Endress+Hauser Proline Promass S 100 Manual

Easy-to-clean flowmeter with self-drainable single-tube system and an ultra-
compact transmitter
Application
• Measuring principle operates independently of physical fluid
properties such as viscosity or density
• Dedicated for applications requiring optimal cleanability
under hygienic conditions
Device properties
• Large range of hygienic process connections
• 3A and EHEDG conform
• Fast recovery from CIP/SIP
• Robust, ultra-compact transmitter housing
• High ingress protection: IP69K
• Local display available
Your benefits
• Low installation costs – compact, horizontal installation
thanks to fully self-draining tube
• Fewer process measuring points – multivariable
measurement (flow, density, temperature)
• Space-saving installation – no in/outlet run needs
• Space-saving transmitter – full functionality on smallest
footprint
• Time-saving local operation without additional software and
hardware – integrated web server
• Integrated verification – Heartbeat Technology™
Products Solutions Services
Technical Information
Proline Promass S 100
Coriolis flowmeter
TI01037D/06/EN/04.14
71254125

Proline Promass S 100
2 Endress+Hauser
Table of contents
Document information ....................... 4
Symbols used ................................ 4
Function and system design ................... 5
Measuring principle ............................ 5
Measuring system ............................. 6
Device architecture ............................ 7
Safety ..................................... 7
Input ..................................... 7
Measured variable ............................. 7
Measuring range .............................. 8
Operable flow range ........................... 8
Output ................................... 9
Output signal ................................ 9
Signal on alarm .............................. 10
Ex connection data ........................... 12
Low flow cut off ............................. 12
Galvanic isolation ............................ 13
Protocol-specific data .......................... 13
Power supply ............................. 18
Terminal assignment .......................... 18
Pin assignment, device plug ...................... 24
Supply voltage .............................. 26
Power consumption ........................... 26
Current consumption .......................... 27
Power supply failure .......................... 27
Electrical connection .......................... 27
Potential equalization ......................... 31
Terminals ................................. 31
Cable entries ............................... 32
Cable specification ............................ 32
Performance characteristics .................. 33
Reference operating conditions ................... 33
Maximum measured error ....................... 33
Repeatability ............................... 34
Response time .............................. 35
Influence of ambient temperature ................. 35
Influence of medium temperature .................. 35
Influence of medium pressure .................... 36
Design fundamentals .......................... 36
Installation ............................... 37
Mounting location ............................ 37
Orientation ................................ 38
Inlet and outlet runs .......................... 38
Special mounting instructions .................... 39
Mounting Safety Barrier Promass 100 ............... 40
Environment .............................. 40
Ambient temperature range ..................... 40
Storage temperature .......................... 42
Climate class ............................... 42
Degree of protection .......................... 42
Shock resistance ............................. 42
Vibration resistance ........................... 42
Interior cleaning ............................. 42
Electromagnetic compatibility (EMC) ............... 43
Process .................................. 43
Medium temperature range ...................... 43
Density ................................... 43
Pressure-temperature ratings .................... 43
Secondary containment pressure rating .............. 46
Flow limit ................................. 46
Pressure loss ............................... 47
System pressure ............................. 47
Thermal insulation ........................... 47
Heating ................................... 48
Vibrations ................................. 48
Mechanical construction .................... 49
Design, dimensions ........................... 49
Weight ................................... 64
Materials .................................. 65
Process connections ........................... 66
Operability ............................... 66
Operating concept ............................ 66
Local display ................................ 67
Remote operation ............................ 67
Service interface ............................. 68
Certificates and approvals ................... 70
CE mark ................................... 70
C-Tick symbol ............................... 70
Ex approval ................................ 71
Hygienic compatibility ......................... 71
Certification PROFIBUS ......................... 71
Modbus RS485 certification ..................... 71
EtherNet/IP certification ........................ 71
Pressure Equipment Directive .................... 71
Other standards and guidelines ................... 72
Ordering information ....................... 72
Application packages ....................... 73
Heartbeat Technology ......................... 73
Concentration ............................... 73
Accessories ............................... 73
Device-specific accessories ...................... 73
Communication-specific accessories ................ 74
Service-specific accessories ...................... 74
System components ........................... 75
Documentation ............................ 75
Standard documentation ........................ 75
Supplementary device-dependent documentation ....... 75

