Brief Operating Instructions
Gammapilot M FMG50
Radiometric measurement
These Instructions are Brief Operating Instructions; they are
not a substitute for the Operating Instructions pertaining to
the device.
For detailed information, refer to the Operating Instructions
and other documentation.
Available for all device versions via:
• Internet: www.endress.com/deviceviewer
• Smart phone/Tablet: Endress+Hauser Operations App
KA01427F/00/EN/01.19
71447251
2019-08-22

Gammapilot M FMG50
2 Endress+Hauser
Order code:
Ext. ord. cd.:
Ser. no.:
www.endress.com/deviceviewer Endress+Hauser
Operations App
XXXXXXXXXXXX
XXXXX-XXXXXX
XXX.XXXX.XX
Serial number
1.
3.
2.
A0023555

Gammapilot M FMG50 Table of contents
Endress+Hauser 3
Table of contents
1 About this document .............................................................. 4
1.1 Symbols used ......................................................................... 4
1.2 Documentation ........................................................................ 5
1.3 Registered trademarks .................................................................. 6
2 Basic safety instructions .......................................................... 6
2.1 Requirements for personnel .............................................................. 6
2.2 Designated use ........................................................................ 7
2.3 Installation, commissioning and operation .................................................... 7
2.4 Hazardous area ........................................................................ 7
2.5 Radiation protection .................................................................... 8
2.6 Workplace safety ...................................................................... 9
2.7 Operational safety ......................................................................9
2.8 Product safety ........................................................................ 10
3 Mounting ....................................................................... 10
3.1 Incoming acceptance, product identification, transport, storage ................................... 10
3.2 Installation conditions .................................................................. 12
3.3 Post-installation check ................................................................. 20
4 Electrical connection ............................................................ 20
4.1 Connection compartment ............................................................... 20
4.2 4 to 20 mA HART connection ............................................................ 20
4.3 Terminal assignment .................................................................. 21
4.4 Cable entries ......................................................................... 22
4.5 Potential equalization .................................................................. 22
4.6 Rated cross-section .................................................................... 23
4.7 Wiring ............................................................................. 23
4.8 Post-connection check ..................................................................23
5 Operation ....................................................................... 24
5.1 Overview of the HART operating options .................................................... 24
5.2 Alternative operation options ............................................................ 25
5.3 Locking/unlocking configuration .......................................................... 28
5.4 Resetting to the default configuration ...................................................... 28
6 Commissioning .................................................................. 29
6.1 Post-installation and post-connection check ................................................. 29
6.2 Commissioning using the Commissioning Wizard ............................................. 30
6.3 Commissioning via SmartBlue (App) ....................................................... 30
6.4 Commissioning via on-site operation ....................................................... 31
6.5 Operation and settings via RIA15 ......................................................... 33
6.6 Data access - Security .................................................................. 33
6.7 Overview of the operating menu .......................................................... 33
7 Maintenance and repair ......................................................... 34
7.1 Cleaning ............................................................................ 34
7.2 Repair ............................................................................. 34
7.3 Replacement ......................................................................... 34
7.4 Spare parts .......................................................................... 35
7.5 Return ............................................................................. 35
7.6 Disposal ............................................................................ 35
7.7 Contact addresses at Endress+Hauser ...................................................... 36
8 Certificates and approvals ....................................................... 36
8.1 Safety Manual (SIL 2/3) ................................................................ 36
8.2 Ex approval ..........................................................................36
8.3 Other standards and guidelines ........................................................... 36

About this document Gammapilot M FMG50
4 Endress+Hauser
8.4 Certificates .......................................................................... 36
8.5 CE mark ............................................................................ 37
8.6 EAC ............................................................................... 37
8.7 Overfill protection ..................................................................... 37
1 About this document
1.1 Symbols used
1.1.1 Safety symbols
CAUTION
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
minor or medium injury.
DANGER
This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in
serious or fatal injury.
NOTICE
This symbol contains information on procedures and other facts which do not result in
personal injury.
WARNING
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
serious or fatal injury.
1.1.2 Symbols for certain types of information and graphics
Warns against radioactive substances or ionizing radiation
Permitted
Procedures, processes or actions that are permitted
Preferred
Procedures, processes or actions that are preferred
Forbidden
Procedures, processes or actions that are forbidden
Tip
Indicates additional information
Reference to documentation

