Application
Continuous, non-contact level measurement of liquids,
pastes and slurries
Features FMR53:
• Especially suited for small process connections; PTFE
sensors usable in chemically aggressive media
• Rod antenna
• Maximum measuring range: 20 m (66 ft)
• Process connection: 1½" thread or flange
• Temp. range: –40 to +150 °C (–40 to +302 °F)
• Pressure range: –1 to +40 bar (–14.5 to +580 psi)
•Accuracy: ± 6 mm
Features FMR54:
• Ideally suited for measurements in bypasses and
stilling wells
• Horn or planar antenna
• Maximum measuring range: 20 m (66 ft)
• Process connection: flange
• Temp. range: –196 to +400 °C (–321 to +752 °F)
• Pressure range: –1 to +160 bar (–14.5 to +2 320 psi)
•Accuracy: ± 6 mm
Your benefits
• Reliable measurement even for changing product and
process conditions
• Integrated data memory (HistoROM) for high
availability
• Intuitive operating menu in national languages for
easy commissioning
• Simple integration into control or asset management
systems
• Exact diagnostic and process information to assist fast
decisions
• International approvals for use in hazardous areas
• 5-point linearity protocol
• WHG and marine approvals
• SIL2 according to IEC 61508, SIL3 in case of
homogeneous or heterogeneous redundancy
• System integration via HART/PROFIBUS PA (Profile
3.02)/FOUNDATION Fieldbus
Technical Information
Micropilot FMR53, FMR54
Level radar
Level measurement in liquids
TI01041F/00/EN/01.12
71162678

D R A F T
Table of contents Micropilot FMR53, FMR54
2 V. 1, Rev. 7, 26-10-2012 Endress+Hauser
Table of contents
Important document information ................ 4
Document conventions ........................... 4
Function and system design .................... 6
Measuring principle ............................. 6
Input ..................................... 8
Measured variable .............................. 8
Measuring range ............................... 8
Operating frequency ............................ 11
Transmitting power ............................ 11
Output ................................... 12
Output signal ................................ 12
Signal on alarm ............................... 13
Linearization ................................ 13
Galvanic isolation ............................. 13
Protocol-specific data ........................... 13
Power supply ............................. 17
Terminal assignment ........................... 17
Device plug connectors .......................... 24
Supply voltage ............................... 25
Power consumption ............................ 27
Current consumption ........................... 27
Power supply failure ............................ 28
Potential equalization ........................... 28
Terminals .................................. 28
Cable entries ................................ 28
Cable specification ............................. 28
Overvoltage protection .......................... 29
Performance characteristics ................... 30
Reference operating conditions ..................... 30
Maximum measured error ........................ 30
Measured value resolution ........................ 30
Reaction time ................................ 30
Influence of ambient temperature ................... 30
Influence of gas layer ........................... 30
Gas phase compensation with external pressure sensor
(PROFIBUS PA, in preparation) ..................... 31
Installation ............................... 32
Installation conditions ........................... 32
Measuring conditions ........................... 36
Installation in vessel (free space) .................... 37
Installation in stilling well ........................ 42
Installation in bypass ........................... 45
Vessels with heat insulation ....................... 48
Environment .............................. 49
Ambient temperature range ....................... 49
Ambient temperature limits ....................... 49
Storage temperature ............................ 58
Climate class ................................ 58
Geometric height according to IEC61010-1 Ed.3 .......... 58
Degree of protection ............................ 58
Vibration resistance ............................ 58
Cleaning the antenna ........................... 58
Electromagnetic compatibility (EMC) ................. 59
Process .................................. 60
Process temperature range ........................ 60
Process pressure range .......................... 60
Dielectric constant ............................. 61
Mechanical construction ..................... 62
Dimensions ................................. 62
Weight .................................... 66
Materials ................................... 67
Operability ............................... 72
Operating concept ............................. 72
Local operation ............................... 72
Operation with remote display and operating module FHX50 .. 73
Remote operation ............................. 73
Integration in tank gauging system ................... 77
System integration via Fieldgate ..................... 78
Certificates and approvals .................... 79
CE mark ................................... 79
C-Tick symbol ............................... 79
Ex approval ................................. 79
Dual seal according to ANSI/ISA 12.27.01 .............. 79
Functional Safety .............................. 79
Sanitary compatibility ........................... 79
AD2000 ................................... 79
Pressure Equipment Directive ...................... 79
Marine certificate (in preparation) ................... 79
Radio standard EN302372-1/2 ..................... 79
FCC / Industry Canada .......................... 79
CRN approval ................................ 80
Track record ................................ 80
Other standards and guidelines ..................... 80
Ordering information ........................ 81
Ordering information ........................... 81
5-point linearity protocol (in preparation) ............... 81
Customized parametrization ....................... 82
Accessories ............................... 83
Device-specific accessories ........................ 83
Communication-specific accessories .................. 85
Service-specific accessories ........................ 86
System components ............................ 86
Documentation ............................ 87
Standard documentation ......................... 87
Supplementary documentation ..................... 87
Safety Instructions (XA) .......................... 87
Registered trademarks ....................... 88

