Endress+Hauser Liquiline CM442 User manual

Products Solutions Services
BA00444C/07/EN/17.13
71238290
Valid as of:
Softwareversion 01.05.00
Operating Instructions
Liquiline
CM442/CM444/CM448
Universal four-wire multichannel controller
Field device

Endress+Hauser
Liquiline CM442/CM444/CM448
Table of contents
1 Document information . . . . . . . 5
1.1 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 Symbols used . . . . . . . . . . . . . . . . . . . . . . . 5
1.3 Documentation . . . . . . . . . . . . . . . . . . . . . 6
2 Basic safety instructions . . . . . . 7
2.1 Requirements for personnel . . . . . . . . . . . 7
2.2 Designated use . . . . . . . . . . . . . . . . . . . . . . 7
2.3 Occupational safety . . . . . . . . . . . . . . . . . . 8
2.4 Operational safety . . . . . . . . . . . . . . . . . . . 8
2.5 Product safety . . . . . . . . . . . . . . . . . . . . . . 8
3 Device description . . . . . . . . . . . 9
3.1 Housing closed . . . . . . . . . . . . . . . . . . . . . . 9
3.2 Housing open . . . . . . . . . . . . . . . . . . . . . . . 9
3.3 Device architecture . . . . . . . . . . . . . . . . . 10
4 Incoming acceptance and
product identification . . . . . . . 12
4.1 Incoming acceptance . . . . . . . . . . . . . . . . 12
4.2 Product identification . . . . . . . . . . . . . . . 12
4.3 Scope of delivery . . . . . . . . . . . . . . . . . . . 13
4.4 Certificates and approvals . . . . . . . . . . . 13
5 Installation . . . . . . . . . . . . . . . . 14
5.1 Installation conditions . . . . . . . . . . . . . . 14
5.2 Mounting the measuring device . . . . . . 16
5.3 Post-installation check . . . . . . . . . . . . . . 19
6 Electrical connection . . . . . . . . 20
6.1 Connection conditions . . . . . . . . . . . . . . 20
6.2 Connecting the measuring device . . . . . 23
6.3 Connecting the sensors . . . . . . . . . . . . . . 30
6.4 Connecting additional inputs, outputs or
relays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
6.5 Connecting digital communication . . . . 36
6.6 Hardware settings . . . . . . . . . . . . . . . . . . 40
6.7 Guaranteeing the degree of protection . 40
6.8 Post-connection check . . . . . . . . . . . . . . 41
7 System integration. . . . . . . . . . 42
7.1 Web server . . . . . . . . . . . . . . . . . . . . . . . . 42
7.2 Service interface . . . . . . . . . . . . . . . . . . . . 44
7.3 Fieldbuses . . . . . . . . . . . . . . . . . . . . . . . . . 45
8 Operation options . . . . . . . . . . 46
8.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . 46
8.2 Access to the operating menu via the
local display . . . . . . . . . . . . . . . . . . . . . . . . 47
8.3 Configuration options . . . . . . . . . . . . . . . 48
9 Commissioning . . . . . . . . . . . . . 52
9.1 Function check . . . . . . . . . . . . . . . . . . . . . 52
9.2 Switching on the unit . . . . . . . . . . . . . . . . 52
9.3 Basic setup . . . . . . . . . . . . . . . . . . . . . . . . . 54
10 Operation. . . . . . . . . . . . . . . . . . 55
10.1 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
10.2 General settings . . . . . . . . . . . . . . . . . . . . 58
10.3 Current inputs . . . . . . . . . . . . . . . . . . . . . . 72
10.4 Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
10.5 Binary inputs and outputs . . . . . . . . . . . . 82
10.6 Additional functions . . . . . . . . . . . . . . . . . 90
11 Diagnostics and
troubleshooting . . . . . . . . . . . 119
11.1 General troubleshooting . . . . . . . . . . . 119
11.2 Diagnostic information on the local
display . . . . . . . . . . . . . . . . . . . . . . . . . . 120
11.3 Diagnostic information via web
browser . . . . . . . . . . . . . . . . . . . . . . . . . 120
11.4 Diagnostic information via fieldbus . . 120
11.5 Adjusting diagnostic information . . . . 121
11.6 Overview of diagnostic information . . 124
11.7 Pending diagnostic messages . . . . . . . 127
11.8 Diagnostics list . . . . . . . . . . . . . . . . . . . 127
11.9 Event logbook . . . . . . . . . . . . . . . . . . . . 127
11.10 Simulation . . . . . . . . . . . . . . . . . . . . . . 131
11.11 Reset measuring instrument . . . . . . . 132
11.12 Device information . . . . . . . . . . . . . . . 133
11.13 Firmware history . . . . . . . . . . . . . . . . . 136