Gammapilot M FMG50 About this document
Endress+Hauser 5
A
Reference to page
Reference to graphic
Notice or individual step to be observed
1.
,
2.
,
3.
Series of steps
Result of a step
Operation via local display
Operation via operating tool
Write-protected parameter
1, 2, 3, ...
Item numbers
A, B, C, ...
Views
Safety instructions
Observe the safety instructions contained in the associated Operating Instructions
1.2 Documentation
The following documentation types are available in the Downloads of the Endress+Hauser
website (www.endress.com/downloads):
For an overview of the scope of the associated Technical Documentation, refer to the
following:
•W@M Device Viewer (www.endress.com/deviceviewer): Enter the serial number from
nameplate
•Endress+Hauser Operations App: Enter the serial number from the nameplate or scan
the 2D matrix code (QR code) on the nameplate
1.2.1 Technical Information (TI)
Planning aid
The document contains all the technical data on the device and provides an overview of the
accessories and other products that can be ordered for the device.

Basic safety instructions Gammapilot M FMG50
6 Endress+Hauser
1.2.2 Operating Instructions (BA)
Your reference guide
These Operating Instructions contain all the information that is required in various phases of
the life cycle of the device: from product identification, incoming acceptance and storage, to
mounting, connection, operation and commissioning through to troubleshooting,
maintenance and disposal.
1.2.3 Safety Instructions (XA)
Depending on the approval, the following Safety Instructions (XA) are supplied with the
device. They are an integral part of the Operating Instructions.
The nameplate indicates the Safety Instructions (XA) that are relevant to the device.
1.3 Registered trademarks
HART®
Registered trademark of the FieldComm Group, Austin, Texas, USA
Apple®
Apple, the Apple logo, iPhone, and iPod touch are trademarks of Apple Inc., registered in the
U.S. and other countries. App Store is a service mark of Apple Inc.
Android®
Android, Google Play and the Google Play logo are trademarks of Google Inc.
Bluetooth®
The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG,
Inc. and any use of such marks by Endress+Hauser is under license. Other trademarks and
trade names are those of their respective owners.
2 Basic safety instructions
2.1 Requirements for personnel
The personnel for installation, commissioning, diagnostics and maintenance must fulfill the
following requirements:
• Trained, qualified specialists must have a relevant qualification for this specific function and
task
• Are authorized by the plant owner/operator
• Are familiar with federal/national regulations
• Before beginning work, the specialist staff must have read and understood the instructions
in the Operating Instructions and supplementary documentation as well as in the
certificates (depending on the application)
• Following instructions and basic conditions
The operating personnel must fulfill the following requirements:

Gammapilot M FMG50 Basic safety instructions
Endress+Hauser 7
• Being instructed and authorized according to the requirements of the task by the facility's
owner-operator
• Following the instructions in these Operating Instructions
2.2 Designated use
The Gammapilot FMG50 is a compact transmitter for non-contact level, point level, density
and concentration measurement. The measuring range is up to 3 m (9.8 ft). The Gammapilot
FMG50 is certified according to IEC 61508 for safety-related operation up to SIL 2/3.
2.3 Installation, commissioning and operation
The Gammapilot FMG50 is designed to meet state-of-the-art safety requirements and
complies with applicable standards and EU regulations. However, if it is used improperly or for
applications for which it is not intended, application-related hazards may arise, e.g. product
overflow due to incorrect installation or configuration. Installation, electrical connection,
commissioning, operation and maintenance of the measuring system must therefore be
carried out exclusively by trained specialists authorized to perform such work by the system
operator. Technical personnel must have read and understood these Operating Instructions
and must adhere to them. Modifications and repairs to the device may only be carried out if
they are expressly permitted in the Operating Instructions.
LWARNING
‣The four screws connecting the detector pipe to the terminal head may not be opened.
A0038007
2.4 Hazardous area
If the measuring system is used in hazardous areas, the corresponding national standards and
regulations must be observed. The device is accompanied by separate "Ex documentation",
which is an integral part of these Operating Instructions. The installation specifications,
connection data and safety instructions listed in this supplementary documentation must be
observed.
• Technical personnel must be qualified and trained for the hazardous area.
• Comply with the metrological and safety-related requirements for the measuring point.

