Operating Instructions
Proline t-mass 65
Thermal mass flowmeter
6

Proline t-mass 65
2Endress+Hauser
Table of contents
1 Document information . . . . . . . . . . . . . . 3
1.1 Document conventions . . . . . . . . . . . . . . . . . . . . . . . 3
2 Safety instructions . . . . . . . . . . . . . . . . . 5
2.1 Designated use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.2 Installation, commissioning and operation . . . . . . 5
2.3 Operational safety . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.4 Return . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.5 Product safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 Identification . . . . . . . . . . . . . . . . . . . . . . 7
3.1 Device designation . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.2 Certificates and approvals . . . . . . . . . . . . . . . . . . 10
3.3 Registered trademarks . . . . . . . . . . . . . . . . . . . . . 10
4 Installation . . . . . . . . . . . . . . . . . . . . . . . 11
4.1 Incoming acceptance, transport and storage . . . 11
4.2 Installation conditions . . . . . . . . . . . . . . . . . . . . . 12
4.3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.4 Post-installation check . . . . . . . . . . . . . . . . . . . . . 27
5 Electrical connection. . . . . . . . . . . . . . . 28
5.1 Connecting the remote version . . . . . . . . . . . . . . 28
5.2 Connecting the measuring unit . . . . . . . . . . . . . . 30
5.3 Degree of protection . . . . . . . . . . . . . . . . . . . . . . . 33
5.4 Post-connection check . . . . . . . . . . . . . . . . . . . . . 34
6 Operation . . . . . . . . . . . . . . . . . . . . . . . . 35
6.1 Display and operating elements . . . . . . . . . . . . . 35
6.2 Brief operating instructions for the function matrix
36
6.3 Error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
6.4 Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
7 Commissioning . . . . . . . . . . . . . . . . . . . 50
7.1 Function check . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
7.2 Switching on the measuring device . . . . . . . . . . 50
7.3 Quick Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
7.4 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
7.5 Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
7.6 Data storage device (HistoROM) . . . . . . . . . . . . . 66
8 Maintenance . . . . . . . . . . . . . . . . . . . . . 67
8.1 External cleaning . . . . . . . . . . . . . . . . . . . . . . . . . 67
8.2 Pipe cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
8.3 Sensor cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
8.4 Replacing seals . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
8.5 In-situ calibration . . . . . . . . . . . . . . . . . . . . . . . . . 68
8.6 Recalibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
9 Accessories . . . . . . . . . . . . . . . . . . . . . . .69
9.1 Device-specific accessories . . . . . . . . . . . . . . . . . . 69
9.2 Communication-specific accessories . . . . . . . . . . 69
9.3 Service-specific accessories . . . . . . . . . . . . . . . . . . 70
10 Trouble-shooting . . . . . . . . . . . . . . . . . .71
10.1 Trouble-shooting instructions . . . . . . . . . . . . . . . 71
10.2 System error messages . . . . . . . . . . . . . . . . . . . . . 72
10.3 Process error messages . . . . . . . . . . . . . . . . . . . . . 76
10.4 Process errors without messages . . . . . . . . . . . . . 76
10.5 Response of outputs to errors . . . . . . . . . . . . . . . . 78
10.6 Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
10.7 Return . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
10.8 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
10.9 Software history . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
11 Technical data. . . . . . . . . . . . . . . . . . . . .88
11.1 Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
11.2 Function and system design . . . . . . . . . . . . . . . . . 88
11.3 Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
11.4 Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
11.5 Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
11.6 Performance characteristics . . . . . . . . . . . . . . . . . 90
11.7 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
11.8 Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
11.9 Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
11.10 Mechanical construction . . . . . . . . . . . . . . . . . . . . 95
11.11 Operability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
11.12 Certificates and approvals . . . . . . . . . . . . . . . . . . . 97
11.13 Ordering information . . . . . . . . . . . . . . . . . . . . . . . 99
11.14 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
11.15 Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Proline t-mass 65 Document information
Endress+Hauser 3
1 Document information
1.1 Document conventions
1.1.1 Safety symbols
1.1.2 Electrical symbols
Symbol Device particularities and document content
"Caution!
“Caution” indicates an action or procedure which, if not performed correctly, can result
in incorrect operation or destruction of the device. Comply strictly with the instructions.
#Warning!
"Warning" indicates an action or procedure which, if not performed correctly, can result
in injury or a safety hazard. Comply strictly with the instructions and proceed with care.
!Note!
"Note" indicates an action or procedure which, if not performed correctly, can have an
indirect effect on operation or trigger an unexpected response on the part of the device.
Symbol Meaning
A0011197
Direct current
A terminal at which DC voltage is present or through which direct current flows.
A0011198
Alternating current
A terminal at which alternating voltage (sinusoidal) is present or through which alternating
current flows.
A0011200
Ground connection
A grounded terminal which, as far as the operator is concerned, is grounded via a grounding
system.
A0011199
Protective ground connection
A terminal which must be connected to ground prior to establishing any other connections.
A0011201
Equipotential connection
A connection that must be connected to the plant grounding system: This may be a potential
equalization line or a star grounding system depending on national or company codes of practice.