D R A F T
Micropilot FMR53, FMR54 Table of contents
Endress+Hauser V. 1, Rev. 7, 26-10-2012 3
Patents .................................. 89

D R A F T
Micropilot FMR53, FMR54
4 V. 1, Rev. 7, 26-10-2012 Endress+Hauser
Important document information
Document conventions Safety symbols
Symbol Meaning
DANGER
A0011189-EN
DANGER!
This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious
or fatal injury.
WARNING
A0011190-EN
WARNING!
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious
or fatal injury.
CAUTION
A0011191-EN
CAUTION!
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in minor
or medium injury.
NOTICE
A0011192-EN
NOTICE!
This symbol contains information on procedures and other facts which do not result in personal
injury.
Electrical symbols
Symbol Meaning
A0011197
Direct current
A terminal to which DC voltage is applied or through which direct current flows.
A0011198
Alternating current
A terminal to which alternating voltage is applied or through which alternating current flows.
A0017381
Direct current and alternating current
• A terminal to which alternating voltage or DC voltage is applied.
• A terminal through which alternating current or direct current flows.
A0011200
Ground connection
A grounded terminal which, as far as the operator is concerned, is grounded via a grounding system.
A0011199
Protective ground connection
A terminal which must be connected to ground prior to establishing any other connections.
A0011201
Equipotential connection
A connection that has to be connected to the plant grounding system: This may be a potential
equalization line or a star grounding system depending on national or company codes of practice.
Symbols for certain types of information
Symbol Meaning
A0011182
Allowed
Indicates procedures, processes or actions that are allowed.
A0011183
Preferred
Indicates procedures, processes or actions that are preferred.
A0011184
Forbidden
Indicates procedures, processes or actions that are forbidden.
A0011193
Tip
Indicates additional information.
A0011194
Reference to documentation
Refers to the corresponding device documentation.

D R A F T
Micropilot FMR53, FMR54
6 V. 1, Rev. 7, 26-10-2012 Endress+Hauser
Function and system design
Measuring principle The Micropilot is a "downward-looking" measuring system, operating based on the time-of-flight method
(ToF). It measures the distance from the reference point (process connection) to the product surface. Radar
impulses are emitted by an antenna, reflected off the product surface and received again by the radar system.
F
L
D
E
R
0%
100%
A0017871
å 1 Setup parameters of the Micropilot
RReference point of the measurement (lower edge of the flange or threaded connection)
E Empty calibration ( = zero)
F Full calibration (= span)
D Measured distance
L Level (L = E - D)
Input
The reflected radar impulses are received by the antenna and transmitted into the electronics. A
microprocessor evaluates the signal and identifies the level echo caused by the reflection of the radar impulse
at the product surface. The unambiguous signal identification is accomplished by the PulseMaster® eXact
software together with the Multi-echo tracking algorithms, based on many years of experience with time-of-
flight technology.
The distance D to the product surface is proportional to the time of flight t of the impulse:
D = c · t/2,
with c being the speed of light.
Based on the known empty distance E, the level L is calculated:
L = E – D
The reference point R of the measurement is located at the process connection. For details see the
dimensional drawing:
•FMR53: (® ä 63)
•FMR54: (® ä 64)
The Micropilot is equipped with functions to suppress interference echoes. The user can activate these
functions. Together with the multi-echo tracking algorithms they ensure that interference echoes (i.e. from
edges and weld seams) are not interpreted as level echo.