Basic safety instructions Gammapilot M FMG50
8 Endress+Hauser
LWARNING
‣Observe the safety instructions associated with the device. These instructions depend on
the certificate ordered.
2.5 Radiation protection
The Gammapilot FMG50 is used in conjunction with a radiation source, contained in a source
container. When handling radiation sources, the following instructions must be observed:
2.5.1 Basic radiation protection guidelines
LWARNING
‣When working with radiation sources, avoid any unnecessary exposure to radiation. All
unavoidable radiation exposure must be kept to a minimum. Three basic concepts apply to
achieve this:
ABC
A0016373
A Shield
B Time
C Distance
LCAUTION
‣When working with source containers, all the instructions for mounting and usage outlined
in the following documents must be observed:
Source container documentation
•FQG60:
TI00445F
•FQG61, FQG62:
TI00435F
•FQG63:
TI00446F
•FQG66:
• TI01171F
• BA01327F

Gammapilot M FMG50 Basic safety instructions
Endress+Hauser 9
Shielding
Ensure the best possible shielding between the radiation source and yourself and all other
persons. Effective shielding is provided by source containers (FQG60, FQG61/ FQG62,FQG63,
FQG66) and all high-density materials (lead, iron, concrete etc.).
Time
Remain as short as possible in the area exposed to radiation.
Distance
Keep as far away from the radiation source as possible. The radiation intensity decreases in
proportion to the square of the distance from the radiation source.
2.6 Workplace safety
For work on and with the device:
‣Wear the required personal protective equipment according to federal/national
regulations.
‣Switch off the supply voltage before connecting the device.
2.7 Operational safety
Risk of injury.
‣Operate the device in proper technical condition and fail-safe condition only.
‣The operator is responsible for interference-free operation of the device.
Conversions to the device
Unauthorized modifications to the device are not permitted and can lead to unforeseeable
dangers.
‣If, despite this, modifications are required, consult with the manufacturer.
Repair
To ensure continued operational safety and reliability,
‣Carry out repairs on the device only if they are expressly permitted.
‣Observe federal/national regulations pertaining to repair of an electrical device.
‣Use original spare parts and accessories from the manufacturer only.
Hazardous area
To eliminate a danger for persons or for the facility when the device is used in the hazardous
area (e.g. explosion protection, pressure vessel safety):
‣Based on the nameplate, check whether the ordered device is permitted for the intended
use in the hazardous area.
‣Observe the specifications in the separate supplementary documentation that is an integral
part of these Instructions.

Mounting Gammapilot M FMG50
10 Endress+Hauser
2.8 Product safety
This measuring device is designed in accordance with good engineering practice to meet state-
of-the-art safety requirements, has been tested, and left the factory in a condition in which it
is safe to operate. It meets general safety standards and legal requirements.
2.8.1 CE mark
The measuring system meets the legal requirements of the applicable EU Directives. These are
listed in the corresponding EU Declaration of Conformity along with the standards applied.
Endress+Hauser confirms successful testing of the device by affixing to it the CE mark.
2.8.2 EAC conformity
The measuring system meets the legal requirements of the applicable EAC guidelines. These
are listed in the corresponding EAC Declaration of Conformity together with the standards
applied.
Endress+Hauser confirms successful testing of the device by affixing to it the EAC mark.
3 Mounting
3.1 Incoming acceptance, product identification, transport, storage
3.1.1 Incoming acceptance
Check the following during incoming acceptance:
 Are the order codes on the delivery note and the product sticker identical?
 Are the goods undamaged?
 Do the nameplate data match the ordering information on the delivery note?
 If required (see nameplate): Are the safety instructions (XA) provided?
If one of these conditions is not met, please contact the manufacturer's sales office.
3.1.2 Product identification
The following options are available for the identification of the measuring device:
• Nameplate specifications
• Extended order code with breakdown of the device features on the delivery note
‣Enter the serial number from the nameplates into W@M Device Viewer
(www.endress.com/deviceviewer)
 All the information about the measuring device and the scope of the associated
Technical Documentation are displayed.