Liquiline CM442/CM444/CM448
4
12 Maintenance. . . . . . . . . . . . . . 138
12.1 Calibration . . . . . . . . . . . . . . . . . . . . . . . 138
12.2 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . 139
13 Repair. . . . . . . . . . . . . . . . . . . . 141
13.1 Spare parts . . . . . . . . . . . . . . . . . . . . . . . 141
13.2 Return . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
13.3 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . 144
14 Accessories . . . . . . . . . . . . . . . 145
14.1 Weather protection cover . . . . . . . . . . 145
14.2 Post mounting kit . . . . . . . . . . . . . . . . . 145
14.3 Measuring cable . . . . . . . . . . . . . . . . . . 145
14.4 Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . 146
14.5 Additional functionality . . . . . . . . . . . . 150
14.6 Software . . . . . . . . . . . . . . . . . . . . . . . . . 152
14.7 Other accessories . . . . . . . . . . . . . . . . . 153
15 Technical data . . . . . . . . . . . . 155
15.1 Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
15.2 Digital inputs, passive . . . . . . . . . . . . . . 156
15.3 Current input, passive . . . . . . . . . . . . . 156
15.4 Output . . . . . . . . . . . . . . . . . . . . . . . . . . 157
15.5 Digital outputs, passive . . . . . . . . . . . . 159
15.6 Current output, active . . . . . . . . . . . . . . 160
15.7 Relay outputs . . . . . . . . . . . . . . . . . . . . . 161
15.8 Protocol-specific data . . . . . . . . . . . . . . 162
15.9 Power supply . . . . . . . . . . . . . . . . . . . . . 165
15.10 Performance characteristics . . . . . . . . 167
15.11 Environment . . . . . . . . . . . . . . . . . . . . 168
15.12 Mechanical construction . . . . . . . . . . . 170
16 Installation and operation in
hazardous environment Class I
Div. 2 . . . . . . . . . . . . . . . . . . . . 170
16.1 Environment/properties . . . . . . . . . . . 170
16.2 Control Drawing . . . . . . . . . . . . . . . . . . 171
Index . . . . . . . . . . . . . . . . . . . . 172

Liquiline CM442/CM444/CM448 Document information
Endress+Hauser 5
1 Document information
1.1 Warnings
The structure, signal words and safety colors of the signs comply with the specifications of
ANSI Z535.6 ("Product safety information in product manuals, instructions and other collateral
materials").
1.2 Symbols used
Safety message structure Meaning
DANGER
!
Causes (/consequences)
Consequences of
non-compliance (if applicable)
‣Corrective action
This symbol alerts you to a dangerous situation .
Failure to avoid the situation will result in a fatal or serious
injury.
WARNING
!
Causes (/consequences)
Consequences of
non-compliance (if applicable)
‣Corrective action
This symbol alerts you to a dangerous situation .
Failure to avoid the situation can result in a fatal or serious
injury.
CAUTION
!
Causes (/consequences)
Consequences of
non-compliance (if applicable)
‣Corrective action
This symbol alerts you to a dangerous situation .
Failure to avoid this situation can result in minor or more
serious injuries.
NOTICE
Cause/situation
Consequences of
non-compliance (if applicable)
‣Action/note
This symbol alerts you to situations that can result in damage
to property and equipment.
Additional information, tips
Permitted or recommended
Forbidden or not recommended

