Empower BOOST User manual

EmpowerTMBOOST Box Contents*
BOOST Sound Amplier (left, right or pair)
Standard Vented Tip (attached to tubing)
Power Tip Large (to be used if more volume is required)
Package of Size 10 Batteries (yellow tab)
Cleaning Wire (with magnet & brush)
Carrying Case
*Exact contents are determined by quantities ordered.
Step 2: Lower volume
Press and quickly release the bottom of the control switch
several times or until whistling stops. Volume may be set
at full volume upon arrival.
Hint: Partially close battery door until your BOOST is
securely in your ear. Then completely close door to turn on.
Step 3: Place tip in entrance of ear canal
Important: Verify tip is pushed all the way on tubing
before inserting tip in ear. The end of tubing should
be visible through the opening of tip. Otherwise,
tube may detach from tip upon removal.
Hold tubing and back of tip (index nger inside tip and
thumb on outside). Gently place tip in entrance of ear
canal. The wider back of tip will form a seal outside of
entrance to prevent amplied sounds from leaving ear.
Step 1: Insert battery
Remove yellow tab from a size 10 zinc-air battery.
To increase battery life, wait one minute to allow
battery to fully charge before inserting battery.
Gently open battery door with the control switch facing
right. Insert battery positive side (at side) up. Carefully
close battery door. If there is resistance closing door,
the negative side of battery may be up.
The BOOST power is controlled by opening and closing
the battery door. Once the door is closed, your BOOST
will begin to amplify sound and whistle.
Hint: The tapered design of tip accommodates majority of ear
canal sizes. Smaller diameter canals will have less of tip inside canal
entrance. Tips are right and left specic; they curve towards back of head.
1
2
3
4
5
Control Switch
Battery Door
Tubing
Standard Vented Tip
Ear Lock
5
1
3
42
1 min.
WAIT Insert
+ side up
+
-
air
Lowers
Volume
Raises
Volume
2B
2B
Pulling up on top of ear allows
your canal to open slightly to
ease tip into
entrance.
.
Installation Guide
page 1 of 2
v2.0817

Step 4: Place BOOST behind ear
Lift body of BOOST over top of ear. If necessary,
use other hand to hold over tip to secure in place.
Move ear lock into bowl of ear. It may be trimmed
if it is too long for the size of ear.
Replacement Tubes, Tips and Domes
Tube Length:
LONG — 42mm (3B)
STANDARD — 38mm (2B)
SHORT — 34mm (1B)
Tube Conguration:
RIGHT EAR
LEFT EAR
BOOST Care: Tubing and tips need to be replaced every three months for optimal performance.
To attach tubing:
Push new tubing straight on.
To attach tip: Align new tip so vented end is lined up
with ear lock. Push tip over tubing ridges until you
feel tubing ush with opening of tip.
To remove tip:
Pinch front of tip and pull
straight o tubing.
Hint: The origin of the ear lock will be tucked inside of tip.
80% of the adult
population t 38mm
To remove tubing:
Rotate tubing 90°and pull o.
2B
2B
2B
BOOST Body
Ear Lock
2B
2B
2B
þ
top
bottom
vent
ear lock
42 3834
2B
2B
2B
All sizes of tubes, tips and domes are available at EmpowerHearing.com
Power Tip
Large
Average Ear Canal Large Ear Canal Variety Pack
Natural
Sound
Maximum
Output
included
included
Vented Tip
Large
Circular Domes
Open
Vented Tip
Standard
Power Tip
Standard
Circular Domes
Closed
page 2 of 2
www.EmpowerHearing.com [e-mail]
