Enable-IT 828WP User manual

Enable-IT 828WP Weatherproof
Professional Grade Ethernet Extender Kit
Quickstart Guide
All Rights Reserved © 1997 - 2020 Enable-IT™, Inc.

INSTALLING THE 828WP WEATHERPROOF EXTENDER KIT
Installation
The Enable-IT 828WP – A Dual Output PoE and Gigabit Extended Ethernet Unit has a distance
restriction of 800ft or 240m over 4-pair Category 5e or higher spec rated wiring. Multiple 828 units
can be daisy chained to reach up to 2,000ft or 1,828m. For the 828WP daisy chain use additional
828W units.
•Total distance limitation of 800ft or 240m from end to end per 828 unit.
•4-pair CAT 5e .24 AWG or better cabling is required for Gigabit throughput.
•Wire pairs used must be straight through, no taps/connection points.
Perform an Out Of The Box Test (OOTBT)
We highly recommend that you perform a quick test to ensure the working order of
your Enable-IT 828WP Weatherproof Ethernet Extender units prior to installing.
This will also serve to familiarize you with how easy the process should be. Using a
Ethernet patch cord attach the 360 PoE Injector (Power & Data Out jack) to the 828WP
left side (single port) sealed jack as shown below in the diagram.
Next use another Ethernet patch cord to connect one of the 828WP right side (dual
ports) jack to your PoE device. Using the power cord, power up the 360 Injector. The
left side Green Power LEDs will turn on and all Yellow Link LEDs will flicker for LAN
traffic activity. This confirms basic proper operation of the units.
For a more detailed test and to confirm your LAN Equipment works with the 828WP
units, connect your Ethernet LAN to the PoE injector LAN in port and then test LAN
port and test connectivity all the way end to end.
Performing the On-Site Installation
After removing the Enable-IT 828WP Weatherproof Ethernet Extender Kit from the box, and
performing the Out Of The Box Testing (OOTBT), all that remains to install the unit on-site is
to mount the unit, attach the LAN device cabling through the open end screw caps, use the
grey sealant around the inserted Ethernet RJ45 LAN cable (inside the screw cap) and
securely tighten the screw caps.
All Rights Reserved © 1997 - 2020 Enable-IT™, Inc. Page of2 6

Mounting the Enable-IT 828WP Weatherproof Ethernet Extender Units
The Enable-IT 828WP Weatherproof extended Ethernet solution is designed for quick wall
mounting. Choose a location to mount each of the Enable-IT 828WP Weatherproof’s where
the maximum distance does not exceed 400ft or 121m from the 360 PoE injector and or the
end PoE device or next 828W unit - (See diagram below). When wall-mounting the Enable-IT
828WP Weatherproof unit it is recommended that you use the appropriate screw anchors for
your mounting surface. If mounting on existing plywood use wood screws; if mounting onto
drywall or sheetrock, use plastic drywall anchors to secure your installation.
TECHNICAL SUPPORT
Enable-IT, Inc.’s Customer Care Team support is available directly to customers and distributors. All
support requests are processed through the online support portal. This allows us to provide
assigned support ticket numbers in order to bring closure to any technical issues.
Online Technical Services
The Enable-IT Support Portal is available 24/7 to open a ticket or check the status of one. Please
use this support website as your first source for help as it contains an on-line knowledge base of
articles, documentation, FAQ's and other problem-solving resources. This web-based support
resource provides the quickest solution to the most common technical support issues.
World Wide Web Site
https://support.enableit.com
Returning Products for Warranty Repair
Enable-IT warrants to the original purchaser of the Product ("you" or the "End User") that, for
the limited lifetime period commencing on the date the Product was purchased (the “Warranty
Period"), the Product will be substantially free from defects in materials and workmanship under
normal use and conditions. This warranty does not apply to Products, which are resold as used,
repaired or reconditioned. Electrical or water damage is not covered under this warranty,
extended warranties or Advanced Replacement Program (AREP).
All Rights Reserved © 1997 - 2020 Enable-IT™, Inc. Page of3 6