D R A F T
Micropilot FMR53, FMR54
Endress+Hauser V. 1, Rev. 7, 26-10-2012 7
Output
The Micropilot is commissioned by entering an empty distance "E" (=zero), a full distance "F" (=span) and
application parameters. The application parameters are automatically adapt into the instrument to the
process conditions. For models with a current output, the factory adjustment for zero point "E" and span "F"
is 4 mA and 20 mA. For digital outputs and the display module, the factory adjustment for zero point "E" and
span "F" is 0 % and 100 %.
A linearization with max. 32 points, based on a table entered either manually or semi-automatically, can be
activated locally or remotely. This function provides a measurement in engineering units and a linear output
signal for spheres, horizontal cylindrical tanks and vessels with conical outlet.
Life cycle of the product
Engineering Procurement Installation Commissioning Operation Maintenance Retirement
A0013773-EN
å 2 Life cycle
Engineering
• Universal measuring principle
• Measurement unaffected by medium properties
• Hardware and software developed according to SIL IEC 61508
Procurement
• Endress+Hauser being the world market leader in level measurement guarantees asset protection
• Worldwide support and service
Installation
• Special tools are not required
• Reverse polarity protection
• Modern, detachable terminals
• Main electronics protected by a separate connection compartment
Commissioning
• Fast, menu-guided commissioning in only a few steps on site or from the control room
• Plain text display in national languages reduces the risk of error or confusion
• Direct local access of all parameters
• Short instruction manual at the device
Operation
• Multi-echo tracking: Reliable measurement through self-learning echo-search algorithms taking into
account the short-term and long-term history in order to check the found echoes for plausibility and to
suppress interference echoes.
• Diagnostics in accordance with NAMUR NE107
Maintenance
• HistoROM: Data backup for instrument settings and measured values
• Exact instrument and process diagnosis to assist fast decisions with clear details concerning remedies
• Intuitive, menu-guided operating concept in national languages saves costs for training, maintenance and
operation
• Cover of the electronics compartment can be opened in hazardous areas
Retirement
• Order code translation for subsequent models
• RoHS-conforming (Restriction of certain Hazardous Substances), unleaded soldering of electronic
components
• Environmentally sound recycling concept

D R A F T
Micropilot FMR53, FMR54
8 V. 1, Rev. 7, 26-10-2012 Endress+Hauser
Input
Measured variable The measured variable is the distance between the reference point and the product surface.
Subject to the empty distance entered "E" the level is calculated.
Alternatively, the level can be converted into other variables (volume, mass) by means of linearization (32
points).
Measuring range Maximum measuring range
Device Maximum measuring range
FMR53 20 m (66 ft)
FMR54 20 m (66 ft)
Usable measuring range
The usable measuring range depends on the size of the antenna, the reflectivity of the medium, the
mounting location and eventual interference reflections.
The following tables describe the groups of media as well as the achievable measuring range as a function of
application and media group. If the dielectric constant of a medium is unknown, it is recommended to
assume media group B to ensure a reliable measurement.
Media groups
Media groups DK (er)Example
A1.4 to 1.9 non-conducting liquids, e.g. liquefied gas 1)
B1.9 to 4 non-conducting liquids, e.g. benzene, oil, toluene, …
C4 to 10 e.g. concentrated acids, organic solvents, esters, aniline, alcohol, acetone, …
D> 10 conducting liquids, e.g. aqueous solutions, dilute acids and alkalis
1) Treat Ammonia NH3 as a medium of group A.

D R A F T
Micropilot FMR53, FMR54
Endress+Hauser V. 1, Rev. 7, 26-10-2012 9
Device Storage tank Buffer tank
A0018833
Calm product surface (e.g. intermittent filling, filling from bottom, immersion
tubes)
A0018835
Moving surfaces (e.g. continuous filling, from above, mixing jets)
Antenna type and size Antenna type and size
FMR53 Rod 390 mm (15 in)
Rod 540 mm (21 in)
- Rod 390 mm (15 in)
Rod 540 mm (21 in)
-
FMR54 Horn 150 mm (6 in) Horn 200 mm (8 in)
Horn 250 mm (10 in)
Horn 150 mm (6 in) Horn 200 mm (8 in)
Horn 250 mm (10 in)
BB
10
(33)
20
(66)
15
(49)
CC DD
A0018844
BB
20
(66)
20
(66)
15
(49)
CC DD
A0018845
BB
10
(33)
7.5
(25)
5
(16)
CC DD
A0018846
BB
12.5
(41)
7.5
(25)
10
(33)
CC DD
A0018847
Measuring range [m (ft)]

