EMKO PROOP 7 Series User manual

PROOP Quick Start Guide

Preface
PROOP, is designed to provide interaction between the user and the automation systems based on
industrial PLC systems This document will be helpful the user to install and connect PROOP
•Before begin the installation of this product, please read the instruction manual
•For the information of PROOP Builder software and installation, refer to the PROOP Builder user
manual
•The contents of the document may have been updated You can access the most updated version at
www emkoelektronik com tr
This symbol is used for safety warnings User must pay attention to these warnings
General Features
Models PROOP 7’’ SERIES
PROOP-7L PROOP-7L.E PROOP-7C PROOP-7C.E
Displa T pe 7” wide TFT LCD
Displa Colors 260K colors
Resolution 800 x 480
LCD Backlight LED Backlight
Touch Method Resistive Analog
Luminance(cd/m2)300
Backlight life(hours) min 50000 hours at 25°C
MCU ARM Cortex-A7, 528Mhz
Flash Memor 4 GB
RAM 512 MB DDR3 SDRAM
Buzzer >=85 dB
USB Client 1x USB 2 0
USB Host 1x USB 2 0
Seri Com-2 RS-485 (Terminal)
Seri Com-3 RS-232 (Terminal)
Seri Com-4 RS-232 (DB-9 Socket)
Ethernet N/A 10/100 Mbps N/A 10/100 Mbps
Digital Inputs N/A 4x Digitals
Digital Outputs N/A 4x Digitals
Analog Inputs N/A
Analog Outputs N/A
Real time clock (RTC) Built in
Operating Voltage 18…30Vdc
Power Consumption 6W
RTC Batter CR2032 button cell lithium battery, 3V(removable)
RTC Batter Life 5 years
Operating Temperature 0…50°C
Storage Temperature -20…60°C
Operating Humidit 0…90%RH (non condensed)
Dimensions 206 x 152 x 50 mm
Panel Cut-out 196 x 142 mm
Weight 700 g
1 Quick Start Manual EN PROOP 03 V03 05/18

Models PROOP 10’’ SERIES
PROOP-10L PROOP-10L.E PROOP-10C PROOP-10C.E PROOP-10P
Displa T pe 10” wide TFT
Displa Colors 16M colors
Resolution 1024 x 600
LCD Backlight LED Backlight
Touch Method Resistive Analog
Luminance(cd/m2)270
Backlight life(hours) min 50000 hours at 25°C
MCU ARM Cortex-A9, 800Mhz
Flash Memor 4 GB
RAM 512 MB DDR3 SDRAM
Buzzer >=85 dB
USB Client 1x USB 2 0
USB Host 1x USB 2 0
Seri Com-2 RS-485 (Terminal)
Seri Com-3 RS-232 (Terminal)
Seri Com-4 RS-232 (DB-9 Socket)
Ethernet N/A 10/100 Mbps N/A 10/100 Mbps 10/100 Mbps
Digital Inputs N/A 5x Digitals
Digital Outputs N/A 4x Digitals
Analog Inputs N/A 2x 4 20mA
Analog Outputs N/A 2x 4 20mA
Real time clock (RTC) Built in
Operating Voltage 18…30Vdc
Power Consumption 8W
RTC Batter CR2032 button cell lithium battery, 3V(removable)
RTC Batter Life 5 years
Operating Temperature 0…50°C
Storage Temperature -20…60°C
Operating Humidit 0…90%RH (non condensed)
Dimensions 278 x 200 x 50 mm
Panel Cut-out 265 x 186 mm
Weight 1300 g
2 Quick Start Manual EN PROOP 03 V03 05/18

Dimensions
PROOP 7’’ Series
PROOP 10’’ Series
3 Quick Start Manual EN PROOP 03 V03 05/18

Panel Mounting
1- Before mounting the device in your panel, make sure that the cutout is of the right size
2- Check front panel gasket position
3- Insert the device through the cut out
4- Insert the mounting clamps to the holes of device
5- Screw up the fixing screws until the unit completely immobile within the panel
4 Quick Start Manual EN PROOP 03 V03 05/18