Proline Promass S 100
Endress+Hauser 3
Registered trademarks ...................... 76

Proline Promass S 100
4 Endress+Hauser
Document information
Symbols used Electrical symbols
Symbol Meaning
Direct current
A terminal to which DC voltage is applied or through which direct current flows.
Alternating current
A terminal to which alternating voltage is applied or through which alternating current flows.
Direct current and alternating current
• A terminal to which alternating voltage or DC voltage is applied.
• A terminal through which alternating current or direct current flows.
Ground connection
A grounded terminal which, as far as the operator is concerned, is grounded via a grounding
system.
Protective ground connection
A terminal which must be connected to ground prior to establishing any other connections.
Equipotential connection
A connection that has to be connected to the plant grounding system: This may be a potential
equalization line or a star grounding system depending on national or company codes of practice.
Symbols for certain types of information
Symbol Meaning
Permitted
Indicates procedures, processes or actions that are permitted.
Preferred
Indicates procedures, processes or actions that are preferred.
Forbidden
Indicates procedures, processes or actions that are forbidden.
Tip
Indicates additional information.
Reference to documentation
Refers to the corresponding device documentation.
Reference to page
Refers to the corresponding page number.
Reference to graphic
Refers to the corresponding graphic number and page number.
Visual inspection
Symbols in graphics
Symbol Meaning
1, 2, 3,... Item numbers
,… ,
Series of steps
A, B, C, ... Views
A-A, B-B, C-C, ... Sections
Flow direction

Proline Promass S 100
Endress+Hauser 5
Symbol Meaning
-
Hazardous area
Indicates a hazardous area.
.
Safe area (non-hazardous area)
Indicates the non-hazardous area.
Function and system design
Measuring principle The measuring principle is based on the controlled generation of Coriolis forces. These forces are
always present in a system when both translational and rotational movements are superimposed.
Fc = 2 · ∆m (ν · ω)
Fc = Coriolis force
∆m = moving mass
ω = rotational velocity
ν = radial velocity in rotating or oscillating system
The amplitude of the Coriolis force depends on the moving mass ∆m, its velocity ν in the system and
thus on the mass flow. Instead of a constant rotational velocity ω, the sensor uses oscillation.
In the sensor, an oscillation is produced in the measuring tube. The Coriolis forces produced at the
measuring tube cause a phase shift in the tube oscillations (see illustration):
• If there is zero flow (i.e. when the fluid stands still), the oscillation measured at points A and B has
the same phase (no phase difference).
• Mass flow causes deceleration of the oscillation at the inlet of the tubes (2) and acceleration at the
outlet (3).
1 2 3
A0016772
The phase difference (A-B) increases with increasing mass flow. Electrodynamic sensors register the
tube oscillations at the inlet and outlet. System balance is created by exciting an eccentrically
arranged swinging mass to antiphase oscillation. The measuring principle operates independently of
temperature, pressure, viscosity, conductivity and flow profile.
Density measurement
The measuring tube is continuously excited at its resonance frequency. A change in the mass and
thus the density of the oscillating system (comprising measuring tube and fluid) results in a
corresponding, automatic adjustment in the oscillation frequency. Resonance frequency is thus a
function of medium density. The microprocessor utilizes this relationship to obtain a density signal.
Volume measurement
Together with the measured mass flow, this is used to calculate the volume flow.
Temperature measurement
The temperature of the measuring tube is determined in order to calculate the compensation factor
due to temperature effects. This signal corresponds to the process temperature and is also available
as an output signal.