Document information Proline t-mass 65
4Endress+Hauser
1.1.3 Symbols for types of information
1.1.4 Symbols for graphics
Symbol Meaning
A0011182
Permitted
Indicates procedures, processes or actions that are permitted.
A0011183
Preferred
Indicates procedures, processes or actions that are preferred.
A0011200
Forbidden
Indicates procedures, processes or actions that are forbidden.
A0011193
Tip
Indicates additional information.
A0011194
Reference to documentation
Refers to the corresponding device documentation.
A0011195
Reference to page
Refers to the corresponding page number.
1., 2., 3. etc. Series of steps
ÃResult of a sequence of actions
A0013562
Help in the event of a problem
Symbol Meaning
1, 2, 3 etc. Item numbers
A, B, C etc. Views
A-A, B-B, C-C etc. Item numbers
A0013441
Flow direction
A0011187
Hazardous area
Indicates the hazardous area.
A0011187
Safe area (non-hazardous area)
Indicates the non-hazardous area.
-
.

Proline t-mass 65 Safety instructions
Endress+Hauser 5
2 Safety instructions
2.1 Designated use
The measuring device described in these Operating Instructions is to be used only for
measuring the mass flow rate of gases (e. g. kg, Nm3Sft3). At the same time, it also measures
gas temperature. The measuring device can be configured to measure a standard range of
pure gases or gas mixtures.
Examples:
•Air
•Oxygen
•Nitrogen
• Carbon Dioxide
• Argon, etc.
The use with corrosive, saturated or unclean gases should be treated with caution In such
cases, please contact your Endress+Hauser sales center for clarification. The use with
unstable gases or gases not deemed to be suitable by Endress+Hauser must be avoided. The
measuring device is not designed to be used with liquids or fluids in the liquid phase.
Resulting from incorrect use or from use other than that designated, the operational safety
of the measuring devices can be jeopardized. The manufacturer accepts no liability for
damages being produced from this.
2.2 Installation, commissioning and operation
Note the following points:
• Installation, connection to the electricity supply, commissioning, operation and
maintenance of the measuring device must be carried out by trained, qualified specialists
authorized to perform such work by the facility's owner operator. The specialist must have
read and understood these Operating Instructions and must follow the instructions they
contain.
• Endress+Hauser is willing to assist in clarifying the chemical resistance properties of parts
wetted by special fluids, including fluids used for cleaning. However small changes in
temperature, concentration or the degree of contamination in the process can result in
changes of the chemical resistance properties. Therefore, Endress+Hauser can not
guarantee or accept liability for the chemical resistance properties of the fluid wetted
materials in a specific application. The operator is responsible for the choice of fluid wetted
materials in regards to their in-process resistance to corrosion.
• If carrying out welding work on the piping, the welding unit should not be grounded by
means of the measuring device.
• The installer must ensure that the measuring device is correctly wired in accordance with
the wiring diagrams. The transmitter must be grounded unless special protection
measures have been taken e.g. galvanically isolated power supply SELV or PELV! (SELV =
Safe Extra Low Voltage; PELV = Protective Extra Low Voltage)
• Invariably, local regulations governing the opening and repair of electrical devices apply.

