Endress+Hauser Micropilot NMR84 User manual

Products Solutions Services
Operating Instructions
Micropilot NMR84
Tank Gauging
BA01453G/00/EN/06.21
71545626
2021-11-04
Valid as of version
01.05.zz (Device firmware)

Micropilot NMR84
2 Endress+Hauser
Order code:
Ext. ord. cd.:
Ser. no.:
www.endress.com/deviceviewer Endress+Hauser
Operations App
XXXXXXXXXXXX
XXXXX-XXXXXX
XXX.XXXX.XX
Serial number
1.
3.
2.
A0023555

Micropilot NMR84 Table of contents
Endress+Hauser 3
Table of contents
1 About this document ................ 4
1.1 Document function ..................... 4
1.2 Symbols .............................. 4
1.3 Documentation ........................ 6
1.4 Registered trademarks ................... 6
2 Basic safety instructions ............ 7
2.1 Requirements for the personnel ............ 7
2.2 Intended use .......................... 7
2.3 Workplace safety ....................... 8
2.4 Operational safety ...................... 8
2.5 Product safety ......................... 8
3 Product description ................. 9
3.1 Product design ......................... 9
4 Incoming acceptance and product
identification ..................... 10
4.1 Incoming acceptance ................... 10
4.2 Product identification .................. 10
4.3 Storage and transport .................. 12
5 Installation ....................... 13
5.1 Installation conditions .................. 13
5.2 Post-installation check .................. 14
6 Electrical connection .............. 15
6.1 Terminal assignment ................... 15
6.2 Connecting requirements ................ 35
6.3 Ensuring the degree of protection .......... 36
6.4 Post-connection check .................. 36
7 Operability ........................ 37
7.1 Overview of the operation options ......... 37
7.2 Structure and function of the operating
menu .............................. 38
7.3 Access to the operating menu via the local or
remote display and operating module ....... 39
7.4 Access to the operating menu via the service
interface and FieldCare ................. 50
7.5 Access to the operating menu via Tankvision
Tank Scanner NXA820 and FieldCare ....... 50
8 System integration ................ 53
8.1 Overview of the Device Description files
(DTM) .............................. 53
9 Commissioning .................... 54
9.1 Terms related to tank measurement ........ 54
9.2 Initial settings ........................ 54
9.3 Configuring the measuring device .......... 57
9.4 Configuring the tank gauging application .... 59
9.5 Advanced settings ..................... 79
9.6 Simulation ........................... 79
9.7 Protecting settings from unauthorized access .79
10 Operation ......................... 80
10.1 Reading off the device locking status ....... 80
10.2 Reading off measured values ............. 80
11 Diagnostics and troubleshooting ... 81
11.1 General trouble shooting ................ 81
11.2 Diagnostic information on local display ...... 82
11.3 Diagnostic information in FieldCare ........ 85
11.4 Overview of the diagnostic messages ....... 87
11.5 Diagnostic list ........................ 93
11.6 Reset measuring device ................. 93
11.7 Device information .................... 93
11.8 Firmware history ...................... 93
12 Maintenance ...................... 94
12.1 Maintenance tasks ..................... 94
12.2 Endress+Hauser services ................ 94
13 Repair ............................ 95
13.1 General information on repairs ............ 95
13.2 Spare parts .......................... 96
13.3 Endress+Hauser services ................ 96
13.4 Return .............................. 96
13.5 Disposal ............................ 96
14 Accessories ....................... 97
14.1 Device-specific accessories ............... 97
14.2 Communication-specific accessories ........ 98
14.3 Service-specific accessories ............... 98
14.4 System components .................... 99
15 Operating menu .................. 100
15.1 Overview of the operating menu .......... 100
15.2 "Operation" menu ..................... 109
15.3 "Setup" menu ........................ 118
15.4 "Diagnostics" menu .................... 239
Index ................................. 251