Document information Liquiline CM442/CM444/CM448
6Endress+Hauser
1.3 Documentation
As a supplement to these Operating Instructions the following manuals are available on the
CD-ROM:
• Brief Operating Instructions Liquiline CM44x, KA01159C
• Operating Instructions Memosens, BA01245C
– Software description for Memosens inputs
– Calibration of Memosens sensors
– Sensor-specific diagnostics and troubleshooting
• Operating Instructions for HART communication, BA00486C
– Onsite settings and installation instructions for HART
– Description of HART drivers
• Guidelines for communication via fieldbus and web server
– HART, SD01187C
– PROFIBUS, SD01188C
– Modbus, SD01189C
– Web server, SD01190C
The CD also contains:
• Technical Information Liquiline CM44x, TI00444C
• Documentation for other devices in the Liquiline family:
– Liquiline CM44xR (DIN rail device)
– Liquistation CSFxx and Liquiport CSP44 (sampler)
•Simulationsoftware

Liquiline CM442/CM444/CM448 Basic safety instructions
Endress+Hauser 7
2 Basic safety instructions
2.1 Requirements for personnel
‣Installation, commissioning, operation and maintenance of the measuring system must only
be carried out by specially trained technical personnel.
‣The technical personnel must be authorized for the specified activities by the system
operator.
‣Electrical connection must only be carried out by a certified electrician.
‣The technical personnel must have read and understood these Operating Instructions and
must adhere to them.
‣Faults at the measuring point may only be rectified by authorized and specially trained
personnel.
Repairs that are not described in these Operating Instructions must only be carried out
directly at the manufacturer or by the service organization.
2.2 Designated use
2.2.1 Non-hazardous atmosphere
Liquiline CM44x is a multichannel controller for connecting digital sensors with Memosens
technology in non-hazardous environments.
The device is designed for use in the following applications:
• Water and wastewater
• Power stations
• Chemical industry
• Industrial wastewater treatment plants
2.2.2 Ex environment in accordance with FM/CSA Class I Div. 2 (CM442 only) improper
use
‣Pay attention to the control drawing and the specified operating conditions in the appendix
to this manual and follow the instructions.
2.2.3 Non-designated use
Any other use than the one described here compromises the safety of persons and the entire
measuring system and is not permitted.
The manufacturer is not liable for damage caused by improper or non-designated use.

Basic safety instructions Liquiline CM442/CM444/CM448
8Endress+Hauser
2.3 Occupational safety
As the user, you are responsible for complying with the following safety conditions:
• Installation instructions
• Local standards and regulations
Electromagnetic compatibility
The product has been tested for electromagnetic compatibility in accordance with the applicable
European standards for industrial applications.
The electromagnetic compatibility indicated only applies to a product that has been connected
in accordance with the instructions in these
Operating Instructions.
2.4 Operational safety
‣Prior to commissioning the entire measuring point, check that all connections are correct.
Ensure that electrical cables and hose connections are not damaged.
‣Do not operate damaged products, and secure them against unintentional commissioning.
Label and identify the damaged product as being defective.
‣If faults cannot be rectified, the products must be taken out of service and secured against
unintentional commissioning.
CAUTION
!
The cleaning system is not switched off during calibration or maintenance activities
Risk of injury due to medium or cleaning agent
‣If a cleaning system is connected, switch it off before removing a sensor from the medium.
‣If you are not switching off the cleaning system because you wish to test the cleaning
function, wear protective clothing, goggles and gloves or take other appropriate measures.
2.5 Product safety
2.5.1 State of the art
The transmitter is designed to meet state-of-the-art safety requirements, has been tested and
left the factory in a condition in which it is safe to operate.
Relevant regulations and European standards have been observed.
2.5.2 IT security
We only provide a warranty if the device is installed and used as described in the Operating
Instructions. The device is equipped with security mechanisms to protect it against any
inadvertent changes to the device settings.
IT security measures in line with operators' security standards and designed to provide
additional protection for the device and device data transfer must be implemented by the
operators themselves.
Support in the performance of this task can be requested from Endress+Hauser.

