A list of all parts and guidelines for assembling and attaching
both the wheel set and the pull-out-handle on the 4272 lifting bag.
Parts list:
English
edition
(05.06.2018)
Instruction manual for 4272 trolley attachment
Handle - POM 1
Handle bracket - Plastic 1
Wheel bracket - Plastic 1
Wheel - PJO, 150x32 - Ø12,3 2
Pindbolt - A4, 510x13x13 1
Steel bolt - DIN 931, A4, M6x180 1
Buttonhead bolt - ISO 7380-2, A4, M8x25 6
Buttonhead bolt - ISO 7380-2, A4, M8x45 4
Hexagon nut - DIN 985, A4, M6 1
Hexagon nut - DIN 985, A4, M12 2
Shim ring - DIN 988, A2, 6x12x1 2
Shim ring - DIN 125-1, A4, 13x24x2,5 4
Flange nut with serration - DIN 6926, A4, M8 10
Description QTY Picture
1

[email protected] www.emg.dk Phone: [phone]Head oce: John Tranums Vej 60, DK-6705 Esbjerg Ø
• Place the plate for the wheels on one of the
ends and align it in the center of the tool box.
• When the plate is placed start drilling the holes
in the tool box.
• At rst drill the hole in the upper right corner.
• Place a buttonhead bolt in the hole to keep it in
place.
• Now drill the hole in bottom left corner.
• Place a buttonhead bolt in the hole.
• Now the plate will stay in place and we can drill
the last four holes.
• Remove the bolts when all holes have been
drilled.
• Next step before mounting the plate will be
assembling the wheel section.
• The order of all the needed parts must be
placed on the pindbolt as seen on the picture to
the left.
14 25
6
2 x
1 x
4 x2 x
1 x
2 x
78
3
2

[email protected] www.emg.dk Phone: [phone]Head oce: John Tranums Vej 60, DK-6705 Esbjerg Ø
• Make sure the hexagon nuts are tight in each
end.
• Vices could be an ideal helping tool for this
step.
• Turn over the bracket and place the wheel
section inside the groove.
• Make sure the shim rings are evenly
dristributed.
• A shim ring should be placed on each side of
each wheel.
• When done, turn over the bracket and place it
to align with the holes we drilled earlier.
• Insert the buttonhead bolt from inside of the
bag.
• Tighten the ange nut to the end of the bolt
pointing out of the bag.
• Repeat on all six bolts.
6 x6 x
3

[email protected] www.emg.dk Phone: [phone]Head oce: John Tranums Vej 60, DK-6705 Esbjerg Ø
4 x4 x
• The next step is assembling the trolley handle.
• The order of all the needed parts must be
placed on the steel bolt as seen on the picture
to the left.
• The steel bolt must go through the holes in the
bracket and both ends of the handle.
• Make sure the shim rings are evenly
dristributed.
• A shim ring should be placed on each side of
the handle.
• Make sure the nuts and bolts are tight.
• With the handle assembled, place it on the
opposite site of the wheels and align it in center.
• Start drilling the holes.
• Insert the buttonhead bolts from the inside of
the bag and fasten the ange nuts as we did
earlier on the wheel bracket.
• Make sure the nuts and bolts are tight.
1 4
2
5
6
31 x
1 x 2 x
1 x 1 x