About this document Micropilot NMR84
4 Endress+Hauser
1 About this document
1.1 Document function
These Operating Instructions contain all the information that is required in various phases
of the life cycle of the device: from product identification, incoming acceptance and
storage, to mounting, connection, operation and commissioning through to
troubleshooting, maintenance and disposal.
1.2 Symbols
1.2.1 Safety symbols
DANGER
This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in
serious or fatal injury.
WARNING
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
serious or fatal injury.
CAUTION
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
minor or medium injury.
NOTICE
This symbol contains information on procedures and other facts which do not result in
personal injury.
1.2.2 Electrical symbols
Alternating current
Direct current and alternating current
Direct current
Ground connection
A grounded terminal which, as far as the operator is concerned, is grounded via a
grounding system.
Protective earth (PE)
Ground terminals that must be connected to ground prior to establishing any other
connections.
The ground terminals are located on the interior and exterior of the device:
• Interior ground terminal: protective earth is connected to the mains supply.
• Exterior ground terminal: device is connected to the plant grounding system.
1.2.3 Tool symbols
Phillips head screwdriver

Micropilot NMR84 About this document
Endress+Hauser 5
Flat blade screwdriver
Torx screwdriver
Allen key
Open-ended wrench
1.2.4 Symbols for certain types of information and graphics
Permitted
Procedures, processes or actions that are permitted
Preferred
Procedures, processes or actions that are preferred
Forbidden
Procedures, processes or actions that are forbidden
Tip
Indicates additional information
Reference to documentation
Reference to graphic
Notice or individual step to be observed
1.
,
2.
,
3.
Series of steps
Result of a step
Visual inspection
Operation via operating tool
Write-protected parameter
1, 2, 3, ...
Item numbers
A, B, C, ...
Views
Safety instructions
Observe the safety instructions contained in the associated Operating Instructions
Temperature resistance of the connection cables
Specifies the minimum value of the temperature resistance of the connection cables

About this document Micropilot NMR84
6 Endress+Hauser
1.3 Documentation
The following documentation types are available in the Downloads area of the Endress
+Hauser website (www.endress.com/downloads):
For an overview of the scope of the associated Technical Documentation, refer to the
following:
•W@M Device Viewer (www.endress.com/deviceviewer): Enter the serial number
from the nameplate
•Endress+Hauser Operations App: Enter the serial number from the nameplate or
scan the matrix code on the nameplate
1.3.1 Technical Information (TI)
Planning aid
The document contains all the technical data on the device and provides an overview of
the accessories and other products that can be ordered for the device.
1.3.2 Brief Operating Instructions (KA)
Guide that takes you quickly to the 1st measured value
The Brief Operating Instructions contain all the essential information from incoming
acceptance to initial commissioning.
1.3.3 Operating Instructions (BA)
The Operating Instructions contain all the information that is required in various phases of
the life cycle of the device: from product identification, incoming acceptance and storage,
to mounting, connection, operation and commissioning through to troubleshooting,
maintenance and disposal.
It also contains a detailed explanation of each individual parameter in the operating menu
(except the Expert menu). The description is aimed at those who work with the device
over the entire life cycle and perform specific configurations.
1.3.4 Description of Device Parameters (GP)
The Description of Device Parameters provides a detailed explanation of each individual
parameter in the 2nd part of the operating menu: the Expert menu. It contains all the
device parameters and allows direct access to the parameters by entering a specific code.
The description is aimed at those who work with the device over the entire life cycle and
perform specific configurations.
1.3.5 Safety Instructions (XA)
Depending on the approval, the following Safety Instructions (XA) are supplied with the
device. They are an integral part of the Operating Instructions.
The nameplate indicates the Safety Instructions (XA) that are relevant to the device.
1.3.6 Installation instructions (EA)
Installation Instruction are used to replace a faulty unit with a functioning unit of the same
type.
1.4 Registered trademarks
Modbus®
Registered trademark of SCHNEIDER AUTOMATION, INC.

