Endress+Hauser PROline promag 53 User manual

Products Solutions Services
BA00052D/06/EN/14.15
71280317
Valid as of version:
V 3.00.XX (device software)
Operating Instructions
Proline Promag 53
FOUNDATION Fieldbus
Electromagnetic flowmeter

Proline Promag 53 FOUNDATION Fieldbus
Endress+Hauser 3
Table of contents
1 Safety instructions . . . . . . . . . . . . . . . . . . 4
1.1 Designated use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Installation, commissioning and operation . . . . . . 4
1.3 Operational safety . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.4 Return . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.5 Notes on safety conventions and icons . . . . . . . . . 5
2 Identification . . . . . . . . . . . . . . . . . . . . . . 6
2.1 Device designation . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.2 Certificates and approvals . . . . . . . . . . . . . . . . . . . . 9
2.3 FOUNDATION Fieldbus device certification . . . . . 9
2.4 Registered trademarks . . . . . . . . . . . . . . . . . . . . . . . 9
3 Installation . . . . . . . . . . . . . . . . . . . . . . .10
3.1 Incoming acceptance, transport and storage . . . 10
3.2 Installation conditions . . . . . . . . . . . . . . . . . . . . . 12
3.3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.4 Post-installation check . . . . . . . . . . . . . . . . . . . . . 44
4 Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
4.1 FOUNDATION Fieldbus cable specification . . . . 45
4.2 Shielding and grounding . . . . . . . . . . . . . . . . . . . 47
4.3 Connecting the remote version . . . . . . . . . . . . . . 48
4.4 Connecting the measuring unit . . . . . . . . . . . . . . 53
4.5 Potential equalization . . . . . . . . . . . . . . . . . . . . . . 57
4.6 Degree of protection . . . . . . . . . . . . . . . . . . . . . . . 59
4.7 Post-connection check . . . . . . . . . . . . . . . . . . . . . 60
5 Operation. . . . . . . . . . . . . . . . . . . . . . . . . 61
5.1 Quick operation guide . . . . . . . . . . . . . . . . . . . . . 61
5.2 Local display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
5.3 Brief Operating Instructions for the
function matrix . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
5.4 Error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
5.5 Operating programs . . . . . . . . . . . . . . . . . . . . . . . 68
5.6 FOUNDATION Fieldbus hardware settings . . . . 70
6 Commissioning. . . . . . . . . . . . . . . . . . . .71
6.1 Function check . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
6.2 Switching on the measuring device . . . . . . . . . . 71
6.3 Commissioning using FOUNDATION Fieldbus . 72
6.4 Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
6.5 Data storage devices . . . . . . . . . . . . . . . . . . . . . . . 80
7 Maintenance. . . . . . . . . . . . . . . . . . . . . .81
7.1 Exterior cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . 81
7.2 Seals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
8 Accessories . . . . . . . . . . . . . . . . . . . . . . . 82
8.1 Device-specific accessories . . . . . . . . . . . . . . . . . . 82
8.2 Accessories specific to measuring principle . . . . 82
8.3 Communication-specific accessories . . . . . . . . . . 83
8.4 Service-specific accessories . . . . . . . . . . . . . . . . . . 83
9 Troubleshooting . . . . . . . . . . . . . . . . . . 84
9.1 Troubleshooting instructions . . . . . . . . . . . . . . . . 84
9.2 System/process error messages . . . . . . . . . . . . . . 88
9.3 Process errors without a message . . . . . . . . . . . . 94
9.4 Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
9.5 Return . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
9.6 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
9.7 Software history . . . . . . . . . . . . . . . . . . . . . . . . . 103
10 Technical data . . . . . . . . . . . . . . . . . . . 104
10.1 Technical data at a glance . . . . . . . . . . . . . . . . . 104
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