Safety instructions Proline t-mass 65
6Endress+Hauser
2.3 Operational safety
Note the following points:
• Measuring devices for use in hazardous environments are accompanied by separate
"Ex documentation", which is an integral part of these Operating Instructions. Strict
compliance with the installation instructions and ratings as stated in this supplementary
documentation is mandatory.
The symbol on the front of this supplementary Ex documentation indicates the approval
and the certification body (e.g. 0Europe, 2USA, 1Canada).
• Burn hazard! When hot fluid passes through the measuring tube, the surface temperature
of the housing increases. In the case of the sensor, in particular, users should expect
temperatures that can be close to the fluid temperature. If the temperature of the fluid is
high, implement sufficient measures to prevent burning or scalding.
• The measuring device complies with the general safety requirements in accordance with
EN 61010-1, the EMC requirements of IEC/EN 61326, and NAMUR recommendation
NE 21, NE 43 and NE 53.
• The separate document on the Pressure Equipment Directive must be observed for
measuring devices used in Category II or III installations in accordance with the Pressure
Equipment Directive.
• The manufacturer reserves the right to modify technical data without prior notice. Your
Endress+Hauser sales center will supply you with current information and updates to
these Operating Instructions.
2.4 Return
• Do not return a measuring device if it is not absolutely certain that it has been fully cleaned
of all traces of hazardous substances, e.g. substances which have penetrated crevices or
diffused through plastic.
• Costs incurred for waste disposal and injury (burns, etc.) due to inadequate cleaning of the
measuring device will be charged to the owner-operator.
• Refer to the measures on →86.
2.5 Product safety
This measuring device is designed in accordance with good engineering practice to meet
state-of-the-art safety requirements, has been tested, and left the factory in a condition in
which it is safe to operate. It complies with the applicable standards and regulations in
accordance with EN 61010-1 "Safety requirements for electrical equipment for
measurement, control and laboratory use". It can, however, be a source of danger if used
incorrectly or for other than the designated use.

Proline t-mass 65 Identification
Endress+Hauser 7
3 Identification
3.1 Device designation
The "t-mass 65" measuring device consists of the following components:
• t-mass 65 transmitter
• t-mass F, t-mass I sensors
Two versions are available:
• Compact version: transmitter and sensor form a single mechanical unit.
• Remote version: transmitter and sensor are installed separately.
3.1.1 Nameplate of the transmitter
A0005101
Fig. 1: Nameplate specifications for the "t-mass 65" transmitter (example)
1 Order code, serial number: See the specifications on the order confirmation for the meanings of the individual letters and
digits.
2 Power supply, frequency, power consumption
3 Available inputs/outputs:
4 Reserved for information on special products
5 Please refer to operating instructions / documentation
6 Reserved for certificates, approvals and for additional information on device version
7 Ambient temperature range
8 Degree of protection
Order Code:
Ser.No.:
TAG No.:
20-55VAC/16-62VDC
50-60Hz 14VA/8W
IP67/NEMA/Type4X65F25-XXXXXXXXXXXX
12345678901
ABCDEFGHJKLMNPQRST
–20°C (–4°F) < Tamb < +60°C (+140°F)
I-OUT ( HART), f-OUT
Proline t-mass 65
RELAY, RELAY
i
1
2
3
4
78
5
6
N12895

Identification Proline t-mass 65
8Endress+Hauser
3.1.2 Nameplate of the sensor
A0005512
Fig. 2: Nameplate specifications for the "t-mass F" sensor (example)
1 Order code, serial number: See the specifications on the order confirmation for the meanings of the individual letters and
digits.
2 Nominal diameter device
3 Pressure range
4 Temperature range
5 Material of measuring tubes
6Sealmaterial
7 Reserved for information on special products
8 Please refer to operating instructions / documentation
9 Ambient temperature range
10 Degree of protection
11 Reserved for additional information on device version (approvals, certificates)
1
2
4
5
6
7
9
11
10
3
Proline t-mass F
ABCDEFGHIJKLMNOPQRST TAG-No.:
Ser.No.:
12345678901
Order Code:
IP67 / NEMA/Type 4X
65F50-XXXXXXXXXXXX
P:
T:
Materials:
Seal:
3.1
-0.5...40bar / -7.25...+580 psi gauge
EPDM / PEEK
316/316L/1.4404/Alloy C 22- (2.4602)
-40°C...+100°C / -40°F...+212°F
-20°C(-4°F) <Tamb< +60°C(+140°F)
i
DN50 DIN/EN PN40
N12895
8

