Endress+Hauser RA33 Technical specifications

KA00299K/09/en/13.10
71119860
SW-Version:
1.00.xx
Brief Operating Instructions
RA33
Batch Controller

Table of contents RA33
2Endress+Hauser
Table of contents
1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.1 Designated use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2 Installation, commissioning and operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 Operational safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.4 Return . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.5 Notes on safety conventions and icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1 Device tag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.2 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.3 Certificates and approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.1 Incoming acceptance, transport and storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.2 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.4 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.5 Post-installation check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4 Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.1 Connection requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.2 Quick wiring guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.3 Connecting the sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.4 Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.5 Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.6 Post-connection check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5 Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.1 General notes for operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.2 Display and operating elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.3 Operating matrix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.1 Quick commissioning/make it run . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.2 Device configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
This document constitutes the Brief Operating Instructions.
More detailed information can be found in the Operating Instructions and the additional
instructions on the CD-ROM supplied.
These Brief Operating Instructions do not act as a substitute for the Operating Instructions
included in the scope of delivery.
The complete device documentation comprises:
• These Brief Operating Instructions
• A CD-ROM with PDF files of:
– Operating Instructions
– Approval and safety certificates
– Further device specific information.

RA33 Safety instructions
Endress+Hauser 3
1 Safety instructions
Safe operation of the device is only guaranteed if the Operating Instructions have been read and
the safety instructions they contain have been observed.
1.1 Designated use
The batch controller is a batching and dosing manager for the batching of any media or mineral
oils.
– The manufacturer cannot take responsibility for any damage caused by misuse of the device.
It is not permitted to make any changes or reconstruction to the device.
– The device may be operated in built-in state only.
1.2 Installation, commissioning and operation
The batch controller is safely manufactured using state-of-the-art technology and complies with
the respective regulations and EU Directives. The device could be dangerous if it is incorrectly
installed or used.
Installation, wiring and maintenance of the device must be carried out only by trained, skilled
personnel authorized to perform such work and instructed by the facility's owner-operator. The
skilled personnel must have read and understood these Operating Instructions and it is
mandatory for them to follow the instructions they contain. The operator must ensure that the
measuring system is correctly wired in accordance with the wiring diagrams. When the housing
cover is removed, the shock protection is disabled (danger of electrocution). The housing may
be opened by trained skilled personnel only.
The batch controller may be operated in a closed and secure state only.
1.3 Operational safety
Technical improvement
The manufacturer reserves the right to improve and update the technical details. For details of
improvements or additions to these instructions, please contact your local sales organization.
1.4 Return
For a return, e.g. in case of repair, the device must be sent in protective packaging. The original
packaging offers the best protection. Repairs must only be carried out by your supplier's service
organization.
!Note!
When sending for repair, please enclose a note with a description of the error and the
application.

Safety instructions RA33
4Endress+Hauser
1.5 Notes on safety conventions and icons
The safety instructions in these Operating Instructions are labeled with the following safety icons
and symbols:
"Caution!
This symbol draws attention to activities or procedures that can lead to defective operation or to
destruction of the device if not carried out properly.
#Warning!
This symbol draws attention to activities or procedures that can lead to injuries to persons, to a
safety risk or to destruction of the device if not carried out properly.
!Note!
This symbol draws attention to activities or procedures that have an indirect effect on operation,
or can trigger an unforeseen device reaction if not carried out properly.

RA33 Identification
Endress+Hauser 5
2 Identification
2.1 Device tag
2.1.1 Nameplate
Compare the nameplate on the device with the following diagram:
a0014625
Fig. 1: Nameplate of the batch controller (example)
1 Device tag
2 Order code and serial number
3 Supply voltage
4 Power consumption
5 Firmware version
6 Approvals, if available
7 Ambient temperature range
8 Device revision
9 Degree of protection
10 Place and year of manufacture

Installation RA33
6Endress+Hauser
2.2 Scope of delivery
The scope of delivery of the batch controller comprises:
• Batch controller (field housing)
• Brief Operating Instructions in paper form, Operating Instructions and additional
documentation (on CD-ROM)
• Optional interface cable and DVD set with FieldCare Device Setup parameter configuration
software
• Optional Field Data Manager software
• Optional mounting hardware for top-hat rail, panel mounting, pipe mounting
• Optional overvoltage protection
!Note!
Please note the device accessories in Section 8 ’Accessories’.
2.3 Certificates and approvals
CE mark, Declaration of Conformity
The device is safely built and tested according to state-of-the-art technology and has left the
factory in perfect condition as regards technical safety. The device meets the relevant standards
and directives as per EN 61 010 "Safety requirements for electrical equipment for measurement,
control and laboratory use".
Thus, the device described in these Operating Instructions meets the legal requirements of the
EU Directives. The manufacturer confirms successful testing of the device by affixing to it the
CE mark.
3 Installation
3.1 Incoming acceptance, transport and storage
The permitted environmental, storage and transportation conditions must be complied with. For
detailed specifications, refer to the "Technical data" chapter in the operating instructions.
3.1.1 Incoming acceptance
On receipt of the goods, check the following points:
• Are the packaging or contents damaged?
• Are the delivered goods complete? Compare the scope of delivery with your order
information.
3.1.2 Transport and storage
Observe the following points:
• Pack the device in such a way as to protect it reliably against impact for storage (and
transportation). The original packaging provides optimum protection.