In order to obtain an authorized RMA approval, the End User must complete the required
information online located at https://support.enableit.com Ifyouhavequestionsordifficulty
completing this information you may contact the Customer Care Team at 888-309-0910 between
the hours of 8:00 a.m. and 5:00 p.m. PT.
Please ship Authorized RMAs to:
RMA Warranty Repair Processing Facility
16027 Brookhurst St, Suite G272
Fountain Valley, CA 92708-1551
Returning Products for Refund
Enable-IT, Inc. offers a generous 45-Day refund on a single Ethernet Extender Kit only, and is
subject to a 15% Restocking Fee. Shipments without a valid or authorized RMA number, or
sent to our corporate Las Vegas address, can be refused and / or billed for additional
shipping.
ENABLE-IT, INC. LIMITED LIFETIME WARRANTY
Enable-IT, Inc. warrants this described product solely pursuant to the following terms and conditions.
1.ENABLE-IT PRODUCT WARRANTY.
a. Express Warranty.
Enable-IT warrants to the original purchaser of the Product ("you" or the "End User") that, for the
limited lifetime period commencing on the date the Product was purchased (the “Warranty Period"),
the Product will be substantially free from defects in materials and workmanship under normal use
and conditions. This warranty does not apply to Products, which are resold as used, repaired or
reconditioned.
Electrical or water damage are not covered under this warranty, extended warranties
or Advanced Replacement Program (AREP).
Enable-IT does not make any warranty with respect to any third party product, software or
accessory supplied with or used in connection with the Product and such third party products,
software and accessories, if any, are provided "AS IS." Warranty claims related to such third party
products, software and accessories must be made to the applicable third party manufacturer.
b. Remedies for Breach of Warranty.
In the event of a breach of the foregoing warranty, Enable-IT will, in its sole discretion and at
its cost, and subject to the terms of the following paragraph, repair the non-conforming
Product, replace the non-conforming Product with a new or reconditioned Product or refund
the purchase price for the Product. Any new or reconditioned Product provided pursuant to
this paragraph is warranted as provided herein for the remainder of the original Warranty
Period. THE REMEDY SET FORTH IN THIS PARAGRAPH SHALL BE THE END USER’S
SOLE AND EXCLUSIVE REMEDY FOR BREACH OF THE FOREGOING WARRANTY.
All Rights Reserved © 1997 - 2020 Enable-IT™, Inc. Page of4 6

c. Conditions for Warranty Qualification.
If authorized by Enable-IT to return a Product which does not conform to the warranty set
forth above, the End User must: (1) obtain a return materials authorization (RMA) number
from Enable-IT by contacting the Customer Service Dept. at 888-309-0910 between the
hours of 7:00 a.m. and 5:00 p.m. PST and otherwise fully comply with Enable-IT’s then-
current RMA policy; (2) return the Product to Enable-IT in its original packaging freight pre-
paid; and (3) provide to Enable-IT the original receipt or bill of sale establishing the date on
which the Product was purchased. Products returned to Enable-IT without an RMA number
will be returned to the End User. Enable-IT shall not be responsible for damage or loss
during shipment of the returned Product to Enable-IT.
d. Voiding of Warranty.
The express warranty set forth above shall not apply to failure of the Product if the Product
has been subjected to: (i) physical abuse, misuse, improper installation, abnormal use,
power failure or surge, or use not consistent with the operating instructions provided by
Enable-IT; (ii) modification (including but not limited to opening the Product housing) or repair
by any party in any manner other than as approved by Enable-IT in writing; (iii) fraud,
tampering, unusual physical or electrical stress, unsuitable operating or physical conditions,
negligence or accidents; (iv) removal or alteration of the Product serial number tag; (v)
improper packaging of Product returns; or (vi) damage during shipment (other than during
the original shipment of the Product to the End User from Enable-IT, if applicable).
e. Warranty Disclaimers.
THE EXPRESS WARRANTY SET FORTH ABOVE IS IN LIEU OF ALL OTHER
WARRANTIES, WHETHER WRITTEN, ORAL, EXPRESS OR IMPLIED. ENABLE-IT
DISCLAIMS, TO THE MAXIMUM EXTENT PERMITTED BY LAW, THE IMPLIED
WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR
NONINFRINGEMENT OF THIRD PARTY RIGHTS. NO PERSON (INCLUDING WITHOUT
LIMITATION, ENABLE-IT’S EMPLOYEES, AGENTS, RESELLERS, OEMS OR
DISTRIBUTORS) IS AUTHORIZED TO MAKE ANY OTHER WARRANTY OR
REPRESENTATION CONCERNING THE PRODUCT. IF THE DISCLAIMER OF ANY
IMPLIED WARRANTY IS NOT PERMITTED BY LAW, THE DURATION OF ANY SUCH
IMPLIED WARRANTY IS LIMITED TO ONE (1) YEAR FROM THE DATE OF PURCHASE.
SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OF IMPLIED WARRANTIES
OR LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY MAY LAST, SO SUCH
LIMITATIONS OR EXCLUSIONS MAY NOT APPLY. THIS WARRANTY GIVES THE END
USER SPECIFIC LEGAL RIGHTS AND THE END USER MAY ALSO HAVE OTHER
RIGHTS, WHICH VARY FROM JURISDICTION TO JURISDICTION. ENABLE-IT DOES
NOT WARRANT THAT THE OPERATION OF THE PRODUCT WILL BE
UNINTERRUPTED
OR ERROR FREE. ENABLE-IT IS NOT RESPONSIBLE FOR ANY DAMAGE TO OR
LOSS OF ANY PROGRAMS, DATA, OR OTHER INFORMATION STORED ON OR
TRANSMITTED USING THE PRODUCT.
All Rights Reserved © 1997 - 2020 Enable-IT™, Inc. Page of5 6