Micropilot NMR84 Basic safety instructions
Endress+Hauser 7
2 Basic safety instructions
2.1 Requirements for the personnel
The personnel for installation, commissioning, diagnostics and maintenance must fulfill
the following requirements:
‣Trained, qualified specialists must have a relevant qualification for this specific function
and task.
‣Are authorized by the plant owner/operator.
‣Are familiar with federal/national regulations.
‣Before starting work, read and understand the instructions in the manual and
supplementary documentation as well as the certificates (depending on the
application).
‣Follow instructions and comply with basic conditions.
The operating personnel must fulfill the following requirements:
‣Are instructed and authorized according to the requirements of the task by the facility's
owner-operator.
‣Follow the instructions in this manual.
2.2 Intended use
Application and measured materials
The measuring device described in these Operating Instructions is intended for the
continuous, contact-less level measurement of liquids. The device must be installed in
metallic stilling wells. Operation is completely harmless to humans and animals.
Depending on the version ordered, the measuring device can also measure potentially
explosive, flammable, poisonous and oxidizing media.
Measuring devices for use in hazardous areas, in hygienic applications or in applications
where there is an increased risk due to process pressure, are labeled accordingly on the
nameplate.
To ensure that the measuring device remains in proper condition for the operation time:
‣Only use the measuring device in full compliance with the data on the nameplate and
the general conditions listed in the Operating Instructions and supplementary
documentation.
‣Check the nameplate to verify if the device ordered can be put to its intended use in the
approval-related area (e.g. explosion protection, pressure vessel safety).
‣Use the measuring device only for media against which the process-wetted materials
are adequately resistant.
‣If the measuring device is not operated at atmospheric temperature, compliance with
the relevant basic conditions specified in the associated device documentation is
absolutely essential.
‣Protect the measuring device permanently against corrosion from environmental
influences.
‣Observe the limit values in the "Technical Information".
The manufacturer is not liable for damage caused by improper or non-designated use.
Residual risk
During operation the sensor may assume a temperature near the temperature of the
measured material.
Danger of burns due to heated surfaces!
‣For high process temperatures: Install protection against contact in order to prevent
burns.

Basic safety instructions Micropilot NMR84
8 Endress+Hauser
2.3 Workplace safety
For work on and with the device:
‣Wear the required personal protective equipment according to federal/national
regulations.
2.4 Operational safety
Risk of injury!
‣Operate the device only if it is in proper technical condition, free from errors and faults.
‣The operator is responsible for interference-free operation of the device.
Modifications to the device
Unauthorized modifications to the device are not permitted and can lead to unforeseeable
dangers:
‣If modifications are nevertheless required, consult with the manufacturer.
Repair
To ensure continued operational safety and reliability:
‣Carry out repairs on the device only if they are expressly permitted.
‣Observe federal/national regulations pertaining to the repair of an electrical device.
‣Use only original spare parts and accessories from the manufacturer.
Hazardous area
To eliminate danger to persons or the facility when the device is used in the hazardous
area (e.g. explosion protection):
‣Check the nameplate to verify if the device ordered can be put to its intended use in the
hazardous area.
‣Observe the specifications in the separate supplementary documentation that is an
integral part of these instructions.
2.5 Product safety
This measuring device is designed in accordance with good engineering practice to meet
state-of-the-art safety requirements, has been tested, and left the factory in a condition in
which it is safe to operate. It meets general safety standards and legal requirements.
NOTICE
Loss of degree of protection by opening of the device in humid environments
‣If the device is opened in a humid environment, the degree of protection indicated on
the nameplate is no longer valid. This may also impair the safe operation of the device.
2.5.1 CE mark
The measuring system meets the legal requirements of the applicable EU Directives. These
are listed in the corresponding EU Declaration of Conformity along with the standards
applied.
Endress+Hauser confirms successful testing of the device by affixing to it the CE mark.

Micropilot NMR84 Product description
Endress+Hauser 9
3 Product description
3.1 Product design
1 1
2 2
4
5
3
4
3
A0027766
 1 Design of Micropilot NMR84
1 Electronics housing
2 Display and operating module (can be operated without opening the cover)
3 Process connection (flange)
4 Planar antenna
5 Antenna extension (for antennas ≥ 200 mm (8 in))

Incoming acceptance and product identification Micropilot NMR84
10 Endress+Hauser
4 Incoming acceptance and product
identification
4.1 Incoming acceptance
Upon receipt of the goods check the following:
• Are the order codes on the delivery note and the product sticker identical?
• Are the goods undamaged?
• Do the nameplate data match the ordering information on the delivery note?
• If required (see nameplate): Are the Safety Instructions (XA) enclosed?
If one of these conditions is not satisfied, contact your Endress+Hauser Sales Center.
4.2 Product identification
The following options are available for identification of the measuring device:
• Nameplate specifications
• Extended order code with breakdown of the device features on the delivery note
•W@M Device Viewer (www.endress.com/deviceviewer): Enter the serial number from
the nameplate
•Endress+Hauser Operations App: Enter the serial number from the nameplate or scan
the matrix code on the nameplate
For an overview of the scope of the associated Technical Documentation, refer to the
following:
•W@M Device Viewer (www.endress.com/deviceviewer): Enter the serial number
from the nameplate
•Endress+Hauser Operations App: Enter the serial number from the nameplate or
scan the matrix code on the nameplate