Proline Promass S 100
6 Endress+Hauser
Measuring system The device consists of a transmitter and a sensor. If a device with Modbus RS485 intrinsically safe is
ordered, the Safety Barrier Promass 100 is part of the scope of supply and must be implemented to
operate the device.
One device version is available: compact version, transmitter and sensor form a mechanical unit.
Transmitter
Promass 100 Device versions and materials:
• Compact, aluminum coated:
Aluminum, AlSi10Mg, coated
• Compact, hygienic, stainless:
Hygienic version, stainless steel 1.4301 (304)
• Ultra compact, hygienic, stainless:
Hygienic version, stainless steel 1.4301 (304)
Configuration:
• Via operating tools (e.g. FieldCare)
• Additionally for device version with onsite display:
Via Web browser (e.g. Microsoft Internet Explorer)
• Also for device version with 4-20 mA HART, pulse/frequency/switch
output:
Via Web browser (e.g. Microsoft Internet Explorer)
• Also for device version with EtherNet/IP output:
– Via Web browser (e.g. Microsoft Internet Explorer)
– Via Add-on Profile Level 3 for automation system from Rockwell
Automation
– Via Electronic Data Sheet (EDS)
A0016693
A0016694
A0016695
Sensor
Promass S • Hygienic design and sensitive fluid handling
• Simultaneous measurement of flow, volume flow, density and
temperature (multivariable)
• Immune to process influences
• Nominal diameter range: DN 8 to 50 (³⁄₈ to 2")
• Materials:
– Sensor: stainless steel, 1.4301 (304)
– Measuring tubes: stainless steel, 1.4539 (904L)
– Process connections: stainless steel, 1.4435 (316L), stainless steel,
1.4404 (316/316L)
– Surface quality: Ramax0.8 µm (32 µin) (mechanically polished)
A0016509
Safety Barrier Promass 100
A0016763
• Dual-channel safety barrier for installation in non-hazardous locations
or Zone 2/Div. 2:
– Channel 1: DC 24 V power supply
– Channel 2: Modbus RS485
• In addition to current, voltage and power limitation, it offers galvanic
isolation of circuits for explosion protection.
• Easy DIN rail mounting (DIN 35mm) for installation in control cabinets

Proline Promass S 100
Endress+Hauser 7
Device architecture
2 31
6 7
5
8
9
10
4
A0016779
 1 Possibilities for integrating measuring devices into a system
1 Control system (e.g. PLC)
2 EtherNet/IP
3 PROFIBUS DP
4 Modbus RS485
5 4-20 mA HART, pulse/frequency/switch output
6 Safety Barrier Promass 100
7 Modbus RS485 intrinsically safe
8 Non-hazardous area
9 Non-hazardous area and Zone 2/Div. 2
10 Intrinsically safe area and Zone 1/Div. 1
Safety IT security
We only provide a warranty if the device is installed and used as described in the Operating
Instructions. The device is equipped with security mechanisms to protect it against any inadvertent
changes to the device settings.
IT security measures in line with operators' security standards and designed to provide additional
protection for the device and device data transfer must be implemented by the operators themselves.
Input
Measured variable Direct measured variables
• Mass flow
• Density
• Temperature
Calculated measured variables
• Volume flow
• Corrected volume flow
• Reference density

Proline Promass S 100
8 Endress+Hauser
Measuring range Measuring ranges for liquids
DN Measuring range full scale values min(F) to max(F)
[mm] [in] [kg/h] [lb/min]
8 ³⁄₈ 0 to 2 000 0 to 73.50
15 ½ 0 to 6 500 0 to 238.9
25 1 0 to 18 000 0 to 661.5
40 1½ 0 to 45 000 0 to 1 654
50 2 0 to 70 000 0 to 2 573
Measuring ranges for gases
The full scale values depend on the density of the gas and can be calculated with the formula below:
max(G) =  max(F) · ρG : x
 max(G) Maximum full scale value for gas [kg/h]
 max(F) Maximum full scale value for liquid [kg/h]
 max(G) <  max(F)  max(G) can never be greater than  max(F)
ρGGas density in [kg/m³] at operating conditions
DN x
[mm] [in] [kg/m3]
8 ³⁄₈ 60
15 ½ 80
25 1 90
40 1½ 90
50 2 90
To calculate the measuring range, use the Applicator sizing tool (→  74)
Calculation example for gas
• Sensor: Promass S, DN 50
• Gas: Air with a density of 60.3 kg/m³ (at 20 °C and 50 bar)
• Measuring range (liquid):70 000 kg/h
• x = 90 kg/m³ (for Promass S, DN 50)
Maximum possible full scale value:
 max(G) =  max(F) · ρG : x = 70 000 kg/h · 60.3 kg/m³ : 90 kg/m³ = 46 900 kg/h
Recommended measuring range
"Flow limit" section (→  46)
Operable flow range Over 1000 : 1.
Flow rates above the preset full scale value are not overridden by the electronics unit, with the result
that the totalizer values are registered correctly.