Safety instructions Proline Promag 53 FOUNDATION Fieldbus
4Endress+Hauser
1 Safety instructions
1.1 Designated use
The measuring device described in this Operating Manual is to be used only for measuring
the flow rate of conductive fluids in closed pipes.
All fluids (including demineralized water) can be metered, provided they have a minimum
conductivity of 5 μS/cm, for example:
• acids, alkalis, pastes, paps, pulps, black liquor, green liquor
• drinking water, wastewater, sewage sludge
• milk, beer, wine, mineral water, yoghurt, molasses, fruit mash
Incorrect use or use other than that designated may result in the operational safety of the
measuring devices being suspended. The manufacturer accepts no liability for damages
resulting from this.
1.2 Installation, commissioning and operation
Note the following points:
• Installation, connection to the electricity supply, commissioning and maintenance of the
device must be carried out by trained, qualified specialists authorized to perform such work
by the facility's owner-operator. The specialist must have read and understood these
Operating Instructions and must follow the instructions they contain.
• The device must be operated only by persons authorized and trained by the system
operator. Strict compliance with the instructions in the Operating Instructions is
mandatory.
• Endress+Hauser is willing to assist in clarifying the chemical resistance properties of parts
wetted by special fluids, including fluids used for cleaning. However, small changes in
temperature, concentration or the degree of contamination in the process can result in
changes to the chemical resistance properties. For this reason, Endress+Hauser does not
accept any responsibility with regard to the corrosion resistance of materials wetted by
fluids in a specific application. The user is responsible for the choice of wetted materials
with regard to their in-process resistance to corrosion.
• If welding work is performed on the piping system, do not ground the welding appliance
through the flowmeter.
• The installer must ensure that the measuring system is correctly wired in accordance with
the wiring diagrams. The transmitter must be grounded, except in cases where special
protective measures have been taken (e.g. galvanically isolated power supply SELV or
PELV).
• Always note the regulations applicable in your country to the operation, maintenance and
repair of electrical devices. Special instructions relating to the device can be found in the
relevant sections of the documentation.
1.3 Operational safety
Note the following points:
• Measuring systems for use in hazardous environments are accompanied by separate
"Ex documentation", which is an integral part of these Operating Instructions. Strict
compliance with the installation instructions and ratings as stated in this supplementary
documentation is mandatory. Depending on the approval and certification agency, the
relevant symbol is depicted on the front page of the supplementary documentation on Ex
ratings (e.g. 0Europe, 2USA, 1Canada).
• The measuring device meets the general safety requirements according to EN 61010-1
and the EMC requirements according to IEC/EN 61326 in addition to the NAMUR
recommendations NE 21, NE 43 and NE 53.

Proline Promag 53 FOUNDATION Fieldbus Safety instructions
Endress+Hauser 5
• Due to the performance rate in the electronic components, the external housing surfaces
are heated to a maximum of 10 K. When conducting hot media through the measuring
tube, the surface temperature of the housing increases. Particularly in the case of the
sensor, temperatures close to the fluid temperature must be anticipated. In the event of
elevated fluid temperatures, please ensure that fire protection is in place.
• The manufacturer reserves the right to modify technical data without prior notice. Your
Endress+Hauser distributor will supply you with current information and updates to these
Operating Instructions.
1.4 Return
The measuring device must be returned if repairs or a factory calibration are required, or if
the wrong measuring device has been ordered or delivered. According to legal regulations,
Endress+Hauser, as an ISO-certified company, is required to follow certain procedures when
handling returned products that are in contact with medium.
To ensure swift, safe and professional device returns, please read the return procedures and
conditions on the Endress+Hauser website at www.services.endress.com/return-material
1.5 Notes on safety conventions and icons
The devices are designed and tested to meet state-of-the-art safety requirements, and have
left the factory in a condition in which they are safe to operate. The devices comply with the
applicable standards and regulations in accordance with EN 61010 -1 "Protection Measures
for Electrical Equipment for Measurement, Control, Regulation and Laboratory Procedures".
The devices can, however, be a source of danger if used incorrectly or for other than the
designated use.
For this reason, always pay particular attention to the safety instructions indicated in these
Operating Instructions by the following icons:
#Warning!
"Warning" indicates an action or procedure which, if not performed correctly, can result in
personal injury or a safety hazard. Comply strictly with the instructions and proceed with
care.
"Caution!
"Caution" indicates an action or procedure which, if not performed correctly, can result in
incorrect operation or destruction of the device. Comply strictly with the instructions.
!Note!
"Note" indicates an action or procedure which, if not performed correctly, can have an indirect
effect on operation or trigger an unexpected response on the part of the device.