D R A F T
Micropilot FMR53, FMR54
10 V. 1, Rev. 7, 26-10-2012 Endress+Hauser
Device Process tank with agitator Stilling well Bypass
A0018837
Turbulent surface. Single stage agitator (frot <
1 Hz)
A0018839
A0018840
A
Antenna type and size
Antenna type and size
FMR53 Rod 390 mm (15 in)
Rod 540 mm (21 in)
- - - -
FMR54 Horn 150 mm (6 in) Horn 200 mm (8 in)
Horn 250 mm (10 in)
Horn
80 to 250 mm (3 to 10 in)
Planar
150 to 300 mm (6 to 12 in)
Horn
80 to 250 mm (3 to 10 in)
BB
8
(26)
4
(13) 6
(20)
CC DD
A0018848
BB
10
(33)
6
(20) 8
(26)
CC DD
A0018850
20
(66)
A, B, C, D
A0018851
38
(125)
A, B, C, D
A0018854
20
(66)
C, D
A0018852
Measuring range [m (ft)]

D R A F T
Micropilot FMR53, FMR54
Endress+Hauser V. 1, Rev. 7, 26-10-2012 11
Operating frequency C-band (~ 6 GHz)
Up to 8 Micropilot transmitters can be installed in the same tank because the transmitter pulses are
statistically coded.
Transmitting power Distance Average energy density in beam direction
1 m (3.3 ft) < 12 nW/cm2
5 m (16 ft) < 0.4 nW/cm2

D R A F T
Micropilot FMR53, FMR54
12 V. 1, Rev. 7, 26-10-2012 Endress+Hauser
Output
Output signal HART
Signal coding FSK ±0.5 mA over current signal
Data transmission rate 1 200 Bit/s
Galvanic isolation Yes
PROFIBUS PA (in preparation)
Signal coding Manchester Bus Powered (MBP)
Data transmission rate 31.25 kBit/s, voltage mode
Galvanic isolation Yes
FOUNDATION Fieldbus (in preparation)
Signal coding Manchester Bus Powered (MBP)
Data transmission rate 31.25 kBit/s, voltage mode
Galvanic isolation Yes
Switch output
For HART devices, the switch output is available as an option. See product structure, feature 20:
"Power Supply, Output", option B: "2-wire; 4-20mA HART, switch output"
Devices with PROFIBUS PA and FOUNDATION Fieldbus always have a switch output.
Switch output
Function Open collector switching output
Switching behavior Binary (conductive or non-conductive), switches when the programmable switch point is
reached
Failure mode non-conductive
Eectrical connection values U = 10.4 to 35 VDC, I = 0 to 40 mA
Internal resistance RI < 880 W
The voltage drop at this internal resistance has to be taken into account on planning the
configuration. For example, the resulting voltage at a connected relay must be sufficient
to switch the relay.
Insulation voltage floating, Insulation voltage 1 350 VDC to power supply aund 500 VAC to ground
Switch point freely programmable, separately for switch-on and switch-off point
Switching delay freely programmable from 0 to 100 sec. , separately for switch-on and switch-off point
Number of switching cycles corresponds to the measuring cycle
Signal source
device variables
• Level linearized
• Distance
• Terminal voltage
• Electronic temperature
• Relative echo amplitude
• Diagnostic values, Advanced diagnostics
Number of switching cycles unlimited

D R A F T
Micropilot FMR53, FMR54
Endress+Hauser V. 1, Rev. 7, 26-10-2012 13
Signal on alarm Depending on the interface, failure information is displayed as follows:
• Current output (for HART devices)
– Failsafe mode selectable (in accordance with NAMUR Recommendation NE 43):
Minimum alarm: 3.6 mA
Maximum alarm (= factory setting): 22 mA
– Failsafe mode with user-selectable value: 3.59 to 22.5 mA
• Local display
– Status signal (in accordance with NAMUR Recommendation NE 107)
– Plain text display
• Operating tool via digital communication (HART, PROFIBUS PA, FOUNDATION Fieldbus) or service
interface (CDI)
– Status signal (in accordance with NAMUR Recommendation NE 107)
– Plain text display
Linearization The linearization function of the device allows the conversion of the measured value into any unit of length
or volume. Linearization tables for calculating the volume in cylindrical tanks are pre-programmed. Other
tables of up to 32 value pairs can be entered manually or semi-automatically.
Galvanic isolation All circuits for the outputs are galvanically isolated from each other.
Protocol-specific data HART
Manufacturer ID 17 (0x11)
Device type ID 41 (0x28)
HART specification 6.0
Device description files (DTM,
DD)
Information and files under:
•www.endress.com
•www.hartcomm.org
HART load Min. 250 W
HART device variables The measured values can be freely assigned to the device variables.
Measured values for PV (primary variable)
• Level linearized
• Distance
• Electronic temperature
• Relative echo amplitude
• Analog output adv. diagnostics
Measured values for SV, TV, FV (second, third and fourth variable)
• Level linearized
• Distance
• Terminal voltage
• Electronic temperature
• Absolute echo amplitude
• Relative echo amplitude
• Area of incoupling
Supported functions • Burst mode
• Additional transmitter status
PROFIBUS PA (in preparation)
Manufacturer ID 17 (0x11)
Ident number 0x1559
Profile version 3.02
GSD file Information and files under:
•www.endress.com
•www.profibus.org
GSD file version

