Endon Canillo User manual

The Light pack contains:
IP44 rated floor standing light.
The following tools may be required:
Selection of cross and flat head screwdrivers.
Electric drill and assorted drill bits.
Wire strippers.
Electrical insulation tape.
INSTRUCTION MANUAL
These products are only suitable for connection to a 240V~50Hz supply.
It is recommended that these floor standing lights are installed by a qualified electrician in accordance with
current IEE Wiring Regulations and local Building Regulations and are for the Domestic environment only.
These light fittings should be connected to a lighting circuit protected by a 5 amp fuse (or a 6 amp miniature
circuit breaker).
These lights have an IP44 (splash proof) rating suitable for use outdoors.
Run supply wire from a 5-amp electrical supply using double insulated 3-core cable of type H05RN-F 1.0mm2
(not supplied) to selected site, ensuring it is adequately protected through the full length of the cable run, it
must come out of the mounting surface in line with the entry to the fitting and should be at least 250mm in
length.
Except where installed in a conduit or duct , which provides equivalent protection against mechanical damage,
a cable buried in the ground shall incorporate an earthed armour or metal sheath or both, suitable for use as a
protective conductor, or be of insulated concentric construction. Buried cables shall be marked by cable
covers or a suitable marking tape. Buried conduits and ducts shall be suitably identified. Buried cables,
conduits and ducts shall be at a sufficient depth to avoid being damaged by any reasonably foreseeable
disturbance of the ground.
This product contains breakable parts – be careful during handling and maintenance to avoid breakage.
The shade can become hot in use. Switch off and allow 10 minutes to cool before cleaning.
If any part of the bulb housing is broken or cracked then it must be replaced immediately to preserve the water
ingress protection, please consult your retailer. This is represented by the symbol
These products contain breakable parts – be careful during handling and maintenance to avoid breakage.
If any modification is made it will invalidate the warranty and may render the products unsafe.
Before you start
Please read these instructions carefully before fitting your new light and retain for reference.
Switch off the mains supply and remove the appropriate fuse or switch off the appropriate circuit breaker
before commencing installation.
Ensure that no one else has access that would enable the supply to be inadvertently reconnected.
Ensure that there are no cables / pipes beneath the surface (other than the supply cable for this fitting).
The mounting surface must be secure and able to accommodate the weight / height of the fitting. If installing on an
existing secure (concrete) base, use the holes in the post base as a template to drill suitable fixing holes and prepare
with suitable ground fixing bolts (not supplied).The supply cable (at least 250mm) must come out of the mounting
surface and directly into the terminal block in the base/post of the fitting.
Check the packaging and make sure that you have all the required parts.
Follow each assembly step in order to prevent incorrect assembly
Make sure all screws / nuts, including electrical connections etc are fully tightened before use.
67699/67700 - Canillo Outdoor post/bollard fittings.
Safety Warnings

1. Diagram A. Determine the
position of your light fitting.
Ensure there is sufficient power
cable to connect to the fitting –
we recommend at least 250mm.
Ensure that the mounting surface
is solid. If you are using anchor
bolts (not supplied) prepare the
mounting surface as appropriate
(and ensure that there are no
other cables or pipes beneath the
surface).
2. Place the base of the light fitting
over the cable and use it as a
template to mark the mounting
hole positions. Drill and plug the
holes ready to mount the fitting
later.
3. Diagram B. Pull the terminal
block assembly out of the base of
the fitting. Remove the cable
clamp and take the lid off the
terminal block housing to expose
the internal terminal block.
4. Connect the house wiring to the
internal terminal block. NOTE:
This is a Class I fitting and
must be earthed. Connect the
incoming mains as per the
WIRING DETAILS diagram
5. Re-fit the terminal block into its
housing and secure – ensuring
that all seals are correctly
located.
6. Secure the cable clamp over the
incoming cable and then push the
terminal block assembly fully
inside the base / stem.
7. Secure the post (screws / bolts
etc not supplied) to the mounting
surface making sure that all
cables are contained inside the
fitting.
8. Unscrew the lid and fit the bulb.
Max. 3.5W GU10. When
changing a bulb, always switch
off at the mains and allow the
bulb to cool before handling.
Dispose of used bulbs carefully.
Do not exceed the wattage stated
or use a different shape bulb from
that indicated on the fitting.
9. Re-fit the lid. Ensure the rubber
seal is in place for ingress
protection. Do not overtighten.
10. Turn on the
power and test.
These assembly diagrams are intended as a guide – if in doubt consult a qualified electrician.
Assembly / user instructions
Endon Lighting
Leeds
UK
LS9 0SE
67699_67700 Canillo-FL-20151222