Gammapilot M FMG50 Mounting
Endress+Hauser 11
‣Enter the serial number from the nameplate into the Endress+Hauser Operations App or
use the Endress+Hauser Operations App to scan the 2-D matrix code (QR Code) provided on
the nameplate
 All the information about the measuring device and the scope of the associated
Technical Documentation are displayed.
3.1.3 Manufacturer address
Endress+Hauser SE+Co. KG
Hauptstraße 1
79689 Maulburg, Germany
Address of the manufacturing plant: See nameplate.
3.1.4 Transporting to the measuring point
LCAUTION
Risk of injury
‣Follow the safety instructions and transport conditions for devices weighing more than
18 kg (39.69 lb).
3.1.5 Storage
Pack the device so that it is protected against impact for storage and transport. The original
packaging provides optimum protection. The permitted storage temperature is:
NaI (Tl) crystal
–40 to +80 °C (–40 to +176 °F)
PVT scintillator (standard)
–40 to +60 °C (–40 to +140 °F)
PVT scintillator (high-temperature version)
–20 to +80 °C (–4 to +176 °F)
As the device contains a battery, it is recommended to store the device at room
temperature in a location that does not receive direct sunlight

Mounting Gammapilot M FMG50
12 Endress+Hauser
3.2 Installation conditions
3.2.1 General information
• The angle of emission of the source container must be exactly aligned to the measuring
range of the Gammapilot FMG50. Observe the measuring range marks of the device.
• The source container and the Gammapilot FMG50 should be mounted as close to the vessel
as possible. Any access to the beam must be blocked to ensure that it is not possible to reach
into this area.
• The Gammapilot FMG50 should be protected against direct sunlight or process heat in
order to increase its service life.
• Option: "Weather protection cover"
• Option: "Heat shield for the sensor"
• Clamps are optionally supplied with the device.
• The mounting device must be installed in such a way as to withstand the weight of the
Gammapilot FMG50 under all anticipated operating conditions (e.g. vibrations).
More information with regard to the safety-related use of the Gammapilot FMG50 can
be found in the Functional Safety Manual.
3.2.2 Dimensions, weights
Gammapilot FMG50
143×118
(5.63×4.65)
A
Ø85 (3.35)
B
248 (9.76)
A0037984
• Version NaI (Tl) 2" :
Total length A: 430 mm (16.93 in), weight: 11.60 kg (25.57 lb)
• Version NaI (Tl) 4" :
Total length A: 480 mm (18.90 in), weight: 12.19 kg (26.87 lb)
• Version PVT 200 :
Total length A: 590 mm (23.23 in), weight: 12.10 kg (26.68 lb)
• Version PVT 400 :
Total length A: 790 mm (31.10 in), weight: 13.26 kg (29.23 lb)

Gammapilot M FMG50 Mounting
Endress+Hauser 13
• Version PVT 800 :
Total length A: 1 190 mm (46.85 in), weight: 15.54 kg (34.26 lb)
• Version PVT 1200 :
Total length A: 1 590 mm (62.60 in), weight: 17.94 kg (39.55 lb)
• Version PVT 1600 :
Total length A: 1 990 mm (78.35 in), weight: 20.14 kg (44.40 lb)
• Version PVT 2000 :
Total length A: 2 390 mm (94.09 in), weight: 22.44 kg (49.47 lb)
• Version PVT 2400 :
Total length A: 2 790 mm (109.84 in), weight: 24.74 kg (54.54 lb)
• Version PVT 3000 :
Total length A: 3 390 mm (133.46 in), weight: 28.14 kg (62.04 lb)
The weight data refer to the stainless steel housing versions. The aluminum housing
versions are 2.5 kg (5.51 lb) lighter.
The additional weight for small parts is: 1 kg (2.20 lb)
3.2.3 Installation conditions for level measurement
Conditions
• The Gammapilot FMG50 is mounted vertically for level measurements.
• When the Gammapilot FMG50 is installed upside-down, it can be given additional support
(retaining bracket) to prevent damage to the connecting cable or to the unit if it falls.

Mounting Gammapilot M FMG50
14 Endress+Hauser
Examples
A
D E
C
B
A0037715
A Vertical cylinder; the Gammapilot FMG50 is mounted vertically with the detector head pointing either
downwards or upwards, the gamma ray is aligned to the measuring range.
B Correct: Gammapilot FMG50 mounted outside the tank insulation
C Incorrect: Gammapilot FMG50 mounted inside the tank insulation
D Conical vessel outlet
E Horizontal cylinder
3.2.4 Installation conditions for point level detection
Conditions
For point level detection, the Gammapilot FMG50 is generally mounted horizontally at the
height of the desired level limit.