Identification Proline Promag 53 FOUNDATION Fieldbus
6Endress+Hauser
2 Identification
2.1 Device designation
The flow measuring system consists of the following components:
• Promag 53 transmitter
• Promag E/H/L/P/W sensors
Two versions are available:
• Compact version: transmitter and sensor form a single mechanical unit
• Remote version: transmitter and sensor are installed separately
2.1.1 Nameplate of the transmitter
a0005475
Fig. 1: Nameplate specifications for the "Promag 53" transmitter (example)
1 Order code/serial number: See the specifications on the order confirmation for the meanings of the individual letters and digits
2 Power supply/frequency
Power consumption
3 Additional functions and software
– EPD: with empty pipe detection electrode
– ECC: with electrode cleaning
4 FOUNDATION Fieldbus: equipped with FOUNDATION Fieldbus H1 interface
ITK 5.01: certified by the Fieldbus Foundation; Interoperability Test Kit, revision 5.01
DEVICE ID: FOUNDATION Fieldbus device identification
5 Reserved for additional information on special products
6 Permitted ambient temperature range
7 Degree of protection
PROMAG 53
-20°C (-4°F) <Tamb<+60°C (+140°F)
IP67 / NEMA/Type 4XOrder Code:
Ser.No.:
TAG No.:
53W1H-XXXXXXXXXXXX
12345678901
ABCDEFGHJKLMNPQRST
20-260VAC 20-64VDC/
50-60Hz
FOUNDATION Fieldbus ITK 5.01
DEVICE ID 452B481042-21000191000
45VA/19W
i
EPD/MSU
N12895
1
2
3
4
5
67
OUNDATIONF
R

Proline Promag 53 FOUNDATION Fieldbus Identification
Endress+Hauser 7
2.1.2 Nameplate of the sensor
a0011854
Fig. 2: Nameplate specifications for the "Promag W" sensor (example)
1 Order code/serial number: See the specifications on the order confirmation for the meanings of the individual letters and digits
2 Calibration factor with zero point
3 Nominal diameter/nominal pressure
4 Medium temperature range
5 Materials: lining/measuring electrode
6 Reserved for additional information on special products
7 Permitted ambient temperature range
8 Please comply with the Operating Instructions
9 Reserved for additional information on device version (approvals, certificates)
10 Calibration tolerance
11 Additional information
– EPD: with empty pipe detection electrode
– R/B: with reference electrode
12 Degree of protection
13 Flow direction
–20°C (–4°F)<Tamb<+60°C (+140°F) NEMA/Type4X
Pat. US 4,382,387 4,704,908 5,540,103
53W1H-XXXXXXXXXXXX
1.0000/0000
–20 ...+150°C/–4 ...+300°F°C °F
PFA
12345678901
ABCDEFGHJKLMNPQRST
DN100 DIN EN PN40/
EPD/MSÜ, R/B
TM:
Order Code:
K-factor:
Ser.No.:
TAG No.:
PROMAG W
1
2
3
712
1.4435/316L
0.2 CAL
4
5
6
10
11
8
9
i
13
N12895
Materials:
Electrodes:

Identification Proline Promag 53 FOUNDATION Fieldbus
8Endress+Hauser
2.1.3 Nameplate for connections
a0006396
Fig. 3: Nameplate specifications for Proline transmitter connections (example)
1 Serial number
2 Possible configuration of current output
3 Possible configuration of relay contacts
4 Terminal assignment, cable for power supply
Terminal no. 1:
– L1 for AC, L+ for DC
Terminal no. 2:
– N for AC, L- for DC
5 Signals present at inputs and outputs, possible configurations and terminal assignment
6 Version of device software currently installed (incl. language group)
7 Type of communication installed
8 Information on current communication software (Device Revision, Device Description)
9 Date of installation
10 Current updates to data specified in points 6 to 9
26(+) / 27(-)
NC:
Versorgung /
Tension d'alimentation
Observer manuel d'instruction
See operating manual
Betriebsanleitung beachten
Communication:
Drivers:
Device SW:
ID XXXX (HEX)
XX.XX.XX
FOUNDATION Fieldbus
26= FF +
27= FF - FOUNDATION Fieldbus
12345678912Ser.No.:
Supply /
24(+) / 25(-)
22(+) / 23(-)
20(+) / 21(-)
N/L-
PE
A:
NO:
P:
L1/L+
12
319475-00XX
X
active
passive
normally open contact
normally closed contact
Date: DD. MMM. YYYY
Update 1
Ex-works / ab-Werk / réglages usine Update 2
(WEA)
1
4
5
6
7
8
9
2
3