Proline t-mass 65 Identification
Endress+Hauser 9
3.1.3 Nameplate for connections
a0013819
Fig. 3: Nameplate specifications for transmitter connections (example)
1 Serial number
2 Possible configuration of current output
3 Possible configuration of relay contacts
4 Terminal assignment, cable for power supply: 85 to 260 V AC, 20 to 55 V AC, 16 to 62 V DC
Terminal No. 1: L1 for AC, L+ for DC
Terminal No. 2: N for AC, L– for DC
5 Signals present at inputs and outputs, possible configuration and terminal assignment (20 to 27),
see also "Electrical values of inputs/outputs", →88
6 Version of device software currently installed
7 Installed communication type, e.g.: HART, PROFIBUS DP, etc.
8 Information on current communication software (Device Revision and Device Description),
e.g.: Dev. 01 / DD 01 for HART
9Dateofmanufacture
10 Current updates to data specified in points 6 to 9
Active: 0/4...20mA, RL max. = 700 Ohm
Passive: 4...20mA, max. 30VDC, Ri < 150 Ohm
Passive: 30VDC, 250mA
(HART: RL.min. = 250 OHM)
fmax = 1kHz
3...30VDC, Ri = 5kOhm
f-OUT
I-OUT (HART)
A
P
STATUS-IN X
f-OUT
Passive: 30VDC, 250mA
fmax = 1kHz
P
Communication:
Drivers:
Device SW: XX.XX.XX
XXXXXXXXXXXXXXXX
Date: 01. MAI 2009
Ex-works / ab-Werk / réglages usine
26(+) / 27(-)
NC:
Versorgung /
Tension d'alimentation
Observer manuel d'instruction
See operating manual
Betriebsanleitung beachten
XXXXXXXXXXXSer.No.:
Supply /
24(+) / 25(-)
22(+) / 23(-)
20(+) / 21(-)
N/L-
PE
A:
NO:
P:
L1/L+
12
319475-00XX
active
passive
normally open contact
normally closed contact
Update 1 Update 2
2
3
1
4
5
6
7
8
9
10

Identification Proline t-mass 65
10 Endress+Hauser
3.2 Certificates and approvals
This measuring device is designed in accordance with good engineering practice to meet
state-of-the-art safety requirements, has been tested, and left the factory in a condition in
which it is safe to operate. The measuring device complies with the applicable standards and
regulations in accordance with EN 61010-1 "Safety requirements for electrical equipment
for measurement, control and laboratory use" and with the EMC requirements of IEC/EN
61326.
The measuring device described in these Operating Instructions thus complies with the
statutory requirements of the EC Directives. Endress+Hauser confirms successful testing of
the measuring device by affixing to it the CE mark.
The measuring device meets the EMC requirements of the Australian Communications and
Media Authority (ACMA).
3.3 Registered trademarks
KALREZ®and VITON®
Registered trademarks of DuPont Performance Elastomers L.L.C., Wilmington, USA
AMS™
Registered trademark of Emmerson Process Management, St. Louis, USA
HART®
Registered trademark of HART Communication Foundation, Austin, USA
HistoROM™, S-DAT®, T-DAT™, F-CHIP®, FieldCare®, Field XpertTM, FieldCheck®,
Applicator®, t-mass®
Registered or registration-pending trademarks of businesses in the Endress+Hauser Group

Proline t-mass 65 Installation
Endress+Hauser 11
4Installation
4.1 Incoming acceptance, transport and storage
4.1.1 Incoming acceptance
On receipt of the goods, check the following points:
• Is the packaging or content undamaged?
• Is the delivery complete and do the delivered goods match your order?
4.1.2 Transport
Observe the following instructions when unpacking and transporting the device to its final
location:
• Transport the measuring device in the container in which it is delivered.
• The covers or caps fitted to the process connections prevent mechanical damage to the
sealing surfaces and contamination in the measuring tube when the unit is being
transported or in storage. Do not remove these covers or caps until immediately before
installation.
• Do not lift measuring devices of nominal diameters > DN 40 (1½") by the transmitter
housing or the connection housing in the case of the remote version →4. For
transportation purposes, use webbing slings slung round the two process connections. Do
not use chains, as they could damage the housing.
#Warning!
Risk of injury if the measuring device slips. The center of gravity of the assembled measuring
device might be higher than the points around which the slings are slung.
When transporting, make sure that the measuring device does not unexpectedly turn
around its axis or slip.
A0004294
Fig. 4: Instructions for transporting sensors with > DN 40 (> 1½")
4.1.3 Storage
Note the following points:
• Pack the measuring device in such a way as to protect it reliably against impact for storage
(and transportation). The original packaging provides optimum protection.
• The permissible storage temperature is: –40 to +80 °C (–40 to +176 °F),
preferably +20 °C (+68 °F).
• Do not remove the protective covers or caps on the process connections until you are ready
to install the device.
• The measuring device must be protected against direct sunlight during storage in order to
avoid unacceptably high surface temperatures.
• Devices delivered with special sealing or bagging for oxygen service must remain sealed or
bagged until ready for installation.