Micropilot NMR84 Incoming acceptance and product identification
Endress+Hauser 11
4.2.1 Nameplate
1
321
22
23
6
7
89
14
16
15
19 20
11
18
12
13
24
25
26 28
27
4
5
Ext. ord. cd.:
Order code:
Ser. no.:
Tp max.:
Mat.:
Date:
FW: Dev.Rev.: ex works
Ta
Ta:
if modification
see sep. label
X =
MWP:
Tank ID:
Tank ref.height:
2
Density range: Kg/m³
17
10
A0027791
 2 Nameplate
1 Manufacturer address
2 Device name
3 Order code
4 Serial number
5 Extended order code
6 Supply voltage
7 Maximum process pressure
8 Maximum process temperature
9 Permitted ambient temperature (Ta)
10 Temperature resistance of cable
11 Thread for cable entry
12 Material in contact with process
13 Not used
14 Firmware version
15 Device revision
16 Metrology certification numbers
17 Customized parametrization data
18 Ambient temperature range
19 CE mark / C-tick mark
20 Additional information on the device version
21 Ingress protection
22 Certificate symbol
23 Data concerning the Ex approval
24 General certificate of approval
25 Associated Safety Instructions (XA)
26 Manufacturing date
27 RoHS mark
28 QR code for the Endress+Hauser Operations App
4.2.2 Manufacturer address
Endress+Hauser SE+Co. KG
Hauptstraße 1
79689 Maulburg, Germany
Place of manufacture: See nameplate.

Incoming acceptance and product identification Micropilot NMR84
12 Endress+Hauser
4.3 Storage and transport
4.3.1 Storage conditions
• Storage temperature: –50 to +80 °C (–58 to +176 °F)
• Store the device in its original packaging.
4.3.2 Transport
LCAUTION
Housing or antenna may be damaged or break away.
Risk of injury
‣Transport the measuring device to the measuring point in its original packaging or at
the process connection.
‣Do not fasten lifting devices (hoisting slings, lifting eyes etc.) at the housing or the
antenna but at the process connection. Take into account the mass center of the device
in order to avoid unintended tilting.
‣Comply with the safety instructions, transport conditions for devices over
18 kg (39.6 lb) (IEC 61010).

Micropilot NMR84 Installation
Endress+Hauser 13
5 Installation
5.1 Installation conditions
5.1.1 Conditions for the stilling well
• Metal (no enamel coating)
• Constant diameter (no rectangular stilling wells)
• Weld seam as smooth as possible
• For best radar propagation behavior it is recommended to have holes instead of slots. If
slots can not be avoided, they should be as thin and short as possible.
• Maximum gap between antenna/horn and wall of the stilling well: 5 mm (0.2 in).
• At any transition (e.g. when using a ball valve or mending pipe segments) gaps must not
exceed 1 mm (0.04 in).
• The stilling well must be smooth on the inside. Average roughness ≤ 6.3 µm (0.248 µin)
• Length and number of the holes do not affect the measurement. The hole diameter
(deburred) can be 1/7 of the well diameter, but should not exceed 30 mm (1.2 in).
• An increase of the pipe diameter is possible if the minimum lengths according to the
following figure and table are taken into account:
øD1 øD1
øD2 øD2
L L
500 (19.7) 500 (19.7)
1 1
≤5 (0.2)
AB
≤5 (0.2)
A0023596
 3 Installation of NMR84 in stilling wells with a larger diameter
A Antenna ≤150 mm (6 in) (without horn extension)
B Antenna ≥ 200 mm (8 in) (with horn extension)
1 Extension from ØD1 to ØD2

Installation Micropilot NMR84
14 Endress+Hauser
D1 1) D2 L
100 mm (4 in) 150 mm (6 in) 300 mm (12 in)
150 mm (6 in) 200 mm (8 in) 300 mm (12 in)
200 mm (8 in) 250 mm (10 in) 300 mm (12 in)
250 mm (10 in) 300 mm (12 in) 450 mm (18 in)
1) = antenna size
5.2 Post-installation check
mIs the device undamaged (visual inspection)?
m
Does the device conform to the measuring point specifications?
For example:
• Process temperature
• Process pressure (refer to the chapter on "Material load curves" of the "Technical Information"
document)
• Ambient temperature range
• Measuring range
mAre the measuring point identification and labeling correct (visual inspection)?
mIs the device adequately protected from precipitation and direct sunlight?