Gammapilot M FMG50 Mounting
Endress+Hauser 15
Measuring system arrangement
AB
A0018075
A Maximum point level detection
B Minimum point level detection
3.2.5 Installation conditions for density measurement
Conditions
• If possible, density should be measured on vertical pipes with forward flow from bottom to
top.
• If only horizontal pipes are accessible, the path of the beam should also be arranged
horizontally to minimize the influence of air bubbles and deposits.
• The Endress+Hauser clamping device or an equivalent clamping device should be used to
fasten the source container and the Gammapilot FMG50 to the measuring pipe.
The clamping device itself must be installed in such a way as to withstand the weight of the
source container and the Gammapilot FMG50 under all anticipated operating conditions.
• The sample point may not be further than 20 m (66 ft) from the measuring point.
• The distance of the density measurement to pipe bends is ≥3 x pipe diameter, and ≥10 x
pipe diameter in the case of pumps.
Measuring system arrangement
The arrangement of the source container and the Gammapilot FMG50 depends on the pipe
diameter (or the radiated length) and the density measuring range. These two parameters
determine the measuring effect (relative change in the pulse rate). The longer the radiated
length, the greater the measuring effect. Therefore, it is advisable to use diagonal irradiation
or a measurement section for small pipe diameters.
To select the measuring system arrangement please contact your Endress+Hauser sales
organization or use the Applicator™ 1)
1) configuration software. The Applicator™ is available from your Endress+Hauser sales organization.

Mounting Gammapilot M FMG50
16 Endress+Hauser
A
1
BC
A0018076
A Vertical beam (90°)
B Diagonal beam (30°)
C Measurement section
1 Sample point
• To increase the accuracy of density measurements, the use of a collimator is
recommended. The collimator screens the detector against background radiation.
• When planning, the total weight of the measuring system must be taken into
consideration.
• A clamping device is available as an accessory
• When the Gammapilot FMG50 is installed upside-down, it can be given additional
support (retaining bracket) to prevent damage to the connecting cable or to the unit if
it falls.
3.2.6 Installation conditions for interface measurement
Conditions
For interface measurement, the Gammapilot FMG50 is typically mounted horizontally at the
upper or lower limit of the interface range. When introducing a radiation source into an
immersion tube, it is important to ensure that the measuring range is already filled with
medium in order to keep the radiation in the vicinity of the source as low as possible. When a
radiation source is used in an immersion tube, the radiation can only be aligned with the
measuring range of the Gammapilot FMG50 using a collimator on the immersion tube.
Description
The measuring principle is based on the fact that the radiation source emits radiation which is
attenuated when it penetrates a material and the medium to be measured. In radiometric
interface measurement, the radiation source is often introduced into a closed, double-wall
immersion tube via a cable extension. This excludes the possibility of contact between the
radiation source and the medium.
Depending on the measuring range and the application, one or several detectors are mounted
on the outside of the vessel. The average density of the medium between the radiation source
and the detector is calculated from the radiation received. A direct correlation to the position
of the interface can then be derived from this density value.

Gammapilot M FMG50 Mounting
Endress+Hauser 17
For more information, see:
CP01205F/00/EN
3.2.7 Installation conditions for density profile measurement (DPS)
Conditions
For density profile measurement, Gammapilot FMG50 devices are installed horizontally at
defined distances, depending on the size of the measuring range. In the case of density profile
measurement, the radiation source is normally inserted in an immersion tube, preferably one
that is double-walled, and introduced into the vessel. When introducing a radiation source
into an immersion tube, it is important to ensure that the measuring range is already filled
with medium in order to keep the radiation in the vicinity of the source as low as possible.
Description
To obtain detailed information on the distribution of layers of different densities in a vessel, a
density profile is measured using a multi-detector solution. Several FMG50 devices are
installed next to one another on the outside of the vessel wall for this purpose. The measuring
range is divided into zones and each compact transmitter measures the density value in its
respective zone. A density profile is derived from these values.
This results in a high-resolution measurement of the distribution of medium layers (e.g. in
separators)
For more information, see:
CP01205F/00/EN
3.2.8 Installation conditions for concentration measurement
Conditions
• If possible, the concentration should be measured on vertical pipes with forward flow from
bottom to top.
• If only horizontal pipes are accessible, the path of the beam should also be arranged
horizontally to minimize the influence of air bubbles and deposits.
• The Endress+Hauser clamping device or an equivalent clamping device should be used to
fasten the source container and the Gammapilot FMG50 to the measuring pipe.
The clamping device itself must be installed in such a way as to withstand the weight of the
source container and the Gammapilot FMG50 under all anticipated operating conditions.
• When the Gammapilot FMG50 is installed upside-down, it can be given additional support
(retaining bracket) to prevent damage to the connecting cable or to the unit if it falls.
• The sample point may not be further than 20 m (66 ft) from the measuring point.
• The distance of the density measurement to pipe bends is ≥3 x pipe diameter, and ≥10 x
pipe diameter in the case of pumps.
Measuring system arrangement
The arrangement of the source container and the Gammapilot FMG50 depends on the pipe
diameter (or the radiated length) and the density measuring range. These two parameters