Installation Proline t-mass 65
12 Endress+Hauser
4.2 Installation conditions
Note the following points:
• The thermal dispersion principle is very sensitive to disturbed flow conditions.
• Observe the recommended inlet and outlet requirements.
• Good engineering practice is necessary for the associated pipe work and installation.
• Ensure correct alignment and orientation of the sensor.
• Take measures to reduce or avoid condensation (e.g. install a condensation trap, thermal
insulation, etc.).
• The maximum permitted ambient temperatures →92 and the medium temperature
range →93 must be observed.
• Install the transmitter in a shaded location or use a protective sun shield.
• For mechanical reasons, and in order to protect the pipe, it is advisable to support heavy
sensors.
4.2.1 Dimensions
The dimensions and installation lengths of the sensor and transmitter can be found in the
"Technical Information" for the device in question. This document can be downloaded as a
PDF file from www.endress.com. A list of the "Technical Information" documents available
can be found in the "Documentation" section on →99.
4.2.2 System pressure and pulsating flow
Reciprocating pumps and some compressor systems can create strong changes in process
pressure that can induce spurious internal flow patterns and therefore cause additional
measurement error. These pressure pulses must be reduced by the appropriate measures:
• Use of expansion tanks
• Use of inlet expanders
• Relocate the flowmeter further downstream
In compressed air systems, it is recommended to mount the flowmeter after the filter, dryer
and buffer devices to avoid pulsations and oil/dirt contamination.
Do not mount the flowmeter directly after the compressor outlet.

Proline t-mass 65 Installation
Endress+Hauser 13
4.2.3 Pipework requirements
Good engineering practice should be followed at all times:
• Correct preparation, welding and finishing techniques
• Correctly sized gaskets
• Correctly aligned flanges and gaskets
• Connecting pipe work should match the internal diameter of the flowmeter. Maximum
pipe diameter mismatch should not exceed:
– 1 mm (0.04 in) for diameters < DN 200 (8")
– 3 mm (0.12 in) for diameters DN 200 (8")
Further information is provided in ISO Standard 14511.
"Caution!
New installations should be free of metallic and abrasive particles to prevent damage to the
sensing elements on start-up.
A0005103
Correctly aligned flanges and gaskets
A0005104 A0005105 A0005106
Pipe diameter one is not equal pipe
diameter two
Incorrectly sized gaskets Incorrectly aligned flanges and
gaskets

Installation Proline t-mass 65
14 Endress+Hauser
4.2.4 Orientation
Make sure that the direction arrow on the sensor matches the direction of flow through the
pipe.
Flanged sensor Insertion sensor
Vertical orientation
A0013785
compact

m
remote

m
compact

m,n
remote

m
Horizontal orientation, transmitter head up
A0013786
compact/remote

n
Horizontal orientation, transmitter head down
A0013787
compact/remote

o
Inclined orientation, transmitter head down
A0009897
compact/remote

p
 = Recommended orientation
= Orientation recommended in certain situations
m In the case of saturated or unclean gases, upward flow in a vertical pipe section is preferred
to minimize condensation/contamination.
n Not recommended if the vibrations are too high or if the installation is unstable.
oOnly suitable for clean/dry gases. Do not mount the sensor from the bottom, on horizontal pipes, if build-up
or condensate are likely to be present. Mount the sensor in a position as indicated below
pIf the gas is very wet or saturated with water (e. g. biogas, undried compressed air), mount in inclined
orientation (approx. 135° ±10°).