Micropilot NMR84 Electrical connection
Endress+Hauser 15
6 Electrical connection
6.1 Terminal assignment
D
E
F
C
B
A
1
1
1
1 3
2
2 4
1
HR
CDI
WP
on
SIM
2
2
3
3
4
4
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
i
D
E
F
C
B
A
1
1
1
1 3
2
2 4
1
HR
CDI
WP
on
SIM
2
2
3
3
4
4
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
i
G1
3
2
POWER
G1
3
2
POWER
G1 N
G3 L
AC 85...264 V
A0026372
 4 Terminal compartment (typical example) and ground terminals
Terminal area A/B/C/D (slots for I/O modules)
Module: Up to four I/O modules, depending on the order code
• Modules with four terminals can be in any of these slots.
• Modules with eight terminals can be in slot B or C.
The exact assignment of the modules to the slots is dependent on the device version
→  18.
Terminal area E
Module: HART Ex i/IS interface
• E1: H+
• E2: H-
Terminal area F
Remote display
• F1: VCC (connect to terminal 81 of the remote display)
• F2: Signal B (connect to terminal 84 of the remote display)
• F3: Signal A (connec t to terminal 83 of the remote display)
• F4: Gnd (connect to terminal 82 of the remote display)
Terminal area G (for High voltage AC power supply and Low voltage AC power
supply)
• G1: N
• G2: not connected
• G3: L
Terminal area G (for Low voltage DC power supply)
• G1: L-
• G2: not connected
• G3: L+
Terminal area: Protective ground
Module: Protective ground connection (M4 screw)

Electrical connection Micropilot NMR84
16 Endress+Hauser
A0018339
 5 Terminal area: Protective ground
6.1.1 Power supply
D
E
F
C
B
A
1
1
1
1 3
2
2 4
1
HR
CDI
WP
on
SIM
2
2
3
3
4
4
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
i
G1
3
2
POWER
4
F
1
1 3
2
2 4
HR
CDI
WP
SIM
G1
3
2
POWER
G1 N AC 85...264 V
A0033413
G1 N
G2 not connected
G3 L
4 Green LED: indicates power supply
The supply voltage is also indicated on the nameplate.
Supply voltage
High voltage AC power supply:
Operational value:
100 to 240 VAC (- 15 % + 10 %) = 85 to 264 VAC , 50/60 Hz
Low voltage AC power supply:
Operational value:
65 VAC (- 20 % + 15 %) = 52 to 75 VAC , 50/60 Hz
Low voltage DC power supply:
Operational value:
24 to 55 VDC (- 20 % + 15 %) = 19 to 64 VDC
Power consumption
Maximum power varies depending on the configuration of the modules. The value shows
maximum apparent power, select the applicable cables accordingly. The actual consumed
effective power is 12 W.
High voltage AC power supply:
28.8 VA
Low voltage AC power supply:
21.6 VA
Low voltage DC power supply:
13.4 W

Micropilot NMR84 Electrical connection
Endress+Hauser 17
6.1.2 Remote display and operating module DKX001
1
3
Vcc
Gnd
A B
2
D
E
F
C
B
A
1
1
1
1 3
2
2 4
1
HR
CDI
WP
on
SIM
2
2
3
3
4
4
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
i
G1
3
2
POWER
F1 3
2 4
HR
WP
Vcc
Gnd
A
B
81 82 83 84
F1 F2 F3 F4
A0037025
 6 Connection of the remote display and operating module DKX001 to the Tank Gauging device (NMR8x,
NMS8x or NRF8x)
1 Remote display and operating module
2 Connecting cable
3 Tank Gauging device (NMR8x, NMS8x or NRF8x)
The remote display and operating module DKX001 is available as an accessory. For
details refer to SD01763D.
• The measured value is indicated on the DKX001 and on the local display and
operating module simultaneously.
• The operating menu cannot be accessed on both modules at the same time. If the
operating menu is entered in one of these modules, the other module is
automatically locked. This locking remains active until the menu is closed in the
first module (back to measured value display).
6.1.3 HART Ex i/IS interface
D
E
F
C
B
A
1
1
1
1 3
2
2 4
1
HR
CDI
WP
on
SIM
2
2
3
3
4
4
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
i
E1
1
2
CDI
i
G1
3
2
POWER
3
A0033414
E1 H+
E2 H-
3 Orange LED: indicates data communication
This interface always operates as the main HART master for connected HART slave
transmitters. The Analog I/O modules, on the other hand, can be configured as a
HART master or slave →  30 →  32.

