Endon EL- 40101 User manual

The Light pack contains:
IP54 rated led Wall light.
The following tools may be required:
Selection of cross and flat head screwdrivers.
Electric drill and assorted drill bits.
Wire strippers.
Electrical insulation tape.
INSTRUCTION MANUAL
This product is only suitable for connection to a 240V~50Hz supply.
It is recommended that this wall light is installed by a qualified electrician in accordance with current IEE
Wiring Regulations and local Building Regulations and is for the Domestic environment only.
The light fitting should be connected to a lighting circuit protected by a 5 amp fuse (or a 6 amp miniature
circuit breaker).
This light has an IP54 rating suitable for use outdoors.
Run supply wire from a 5-amp electrical supply using double insulated 3-core cable of type H05RN-F 1.0mm2
(not supplied) to selected site, ensuring it is adequately protected through the full length of the cable run, it
must come out of the mounting surface in line with the entry to the fitting.
Except where installed in a conduit or duct , which provides equivalent protection against mechanical damage,
a cable buried in the ground shall incorporate an earthed armour or metal sheath or both, suitable for use as a
protective conductor, or be of insulated concentric construction. Buried cables shall be marked by cable
covers or a suitable marking tape. Buried conduits and ducts shall be suitably identified. Buried cables,
conduits and ducts shall be at a sufficient depth to avoid being damaged by any reasonably foreseeable
disturbance of the ground.
This product contains breakable parts – be careful during handling and maintenance to avoid breakage.
These fittings use none-replaceable LED`s.
If any part of the (LED) housing is broken or cracked then it cannot be replaced and the fittings must not be
used - as the water ingress protection has been compromised.
Clean using a dry cloth only – do not use liquid or abrasive cleaners.
If any modification is made it will invalidate the warranty and may render the product unsafe.
Before you start
Please read these instructions carefully before fitting your new light and retain for reference.
Switch off the mains supply and remove the appropriate fuse or switch off the appropriate circuit breaker
before commencing installation.
Ensure that no one else has access that would enable the supply to be inadvertently reconnected.
Check the packaging and make sure that you have all the required parts.
Follow each assembly step in order to prevent incorrect assembly
Make sure all screws / nuts, including electrical connections etc are fully tightened before use.
AS THESE LEDs ARE NOT DIMMABLE, DO NOT CONNECT THIS PRODUCT TO A DIMMER SWITCH.
EL- 40101 - Outdoor led wall fitting.
Safety Warnings

Endon Lighting
LS9 0SE
20150929
These assembly diagrams are intended as a guide – if in doubt consult a qualified electrician.
Assembly / user instructions
U130 104
Diagram A
Diagram B
1. Determine the position
of your light fitting. Make
sure there is sufficient
cable coming out of the
wall to connect to the
terminal block. Ensure
that the mounting
surface is solid,
preferably a brick or
block wall and ensure
that there are no other
cables or pipes beneath
the surface.
2. Diagram A. Remove the
back pate bracket by
undoing the 4 bracket
grub screws as shown.
3. Diagram B. Use the
back plate bracket as a
template and mark the 2
fixings holes, making
sure the back plate is the
correct way up and the
top of it is horizontal.
Drill and plug the
mounting surface.
4. Bring the incoming
mains cable through the
grommet in the back
plate and then use
appropriate fixings to
secure the back plate to
the wall. The terminal
block can be removed
from the back plate for
ease of wiring to the
mains.
5. Diagram C. Connect the
mains wiring to the
internal terminal block
(A) – see wiring details.
The cable entry grommet
and any seals must be
securely in place to
ensure that the water
ingress protection is
maintained. NOTE: This
is a Class I fitting and
must be earthed.
6. Fit the front frame over
the back plate and
secure with the 2 grub
screws removed in 2
above. Take care not to
trap or strain the internal
cables.
7. Turn on the power and
test.
Back
plate
bracket
Incoming mains
cable
WIRING DETAILS
Bracket
screw
(A)
Bracket
screw
Mounting
screws
Terminal Block
taken off back
plate
Diagram C