D R A F T
Micropilot FMR53, FMR54
14 V. 1, Rev. 7, 26-10-2012 Endress+Hauser
Output values Analog Input:
• Level linearized
• Distance
• Terminal voltage
• Electronic temperature
• Absolute echo amplitude
• Relative echo amplitude
Digital Input:
• Extended diagnostic blocks
• Status output PFS Block
Input values Analog Output:
• Analog value from PLC (for sensor block external pressure and temperature)
• Analog value from PLC to be indicated on the display
Digital Output:
• Extended diagnostic block
• Level limiter
• Sensor block measurement on
• Sensor block save history on
• Status output
Supported functions • Identification & Maintenance
Einfachste Geräteidentifizierung seitens des Leitsystems und des Typenschildes
• Automatic Ident Number Adoption
GSD compatibility mode with respect to the preceding product Micropilot M
FMR2xx
• Physical Layer Diagnostics
Installation check of the PRFIBUS segment and the Micropilot FMR5x via the
terminal voltage and telegram surveillance.
• PROFIBUS Up-/Download
Up to 10 times faster writing and reading of parameters via PROFIBUS up-/
download
• Condensed Status
Simple and self-explanatory diagnostic information by categorization of occurring
diagnostic messages.
FOUNDATION Fieldbus (in preparation)
Manufacturer ID 0x452B48
Device type 0x1028
Device Revision 0x01
DD Revision Information and files can be found:
•www.endress.com
•www.fieldbus.org
CFF Revision
Device Tester Version (ITK
Version)
6.0.1
ITK Test Campaign Number IT085300
Link Master (LAS) capable yes
Link Master / Basic Device
selectable
yes; default: Basic Device
Node address Default: 247 (0xF7)
Features supported Following methods are supported:
• Restart
• ENP Restart
• Setup
• Linearization
• Self Check
Virtual Communication Relationships (VCRs)
Number of VCRs 44
Number of Link Objects in VFD 50

D R A F T
Micropilot FMR53, FMR54
Endress+Hauser V. 1, Rev. 7, 26-10-2012 15
Permanent entries 1
Client VCRs 0
Server VCRs 10
Source VCRs 43
Sink VCRs 0
Subscriber VCRs 43
Publisher VCRs 43
Device Link Capabilities
Slot time 4
Min. inter PDU delay 8
Max. response delay 20
Transducer Blocks
Block Content Output values
Setup Transducer Block Contains all parameters for a standard commissioning
procedure
• Level or volume 1)
(Channel 1)
• Distance (Channel 2)
Advanced Setup Transducer
Block
Contains all parameters for a more detailed configuration
of the device
no output values
Display Transducer Block Contains all parameters for the configuration of the
display module
no output values
Diagnostic Transducer Block Contains diagnostic information no output values
Expert Configuration
Transducer Block
Contains parameters which require detailed knowledge
of the functionalities of the device
no output values
Expert Information
Transducer Block
Contains information about the state of the device no output values
Service Sensor Transducer
Block
Contains parameters which can only be operated by
Endress+Hauser service personnel
no output values
Service Information
Transducer Block
Contains information on the state of device which is
relevant for service operations
no output values
Data Transfer Transducer
Block
Contains parameters which allow to backup the device
configuration in the display module and to restore it into
the device.
no output values
1) depending on the configuration of the block
Function Blocks
Block Content Number of
permanent
blocks
Number of
instantiable
blocks
Execution
time
Functionality
Resource Block The Resource Block contains all the data
that uniquely identifies the field device.
It is an electronic version of a nameplate
of the device.
1 0 - enhanced
Multiple
Analog Input
Block
The AI block takes the manufacturer's
input data, selected by channel number,
and makes it available to other function
blocks at its output.
2 3 25 ms enhanced
Discrete Input
Block
The DI block takes a discrete input value
(e.g. indication of an level limit), and
makes it available to other function
blocks at its output.
1 2 20 ms standard

