Endon YG- 8002 User manual

The Light pack contains:
Short Post Lantern with integral terminal block.
The following tools may be required:
Selection of cross and flat head screwdrivers.
Electric drill and assorted drill bits.
Wire strippers.
Electrical insulation tape.
INSTRUCTION MANUAL
This product is only suitable for connection to a 240V~50Hz supply.
It is recommended that this light is installed by a qualified electrician in accordance with current IEE
Wiring Regulations and local Building Regulations.
The light fitting should be connected to a lighting circuit protected by a 5 amp fuse (or a 6 amp
miniature circuit breaker).
This light has an IP44 (splash proof) rating suitable for use outdoors.
Run supply wire from a 5-amp electrical supply using double insulated 3-core cable of type
H05RN-F1.0mm2(not supplied) to selected site, ensuring it is adequately protected through the full
length of the cable run, it must come out of the flat surface of the mounting surface in line with the
entry to the fitting.
Except where installed in a conduit or duct , which provides equivalent protection against
mechanical damage, a cable buried in the ground shall incorporate an earthed armour or metal
sheath or both, suitable for use as a protective conductor, or be of insulated concentric
construction. Buried cables shall be marked by cable covers or a suitable marking tape. Buried
conduits and ducts shall be suitably identified. Buried cables, conduits and ducts shall be at a
sufficient depth to avoid being damaged by any reasonably foreseeable disturbance of the ground.
This product contains breakable parts – be careful during handling and maintenance to avoid
breakage.
If the cover is broken or cracked then it must be replaced immediately to preserve the water ingress
protection, please consult your retailer. This is represented by the symbol
When fixing to the mounting surface ensure that the fixings used are appropriate for the mounting
surface on which they are being used and that the mounting surface is level and secure.
If any modification is made it will invalidate the warranty and may render the product unsafe.
Before you start
Please read these instructions carefully before fitting your new light and retain for reference.
Switch off the mains supply and remove the appropriate fuse or switch off the appropriate circuit
breaker before commencing installation.
Ensure that no one else has access that would enable the supply to be inadvertently reconnected.
Ensure that there are no cables / pipes beneath the surface (other than the supply cable for this
fitting).
Check the packaging and make sure that you have all the required parts.
Follow each assembly step in order to prevent incorrect assembly
Make sure all screws / nuts, including electrical connections etc are fully tightened before use.
YG- 8002 Short Post Lantern.
Safety Warnings

Endon Lighting
LS9 0SE
These assembly diagrams are intended as a guide – if in doubt consult a qualified electrician.
Assembly / user instructions
20150309 W28 24
Diagram A
Diagram B
Diagram C
1. Determine the position of
your light fitting. Ensure
that there is sufficient
power cable to connect
to the fitting – we
recommend at least
20cm.
2. Diagram A. Locate the
terminal block bracket
inside the (short) post.
3. Diagram B. Connect the
mains supply cable to the
internal terminal block –
see wiring details.
IMPORTANT: This is a
Class I fitting and
MUST be earthed.
4. Diagram C and D.
Secure the post to the
mounting surface making
sure that the internal
cables are not trapped or
damaged. Fit the bulb –
never fit bulbs of a
higher wattage or of a
type other than those
specified on the label
as this may cause over
heating and damage
the fitting. Close and
secure the lid.
5. Turn on the power and
test.
Diagram D