Proline Promass S 100
Endress+Hauser 9
Output
Output signal Current output
Current output 4-20 mA HART (active)
Maximum output values • DC 24 V (no flow)
• 22.5 mA
Load 0 to 700 Ω
Resolution 0.38 µA
Damping Adjustable: 0.07 to 999 s
Assignable measured
variables
• Mass flow
• Volume flow
• Corrected volume flow
• Density
• Reference density
• Temperature
The range of options increases if the measuring device has one or more
application packages.
Pulse/frequency/switch output
Function Can be set to pulse, frequency or switch output
Version Passive, open collector
Maximum input values • DC 30 V
• 25 mA
Voltage drop For 25 mA: ≤ DC 2 V
Pulse output
Pulse width Adjustable: 0.05 to 2 000 ms
Maximum pulse rate 10 000 Impulse/s
Pulse value Adjustable
Assignable measured
variables
• Mass flow
• Volume flow
• Corrected volume flow
Frequency output
Output frequency Adjustable: 0 to 10 000 Hz
Damping Adjustable: 0 to 999 s
Pulse/pause ratio 1:1
Assignable measured
variables
• Mass flow
• Volume flow
• Corrected volume flow
• Density
• Reference density
• Temperature
The range of options increases if the measuring device has one or more
application packages.
Switch output
Switching behavior Binary, conductive or non-conductive
Switching delay Adjustable: 0 to 100 s

Proline Promass S 100
10 Endress+Hauser
Number of switching
cycles
Unlimited
Assignable functions • Off
• On
• Diagnostic behavior
• Limit value
– Mass flow
– Volume flow
– Corrected volume flow
– Density
– Reference density
– Temperature
– Totalizer 1-3
• Flow direction monitoring
• Status
– Partially filled pipe detection
– Low flow cut off
The range of options increases if the measuring device has one or more
application packages.
PROFIBUS DP
Signal encoding NRZ code
Data transfer 9.6 kBaud…12 MBaud
Modbus RS485
Physical interface In accordance with EIA/TIA-485-A standard
Terminating resistor • For device version used in non-hazardous areas or Zone 2/Div. 2: integrated
and can be activated via DIP switches on the transmitter electronics module
• For device version used in intrinsically safe areas: integrated and can be
activated via DIP switches on the Safety Barrier Promass 100
EtherNet/IP
Standards In accordance with IEEE 802.3
Signal on alarm Depending on the interface, failure information is displayed as follows:
Current output
4-20 mA
Failure mode Selectable (as per NAMUR recommendation NE 43):
• Minimum value: 3.6 mA
• Maximum value: 22 mA
• Defined value: 3.59 to 22.5 mA
• Actual value
• Last valid value
HART
Device diagnostics Device condition can be read out via HART Command 48