Liquiline CM442/CM444/CM448 Device description
Endress+Hauser 9
3Devicedescription
3.1 Housing closed
3.2 Housing open
a0012681
Fig. 1: Mounted on a post
1
2
3
4
5
6
Display
Weather protection cover (optional)
Navigator
Sensor cable or current output cable
Power supply cable
Soft keys, assignment depends on menu
a0016165
Fig. 2: Example of a four-channel device with an open display cover (without wiring)
1
2
3
4
5
Storage slot for SD card
Base module
Extension modules (optional)
Shock protection, dummy cover and end cover
Extension backplane
6
7
8
9
10
Cable mounting rail
Threaded bolt for protective ground connection
Extension power unit with internal cable
M12 connectors for sensor connection (optional)
Display cable

Device description Liquiline CM442/CM444/CM448
10 Endress+Hauser
3.3 Device architecture
3.3.1 Slot and port assignment
a0019832
a0019833
Fig. 3: Slot and port assignment of the hardware modules
Fig. 4: Slot and port assignment on the display
• Inputs are assigned to measuring channels in
ascending order of the slots and ports.
Adjacent example:
If "CH1: 1:1 pH glass" is displayed, this means:
Channel 1 (CH1) is slot 1 (base module) : port 1
(input 1), pH glass sensor
• The outputs and relays are named after their
function, e.g. "Current output", and are displayed with
the slot and port numbers in ascending order

Liquiline CM442/CM444/CM448 Device description
Endress+Hauser 11
3.3.2 Terminal diagram
The unique terminal name is derived from the following:
Slot No. : Port No. : Terminal
Example, NO contact of a relay:
Device with 4 inputs for digital sensors, 4 current outputs and 4 relays
• Base module BASE-E (contains 2 sensor inputs, 2 current outputs)
• Module 2DS (2 sensor inputs)
• Module 2AO (2 current outputs)
•Module4R(4relays)
a0015979
Fig. 5: Creating a terminal diagram taking the example of the NO contact (terminal 41) of a relay

Incoming acceptance and product identification Liquiline CM442/CM444/CM448
12 Endress+Hauser
4 Incoming acceptance and product identification
4.1 Incoming acceptance
1. Make sure the packaging is undamaged.
Inform the supplier about any damage to the packaging.
Keep the damaged packaging until the matter has been settled.
2. Make sure the contents are undamaged.
Inform the supplier about damage to the contents.
Keep the damaged products until the matter has been settled.
3. Check that the delivery is complete and nothing is missing.
Compare the scope of delivery against the delivery papers and your order.
4. Pack the product in such a way as to protect it reliably against impact and moisture for
storage and transportation.
The original packaging offers the best protection.
Keep to the approved ambient conditions (see "Technical data").
If you have any questions, contact your supplier or your local sales center.
4.2 Product identification
4.2.1 Nameplate
Nameplates can be found:
• On the outside of the housing
• On the packaging (adhesive label, portrait format)
• On the inside of the display cover
The nameplate provides you with the following information on your device:
• Manufacturer ID
•Ordercode
• Extended order code
• Serial number
• Firmware version
• Input and output variables
• Protection class
• Ambient conditions
• Activation codes
• Safety notices and warnings
Compare the data on the nameplate with your order.

Liquiline CM442/CM444/CM448 Incoming acceptance and product identification
Endress+Hauser 13
4.2.2 Identifying the product
The order code and serial number of your device can be found in the following locations:
• On the nameplate
• In the delivery papers
To find out the version of your device, enter the order code indicated on the nameplate in
the search screen at the following address:
www.products.endress.com/order-ident
4.3 Scope of delivery
• 1 controller in the version ordered
• 1 mounting plate
• 1 wiring label (attached at the factory to the inside of the display cover)
• 1 CD with Operating Instructions
• 1 printed copy of the Brief Operating Instructions in the language ordered
If you have any questions, contact your supplier or your local sales center.
4.4 Certificates and approvals
4.4.1 CE mark: Declaration of Conformity
With this declaration, the manufacturer guarantees that the product conforms to the
regulations of European Directive 2004/108/EC concerning electromagnetic compatibility and
Low Voltage Directive 2006/95/EC. This is proven by observing the standards listed in the
Declaration of Conformity.
4.4.2 cCSAus
The product meets the requirements of "CLASS 2252 05 - Process Control Equipment" and
"CLASS 2252 85 - Process Control Equipment - Certified to US Standards".
4.4.3 FM/CSA (CM442 only)
FM/CSA Cl. I, Div. 2
The device has been developed and tested according to the following standards:
• FM3600 (1998)
• FM3611 (2004)
• FM3810 (2005)
• ANSI/ISA NEMA250 (1999)
• ANSI/IEC 60529 (2001)
4.4.4 MCERTS
Application has been submitted for CM442