Proline t-mass 65 Installation
Endress+Hauser 15
4.2.5 Inlet and outlet runs
The thermal dispersion principle is sensitive to disturbed flow conditions.
As a general rule, the thermal flowmeter should always be installed as far away as possible
from any flow disturbances. For further information ISO Standard 14511.
!Note!
• Where two or more flow disturbances are located upstream of the meter, the longest
indicated inlet length should prevail. For example if a control valve is additionally mounted
upstream from the measuring device and an elbow on the inlet side, select the
recommended inlet length for control valves: 50 × DN
• For very light gases such as Helium and Hydrogen all upstream distances should be
doubled.
The minimum recommendations for inlet and outlet runs (without flow conditioner) are:
Flanged sensor
Insertion sensor
!Note!
A specially designed perforated plate flow conditioner can be installed if it is not possible to
observe the inlet runs required (→16).
1
A0007523
2
A0007524
3
A0007525
4
A0007526
5
A0007527
6
A0007528
1 = Reduction, 2 = Expansion, 3 = 90° elbow or T-piece, 4 = 2 × 90° elbow,
5 = 2 × 90° elbow (3-dimensional), 6 = Control valve
1
A0007529
2
A0007530
3
A0007531
4
A0007532
5
A0007564
6
A0007534
1 = Reduction, 2 = Expansion, 3 = 90° elbow or T-piece, 4 = 2 × 90° elbow,
5 = 2 × 90° elbow (3-dimensional), 6 = Control valve or pressure regulator
15xDN 2xDN
15xDN 2xDN
15xDN 2xDN
20xDN 2xDN
35xDN 2xDN
50xDN 2xDN
20xDN 5xDN
20xDN 5xDN
20xDN 5xDN
25xDN 5xDN
40xDN 5xDN
50xDN 5xDN

Installation Proline t-mass 65
16 Endress+Hauser
Outlet runs with pressure measuring points
The pressure measuring point should be installed downstream of the measuring device, so
that there is no potential influence of the pressure transmitter process connection on the
flow entering the measuring point.
A0005114
Fig. 5: Installing a pressure measuring point (PT = pressure transmitter)
Perforated plate flow conditioner
It is recommended to install a perforated plate flow conditioner if the recommended inlet
runs are not available.
A0005115
Fig. 6: The figure above illustrates the minimum recommended inlet and outlet runs expressed in multiples of the pipe diameter
using a flow conditioner.
1 = Flow conditioner with the flanged sensor, 2 = Flow conditioner with the insertion sensor
Flow conditioner for use with insertion sensors 65I →69
The well known "Mitsubishi" design is recommended for this application DN 80 mm to
DN 300 mm (3" to 12"). The flow conditioner must be installed at a distance of 8 × DN
upstream of the sensor. A further 5 pipe diameters minimum inlet run is required upstream
of the actual conditioner itself.
Measured errors can occur depending on disturbances in the inlet run. Therefore it is
advisable to choose inlet runs that are as long as possible.
!Note!
In the case of insertion devices, the inlet run selected downstream of the conditioner should
be as long as possible.
PT
2...5xDN
2 × DN5 - 10 × DN >8 × DN 5 × DN
5 - 10 × DN
2
1

Proline t-mass 65 Installation
Endress+Hauser 17
Perforated plate flow conditioners (19 hole) for use with flanged sensor 65F →69
This is a special Endress+Hauser version designed especially for use with the t-mass F sensor
(sizes DN 25 to 100 / 1" to 4"). The mounting hole patterns and sizing are of a multi-variant
design which means that one plate will fit different flange pressure classes e.g. Cl. 150 and
Cl. 300.
The flow conditioner and gaskets are fitted between the pipe flange and the measuring
device →7. Use only standard bolts which match the flange bolt hole to guarantee that
the flow conditioner is centered correctly.
The alignment notch must also be pointing in the same plane as the transmitter. Incorrect
installation of the flow conditioner will have a small effect on the measurement accuracy.
A0005116
Fig. 7: Flow conditioner mounting arrangement (example)
1=perforatedplateflowconditioner,2= seal/gasket,3= alignment notch, 4 = alignment in the same plane as the transmitter
Note
• Order the t-mass F sensor and the flow conditioner together to ensure that they are
calibrated together. Joint calibration guarantees optimum performance. Ordering the flow
conditioner separately and using it with the measuring device will further increase
measurement uncertainty.
• The use of conditioners from other suppliers will affect the flow profile and pressure drop
and will have an adverse effect on performance.
• Bolts, nuts, seals, etc. are not included in the scope of supply and must be supplied by the
customer.
1
2
2
3
4
1
1
1