Proline Promag 53 FOUNDATION Fieldbus Identification
Endress+Hauser 9
2.2 Certificates and approvals
The devices are designed and tested to meet state-of-the-art safety requirements in
accordance with sound engineering practice. They have left the factory in a condition in
which they are safe to operate. The devices comply with the standards EN 61010 -1
"Protection Measures for Electrical Equipment for Measurement, Control, Regulation and
Laboratory Procedures" and with the EMC requirements of IEC/EN 61326.
The measuring system described in these Operating Instructions therefore complies with the
legal requirements of the EU Directives. Endress+Hauser confirms this by affixing the CE
mark to it and by issuing the CE Declaration of Conformity.
The measuring system is in conformity with the EMC requirements of the "Australian
Communications and Media Authority (ACMA)".
2.3 FOUNDATION Fieldbus device certification
The flowmeter has passed all the test procedures implemented and has been certified and
registered by the Fieldbus Foundation. The device thus meets all the requirements of the
following specifications:
• Certified to FOUNDATION Fieldbus specification
• The flowmeter meets all the specifications of the FOUNDATION Fieldbus H1.
• Interoperability Test Kit (ITK), revision 5.01: The device can also be operated in
conjunction with other manufactures certified devices.
• Physical Layer Conformance Test by Fieldbus Foundation
2.4 Registered trademarks
KALREZ® and VITON®
Registered trademarks of E.I. Du Pont de Nemours & Co., Wilmington, USA
TRI-CLAMP®
Registered trademark of Ladish & Co., Inc., Kenosha, USA
FOUNDATION™ Fieldbus
Registered trademark of the Fieldbus Foundation, Austin, USA
HistoROM™, S-DAT®, T-DAT™, F-CHIP®, FieldCare®, Fieldcheck®, Applicator®
Registered or registration-pending trademarks of Endress+Hauser Flowtec AG, Reinach, CH

Installation Proline Promag 53 FOUNDATION Fieldbus
10 Endress+Hauser
3Installation
3.1 Incoming acceptance, transport and storage
3.1.1 Incoming acceptance
On receipt of the goods, check the following points:
• Check the packaging and the contents for damage.
• Check the shipment, make sure nothing is missing and that the scope of supply matches
your order.
3.1.2 Transport
The following instructions apply to unpacking and to transporting the device to its final
location:
• Transport the devices in the containers in which they are delivered.
• Do not remove the protection plates or caps on the process connections until you are ready
to install the device. This is particularly important in the case of sensors with PTFE linings.
Special notes on flanged devices
"Caution!
• The wooden covers mounted on the flanges before the device leaves the factory protect the
linings on the flanges during storage and transportation. Do not remove these protection
plates until immediately before the device is installed in the pipe.
• Do not lift flanged devices by the transmitter housing or, in the case of the remote version,
by the connection housing.
Transporting flanged devices DN
 300 (12")
Use webbing slings slung round the two process connections. Do not use chains, as they
could damage the housing.
#Warning!
Risk of injury if the measuring device slips. The center of gravity of the assembled measuring
device might be higher than the points around which the slings are slung.
At all times, therefore, make sure that the device does not unexpectedly turn around its axis
or slip.
a0004294
Fig. 4: Transporting sensors with DN  300 (12")

Proline Promag 53 FOUNDATION Fieldbus Installation
Endress+Hauser 11
Transporting flanged devices DN > 300 (12")
Use only the metal eyes on the flanges for transporting the device, lifting it and positioning
the sensor in the piping.
"Caution!
Do not attempt to lift the sensor with the tines of a fork-lift truck beneath the metal casing.
This would buckle the casing and damage the internal magnetic coils.
a0004295
Fig. 5: Transporting sensors with DN > 300 (12")
3.1.3 Storage
Note the following points:
• Pack the measuring device in such a way as to protect it reliably against impact for storage
(and transportation). The original packaging provides optimum protection.
• The storage temperature corresponds to the operating temperature range of the
measuring transmitter and the appropriate measuring sensors →108.
• The measuring device must be protected against direct sunlight during storage in order to
avoid unacceptably high surface temperatures.
• Choose a storage location where moisture does not collect in the measuring device. This
will help prevent fungus and bacteria infestation which can damage the lining.
• Do not remove the protection plates or caps on the process connections until you are ready
to install the device. This is particularly important in the case of sensors with PTFE linings.