Proline Promass S 100
Endress+Hauser 11
Pulse/frequency/switch output
Pulse output
Failure mode Choose from:
• Actual value
• No pulses
Frequency output
Failure mode Choose from:
• Actual value
• Defined value: 0 to 12 500 Hz
• 0 Hz
Switch output
Failure mode Choose from:
• Current status
• Open
• Closed
PROFIBUS DP
Status and alarm
messages
Diagnostics in accordance with PROFIBUS PA Profile 3.02
Modbus RS485
Failure mode Choose from:
• NaN value instead of current value
• Last valid value
EtherNet/IP
Device diagnostics Device condition can be read out in Input Assembly
Local display
Plain text display With information on cause and remedial measures
Backlight Red backlighting indicates a device error.
Status signal as per NAMUR recommendation NE 107
Operating tool
• Via digital communication:
– HART protocol
– PROFIBUS DP
– Modbus RS485
– EtherNet/IP
• Via service interface
Plain text display With information on cause and remedial measures
Additional information on remote operation (→  67)

Proline Promass S 100
12 Endress+Hauser
Web browser
Plain text display With information on cause and remedial measures
Light emitting diodes (LED)
Status information Status indicated by various light emitting diodes
The following information is displayed depending on the device version:
• Supply voltage active
• Data transmission active
• Device alarm/error has occurred
• EtherNet/IP network available
• EtherNet/IP connection established
Ex connection data These values only apply for the following device version:
Order code for "Output", option M: Modbus RS485, for use in intrinsically safe areas
Safety Barrier Promass 100
Safety-related values
Terminal numbers
Supply voltage Signal transmission
2 (L-) 1 (L+) 26 (A) 27 (B)
Unom = DC 24 V
Umax = AC 260 V
Unom = DC 5 V
Umax = AC 260 V
Intrinsically safe values
Terminal numbers
Supply voltage Signal transmission
20 (L-) 10 (L+) 62 (A) 72 (B)
Uo = 16.24 V
Io = 623 mA
Po = 2.45 W
For IIC*: Lo = 92.8 µH, Co = 0.433 μF, Lo/Ro = 14.6 μH/Ω
For IIB*: Lo= 372 µH, Co = 2.57 μF, Lo/Ro = 58.3 μH/Ω
* The gas group depends on the sensor and nominal diameter.
For an overview and for information on the interdependencies between the gas group - sensor - nominal
diameter, see the "Safety Instructions" (XA) document for the measuring device
Transmitter
Intrinsically safe values
Order code for
"Approvals"
Terminal numbers
Supply voltage Signal transmission
20 (L-) 10 (L+) 62 (A) 72 (B)
• Option BM: ATEX II2G + IECEx Z1 Ex ia, II2D Ex tb
• Option BO: ATEX II1/2G + IECEx Z0/Z1 Ex ia, II2D
• Option BQ: ATEX II1/2G + IECEx Z0/Z1 Ex ia
• Option BU: ATEX II2G + IECEx Z1 Ex ia
• Option C2: CSA C/US IS Cl. I, II, III Div. 1
• Option 85: ATEX II2G + IECEx Z1 Ex ia + CSA C/US
IS Cl. I, II, III Div. 1
Ui = 16.24 V
Ii = 623 mA
Pi = 2.45 W
Li = 0 µH
Ci = 6 nF
For an overview and for information on the interdependencies between the gas group - sensor - nominal
diameter, see the "Safety Instructions" (XA) document for the measuring device
Low flow cut off The switch points for low flow cut off are user-selectable.

Proline Promass S 100
Endress+Hauser 13
Galvanic isolation The following connections are galvanically isolated from each other:
• Outputs
• Power supply
Protocol-specific data HART
Manufacturer ID 0x11
Device type ID 0x4A
HART protocol revision 7.0
Device description files
(DTM, DD)
Information and files under:
www.endress.com
HART load Min. 250 Ω
Dynamic variables Read out the dynamic variables: HART command 3
The measured variables can be freely assigned to the dynamic variables.
Measured variables for PV (primary dynamic variable)
• Mass flow
• Volume flow
• Corrected volume flow
• Density
• Reference density
• Temperature
Measured variables for SV, TV, QV (secondary, tertiary and quaternary
dynamic variable)
• Mass flow
• Volume flow
• Corrected volume flow
• Density
• Reference density
• Temperature
• Totalizer 1
• Totalizer 2
• Totalizer 3
The range of options increases if the measuring device has one or more
application packages.
Heartbeat Technology Application Package
Additional measured variables are available with the Heartbeat Technology
application package:
• Carrier pipe temperature
• Oscillation amplitude 0
Device variables Read out the device variables: HART command 9
The device variables are permanently assigned.
A maximum of 8 device variables can be transmitted:
• 0 = mass flow
• 1 = volume flow
• 2 = corrected volume flow
• 3 = density
• 4 = reference density
• 5 = temperature
• 6 = totalizer 1
• 7 = totalizer 2
• 8 = totalizer 3
• 9 = dynamic viscosity
• 10 = kinematic viscosity
• 11 = temp. compensated dynamic viscosity
• 12 = temp. compensated kinematic viscosity
• 13 = target mass flow
• 14 = carrier mass flow
• 15 = concentration

