1Analog Outputs (3AODO8/3OTSG8/OUT08) .......................................................... 57
3.3.2Digital Outputs (3AODO8/3OTSG8/OUT08)........................................................... 59
Chapter 4.Operation 61
4.1Powering Up/Powering Down the Device ........................................................................... 61
4.2Establishing Communications ............................................................................................ 61
4.2.1Communicating with the SCADA Host.................................................................... 61
4.2.2Communicating with a Laptop Using a Serial Port................................................... 62
4.2.3Communicating with a Laptop Using Ethernet........................................................ 62
4.3Maintaining Backups .......................................................................................................... 63
4.3.1Backing up Historical Data and Your Configuration................................................. 63
4.3.2Backing up Your Solution........................................................................................ 63
Chapter 5.Service and Troubleshooting 65
5.1Returning the Unit for Repairs ............................................................................................ 66
5.2Interpreting the Status LEDs ............................................................................................... 67
5.3Removing/Replacing the Power Module ............................................................................. 72
5.3.1Removing a Power Module..................................................................................... 72
5.3.2Replacing a Power Module...................................................................................... 72
5.4Removing/Replacing the SRAM Batteries............................................................................ 73
5.4.1Battery in Power Module ........................................................................................ 74
5.4.2Battery in CPU Module............................................................................................ 74
5.5Removing/Replacing the CPU Logic Module (3CPU16)........................................................ 74
5.6Removing/Replacing an I/O Logic Module .......................................................................... 76
5.7Removing/Replacing a Personality Module ......................................................................... 77
5.8Upgrading System Firmware .............................................................................................. 78
Index 81

Emerson FB3000 RTU Instruction Manual
D301851X012
October 2022
Introduction 1
Chapter 1. Introduction
The Emerson FB3000 Remote Terminal Unit (RTU) runs measurement and control applications
suitable for the oil and gas, water, wastewater, and other process industries. You can also purchase
the FB3000 as an I/O-only device (FBxRemote I/O™) where control runs in a separate host FB3000
RTU. This manual describes how to install and configure the FB3000 hardware.
For information on using the FBxConnect™ configuration software, see the online help that
accompanies FBxConnect.
This chapter covers the following topics:
Safety Labels
Features
FB3000 Chassis
Central Processing Unit (CPU)
I/O
Power Options
Communications
Software Tools
RoHS Compliance
Secure Gateway
Figure 1-1. FB3000 RTU
1
Chassis (8 Slot shown)
2
Chassis Ground Lug
3
Power Supply Modules (2)
4
Ethernet Ports (on CPU logic module)
5
Micro A-B USB Connector (on CPU logic module)
6
Access Door (for battery replacement)
7
Personality Modules (residing in lower bay of slots 1 to 8)
8
CPU logic Module (slot 1 only) and I/O logic Modules (slots 2 to 8)
9
Connector to attach an additional chassis (right hand connector not present on 4-slot
chassis)

Emerson FB3000 RTU Instruction Manual
D301851X012
October 2022
2 Introduction
1.1 Safety Labels
This product may display safety label(s) to identify potential hazards. The same types of notices
appear within the documentation. Whenever you see an exclamation point (!) enclosed within a
triangle (shown , below), consult the documentation for additional safety information about the
hazard and how to avoid it. The labels used are:
Important
Important information to know when using the product.
SAFETY FIRST
General instructions and safety reminders.
CAUTION
DANGER TO PERSONNEL AND EQUIPMENT
Observe all precautionary signs posted on the equipment.
Failure to do so may result in injury to personnel or cause damage to the equipment.
WARNING
DANGER TO PERSONNEL AND EQUIPMENT
Observe all precautionary signs posted on the equipment.
Failure to do so may result in injury to personnel or cause damage to the equipment.
DANGER
MAY CAUSE DEATH
Observe all precautionary signs posted on the equipment.
Failure to do so may result in death or serious injury to personnel.
1.2 Features
The FB3000 RTU includes the following key features:
Operates in Class I Division 2 non-incendive and Ex ec Zone 2 non-sparking environments when
installed within a suitable enclosure.
Eight slot chassis may be extended with one, two, or three extension chassis.
Four-slot chassis available for smaller applications. It can also serve as the final extension
chassis (furthest on the right) in a multi-chassis assembly.
Supports I/O modules (logic module holding I/O electronics/logic) and associated
“personality” modules (handling wiring and termination).
Eight-slot chassis supports one or two power supply modules (four-slot chassis supports one).
Obtains power from a DC power supply (10.5-30Vdc).