Installation Liquiline CM442/CM444/CM448
14 Endress+Hauser
5Installation
5.1 Installation conditions
5.1.1 Dimensions
a0012396
Fig. 6: Dimensions of field housing in mm (inch)

Liquiline CM442/CM444/CM448 Installation
Endress+Hauser 15
5.1.2 Mounting plate
5.1.3 Weather protection cover (optional)
NOTICE
Effect of climatic conditions (rain, snow, direct sun etc.)
Impaired operation to complete transmitter failure
‣When installing outside, always use the weather protection cover (accessory).
a0012426
Fig. 7: Mounting plate in mm (inch)
a0012428
Fig. 8: Weather protection cover in mm (inch)

Installation Liquiline CM442/CM444/CM448
16 Endress+Hauser
5.2 Mounting the measuring device
You will require the post mounting kit to mount the unit on a pipe, post or railing (circular or
square, clamping range 20 to 61 mm (0.79 to 2.40")). The post mounting kit can be ordered as
an option.
5.2.1 Post mounting
a0012665
Fig. 9: Post mounting
1
2
3
4
Weather protection cover (optional)
Post mounting plate (post mounting kit)
Spring washers and nuts (post mounting kit)
Pipe clamps (post mounting kit)
5
6
7
8
Spring washers and nuts (post mounting kit)
Pipe or post (circular/square)
Mounting plate
Threaded rods (post mounting kit)
a0012666
Fig. 10: Post mounting
a0012667
Fig. 11: Attach the device and click it into place

Liquiline CM442/CM444/CM448 Installation
Endress+Hauser 17
5.2.2 Railing mounting
a0012668
Fig. 12: Railing mounting
1
2
3
4
5
Weather protection cover (optional)
Post mounting plate (post mounting kit)
Spring washers, nuts (post mounting kit)
Pipe clamps (post mounting kit)
Spring washers, nuts (post mounting kit)
6
7
8
9
Pipe or railing (circular/square)
Mounting plate
Threaded rods (post mounting kit)
Screws (post mounting kit)
a0012669
Fig. 13: Railing mounting
a0012670
Fig. 14: Attach the device and click it into place

Installation Liquiline CM442/CM444/CM448
18 Endress+Hauser
5.2.3 Wall mounting
Mount the controller in such a way that the wall support surface is the size of the rear housing
panel at the very least.
a0012686
Fig. 15: Mounting distance in mm (inch)
a0012684
Fig. 16: Wall mounting
1Wall
2 4 drill holes1)
3Mountingplate
4 Screws Ø 6 mm (not part of
scope of supply)
1) The size of the drill holes depends on the dowels used. The dowels and screws must be provided by the customer.
a0012685
Fig. 17: Attach the device and click it into
place

Liquiline CM442/CM444/CM448 Installation
Endress+Hauser 19
5.2.4 Disassembly (for conversion, cleaning etc.)
NOTICE
The device can be damaged if dropped
‣When pushing the housing out of the holder, secure the housing in such a way that you do
not drop it. If possible, ask a second person to help you.
5.3 Post-installation check
‣After installation, check the transmitter for damage.
‣Check whether the transmitter is protected against moisture and direct sunlight (e.g. by the
weather protection cover).
a0013154
Fig. 18: Disassembly
1. Hold down the latch
2. Push up the housing to remove it from the holder
a0013155
Fig. 19: Disassembly
3. Remove the device from the front

Electrical connection Liquiline CM442/CM444/CM448
20 Endress+Hauser
6 Electrical connection
WARNING
!
The device is live!
Incorrect wiring can result in injury or fatality
‣The electrical connection may only be established by an electrical technician.
‣The electrical technician must have read and understood these Operating Instructions and
must follow the instructions they contain.
‣Prior to beginning any wiring work, make sure voltage is not applied to any of the cables.
6.1 Connection conditions
6.1.1 Remote operation via HART (e.g. via HART modem and FieldCare)
a0015608
Fig. 20: HART via modem
1 Base-L, -H or -E device module: current output 1 with HART
2 HART modem for connecting to PC, e.g. FXA1951)
3 HART handheld terminal
1) Switch set to "on" (substitutes the resistor)