Proline Promass S 100
14 Endress+Hauser
PROFIBUS DP
Manufacturer ID 0x11
Ident number 0x1561
Profile version 3.02
Device description files (GSD,
DTM, DD)
Information and files under:
•www.endress.com
•www.profibus.org
Output values
(from measuring device to
automation system)
Analog input 1 to 8
• Mass flow
• Volume flow
• Corrected volume flow
• Target mass flow
• Carrier mass flow
• Density
• Reference density
• Concentration
• Dynamic viscosity
• Kinematic viscosity
• Temp. compensated dynamic viscosity
• Temp. compensated kinematic viscosity
• Temperature
• Carrier pipe temperature
• Electronic temperature
• Oscillation frequency
• Oscillation amplitude
• Frequency fluctuation
• Oscillation damping
• Tube damping fluctuation
• Signal asymmetry
• Exciter current
Digital input 1 to 2
• Partially filled pipe detection
• Low flow cut off
Totalizer 1 to 3
• Mass flow
• Volume flow
• Corrected volume flow
Input values
(from automation system to
measuring device)
Analog output 1 to 3 (fixed assignment)
• Pressure
• Temperature
• Reference density
Digital output 1 to 3 (fixed assignment)
• Digital output 1: switch positive zero return on/off
• Digital output 2: perform zero point adjustment
• Digital output 3: switch switch output on/off
Totalizer 1 to 3
• Totalize
• Reset and hold
• Preset and hold
• Stop
• Operating mode configuration:
– Net flow total
– Forward flow total
– Reverse flow total

Proline Promass S 100
Endress+Hauser 15
Supported functions • Identification & Maintenance
Simplest device identification on the part of the control system and
nameplate
• PROFIBUS upload/download
Reading and writing parameters is up to ten times faster with PROFIBUS
upload/download
• Condensed status
Simplest and self-explanatory diagnostic information by categorizing
diagnostic messages that occur
Configuration of the device
address
• DIP switches on the I/O electronics module
• Via operating tools (e.g. FieldCare)
Modbus RS485
Protocol Modbus Applications Protocol Specification V1.1
Device type Slave
Slave address range 1 to 247
Broadcast address range 0
Function codes • 03: Read holding register
• 04: Read input register
• 06: Write single registers
• 08: Diagnostics
• 16: Write multiple registers
• 23: Read/write multiple registers
Broadcast messages Supported by the following function codes:
• 06: Write single registers
• 16: Write multiple registers
• 23: Read/write multiple registers
Supported baud rate • 1 200 BAUD
• 2 400 BAUD
• 4 800 BAUD
• 9 600 BAUD
• 19 200 BAUD
• 38 400 BAUD
• 57 600 BAUD
• 115 200 BAUD
Data transfer mode • ASCII
• RTU
Data access Each device parameter can be accessed via Modbus RS485.
For Modbus register information (→  75)
EtherNet/IP
Protocol • The CIP Networks Library Volume 1: Common Industrial Protocol
• The CIP Networks Library Volume 2: EtherNet/IP Adaptation of CIP
Communication type • 10Base-T
• 100Base-TX
Device profile Generic device (product type: 0x2B)
Manufacturer ID 0x49E
Device type ID 0x104A
Baud rates Automatic ¹⁰⁄₁₀₀ Mbit with half-duplex and full-duplex detection
Polarity Auto-polarity for automatic correction of crossed TxD and RxD pairs
Supported CIP connections Max. 3 connections
Explicit connections Max. 6 connections