Installation Proline Promag 53 FOUNDATION Fieldbus
12 Endress+Hauser
3.2 Installation conditions
3.2.1 Dimensions
All the dimensions and lengths of the sensor and transmitter are provided in the separate
documentation "Technical Information".
3.2.2 Mounting location
The accumulation of air or gas bubbles in the measuring tube could result in an increase in
measuring errors.
Avoid the following locations:
• At the highest point of a pipeline. Risk of air accumulating.
• Directly upstream from a free pipe outlet in a vertical pipeline.
A0011899
Fig. 6: Mounting location
Installing pumps
Do not install the sensor on the intake side of a pump. This precaution is to avoid low
pressure and the consequent risk of damage to the lining of the measuring tube. Information
on the lining's resistance to partial vacuum →113.
It might be necessary to install pulse dampers in systems incorporating reciprocating,
diaphragm or peristaltic pumps. Information on the measuring system's resistance to
vibration and shock →109.
A0011900
Fig. 7: Installing pumps
Partially filled pipes
Partially filled pipes with gradients necessitate a drain-type configuration. The Empty Pipe
Detection function offers additional protection by detecting empty or partially filled pipes →
h 2 × DN³

Proline Promag 53 FOUNDATION Fieldbus Installation
Endress+Hauser 13
78.
"Caution!
Risk of solids accumulating. Do not install the sensor at the lowest point in the drain. It is
advisable to install a cleaning valve.
A0011901
Fig. 8: Installation in partially filled pipe
Down pipes
Install a siphon or a vent valve downstream of the sensor in down pipes longer than 5 m
(16 ft). This precaution is to avoid low pressure and the consequent risk of damage to the
lining of the measuring tube. This measure also prevents the system losing prime, which
could cause air inclusions.
Information on the lining's resistance to partial vacuum →113
A0011902
Fig. 9: Measures for installation in a down pipe (h > 5 m / 16 ft)
1Ventvalve
2Siphon
³5 × DN
³2 × DN
h
2
1

Installation Proline Promag 53 FOUNDATION Fieldbus
14 Endress+Hauser
3.2.3 Orientation
An optimum orientation position helps avoid gas and air accumulations and deposits in the
measuring tube. Promag, nevertheless, supplies a range of functions and accessories for
correct measuring of problematic fluids:
• Electrode Cleaning Circuitry (ECC) to prevent electrically conductive deposits in the
measuring tube, e.g. for fluids causing buildup (see "Description of Device Functions"
manual).
• Empty Pipe Detection (EPD) ensures the detection of partially filled measuring tubes or in
the case of degassing fluids →78.
Vertical orientation
A vertical orientation is ideal in the following cases:
• For self-emptying piping systems and when using empty pipe detection.
• For sludge containing sand or stones and where the solids cause sedimentation.
A0011903
Fig. 10: Vertical orientation
Horizontal orientation
The measuring electrode plane should be horizontal. This prevents brief insulation of the
two electrodes by entrained air bubbles.
"Caution!
Empty Pipe Detection functions correctly with the measuring device installed horizontally
only when the transmitter housing is facing upward (see diagram). Otherwise there is no
guarantee that Empty Pipe Detection will respond if the measuring tube is only partially
filled.
A0011904
Fig. 11: Horizontal orientation
1 EPD electrode for empty pipe detection
(not available for "measuring electrode only" option, not in Promag H, DN 2 to 15 (1/12 to 1/2"))
2 Measuring electrodes for signal detection
3 Reference electrode for potential equalization
(not available for "measuring electrode only" option, not in Promag H)
A
1
22
A
3

Proline Promag 53 FOUNDATION Fieldbus Installation
Endress+Hauser 15
3.2.4 Inlet and outlet runs
If possible, install the sensor in a location upstream of fittings such as valves, T-pieces,
elbows, etc.
Compliance with the following requirements for the inlet and outlet runs is necessary in
order to ensure measuring accuracy.
• Inlet run 5 × DN
•Outletrun2 × DN
A0011905
Fig. 12: Inlet and outlet runs
3.2.5 Vibrations
Secure and fix both the piping and the sensor if the vibrations are severe.
"Caution!
It is advisable to install sensor and transmitter separately if vibration is excessively severe.
Information on the permitted resistance to vibration and shock →109.
A0011906
Fig. 13: Measures to prevent vibration of the measuring device (L > 10 m / 33 ft)
³5 × DN ³2 × DN
L