RA33 Installation
Endress+Hauser 7
• The permitted storage temperature range is -40 to +85°C (-40 to +185 °F); storage in the
temperature limit ranges is possible for a limited time only (maximum of 48 hours).
3.2 Dimensions
a0013438
Fig. 2: Dimensions of the device

Installation RA33
8Endress+Hauser
a0014169
Fig. 3: Mounting plate for wall, pipe and panel mounting
a0014171
Fig. 4: Panel cutout

RA33 Installation
Endress+Hauser 9
a0014610
Fig. 5: Dimensions of the top-hat rail adapter
3.3 Installation
The device with field housing and accessories is suitable for wall mount, pipe mounting, panel
mounting and top-hat rail installation.
The orientation is only determined by the legibility of the display. Connections and outputs are
fed out of the bottom of the device. The pipes are connected via coded clamps.
Operating temperature range:
-20 to 60 °C (-4 to 140 °F)
"Caution!
To prevent heat build-up, do not expose the device to extreme heat or strong direct sunshine.
Operating the device in the upper temperature limit range decreases the operating life of the
display.
3.4 Installation
3.4.1 Wall mounting
1. Use the mounting plate as the template for drilled holes, dimensions →å3
2. Attach the batch controller to the mounting plate and fasten it in place from the rear using
4 screws.
3. Fasten the mounting plate to the wall using 4 screws.

Installation RA33
10 Endress+Hauser
a0014170
Fig. 6: Wall mounting
3.4.2 Panel mounting
1. Make the panel cutout in the required size, dimensions →å4.
2. Attach the seal (item 1) to the housing.
a0014283
Fig. 7: Panel mounting

RA33 Installation
Endress+Hauser 11
3. Screw the threaded rods (item 2) into the mounting plate (dimensions →å3).
a0014173
Fig. 8: Preparing the mounting plate for panel mounting
4. Push the device into the panel cutout from the front and attach the mounting plate to the
device from the rear using the 4 screws provided (item 3).
5. Fasten the device in place by tightening the threaded rods.
a0014284
Fig. 9: Panel mounting

Installation RA33
12 Endress+Hauser
3.4.3 Support rail/top-hat rail (to EN 50 022)
1. Fasten the top-hat rail adapter (item 1, dimensions →å5) to the device using the screws
provided (item 2) and open the top-hat rail clips.
a0014176
Fig. 10: Preparing for top-hat rail mounting
2. Attach the device to the top-hat rail from the front and close the top-hat rail clips.
a0014177
Fig. 11: Top-hat rail mounting

RA33 Installation
Endress+Hauser 13
3.4.4 Pipe mounting
1. Pull the steel belts through the mounting plate (dimensions →å3) and fasten them to
the pipe.
a0014178
Fig. 12: Preparing for pipe mounting
2. Attach the device to the mounting plate and fasten it in place using the 4 screws provided.
a0014179
Fig. 13: Pipe mounting

Wiring RA33
14 Endress+Hauser
3.5 Post-installation check
!Note!
For installing the batch controller and the associated temperature sensors, observe the general
installation instructions according to EN 1434 Part 6.
4 Wiring
4.1 Connection requirements
#Warning!
Note that the entire electrical connection must be carried out only while the device is
de-energized.
"Caution!
• Before commissioning, ensure that the supply voltage corresponds to the specification on the
nameplate.
• Provide a suitable switch or power-circuit breaker in the building installation. This switch
must be installed close to the device (so that it is easily accessible) and marked as a circuit
breaker.
• An overload protection unit (rated current = 10 A) is required for the power cable.
4.2 Quick wiring guide
a0014120
Fig. 14: Connection diagram of the batch controller
For the connection of the communication interfaces, see the "Communication" section,
→ä19.