Proline Promass S 100
16 Endress+Hauser
I/O connections Max. 6 connections (scanner)
Configuration options for
measuring device
• DIP switches on the electronics module for IP addressing
• Manufacturer-specific software (FieldCare)
• Add-on Profile Level 3 for Rockwell Automation control systems
• Web browser
• Electronic Data Sheet (EDS) integrated in the measuring device
Configuration of the EtherNet
interface
• Speed: 10 MBit, 100 MBit, auto (factory setting)
• Duplex: half-duplex, full-duplex, auto (factory setting)
Configuration of the device
address
• DIP switches on the electronics module for IP addressing (last octet)
• DHCP
• Manufacturer-specific software (FieldCare)
• Add-on Profile Level 3 for Rockwell Automation control systems
• Web browser
• EtherNet/IP tools, e.g. RSLinx (Rockwell Automation)
Device Level Ring (DLR) No
Fix Input
RPI 5 ms to 10 s (factory setting: 20 ms)
Exclusive Owner Multicast Instance Size [byte]
Instance configuration: 0x68 398
O → T configuration: 0x66 64
T → O configuration: 0x64 44
Exclusive Owner Multicast Instance Size [byte]
Instance configuration: 0x69 -
O → T configuration: 0x66 64
T → O configuration: 0x64 44
Input only Multicast Instance Size [byte]
Instance configuration: 0x68 398
O → T configuration: 0xC7 -
T → O configuration: 0x64 44
Input only Multicast Instance Size [byte]
Instance configuration: 0x69 -
O → T configuration: 0xC7 -
T → O configuration: 0x64 44
Input Assembly • Current device diagnostics
• Mass flow
• Volume flow
• Corrected volume flow
• Density
• Reference density
• Temperature
• Totalizer 1
• Totalizer 2
• Totalizer 3
Configurable Input
RPI 5 ms to 10 s (factory setting: 20 ms)
Exclusive Owner Multicast Instance Size [byte]
Instance configuration: 0x68 398
O → T configuration: 0x66 64
T → O configuration: 0x65 88
Exclusive Owner Multicast Instance Size [byte]
Instance configuration: 0x69 -

Proline Promass S 100
Endress+Hauser 17
O → T configuration: 0x66 64
T → O configuration: 0x65 88
Input only Multicast Instance Size [byte]
Instance configuration: 0x68 398
O → T configuration: 0xC7 -
T → O configuration: 0x65 88
Input only Multicast Instance Size [byte]
Instance configuration: 0x69 -
O → T configuration: 0xC7 -
T → O configuration: 0x65 88
Configurable Input Assembly • Current device diagnostics
• Mass flow
• Volume flow
• Corrected volume flow
• Density
• Reference density
• Temperature
• Totalizer 1
• Totalizer 2
• Totalizer 3
The range of options increases if the measuring device has one or
more application packages.
Fix Output
Output Assembly • Activation of reset totalizers 1-3
• Activation of pressure compensation
• Activation of reference density compensation
• Activation of temperature compensation
• Reset totalizers 1-3
• External pressure value
• Pressure unit
• External reference density
• Reference density unit
• External temperature
• Temperature unit
Configuration
Configuration Assembly Only the most common configurations are listed below.
• Software write protection
• Mass flow unit
• Mass unit
• Volume flow unit
• Volume unit
• Corrected volume flow unit
• Corrected volume unit
• Density unit
• Reference density unit
• Temperature unit
• Pressure unit
• Length
• Totalizer 1-3:
– Assignment
– Unit
– Measuring mode
– Failure mode
• Alarm delay