Installation Proline Promag 53 FOUNDATION Fieldbus
16 Endress+Hauser
3.2.6 Foundations, supports
If the nominal diameter is DN 350 (14"), mount the sensor on a foundation of adequate
load-bearing strength.
"Caution!
Risk of damage.
Do not support the weight of the sensor on the metal casing: the casing would buckle and
damage the internal magnetic coils.
a0003209
Fig. 14: Correct support for large nominal diameters (DN  350 / 14")
3.2.7 Adapters
Suitable adapters to DIN EN 545 (double-flange reducers) can be used to install the sensor
in larger-diameter pipes. The resultant increase in the rate of flow improves measuring
accuracy with very slow-moving fluids.
The nomogram shown here can be used to calculate the pressure loss caused by cross-section
reduction.
!Note!
The nomogram only applies to liquids of viscosity similar to water.
1. Calculate the ratio of the diameters d/D.
2. From the nomogram, read off the pressure loss as a function of fluid velocity
(downstream from the reduction) and the d/D ratio.
A0011907
Fig. 15: Pressure loss due to adapters
100
10
0.5
d / D
[mbar]
0.6 0.7 0.8 0.9
1 m/s
2 m/s
3 m/s
4 m/s
5 m/s
6 m/s
7 m/s
8 m/s
1
D
d
max. 8°

Proline Promag 53 FOUNDATION Fieldbus Installation
Endress+Hauser 17
3.2.8 Nominal diameter and flow rate
The diameter of the pipe and the flow rate determine the nominal diameter of the sensor.
The optimum flow velocity is between 2 and 3 m/s (6 to 10 ft/s). The flow velocity (v),
moreover, has to be matched to the physical properties of the fluid:
• v < 2 m/s (6 ft/s): for abrasive fluids where solids do not cause sedimentation (e.g. lime
milk)
• v > 2 m/s (6 ft/s): for fluids producing buildup (e.g. wastewater sludge)
!Note!
Flow velocity can be increased, if necessary, by reducing the nominal diameter of the sensor
through the use of adapters →16.
Recommended flow (SI units)
Nominal diameter Promag E/P Promag H Promag L Promag W
[mm] Min./max. full scale value (v ≈0.3 or 10 m/s) in [dm³/min]
2 – 0.06 to 1.8 – –
4 – 0.25 to 7 – –
8–1to30––
15 4 to 100 4 to 100 – –
25 9 to 300 9 to 300 9 to 300 9 to 300
32 15 to 500 – 15 to 500 15 to 500
40 25 to 700 25 to 700 25 to 700 25 to 700
50 35 to 1100 35 to 1100 35 to 1100 35 to 1100
65 60 to 2000 60 to 2000 60 to 2000 60 to 2000
80 90 to 3000 90 to 3000 90 to 3000 90 to 3000
100 145 to 4700 145 to 4700 145 to 4700 145 to 4700
125 220 to 7500 220 to 7500 220 to 7500 220 to 7500
[mm] Min./max. full scale value (v ≈0.3 or 10 m/s) in [m³/h]
150 20 to 600 20 to 600 20 to 600 20 to 600
200 35 to 1100 – 35 to 1100 35 to 1100
250 55 to 1700 – 55 to 1700 55 to 1700
300 80 to 2400 – 80 to 2400 80 to 2400
350 110 to 3300 – 110 to 3300 110 to 3300
375 – – 140 to 4200 140 to 4200
400 140 to 4200 – 140 to 4200 140 to 4200
450 180 to 5400 – 180 to 5400 180 to 5400
500 220 to 6600 – 220 to 6600 220 to 6600
600 310 to 9600 – 310 to 9600 310 to 9600
700 – – 420 to 13500 420 to 13500
800 – – 550 to 18000 550 to 18000
900 – – 690 to 22500 690 to 22500
1000 – – 850 to 28000 850 to 28000
1200 – – 1250 to 40000 1250 to 40000
1400 – – – 1700 to 55000
1600 – – – 2200 to 70000
1800 – – – 2800 to 90000
2000 – – – 3400 to 110000