D R A F T
Micropilot FMR53, FMR54
16 V. 1, Rev. 7, 26-10-2012 Endress+Hauser
Block Content Number of
permanent
blocks
Number of
instantiable
blocks
Execution
time
Functionality
PID Block The PID block serves as proportional-
integralderivative controller and is used
almost universally to do closed-loop-
control in the field including cascade and
feedforward.
1 1 25 ms standard
Arithmetic
Block
This block is designed to permit simple
use of popular measurement math
functions. The user does not have to
know how to write equations. The math
algorithm is selected by name, chosen by
the user for the function to be done.
1 1 25 ms standard
Signal
Characterizer
Block
The signal characterizer block has two
sections, each with an output that is a
non-linear function of the respective
input. The non-linear function is
determined by a single look-up table
with 21 arbitrary x-y pairs.
1 1 25 ms standard
Input Selector
Block
The input selector block provides
selection of up to four inputs and
generates an output based on the
configured action. This block normally
receives its inputs from AI blocks. The
block performs maximum, minimum,
middle, average and ‘first good’ signal
selection.
1 1 25 ms standard
Integrator
Block
The Integrator Function Block integrates
a variable as a function of the time or
accumulates the counts from a Pulse
Input block. The block may be used as a
totalizer that counts up until reset or as a
batch totalizer that has a setpoint, where
the integrated or accumulated value is
compared to pre-trip and trip settings,
generating discrete signals when these
settings are reached.
1 1 25 ms standard
Analog Alarm
Block
1 1 25 ms standard
Up to 20 blocks can be instantiated in the device altogether, including the blocks already instantiated
on delivery.

D R A F T
Micropilot FMR53, FMR54
Endress+Hauser V. 1, Rev. 7, 26-10-2012 17
Power supply
Terminal assignment 2-wire: 4-20mA HART
+
–
4...20 mA
4...20 mA
5
5
4
4
1
1
2
2
8
9
3
3
+
+
–
–
1
+
2
4...20mA
HART
10 mm
Spare part
71108xxx
2- wire level
4-20 mA 4-20 mA
HART
[21]
open
-
1
+2
4-20mA
1-channel overvoltage protection
-
71128617
[16]
A
+
–
7
B
6
A0011294
å 3 Terminal assignment 2-wire; 4-20mA HART
AWithout integrated overvoltage protection
B With integrated overvoltage protection
1Active barrier with power supply (e.g. RN221N): Observe terminal voltage (® ä 25)
2HART communication resistor (³250 W): Observe maximum load (® ä 25)
3 Connection for Commubox FXA195 or FieldXpert SFX100 (via VIATOR Bluetooth modem)
4Analog display device: Observe maximum load (® ä 25)
5Cable screen; observe cable specification (® ä 28)
6 Terminals for 4-20mA HART (passive)
7 Overvoltage protection module
8 Terminal for potential equalization line
9 Cable entry

D R A F T
Micropilot FMR53, FMR54
18 V. 1, Rev. 7, 26-10-2012 Endress+Hauser
2-wire: 4-20mA HART, switch output
1
3+
+2
4
4-20mA/
FIELDBUS
4-20mA/
2-channel overvoltage protection
-
-
71128619
[17]
B
1
+
2
4...20 mA
HART
10 mm
Spare part
71108xxx
2- wire
4-20 mA PFS
HART
[02/03]
open
-
A
1
+
2
-
3
+4
-
10
9
8
7
11
+
+
-
-
2
2
3
3
4
4
6
5
5
1
1
4...20 mA
4...20 mA
³ W250
³ W250
3+
3+
4-
4-
+
+
–
–
A0013759
å 4 Terminal assignment 2-wire; 4-20mA HART, switch output
AWithout integrated overvoltage protection
B With integrated overvoltage protection
1Active barrier with power supply (e.g. RN221N): Observe terminal voltage (® ä 25)
2HART communication resistor (³250 W): Observe maximum load (® ä 25)
3 Connection for Commubox FXA195 or FieldXpert SFX100 (via VIATOR Bluetooth modem)
4Analog display device: Observe maximum load (® ä 25)
5Cable screen; observe cable specification (® ä 28)
6 Terminals for 4-20mA HART (passive)
7 Terminals for switch output (open collector)
8 Terminal for potential equalization line
9 Cable entry for 4-20mA HART line
10 Cable entry for switch output line
11 Overvoltage protection module