2. LIMITATION OF LIABILITY.
IN NO EVENT SHALL ENABLE-IT BE LIABLE TO THE END USER, OR ANY THIRD PARTY, FOR
ANY INDIRECT, SPECIAL, PUNITIVE, INCIDENTAL OR CONSEQUENTIAL DAMAGES IN
CONNECTION WITH OR ARISING OUT OF THE SALE OR USE OF THE PRODUCT
(INCLUDING BUT NOT LIMITED TO LOSS OF PROFIT, USE, DATA, OR OTHER ECONOMIC
ADVANTAGE), HOWEVER IT ARISES, INCLUDING WITHOUT LIMITATION BREACH OF
WARRANTY, OR IN CONTRACT OR IN TORT (INCLUDING NEGLIGENCE), OR STRICT
LIABILITY, EVEN IF ENABLE-IT HAS BEEN PREVIOUSLY ADVISED OF THE POSSIBILITY OF
SUCH DAMAGE AND EVEN IF A LIMITED REMEDY SET FORTH IN THIS AGREEMENT FAILS
OF ITS ESSENTIAL PURPOSE. IN NO EVENT SHALL ENABLE-IT’S LIABILITY TO THE END
USER, OR ANY THIRD PARTY, EXCEED THE PRICE PAID FOR THE PRODUCT. BECAUSE
SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR
CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATIONS MAY NOT APPLY
TO THE END USER.
3. LICENSE AND LIMITATIONS.
The firmware and software embedded in the Product (the "Embedded Software") are licensed to
you. Your use of the Product is your acceptance of the warranty terms above and the terms below.
You may use the Embedded Software solely in conjunction with your use of the Product. All
worldwide right, title and interest in and to the Product, or any portion thereof (including but not
limited to the Embedded Software), including all copyrights, patent rights, trademarks, trade
secrets, and other intellectual property rights therein and thereto, are and shall remain the exclusive
property of Enable-IT and/or its licensors. You acknowledge and agree that you may not, and may
not allow any third party to, (i) use the Embedded Software in a manner that is inconsistent with the
above express right granted to you or (ii) modify, distribute, reproduce, decompile, disassemble,
reverse engineer or otherwise attempt to discover the source code for the Embedded Software.
CONTACT US
Sales and Customer Care:
Toll Free US and Canada 888 309-0910
866 389-8605 Fax
Other International [phone]
[phone] Fax
E Mail [email protected]
[email protected]
RMA Support:
https://support.enableit.com
All Rights Reserved © 1997 - 2020 Enable-IT™, Inc. Page of6 6