Proline Promass S 100
18 Endress+Hauser
Power supply
Terminal assignment Overview: housing version
A
B
C
2
2.1 2.2
3
3.1 3.2
1
1.1 1.2 1.3
4
4.2
4.1
A0016770
A Housing version: compact, aluminum coated
B Housing version: compact, hygienic, stainless
C Housing version: ultra compact, hygienic, stainless, M12 device plug
1 Connection version: 4-20 mA HART, pulse/frequency/switch output
1.1 Signal transmission: pulse/frequency/switch output
1.2 Signal transmission: 4-20 mA HART
1.3 Supply voltage
2 Connection version: Modbus RS485
2.1 Signal transmission
2.2 Supply voltage
3 Connection version: EtherNet/IP
3.1 Signal transmission
3.2 Supply voltage
4 Connection version: PROFIBUS DP
4.1 PROFIBUS DP
4.2 Supply voltage
Transmitter
Connection version 4-20 mA HART with pulse/frequency/switch output
Order code for "Output", option B

Proline Promass S 100
Endress+Hauser 19
Depending on the housing version, the transmitters can be ordered with terminals or device plugs.
Order code for
"Housing"
Connection methods available Possible options for order code
"Electrical connection"
Outputs Power
supply
Options
A, B
Terminals Terminals • Option A: coupling M20x1
• Option B: thread M20x1
• Option C: thread G ½"
• Option D: thread NPT ½"
Options
A, B
Device plug Terminals • Option L: plug M12x1 + thread NPT ½"
• Option N: plug M12x1 + coupling M20
• Option P: plug M12x1 + thread G ½"
• Option U: plug M12x1 + thread M20
Options
A, B, C
Device plug Device plug Option Q: 2 x plug M12x1
Order code for "Housing":
• Option A: compact, coated aluminum
• Option B: compact, hygienic, stainless
• Option C: ultra compact, hygienic, stainless, M12 device plug
L
L
26
27
+
_
24
25
1
2
+
_
+
_1
2
3
A0016888
 2 Terminal assignment 4-20 mA HART with pulse/frequency/switch output
1 Power supply: DC 24 V
2 Output 1: 4-20 mA HART (active)
3 Output 2: pulse/frequency/switch output (passive)
Order code for
"Output"
Terminal number
Power supply Output 1 Output 2
2 (L-) 1 (L+) 27 (–) 26 (+) 25 (–) 24 (+)
Option BDC 24 V 4-20 mA HART (active) Pulse/frequency/switch
output (passive)
Order code for "Output":
Option B: 4-20 mA HART with pulse/frequency/switch output

Proline Promass S 100
20 Endress+Hauser
PROFIBUS DP connection version
For use in the non-hazardous area and Zone 2/Div. 2.
Order code for "Output", option L
Depending on the housing version, the transmitters can be ordered with terminals or device plugs.
Order code for
"Housing"
Connection methods available Possible options for order code
"Electrical connection"
Output Power
supply
Options
A, B
Terminals Terminals • Option A: coupling M20x1
• Option B: thread M20x1
• Option C: thread G ½"
• Option D: thread NPT ½"
Options
A, B
Device plug Terminals • Option L: plug M12x1 + thread NPT ½"
• Option N: plug M12x1 + coupling M20
• Option P: plug M12x1 + thread G ½"
• Option U: plug M12x1 + thread M20
Options
A, B, C
Device plug Device plug Option Q: 2 x plug M12x1
Order code for "Housing":
• Option A: compact, coated aluminum
• Option A: compact, hygienic, stainless
• Option C: ultra compact, hygienic, stainless, M12 device plug
L
L
26
27
B
A
1
2
+
_1
2
A0022716
 3 PROFIBUS DP terminal assignment
1 Power supply: DC 24 V
2 PROFIBUS DP
Order code for
"Output"
Terminal number
Power supply Output
2 (L-) 1 (L+) 26 (RxD/TxD-P) 27 (RxD/TxD-
N)
Option LDC 24 V B A
Order code for "Output":
Option L: PROFIBUS DP, for use in non-hazardous areas and Zone 2/div. 2