D R A F T
Micropilot FMR53, FMR54
Endress+Hauser V. 1, Rev. 7, 26-10-2012 19
2-wire: 4-20mA HART, 4-20mA
1
3
+
+2
4
4...20mA
HART
4...20mA
10 mm
Spare part
71108xxx
2- wire level
4-20 mA 4-20 mA
HART
[04/05]
open
-
-
11
A
1
3+
+2
4
4-20mA/
FIELDBUS
4-20mA/
2-channel overvoltage protection
-
-
71128619
[17]
14
13
12
+
+
+
+
+
-
-
-
-
1
1
2
2
3
3
9
9
5
5
8
8
6
6
7
7
4
4
+
+
–
–
+
+
–
–
4...20 mA
4...20 mA
10
B
4...20 mA
4...20 mA
A0013923
å 5 Terminal assignment 2-wire, 4-20 mA HART, 4...20mA
AWithout integrated overvoltage protection
B With integrated overvoltage protection
1 Connection current output 2
2 Connection current output 1
3Supply voltage for current output 1 (e.g. RN221N); Observe terminal voltage (® ä 26)
4Cable screen; observe cable specification (® ä 28)
5HART communication resistor (³ 250 W): Observe maximum load (® ä 26)
6 Connection for Commubox FXA195 or FieldXpert SFX100 (via VIATOR Bluetooth modem)
7Analog display device ; observe maximum load (® ä 26)
8Analog display device ; observe maximum load (® ä 26)
9Supply voltage for current output 2 (e.g. RN221N); Obesrve terminal voltage (® ä 26)
10 Overvoltage protection module
11 Terminals for current output 2
12 Terminal for the potential equalization line
13 Cable entry for current output 1
14 Cable entry for current output 2
This version is also suited for single-channel operation. In this case, current output 1 (terminals 1 and
2) must be used.

D R A F T
Micropilot FMR53, FMR54
20 V. 1, Rev. 7, 26-10-2012 Endress+Hauser
4-wire: 4-20mA HART (10.4 to 48 VDC)
3
1
+
L+ 4
2
4...20 mA
HART
10.4...48 V=
10 mm
Spare part
71108xxx
2- wire
4-20 mA
HART
[08]
open
-
L-
A
13
12
11
910
+
-
2 3 4
6
7
8
5
1
4...20 mA
³ W250
A0011340
å 6 Terminal assignment 4-wire; 4-20mA HART (10.4 to 48 VDC)
1Evaluation unit, e.g. PLC
2HART communication resistor (³250 W): Observe maximum load (® ä 27)
3 Connection for Commubox FXA195 or FieldXpert SFX100 (via VIATOR Bluetooth modem)
4Analog display device: Observe maximum load (® ä 27)
5Signal cable including screening (if required), observe cable specification (® ä 28)
6 Protective connection; do not disconnect!
7Protective earth, observe cable specification (® ä 28)
8 Terminals for 4...20mA HART (active)
9 Terminals for supply voltage
10 Supply voltage: Observe terminal voltage (® ä 27), observe cable specification (® ä 28)
11 Terminal for potential equalization
12 Cable entry for signal line
13 Cable entry for power supply
!CAUTION
To ensure electrical safety:
►Do not disconnect the protective connection (7).
►Disconnect the supply voltage before disconnecting the protective earth (8).
Connect protective earth to the internal ground terminal (8) before connecting the supply voltage. If
necessary, connect the potential matching line to the external ground terminal (12).
In order to ensure electromagnetic compatibility (EMC): Do not only ground the device via the
protective earth conductor of the supply cable. Instead, the functional grounding must also be
connected to the process connection (flange or threaded connection) or to the external ground
terminal.
An easily accessible power switch must be installed in the proximity of the device. The power switch
must be marked as a disconnector for the device (IEC/EN61010).
