Introduction
1
1.0 INTRODUCTION
The Liebert IntelliSlot Relay Card (IS-RELAY) provides contact
closure for remote monitoring of alarm conditions in your Liebert unit.
The card is easy to install and integrates with other relay contact
monitoring systems.
This advanced power-management device is designed to function in
units with a Liebert IntelliSlot port. Some examples are:
• Liebert Nfinity™
• Liebert NX™
• Liebert UPStation GXT3™
Visit the Liebert Web site at www.liebert.com for the current list of
supported products.
On supported units, the inverter shut-off command can be controlled
from the computer directly connected to the UPS (via the factory-
installed DB9 connector) and will conserve battery power after the
workstation shutdown is completed.
The Liebert IntelliSlot Relay Card is rated for 24VAC/VDC at 1A.
Inspecting Shipment on Receipt
Upon accepting shipment, inspect the packaging and product for any
damaged or missing parts. If any damage is observed, report it to the
shipping company and your local Emerson Network Power
representative. If any components are missing, contact your local
representative for replacement.
Items included with the shipment are:
• Liebert IntelliSlot Relay Card protected by an anti-static bag
• User manual

Installation
2
2.0 INSTALLATION
Make sure you have the following parts and tools before you begin.
Required Parts and Tools
• Liebert IntelliSlot Relay Card (provided)
• #2 (medium) Phillips or small flathead screwdriver
Instructions
1. Turning off the unit prior to installation is suggested, although
not required.
2. Locate the Liebert IntelliSlot port, which is on the rear of some
units, as shown in the examples below. Refer to the unit’s user
manual for port location and orientation.
3. Remove the two retaining screws from the Liebert IntelliSlot port
cover plate on the unit. Save the screws for reassembly in Step 5.
4. As you insert the card, make sure the holes are aligned with those
on the UPS. Initially, the card should slide in freely as you
carefully align screw holes. As you feel it click into place, press
firmly to ensure solid seating in the slot.
5. Use the screwdriver to secure the Liebert IntelliSlot Relay Card to
the UPS chassis with the two retaining screws removed in Step 3.
Make sure the screws are snug, not tight, to avoid damage to the
device.
Remove
screws
Liebert IntelliSlot
Relay Card

Installation
3
6. Use these guidelines for terminal block specifications:
Proceed to the following sections:
•3.0 - Pin Configuration to configure the terminal blocks.
•4.0 - Jumper Setup to configure the jumpers.
Acceptable Wire Size Wire Strip Length
24-16 AWG 0.24-0.28 in. (6-7mm)

Pin Configuration
4
3.0 PIN CONFIGURATION
The card has two terminals blocks, TB1 (green, numbered 1-9) and
TB2 (black, 10-18), as shown in Figure 1.
Figure 1 Pin location and numbering
Refer to your Liebert product user manual for the pin configuration for
the terminal blocks. The pin functions in Table 1 apply only to the
Liebert units listed in Section 1.0 - Introduction.
Table 1 Relay card pin configuration
Pin Function Operation
1 Common - Low Battery
2 Low Battery Closed if Low Battery point occurs.
3 Low Battery Closed if battery is OK
4 Common - UPS Fault
5 UPS Fault Closed if UPS fault occurs
6 UPS Fault Closed if no UPS failure
7 Common - On Battery
8 On Battery Closed if On Battery power (Utility failure)
9 On Battery Closed if not On Battery power (Utility OK)
10 Signal Ground Use for UPS Any-Mode Shutdown
11 Signal Ground Use for UPS Any-Mode Shutdown
12 UPS Any-Mode Shutdown Turn UPS output Off when shorted
to Pin 10 or 11
13 Summary Alarm* Closed if no alarm conditions are present
14 Summary Alarm* Closed if Summary Alarm occurs
15 Common - Summary Alarm*
16 On UPS Closed if On UPS (inverter) power
17 On Bypass Closed if On Bypass
18 Common - On Bypass
10
189
1
TB1
green
TB2
black

Jumper Setup
5
4.0 JUMPER SETUP
The card has five jumpers, P3 through P7, as shown in Figure 2.
Each jumper connects two pins.
Figure 2 Jumper location and numbering
By default all five jumpers have shunts installed. The two pins are
shunted together to provide the functions shown in Table 2, allowing
relay commons to be tied together.
NOTE: The jumpers should be removed if there is any external volt-
age source that may intentionally or inadvertently be connected to the
relay.
Removing the shunt from any two pins breaks the connection between
the relay commons so they are not tied together.
Table 2 Jumper connections
Jumper Relay
P6 On Battery
P5 UPS Fault
P4 Low Battery
P3 On Bypass
P7 Summary Alarm
Jumper
P6
Jumper
P5
Jumper
P4
Jumper
P3
Jumper
P7
FRONT OF
CARD
