Empire LS40CBB User manual

Page 1
BIRCH LOGS
�
WARNING
If not installed, operated and maintained
in accordance with the manufacturer's
instructions, this product could expose you
to substances in fuel or from fuel combustion
which can cause death or serious illness.
Please See Our Website For Log Assembly Videos.
WARNING
FIRE OR EXPLOSION HAZARD
If the information in these instructions is
not followed exactly, a re or explosion may
result causing property damage, personal
injury or loss of life.
— Do not store or use gasoline or other
ammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch;
do not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier
from a neighbor’s phone. Follow
the gas supplier’s instructions.
• If you cannot reach your gas
supplier, call the re department.
— Installation and service must be
performed by a qualied installer,
service agency or the gas supplier.
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
LS40CBB Shown
LOG SET MODEL
LS(36,40)CBB
For Use With
DVCT(36,40) Fireplaces
GAS-FIRED
INSTALLATION INSTRUCTIONS
(SEE HOMEOWNER MANUAL FOR OPERATING INSTRUCTIONS)

41605-1-0320Page 2
TABLE OF CONTENTS
SECTION PAGE
LS(36,40)CBB Log Sets...............................................................................................................................................3
Log Identication LS(36,40)CBB.............................................................................................................................4 - 5
Log And Ember Placement LS(36,40)CBB ..................................................................................................................6
Log Placement LS(36,40)CBB..............................................................................................................................7 - 22
Master Parts Distributor List.......................................................................................................................................23
How To Order Repair Parts........................................................................................................................................23

41605-1-0320 Page 3
LS(36,40)CBB - LOG SETS
LS40CBB - LOG SET
LS36CBB - LOG SET

41605-1-0320Page 4
PART NO. &
DESCRIPTION
LS36CBB
PART NO. &
DESCRIPTION
LS40CBB
TOP VIEW FRONT VIEW
R12966
Top View
Middle
Ember Bed 1
R12980
Front View
Ember Bed 1
R12967
Top View
Left Rear
Ember Bed 2
R12981
Front View
Ember Bed 2
R12968
Top View
Right Rear
Ember Bed 3
R12982
Front View
Ember Bed 3
R12969
Top View
Log (A)
R12983
Front View
Log (A)
R12970
Top View
Log (B)
R12984
Front View
Log (B)
R12971
Top View
Log (C)
R12985
Front View
Log (C)
R12972
Top View
Log (D)
R12986
Front View
Log (D)
LOG IDENTIFICATION - LS(36,40)CBB

41605-1-0320 Page 5
LOG IDENTIFICATION - LS(36,40)CBB
PART NO. &
DESCRIPTION
LS36CBB
PART NO. &
DESCRIPTION
LS40CBB
TOP VIEW FRONT VIEW
R12973
Top View
Log (E)
R12987
Front View
Log (E)
R12974
Top View
Log (F)
R12988
Front View
Log (F)
R12975
Top View
Log (G)
R12989
Front View
Log (G)
R12976
Top View
Log (H)
R12990
Front View
Log (H)
R12977
Top View
Log (I)
R12991
Front View
Log (I)
R12978
Top View
Log (J)
R12992
Front View
Log (J)

41605-1-0320Page 6
LOG AND EMBER PLACEMENT LS(36,40)CBB
NOTE: Install liners before logs. See separate Liner Installation
manual for details.
CAUTION
Do not handle these logs with your bare hands. Always
wear gloves to prevent skin irritation from ceramic bers.
After handling the logs, wash your hands gently with soap
and water to remove any trace of bers.
Accessing the Interior of the Fireplace
See Homeowners Manual for instruction on how to remove the
barrier screen and glass door.
Log Set Installation
The positioning of the logs is critical to the safe and clean
operation of this replace. Sooting and other problems may result
if the logs are not properly and rmly positioned in the replace.
Please refer to (Figure 1) and the following WARNING when
completing log placement instructions. For step by step log
placement instructions, (See Pages 9 - 24).
WARNING
Failure to position the parts in accordance with this diagram
or failure to use only parts specically approved with this
replace may result in property damage or personal injury.
Figure 1
Burner Pin Location
4
3
5
2
1
6
Figure 2
Glowing Embers Information
1. Carefully separate the ember material into small amounts
(no larger than “dime-size” pieces).
a. Fluffed up pieces of ember material one layer thick
will produce the best ember glow. Do not place more
than one layer of ember material onto the burner.
Excess ember material will decrease the ember
glow effect.
b. Save any remaining ember material for future
applications (as needed).
Figure 3
Video of log installation available on our website at:
www.empirecomfort. com.