Emerson FB3000 RTU Instruction Manual
D301851X012
October 2022
Introduction 3
Supports serial communication options for RS-232 and RS-485.
Provides two Ethernet (10/100/1000Base-T) ports.
Provides Micro A-B USB connector to support DNP3 communications.
1.3 FB3000 RTU Chassis
The FB3000 RTU has either a four-slot or an eight-slot chassis. The CPU is always in slot one of the
base chassis.
Figure 1-2. Chassis – 8 Slot Version (with/without slot covers)
Each slot includes an upper section and a lower section. The upper section holds the internal logic
module, and the lower section holds the personality module used for wiring.
If your RTU is not fully populated with modules, you can fill the empty slots with slot covers to
protect the connectors from dust. These are installed/removed using the same screws used for
personality modules.
If you require more than seven I/O slots provided by an eight-slot chassis, you can optionally
purchase one, two, or three extension chassis to attach to the base chassis, allowing an additional
8, 16, or 24 I/O slots for a total of 15, 23, or 31 slots in a single RTU.
Alternatively, a four-slot chassis may be added to the end of any eight-slot chassis so long as the
four chassis limit is not exceeded; this allows for configurations of 11, 19, or 27 I/O slots for a single
RTU.
1.4 Central Processing Unit (CPU)
The RTU’s CPU is a Freescale (NXP) SoloX dual-core architecture processor with an Arm® Cortex®-
A9 core, and an Arm Cortex-M4 core. If your RTU includes multiple chassis, there is still only one
CPU module in the first slot of the first chassis; all other chassis hold only I/O modules.
There are two CPU versions available:
3CPU16 – FB3000 RTU with full control and I/O capabilities
3IOCPU – FBxRemote I/O for I/O only with no control, no calculation support, and no
application support.

Emerson FB3000 RTU Instruction Manual
D301851X012
October 2022
4 Introduction
1.5 Memory
The RTU includes both static and flash memory.
Table 1-1. Memory
Memory
Usage
256 MB Flash Firmware image and report files; with 104 MB reserved for file
system and 128 MB available for database and history
16 MB SRAM Historical data logs and configuration
1 GB DDR3 SDRAM Firmware execution and execution memory
1.6 I/O
Other than slot 1 in the base chassis (which is reserved for the CPU), any slot can contain an I/O
module, however, not all I/O slots support all I/O module types.
1.6.1 Example – 12 Channel Mixed I/O Module (3MIX12/3MSG12)
I/O is configured within FBxConnect software.
For example, each 12-channel Mixed I/O module (labelled 3MIX12) supports the following
inputs/outputs:
Eight (8) input channels that you can individually configure using FBxConnect as analog inputs (AI),
digital inputs (DI), or pulse inputs (PI).
AIs are software-selectable as either 1VDC to-5VDC or 4 mA to 20 mA.
Two (2) analog output channels.
Two (2) digital output channels.

Emerson FB3000 RTU Instruction Manual
D301851X012
October 2022
Introduction 5
1.7 Power
You power the RTU using an external DC input. The 8-slot chassis includes two power supply
modules; the 4-slot chassis includes a single power supply module.
Table 1-2. Power
Power Source
Description
External DC Power Supply 10.5 Vdc to 30 Vdc external supply
Note
The RTU does not include an internal charger or other infrastructure to support a battery or
battery/solar power combination. If you choose to use a solar panel, you must provide your own
external charging mechanisms and connect to the external power terminals.
1.8 Communications
The RTU includes four serial communication ports, two Ethernet ports, and one Micro A-B USB port.
The Ethernet ports reside on the top of the CPU module and use RJ-45-style 8P8C sockets. Each
port supports a maximum of six concurrent TCP connections (sockets). The Micro A-B USB port
resides on the front of the CPU module and supports DNP3 communication. The serial ports allow
communication using DNP3, Modbus slave and Modbus master protocols.
Table 1-3. Serial Ports
Port
Serial Communication Type
Use
COM1 Software-selectable for RS-232 or
RS-485 operation
4-wire
RS-232, or RS-485 communication to host or
other devices
4-wire used with external radio.
Note
: Under older standards RS-485 (4-wire)
is identified as RS-422.
COM2 Software-selectable for RS-232 or
RS-485 operation
4-wire
RS-232, or RS-485 communication to host or
other devices
4-wire used with external radio.
Note
: Under older standards RS-485 (4-wire)
is identified as RS-422.
COM3 Isolated RS-485 operation
2-wire
RS-485 communication to host or other
devices such as 4088B.
COM4 Isolated RS-485 operation
2-wire
RS-485 communication to host or other
devices such as 4088B.
Note
For an I/O-only CPU (3IOCPU) FBxConnect pass-through communication from a host requires
Ethernet communication; serial ports are supported only through a local connection.