Electrical connection Micropilot NMR84
18 Endress+Hauser
6.1.4 Slots for I/O modules
The terminal compartment contains four slots (A, B, C and D) for I/O modules. Depending
on the device version (ordering features 040, 050 and 060) these slots contain different
I/O modules. The table below shows which module is located in which slot for a specific
device version.
The slot assignment for the device is also indicated on a label attached to the back
cover of the display module.
Spare parts for: Proservo NMS81
Ser.-no.:8A21AC098AF4
Spare part Spare no./structure
Displacer
Wire Drum
Additional information:
XPF0002-AABICR+
AAEAEBEFLALC76
XPF0002-AABEFEG+
XPF0002-AABEFEG+
XPF0002-AABEFEG+
XPF0002-AABEFEG+
XPF0002-AABEFEG+
XPF0002-AABEFEG+
XPF0002-AABEFEG+
XPF0002-AABEFEG+
71273689
7122xxxx
XPF0002-AABEFEG+
AAAAACDEFEG+
XPF0002-AAACABADJ+
AAHAHCHRIJJAJBKP
71023451
71023451
71023451
Cover
IOM-V1
IOM-A/RTD
IOM-D
Slot A
Slot B
Slot C
Slot D
IO Mod FF
Display
Display asm.
Detector
Main electr.
SMS electr.
6
7
8
9
10
11
12
5
4
3
2
1
www.endress.com/deviceviewer
1
D
C
B
A
A0030070
1 Label showing (among other things) the modules in the slots A to D.
A Cable entry for slot A
B Cable entry for slot B
C Cable entry for slot C
D Cable entry for slot D
List of abbreviations used in table "Primary Output" (040) = "Modbus" (A1)
• O - Ordering feature
• T - Terminal area
• 040 - Primary Output
• 050 - Secondary IO Analog
• 060 - Secondary IO Digital Ex d/XP
• M - Modbus
• D - Digital
• A/XP - Analog Ex d/XP
• A/IS - Analog Ex i/IS

Micropilot NMR84 Electrical connection
Endress+Hauser 19
"Primary Output" (040) = "Modbus" (A1)
O 1)
NMx8x - XX XX XXxxxx ...
060050040
T 2)
040 3) 050 4) 060 5)
D C B A
1 1
2 2
3 3
4 4
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
A0023888
A1 X0 X0 M - - -
A1 X0 A1 M - - D
A1 X0 A2 M - D D
A1 X0 A3 M D D D
A1 X0 B1 M M - -
A1 X0 B2 M M - D
A1 X0 B3 M M D D
A1 A1 X0 M A/XP - -
A1 A1 A1 M A/XP - D
A1 A1 A2 M A/XP D D
A1 A1 B1 M M A/XP -
A1 A1 B2 M M A/XP D
A1 A2 X0 M A/XP A/XP -
A1 A2 A1 M A/XP A/XP D
A1 A2 B1 M A/XP A/XP M
A1 B1 X0 M A/IS - -
A1 B1 A1 M A/IS - D
A1 B1 A2 M A/IS D D
A1 B1 B1 M M A/IS -
A1 B1 B2 M M A/IS D
A1 B2 X0 M A/IS A/IS -
A1 B2 A1 M A/IS A/IS D
A1 B2 B1 M A/IS A/IS M
A1 C2 X0 M A/IS A/XP -
A1 C2 A1 M A/IS A/XP D
A1 C2 B1 M A/IS A/XP M
1) Ordering feature
2) Terminal area
3) Primary Output
4) Secondary IO Analog
5) Secondary IO Digital Ex d/XP

Electrical connection Micropilot NMR84
20 Endress+Hauser
List of abbreviations used in table "Primary Output" (040) = "V1" (B1)
• O - Ordering feature
• T - Terminal area
• 040 - Primary Output
• 050 - Secondary IO Analog
• 060 - Secondary IO Digital Ex d/XP
• V1 - Sakura V1
• M - Modbus
• D - Digital
• A/XP - Analog Ex d/XP
• A/IS - Analog Ex i/IS