41605-1-0320 Page 7
1. Place Ember Bed 1 onto burner base pins (3) and (4) - located between the front and rear burner tubes.
LOG PLACEMENT LS(36,40)CBB
TOP VIEW
FRONT VIEW

41605-1-0320Page 8
2. Place Ember Bed 2 onto burner base pins (1) and (2) - located on left rear of the burner base behind rear burner.
LOG PLACEMENT LS(36,40)CBB (CONT'D)
TOP VIEW
FRONT VIEW

41605-1-0320 Page 9
3. Place Ember Bed 3 on the right rear of the burner base. Align with the angle of the burner tube and Ember Bed 2.
LOG PLACEMENT LS(36,40)CBB (CONT'D)
FRONT VIEW
TOP VIEW

41605-1-0320Page 10
4. Place Decorative Rocks across burner base in front of the burner tube. Do not cover the burner tube ports.
LOG PLACEMENT LS(36,40)CBB (CONT'D)
TOP VIEW
FRONT VIEW

41605-1-0320 Page 11
LOG PLACEMENT LS(36,40)CBB (CONT'D)
5. Place the Glowing Embers on the burner tubes covering all ports.
TOP VIEW
FRONT VIEW

41605-1-0320Page 12
LOG PLACEMENT LS(36,40)CBB (CONT'D)
6. Place Log (A) onto Ember Beds 2 and 3 - located against rear.
FRONT VIEW
TOP VIEW

41605-1-0320 Page 13
LOG PLACEMENT LS(36,40)CBB (CONT'D)
7. Place Log (B) onto the front right pin (6) on burner base and indent on Ember Bed 1 - located on right.
TOP VIEW
FRONT VIEW

41605-1-0320Page 14
8. Place Log (C) onto air shutter box and against right liner – located on far right.
LOG PLACEMENT LS(36,40)CBB (CONT'D)
FRONT VIEW
TOP VIEW

41605-1-0320 Page 15
LOG PLACEMENT LS(36,40)CBB (CONT'D)
9. Place Log (D) onto Logs (A) and (C), resting against rear liner – located on rear right.
TOP VIEW
FRONT VIEW

41605-1-0320Page 16
10. Place Log (E) onto the front left pin (5) on burner base and rests on Ember 1 and left liner – located on far left and under Log (A).
LOG PLACEMENT LS(36,40)CBB (CONT'D)
FRONT VIEW
TOP VIEW

41605-1-0320 Page 17
LOG PLACEMENT LS(36,40)CBB (CONT'D)
11. Place Log (F) onto the pin of Ember Bed 1 and rests on Log (E) – located on center left.
TOP VIEW
FRONT VIEW

41605-1-0320Page 18
FRONT VIEW
TOP VIEW
12. Place Log (G) on oor liner and located by indent on log – located on front left.
LOG PLACEMENT LS(36,40)CBB (CONT'D)

41605-1-0320 Page 19
LOG PLACEMENT LS(36,40)CBB (CONT'D)
13. Place Log (H) on oor liner and rests on Ember Bed 1 – located on front center.
TOP VIEW
FRONT VIEW

41605-1-0320Page 20
14. Place Log (I) on oor liner and rests on Ember Bed 1 - located on front right center.
LOG PLACEMENT LS(36,40)CBB (CONT'D)
FRONT VIEW
TOP VIEW
