Eminent EM4595 User manual

EM4595
Universal Wi-Fi repeater with WPS

2
|
ENGLISH
EM4595 – Universal Wi-Fi repeater with WPS
Table of contents
1.0 Introduction ...........................................................................................................2
1.1 Packing contents...............................................................................................2
1.2 Device Overview................................................................................................3
2.0 Where to place the EM4595 repeater? ..................................................................5
3.0 Configure the wireless repeater using the WPS button..........................................6
4.0 Connecting a wireless WPS adapter to the EM4595..............................................7
5.0 Configuring the EM4595 manually.........................................................................7
5.1 Manual configuration .........................................................................................7
6.0 Access Point mode..............................................................................................10
7.0 Frequently Asked Questions and other related information..................................12
8.0 Service and support.............................................................................................12
9.0 Warning and points of attention...........................................................................12
10.0 Warranty conditions...........................................................................................14
1.0 Introduction
Congratulations with the purchase of this high-quality Eminent product! This product
has undergone extensive testing by Eminent’s technical experts. Should you
experience any problems with this product, you are covered by Eminent
warranty. Please keep this manual and the receipt in a safe place.
Register your product now on www.eminent-online.com and receive product updates!
1.1 Packing contents
The following parts need to be present in the packing:
•EM4595
•QIG
•Ethernet cable

3
|
ENGLISH
1.2 Device Overview
Front Panel
LABEL
DESCRIPTION
WPS Button
Connect EM4595 to any WPS capable devices (5 sec. to
connect to router/AP or 2 sec. when connecting a wireless
client)
LABEL
STATE
DESCRIPTION
LED Signal strength
3 BARS
Connected
90% and above (Excellent)
2 BARS
Connected
55-89% (Recommended)
1 BAR
Connected
10-54% (Weak)
WPS
Signal Indicator

4
|
ENGLISH
Bottom panel
Side panel
LABEL
DESCRIPTION
RESET
Press the reset button for 5-7 seconds to restore the device
to default factory settings wait approx. 1 minute for the
device to reboot (Signal indicator turns green).
Ethernet port
Connect to computers / Ethernet devices, or modem/router
using as AP
LAN
Reset

5
|
ENGLISH
2.0 Where to place the EM4595 repeater?
The best location to place the EM4595 is approximately half-way between your
wireless router and your wireless computer(s) which has/have the weakest wireless
reception. This way, the signal strength will be as good as possible. Refer to the
following images for an example:
Hint: Before placing the EM4595 on its destined location, the device needs to be
setup. Setting up the EM4595 wireless repeater can be done best, if the EM4595 is
located near your wireless router. After setting up the EM4595, you can place the
EM4595 at a location defined by using the signal indicator LEDs and the
recommended setup as described previously.

6
|
ENGLISH
3.0 Configure the wireless repeater using the
WPS button
1. Please check if your wireless modem/router has a WPS button. Also check
whether your wireless router has a properly configured internet connection.
2. Connect the EM4595 to a wall outlet. Please place the EM4595 close to the
modem/router during setup.
3. Wait for the LED to turn green.
4. Press the WPS button on your wireless router for approximately 3 seconds*.
5. Now press the WPS button on the EM4595 Wireless Repeater for approximately 5
seconds. Refer to the following image for the WPS button:
6. The connection between your wireless router and the EM4595 wireless repeater
will be established automatically (this will take approx. 1 minute including reboot).
The smart led indicator will stop flashing and indicate the signal strength. Wait
until the WiFi led turns blue.
*Refer to the manual of your wireless router for the exact duration of pressing the
WPS button. This can differ from brand or model.
WPS

7
|
ENGLISH
Note: If the WPS button is used, the SSID and network key are the same as used on
your wireless router. Some WPS routers will change their original SSID to another
SSID if WPS is used. In this installation guide, the SSID of the wireless router is
‘Eminent’.
4.0 Connecting a wireless WPS adapter to the
EM4595
1. Press the WPS button on the EM4595 for about 3 seconds.
2. Now press the WPS button on your wireless adapter.
3. The connection between the wireless WPS adapter and EM4595 will be
established. Depending on the Windows version you are using, you should see a
connected icon in the taskbar.
Note: Some wireless WPS adapters require the use of the supplied software to create
a WPS connection. Refer to the manual of your wireless WPS adapter for more
information.
5.0 Configuring the EM4595 manually
It is possible to configure the repeater manually instead of using the WPS button.
5.1 Manual configuration
1. Connect the EM4595 to a wall outlet (preferably close to the modem/router).
2. Wait for the signal indicator to turn green. This will take approximately 1 minute.
3. Connect to the EM4595 via Wi-Fi SSID: Eminent_repeater, or use the Ethernet
cable to connect to the EM4595 directly.
4. Open your internet browser and type http://192.168.10.1 in your internet browser
and then hit Enter.
5. The login screen will appear. Enter the Username: “admin” and Password:
“admin”, then click “Log in” to login.

8
|
ENGLISH
6. The Repeaters menu will appear.

9
|
ENGLISH
7. Make sure Repeater mode is enabled.
8. Click on the Site Survey button.
9. You will see a screen with all the available Wi-Fi networks.
10. Select the corresponding network you want to connect to in the “Select” field.
11. Your router’s Wi-Fi network name will be shown in the Network Name ( SSID )
field.
12. Enter the security key of your wireless network in the Pre-Shared Key field.
13. If you want to ensure easy login to your repeater after connecting to your home
network, you can select the option Auto configure LAN IP address. Your repeater
will now obtain ip address from your router. If you don’t change this option the
repeaters ip address will remain 192.168.10.1.
14. Click on Save/Apply button.
15. The EM4595 will reboot and connect to your router.
16. You can now connect your wireless network adapter(s) to your repeaters Wi-Fi
network name and entering the wireless security key of the wireless network you
previously connected.
Note: After the settings have been applied, the EM4595 will reboot. Your device will no
longer be connected to the wireless network SSID of the EM4595.
11
12
10

10
|
ENGLISH
6.0 Access Point mode
1. Connect the EM4595 to a wall outlet (preferably close to the modem/router).
2. Wait for the signal indicator to turn green. This will take approximately 1 minute.
3. Connect to the EM4595 via Wi-Fi SSID: Eminent_repeater, or use the Ethernet
cable to connect to the EM4595 directly.
4. Open your internet browser and type http://192.168.10.1 in your internet browser
and then hit Enter.
5. The login screen will appear. Enter the Username: “admin” and Password:
“admin”, then click “Log in” to login.
6. The Repeaters menu will appear.