RA33 Wiring
Endress+Hauser 15
Terminal assignment
Terminals Terminal assignment Inputs
1 + RTD power supply Temperature
(Optionally RTD or current input)
2 - RTD power supply
5+RTDsensor
6 - RTD sensor
52 + 0/4 to 20 mA input
53 Ground for 0/4 to 20 mA input
54 + 0/4 to 20 mA input Density
(Current input)
55 Ground for 0/4 to 20 mA input
10 + pulse input (voltage or contact) Flow
(Optionally pulse or current input)
11 - pulse input (voltage or contact)
50 + 0/4 to 20mA or current pulse (PFM)
51 Ground for 0/4 to 20 mA input, flow
80 + digital input 1 (switch input) • Time synchronization
• Start batch
• Stop batch
• Reset batch
81 - digital input (terminal 1)
82 + digital input 2 (switch input) • Time synchronization
81 - digital input (terminal 2)
Outputs
60 + status/pulse output 1 (open collector) Batch control: pump/valve, volume
counter, signal for end of batch, fault
61 - status/pulse output 1 (open collector)
62 + status/pulse output 2 (open collector)
63 - status/pulse output 2 (open collector)
70 + 0/4 to 20mA/pulse output Current values (e.g. power) or
counter values (e.g. energy)
71 0/4 to 20mA/pulse output
13 Relay 1 normally open (NO) Batch control: pump/valve, fault
14 Relay 1 normally open (NO)
23 Relay 2 normally open (NO)
24 Relay 2 normally open (NO)
90 24V sensor power supply (LPS) 24 V power supply
(e.g. for sensor power supply)
91 Power supply ground

Wiring RA33
16 Endress+Hauser
4.2.1 Open housing
a0014368
Fig. 15: Opening the housing of the batch controller
1 Terminal assignment labeling
2Terminals
Power supply
L/+ L for AC
+ for DC
N/- N for AC
- for DC

RA33 Wiring
Endress+Hauser 17
4.3 Connecting the sensors
4.3.1 Flow
Flow sensors with external power supply
a0013521
Fig. 16: Connecting a flow sensor
1 Voltage pulses or contact sensors including EN 1434 Type IB, IC, ID, IE
2 Current pulses
3 0/4 to 20 mA signal (not in combination with MID approval option)
Flow sensors with power supply via the batch controller
a0014180
Fig. 17: Connecting active flow sensors
14-wiresensor
22-wiresensor

Wiring RA33
18 Endress+Hauser
4.3.2 Temperature
!Note!
To ensure the highest level of accuracy, we recommend using the RTD 4-wire connection, as
this compensates for measurement inaccuracies caused by the mounting location of the sensors
or the line length of the connecting cables.
Density
Connecting the RTD sensors
a0014185
1 = 4-wire connection, 2 = 3-wire connection, 3 = 2-wire connection
Terminals 1, 2, 5, 6: T warm
Terminals 3, 4, 7, 8: T cold
Temperature transmitter
connection
a0014186
1 = without external power supply of the transmitter, 2 = with external power supply of
the transmitter
Terminals 52, 53: T warm
Terminals 54, 55: T cold
Density sensor connection
1 = without external power supply of the pressure sensor, 2 = with external power supply
of the pressure sensor

RA33 Wiring
Endress+Hauser 19
4.4 Outputs
4.4.1 Analog output
This output can be used either as a 0/4 to 20 mA current output or as a voltage pulse output.
The output is galvanically isolated. For the terminal assignment, refer to →ä14.
4.4.2 Pulse output
Active voltage pulses are output at the pulse output.
Voltage level:
• 0 to 2 V corresponds to Low level
• 15 to 20 V corresponds to High level
Maximum output current: 22 mA
4.4.3 Open collector output
The two digital outputs can be used as status or pulse outputs. Make the selection in the
following menus: Setup ÉAdvanced setup or Expert ÉOutputs ÉOpen Collector
4.5 Communication
!Note!
The USB interface is always active and can be used independently of other interfaces. Parallel
operation of multiple optional interfaces, e.g. fieldbus and Ethernet, is not possible.
4.5.1 Ethernet TCP/IP (optional)
The Ethernet interface is galvanically isolated (testing voltage: 500 V). A standard patch cable
(e.g. CAT5E) can be used to connect the Ethernet interface. A special cable gland is available for
this purpose which allows users to guide pre-terminated cables through the housing. Via the
Ethernet interface, the device can be connected using a hub or a switch or directly to office
equipment.
• Standard: 10/100 Base-T/TX (IEEE 802.3)
• Socket: RJ-45
• Max. line length: 100 m

Wiring RA33
20 Endress+Hauser
a0014600
Fig. 18: Ethernet TCP/IP, Modbus TCP connection
1Ethernet,RJ45
2 Cable entry for Ethernet cable
4.5.2 Modbus TCP (optional)
The Modbus TCP interface is used to connect the device to higher-order systems to transmit all
measured values and process values. The Modbus TCP interface is physically identical to the
Ethernet interface (→ä19). Connection →å18.
4.5.3 Modbus RTU (optional)
The Modbus RTU (RS-485) interface is galvanically isolated (testing voltage: 500 V) and used to
connect the device to higher-order systems to transmit all measured values and process values.
It is connected via a 3-pin plug-in terminal in the housing cover.
a0014603-en
Fig. 19: Modbus RTU connection
