Emtek Classic Operating instructions

Installation & Programming Guide
Classic & Modern Styles
Electronic Deadbolt Locksets
Classic Style
Modern Style

2
4c
4d
2
3
ITEM NO. DESCRIPTION QTY.
1Key 2
2Outside Trim Plate Assembly 1
3Deadbolt Latch Assembly 2 ⁄”or 2 ¾” Backset 1
4Inside Trim Plate Assembly 1
4a Inside Chassis
1
4b Inside Trim Plate
1
4c
#8-32 x ⁄” Flat Head Machine Screw 2
4d
9V Alkaline Battery 1
5#8-32 x 1½” Flat Head Machine Screw 2
6#8 x ¾”Wood Screw 4
7Strike Plate 1
8Security Plate 1
9#10 x 3”Wood Screw 2
6
5
1
6
8
9
7
4
4b
4a
What’s in the Box

3
2-⁄” or 2-3/4” Backset
2 ⁄” Diameter Bore
⁄” Deep
2 ¼”
1 “ 1” Diameter Edge Bore
2. Door Jamb Prep
1. Door Prep
Preparation
Step 1: Fasten Security Plate using two #10 x 3”Wood Screws (item #9).
Step 2: Fasten Strike Plate using two #8 x ¾”Wood Screws (item #6).
2-3/4"
#10 x 3”Wood Screws
⁄” Deep
2 ¾”
1 ⁄”
¾”
#8 x ¾”Wood Screws
1¼”
1¼” Deep

4
Fasten Latch using two #8 x ¾”Wood Screws (item #6).
2. Remove Screws from Inside Trim Plate
1. Install Latch
How to Install
!
REMOVE INSIDE CHASSIS FROM TRIM PLATE
BEFORE INSTALLING THE OUTSIDE TRIM.
THUMBTURN MUST BE IN UNLOCKED POSITION.
Unlocked Locked
THE LATCH ASSEMBLY MUST BE ORIENTED
AS SHOWN AND THE BOLT MUST BE IN THE
RETRACTED POSITION FOR INSTALLATION.
!
Use a Phillips head screwdriver to remove screws (item #4c) shown below and detach Inside Trim
Plate from the Inside Chassis.
Crosshairs
at bottom.
screws
(item #4c)

5
3. Install Outside Trim Plate Assembly
4. Install Inside Chassis
Position the Outside Trim Plate Assembly through the bore hole.
!
ONCE POSITIONED,
OUTSIDE TRIM PLATE
ASSEMBLY REQUIRES
SUPPORT.
HOLE FOR FLAT
SHAFT MUST BE IN
VERTICAL POSITION
FOR INSTALLATION.
!
Step 1: Conrm the position of Flat Shaft.
√ Correct for Installation.
X Incorrect for Installation.
Fit Flat Shaft
through latch.
Flat Shaft must be
in vertical position
for installation.
Feed wire harness
through the bore hole.

6
4. Install Inside Chassis
Step 2: Feed the Wire Harness through Inside Chassis.
Step 3: Fasten Inside Chassis using two #8-32 x 1½” Flat Head Machine Screws (item #5).
CHECK ALIGNMENT BEFORE
FULLY TIGHTENING SCREWS.
!

7
A
B
Step 4: Connect Wire Harness (A) and tuck Connectors as shown (B).
Step 5: Install Battery.
For optimal performance, always use a good quality battery.
9V Battery

8
*Unlocked position is required for installation and removal of the Inside
Trim Plate Assembly.
*Unlocked
Correct for installation
Locked
Screws (item #4c)
Incorrect for installation
!
!
THUMBTURN MUST BE IN
UNLOCKED POSITION FOR
INSTALLATION.
USER CODES
ARE LOCATED
ON THE INSIDE
TRIM PLATE &
ON PAGE 11.
Inside
5. Install Inside Trim Plate
Fasten Inside Trim Plate using two #8-32 x ⁄” Flat Head Machine Screws
(item #4c).