Emerson FB3000 RTU Instruction Manual
D301851X012
October 2022
6 Introduction
1.9 Software Tools
The FBxConnect™configuration software provides a series of wizards that enables you to perform
configuration activities for the RTU. You connect a PC running the FBxConnect configuration
software to the RTU using one of the serial, Ethernet, or USB ports. You can then:
Set parameters within your application
Configure I/O channels
Specify the serial communication method for a port (RS-232 to RS-485) as needed
Update system firmware
Optional FBxDesigner™programming software lets you create custom applications for the RTU
using any of the five IEC61131 languages.
1.10 RoHS Compliance
RoHS2
RoHS (2) EU Directive 2011/65/EU
China RoHS
1.11 Secure Gateway
For enhanced data security when using an IP/Ethernet connection or a serial connection into an IP
terminal server, Emerson Energy and Transportation Solutions recommends adding an industrial
router with VPN and firewall security. Recommended solutions include the MOXA EDR‐810, the
Hirschman Eagle One, or the Phoenix mGuard rs4000 (or equivalents). An example of how to install
one of these devices to the RTU can be found in the Emerson Energy and Transportation Solutions
MOXA®Industrial Secure Router Installation Guide (part number D301766X012). For further
information, contact your Emerson Impact Partner or the individual vendor’s website.

Emerson FB3000 RTU Instruction Manual
D301851X012
October 2022
Installation 7
Chapter 2. Installation
This chapter covers the following topics:
Hazardous Locations
Required Tools
Site Considerations
General Wiring Guidelines
Grounding
Mounting the Chassis
Removing the Battery Saver Tab
Connecting Power
Removing the I/O Cover
Connecting Communications Ports
2.1 Hazardous Locations
For North America the FB3000 has certifications for Class I Division 2 (Groups A, B, C & D) non-
incendive and non-hazardous locations only. For other world areas the FB3000-has ATEX and IEC Ex
certifications for Ex ec Zone 2 non-sparking installations and non-hazardous locations only. his is
body text.
All certifications are listed on the data plate located on the top of the device. Refer to the CSA
Approval Information document (CD9411) for special information for Class I Division 2 and Ex ec
Zone 2 installations.
2.2 Required Tools
The RTU ships from the factory fully assembled.
Certain tools and equipment are required for installing and servicing the RTU.
Table 2-1. Required Tools
Tool
Use
#2 Phillips screwdriver Chassis ground lug, panel installation, removal of rear panel.
¼” slotted blade screwdriver Personality module removal
Magnets Battery removal
Non-metallic tool Battery removal
Laptop PC running Field
Tools™ with FBxConnect™
configuration software
Software configuration

Emerson FB3000 RTU Instruction Manual
D301851X012
October 2022
8 Installation
2.3 Site Considerations
The RTU must reside in an accessible location for configuration and service. Refer to the
dimensional drawings for information on the space required.
Figure 2-1. FB3000 Dimensions – 8 Slot (with/without DIN Rail mounting plate assembly
1
No DIN mounting plates in this view

Emerson FB3000 RTU Instruction Manual
D301851X012
October 2022
Installation 9
Figure 2-2. FB3000 Dimensions – 4 slot (with/without DIN rail mounting plate assembly)
1
No DIN mounting plate in this view

Emerson FB3000 RTU Instruction Manual
D301851X012
October 2022
10 Installation
2.3.1 Connecting Extension Chassis
The FB3000 8-slot chassis supports up to 3 additional chassis. When connecting an extension
chassis to the “base” chassis (the chassis containing the CPU module), use only the right-hand side
of the base chassis. The FB3000 base chassis cannot support an extension chassis using the left-
hand connector.
The FB3000 4-slot chassis can serve as a single base chassis, or as the last extension chassis in an 8-
slot chassis assembly. The FB3000 4-slot chassis cannot have an extension chassis since it has no
right-hand connector.
DANGER
EXPLOSION HAZARD - MAY CAUSE DEATH
When installing in a hazardous location, the installer must ensure the side connectors between
the chassis are fully engaged.
Failure to do so may result in death or serious injury to personnel.
CAUTION
MAY CAUSE INJURY TO PERSONNEL AND EQUIPMENT
When mounting an FB3000 with one or more extension chassis in an enclosure, ensure that you
mount the racks in a left to right
horizontal direction (wall mount on DIN-rails)
inside the end user
system enclosure to allow for adequate heat dissipation.
Never
mount the racks in a
vertical
stacked direction.
Notes
If using multiple chassis, the length dimension increases by approximately 220 mm (8.7 in) for
each additional chassis 8-slot chassis, so:
If using multiple chassis, the length dimension increases by approximately 220 mm (8.7 in) for
each additional chassis 8-slot chassis
If using two 8-slot chassis, overall length is approximately 465 mm (18.30 in)
If using three 8-slot chassis, overall length is approximately 685 mm (26.96 in)
If using four 8-slot chassis, overall length is approximately 905 mm (35.62 in)
A 4-slot chassis can serve as an extension chassis, but only as the last chassis in the assembly,
and it adds approximately 134.84 mm (5.309 in) to the length of a one, two or three 8-slot
chassis assembly
Squeeze hard to remove connector covers on the two mating chassis. You may need to use both
hands.