Installation
Before beginning installation of this product, please read the instruction manual
and warnings below carefully
A visual inspection of this product for possible damage occured during shipment is recommended before
installation It is your responsibility to ensure that qualified mechanical and electrical technicians install this
product
Do not use the unit in combustible or explosive gaseous atmospheres
Do not expose the unit to direct sun rays or any other heat source
Do not place the unit in the neighbourhood of magnetic equipment such as transformers, motors or
devices which generate interference (welding machines, etc )
To reduce the effect of electrical noise on device, Low voltage line (especially sensor inputcable) wiring
must be separated from high current and voltage line
During the equipment is putted in hole on the metal panel while mechanical installation some metal burrs
can cause injury on hands, you must be careful
Montage of the product on a system must be done with it’s own fixing clamps
Do not do the montage of the device with inappropriate fixing clamps Be sure that device will not fall while
doing the montage
If possible, use shielded cable and shield must be connected to ground only one side
Keep the power off until all of the wiring is completed so that electric shock and trouble with the unit can
be prevented
The digital outputs and supply connections is designed to be isolated from each other
Before commissioning the device, parameters must be set in accordance with desired use
Incomplete or incorrect configuration can cause dangerous stiuations
The unit is normally supplied without a power switch or a fuse Use power switch and fuse as required
Be sure to use the rated power supply voltage to protect the unit against damage and to prevent failure
After the device power on, check power LED lights from on the device screen
If there is danger of serious accident resulting from a failure or defect in this unit, power off the system and
the electrical connection of the device from the system
Never attempt to disassemble, modify or repair this unit Tampering with the unit may results in
malfunction, electric shock or fire
Please contact us in case of an unexpected situation
It is your responsibility if this equipment is used in a manner not specified in this instruction manual
The users should use PROOP Builder software to perform editing in PROOP's product
5 Quick Start Manual EN PROOP 03 V03 05/18

PROOP Builder Program Setup
Please, follow the steps on the below for installation the PROOP Builder Software Program
Step 1:
It is strongly recommended that before proceeding, you ensure that no other Windows programs are
running
Step 2:
Run the setup exe included in the installation package
Step 3:
Continue the installation by following the dialog boxes on the screen and choose where to install
Step 4:
After selecting the default folder, click “Next >” button If necessary, you can retrieve individual steps with
“< Back” button Program will automatically be installed in the default folder
Step 5:
After installation, click “Finish” button in the dialog box on the screen and finish the operation
Step 6:
Click the Windows Start > Programs > Proop Builder shortcut to start the application
6 Quick Start Manual EN PROOP 03 V03 05/18

Pin Connections
Suppl (For PROOP 7 and 10) COM4 (For PROOP 7 and 10)
Terminal Terminal
+ 2- Rx
- 3- Tx
5- GND
7- RTS
8- CTS
COM1 (For PROOP 7) COM2 - COM3 (For PROOP 7)
Terminal Terminal
Rx+ A
Rx- B
Tx+ GND
Tx- Rx
Tx
GND
COM1 - COM2 (For PROOP 10) COM3 (For PROOP 10)
Terminal Terminal
Rx+ Rx
Rx- Tx
Tx+ GND
Tx-
GND
A
B
GND
Digital Inputs/Outputs (For PROOP 7)
Terminal Comment Connection Sheme
DO- Digital Output
Supply -
DO4
Digital Outputs
DO3
DO2
DO1
DO+ Digital Output
Supply +
DI4
Digital Inputs
DI3
DI2
DI1
+/- NPN / PNP Selection of
Digital Inputs
7 Quick Start Manual EN PROOP 03 V03 05/18

Analog/Digital Inputs (For PROOP 10)
Terminal Açıklama Bağlantı Şeması
A2-
Analog Input 2
A2+
A1+
Analog Input 1
A1-
DI5
Digital Inputs
DI4
DI3
DI2
DI1
+/- NPN / PNP Selection of
Digital Inputs
Analog/Digital Outputs (For PROOP 10)
Terminal Açıklama Bağlantı Şeması
AO+ Analog Output
Supply +
AO- Analog Output
Supply -
AO2
Analog Outputs
AO1
DO- Dijital Output
Supply -
DO4
Dijital Outputs
DO3
DO2
DO1
DO+ Dijital Output
Supply +
8 Quick Start Manual EN PROOP 03 V03 05/18

Warrant
This warranty is provided for a period of two years This warranty is in force if duty and responsibilities
which are determined in warranty document and instruction manual performs by the customer completely
Maintenance
Repairs should only be performed by trained and specialized personnel Cut power to the device before
accessing internal parts
Do not clean the case with hydrocarbon based solvents (Petrol, Trichlorethylene etc ) Use of these solvents
can reduce the mechanical reliability of the device
Other Informations
Manufacturer Information:
Emko Elektronik Sanayi ve Ticaret A Ş
Demirtaş Organize Sanayi Bölgesi Karanfil Sk No:616369 BURSA
Phone : [phone]
Fax : [phone]
Repair and maintenance service information:
Emko Elektronik Sanayi ve Ticaret A Ş
Demirtaş Organize Sanayi Bölgesi Karanfil Sk No:616369 BURSA
Phone : [phone]
Fax : [phone]
9 Quick Start Manual EN PROOP 03 V03 05/18