9
Your Emtek lock is shipped with two 4-digit user codes and a 6-digit programming code.
These codes are randomly generated at the factory.
(Turn to next page for Programming Instructions.)
Your Lock is Ready to Use
How to Use
1
2
EMTE K
2
1
EMTE K

10
How to Program
Programming Your Lock
In order to perform each of the following six functions, the lock must rst be placed in Programming
Mode:
*If no input within 10 seconds, Yellow LED goes out, Red LED ashes and lock exits Programming Mode.
1. Press and hold EMTEK button for 3 seconds
2. Yellow LED ashes, then remains solid*, number keys also illuminate
3. Enter Programming Code
4. Yellow LED ashes, then 1 beep
5. Yellow LED remains solid (awaiting button press; see following Table)
Ifyou wIsh to Press
Button
ActIons IndIcAtors
Change
Programming
Code
(6 digits)
1Enter New
Programming
Code
(6 digits)
Re-Enter
New
Programming
Code
(6 digits)
• 1 Green LED ash
• 1 beep
• 1 Green LED ash
• 1 beep
• 2 Green LED ashes
• 2 beeps
Add User Code
(4 digits)
(Store up to 20
User Codes)
2Enter New
User Code
(4 digits)
Re-Enter
New User
Code
(4 digits)
• 1 Green LED ash
• 1 beep
• 1 Green LED ash
• 1 beep
• 2 Green LED ashes
• 2 beeps
Delete User Code 3Enter User
Code to be
Deleted
Re-Enter
User Code to
be Deleted
• 1 Green LED ash
• 1 beep
• 1 Green LED ash
• 1 beep
• 2 Green LED ashes
• 2 beeps
**Enable/Disable
All User Codes
4Entering ‘4’ disables all Users
(enables all if disabled)
• 2 Green LED ashes
• 2 beeps
Delete All User
Codes
5Re-Enter Programming Code • 1 Green LED ash
• 1 beep
• 2 Green LED ashes
• 2 beeps
Turn Beeper
On/Off
6Entering ‘6’ turns OFF (or ON) • 1 Green LED ash
• 1 beep
• 2 Green LED ashes
• 2 beeps
**Also referred to as “vacation mode”. This command temporarily disables all user codes (metal key override will still work).

11
U.S. patents:
8,176,761
8,141,400
Canadian patents:
2,698,041
2,789,278
2,789,280
Restoring the Lock to Factory Default Setting
This procedure clears the lock of all users and restores the
Programming Code and 2 User Codes shipped with the lock.
Function Indicators
Valid Code • 1 short beep, EMTEK button ashes
Green.
Invalid Code/Access Denied* • 1 Red LED ash
• 2 short beeps
Lock-Out Mode Error • 2 short beeps
• 1 short beep per second for duration
Access Accepted • 1 short beep
• 1 Green LED ash
Low Battery • 4 Red LED ashes
• 4 short beeps
Blackout Battery** • 1 long Red LED ash
• 4 long beeps
Button Press Accepted • 1 Yellow LED ash
• 1 Short Beep
Outside Thumb Turn Enabled • 2 Green LED ashes
* If 3 consecutive incorrect codes are entered, the lock emits 4 short beeps and a ashing Red EMTEK button. The lock will not accept
additional input for 20 seconds (20 beeps). When the next valid code is entered the lock will beep quickly 10 times to alert of the
incorrect codes.
** Battery voltage has dropped too low; keypad will be disabled but metal key override will still work.
Keypad Operation - Beeper & LED Indicators

Copyright © Emtek Products, ASSA ABLOY Residential Group Inc. DBA Emtek Products, 2021
Reproduction in whole or in part without the express written permission of Emtek Products is prohibited.
IN8-MODKEYPADDB
Emtek Products
Tel: [phone] • 626-961-0413
Fax: [phone] • 626-336-2812
emtek.com
10/13/2021