Mounting Gammapilot M FMG50
18 Endress+Hauser
determine the measuring effect (relative change in the pulse rate). The longer the radiated
length, the greater the measuring effect. Therefore, it is advisable to use diagonal irradiation
or a measurement section for small pipe diameters.
For the configuration of the measuring system, please contact your Endress+Hauser sales
organization or use the Applicator™ 1) configuration program.
A
1
BC
A0018076
A Vertical beam (90°)
B Diagonal beam (30°)
C Measurement section
1 Sample point
• When planning, the total weight of the measuring system must be taken into
consideration.
• The Gammapilot FMG50 can be given additional support (retaining bracket) to secure
it against falling or to prevent damage to the connecting cable.
• A clamping device is available as an accessory
3.2.9 Installation conditions for concentration measurement with radiating media
Measurement of the concentration of radiating media in vessels
The concentration of radiating media in vessels can be determined by taking a measurement
at the vessel wall. The intensity of the radiation received is proportional to the concentration
of the radiating medium in the vessel. It is important to note that the medium in the vessel
also absorbs its own radiation. The detected radiation will not increase further with larger
diameters and the signal is saturated. This saturation length depends on the half-value layer
of the material.
The level in the vessel must be constant in the vicinity of the detector to ensure the
measurement is correct.
Measurement of the mass flow of radiating media
In the case of belt scales and pipes, the concentration of the radiating medium can be
measured in the sample. Here, the device is mounted above or below the conveyor belt so that
it is parallel to the belt direction, or is mounted on the pipe. The intensity of the radiation

Gammapilot M FMG50 Mounting
Endress+Hauser 19
received is proportional to the concentration of the radiating medium in the conveyed
material.
3.2.10 Installation conditions for flow measurement
Measurement of mass flow (liquids)
The density signal determined by the Gammapilot FMG50 is transmitted to the Promag 55S.
The Promag 55S measures the volume flow; the Promag can determine a mass flow in
connection with the calculated density value.
rC
rS
1
2
rM
m
V
A0018093
 1 Mass flow measurement (m) using a density meter and a flowmeter. If the density of the solids
(ρs) and the density of the carrier liquid (ρc) are also known, the solids flow rate can be calculated.
1 Gammapilot FMG50 -> total density ( ρm) consisting of the carrier liquid and solids
2 Flowmeter (Promag 55S) -> volume flow (V). The solids density (ρs) and the density of the carrier
liquid (ρc) also have to be entered in the transmitter
Measurement of mass flow (solids)
Bulk solids applications on conveyor belts and conveyor screws.
The source container is positioned above the conveyor belt and the Gammapilot FMG50 below
the conveyor belt. The radiation is attenuated by the medium on the conveyor belt. The
intensity of the radiation received is proportional to the density of the medium. The mass flow
is calculated from the belt speed and the radiation intensity.

Electrical connection Gammapilot M FMG50
20 Endress+Hauser
1
A0036637
1 Gammapilot FMG50
3.3 Post-installation check
After installing the measuring device, carry out the following checks:
 Is the device damaged (visual inspection)?
 Does the device match the measuring point specifications (ambient temperature,
measuring range etc.)?
 If available: are the measuring point number and labeling correct (visual inspection)?
 Is the measuring device sufficiently protected against sunlight?
 Are the cable glands tightened correctly?
4 Electrical connection
4.1 Connection compartment
1
A0038877
1 Connection compartment
4.2 4 to 20 mA HART connection
Connection of the device with HART communication, power source and 4 to 20 mA display