Installation Proline Promag 53 FOUNDATION Fieldbus
18 Endress+Hauser
Recommended flow (US units)
Nominal diameter Promag E/P Promag H Promag L Promag W
[inch] Min./max. full scale value (v ≈0.3 or 10 m/s) in [gal/min]
1/12" – 0.015 to 0.5 – –
1/8" – 0.07 to 2 – –
3/8" – 0.25 to 8 – –
½" 1.0 to 27 1.0 to 27 – –
1" 2.5 to 80 2.5 to 80 2,5 to 80 2.5 to 80
1 ¼" 4 to 130 – – 4 to 130
1 ½" 7 to 190 7 to 190 7 to 190 7 to 190
2" 10 to 300 10 to 300 10 to 300 10 to 300
2 ½" 16 to 500 16 to 500 16 to 500 16 to 500
3" 24 to 800 24 to 800 24 to 800 24 to 800
4" 40 to 1250 40 to 1250 40 to 1250 40 to 1250
5" 60 to 1950 60 to 1950 60 to 1950 60 to 1950
6" 90 to 2650 90 to 2650 90 to 2650 90 to 2650
8" 155 to 4850 – 155 to 4850 155 to 4850
10" 250 to 7500 – 250 to 7500 250 to 7500
12" 350 to 10600 – 350 to 10600 350 to 10600
14" 500 to 15000 – 500 to 15000 500 to 15000
15" – – 600 to 19000 600 to 19000
16" 600 to 19000 – 600 to 19000 600 to 19000
18" 800 to 24000 – 800 to 24000 800 to 24000
20" 1000 to 30000 – 1000 to 30000 1000 to 30000
24" 1400 to 44000 – 1400 to 44000 1400 to 44000
28" – – 1900 to 60000 1900 to 60000
30" – – 2150 to 67000 2150 to 67000
32" – – 2450 to 80000 2450 to 80000
36" – – 3100 to 100000 3100 to 100000
40" – – 3800 to 125000 3800 to 125000
42" – – 4200 to 135000 4200 to 135000
48" – – 5500 to 175000 5500 to 175000
[inch] Min./max. full scale value (v ≈0.3 or 10 m/s) in [Mgal/d]
54" – – – 9 to 300
60" – – – 12 to 380
66" – – – 14 to 500
72" – – – 16 to 570
78" – – – 18 to 650

Proline Promag 53 FOUNDATION Fieldbus Installation
Endress+Hauser 19
3.2.9 Length of connecting cable
In order to ensure measuring accuracy, please comply with the following instructions when
installing the remote version:
• Secure the cable run or route the cable in an armored conduit. Movement of the cable can
falsify the measuring signal, particularly if the fluid conductivity is low.
• Route the cable well clear of electrical machines and switching elements.
• Ensure potential equalization between sensor and transmitter, if necessary.
• The permissible cable length Lmax depends on the fluid conductivity (→19).
• The maximum connecting cable length is 10 m (32.8 ft) when empty pipe detection
(EPD →78) is switched on.
a0010734
Fig. 16: Permitted lengths for connecting cable in remote version, as a function of the conductivity of the fluid
Gray shaded area = permissible range
Lmax = length of connecting cable
200
100
5
10 100 200
Lmax
[m][m]
[µS/cm]
Lmax
[ft]
200 6000 400

Installation Proline Promag 53 FOUNDATION Fieldbus
20 Endress+Hauser
3.3 Installation
3.3.1 Installing the Promag E sensor
"Caution!
• The protective covers mounted on the two sensor flanges guard the PTFE lining, which is
turned over the flanges. Consequently, do not remove these protection plates until
immediately before the sensor is installed in the pipe.
• Protection plates must remain in place while the device is in storage.
• Make sure that the lining is not damaged or removed from the flanges.
!Note!
Bolts, nuts, seals, etc. are not included in the scope of supply and must be supplied by the
customer.
The sensor is designed for installation between the two piping flanges:
• It is essential that you observe the necessary screw tightening torques on →21.
• If grounding disks are used, follow the mounting instructions which will be enclosed with
the shipment.
A0011908
Fig. 17: Installing the Promag P sensor
Seals
Comply with the following instructions when installing seals:
• PFA or PTFE lining seals are not required.
• Only use seals that comply with DIN EN 1514-1 for DIN flanges.
• Make sure that the seals do not protrude into the piping cross-section.
"Caution!
Risk of short circuit! Do not use electrically conductive sealing compound such as graphite.
An electrically conductive layer could form on the inside of the measuring tube and short-
circuit the measuring signal.
Ground cable
• If necessary, special ground cables can be ordered as accessories for potential equalization,
→82.
• For information on potential equalization and detailed installation instructions for using
ground cables, please refer to →57.