Installation Proline t-mass 65
18 Endress+Hauser
4.2.6 Heating
Some applications require suitable measures to avoid heat loss (condensation). Heating can
be electric, e. g. with heated elements, or by means of copper pipes carrying hot water or
steam.
"Caution!
Risk of electronics overheating! Consequently, make sure that the adapter between sensor
and transmitter and the connection housing of the remote version always remain free of
insulating material.
4.2.7 Thermal insulation
If the gas is very wet or saturated with water (e.g. biogas), the piping and sensor housing
should be insulated to prevent water droplets from condensing on the transducer.
A0005122
Fig. 8: Maximum thermal insulation for t-mass 65F and 65I
a Maximum insulation height for the flanged sensor
b Maximum insulation height for the insertion sensor
4.2.8 Vibrations
"Caution!
Excessive vibration can result in mechanical damage to the measuring device and its
mounting.
Observe the vibration specification in the technical data section →93
aa
bb

Proline t-mass 65 Installation
Endress+Hauser 19
4.3 Installation
4.3.1 Mounting the insertion sensor
The sensor can be mounted into a welding boss or a retractable mounting set. If a retractable
mounting set is being used, then refer to the supplementary documentation delivered with
the mounting set.
Mounting the welding boss
This instruction describes mounting of the Endress+Hauser welding boss. If a welding boss
is already available or a customer-specific one is being used, then go to the next section
"Insertion depth calculation and adjustment."
!Note!
• Take the orientation and inlet and outlet runs into account before mounting the welding
socket →14 ff.
• The welding boss is made of stainless steel 1.4404 (316/316L). Use appropriate welding
technique.
"Caution!
• When mounting the fitting to a thin wall duct, use a suitable support bracket for the sensor
and weld the welding boss to a base plate to spread the load. Otherwise, the mounting may
be unstable and the duct wall can be damaged.
#Warning!
• These instructions are only applicable to installation in an un-pressurized line, without gas
present and at safe temperatures.
1. Drill or a cut hole of Ø 31.0 mm ± 0.5 mm (1.22 ± 0.019") in the pipe.
2. Deburr the hole.
3. Fit the edge of the welding boss into the hole, align it vertically and weld it on →9.
A0010098
Fig. 9: Positioning the welding socket on the pipe (or duct)
Insertion depth calculation and adjustment
To ensure optimum measurement performance, the insertion sensor must be installed in the
correct position in the pipe or duct (30% of the internal diameter).
A millimeter and inch scale is provided along the entire length of the sensor tube. This
makes it possible to align the sensor at the right depth.
4. Calculate the insertion depth:
– with the help of the Quick Setup "Sensor" →53 or
– using the following dimensions and formulae
90°
90°

Installation Proline t-mass 65
20 Endress+Hauser
A0005118
Fig. 10: Dimensions needed to calculate the insertion depth
A Pipes: internal diameter
Ducts: internal dimension
B Wall thickness
C Dimension from pipe/duct to the compression fitting
The following dimensions are required to calculate the insertion depth:
!Note!
For detailed remarks on calculation refer to Technical Information TI00069D.
• Calculated insertion depth = (0.3 × A) + B + C + 2 mm (0.08 in)
Note down the calculated value.
A0010001
Fig. 11: Aligning the sensor to the calculated insertion depth
ABC ABC
230
220
210
200
190
180
9
8
7
230
220
210
200
190
180
9
8
7
230
220
210
200
190
180
9
8
7
A • For circular pipes: the internal diameter (DN)
• For rectangular ducts:
– The internal duct height if the sensor is installed vertically
– The internal duct width if the sensor is installed horizontally
!Note!
Minimum length of dimension A = 80 mm (3.15 in)
B Pipe / duct wall thickness
C Height of the welding nozzle at the pipe/duct including the sensor compression fitting or low pressure
mounting set (if used).
1
3
4
2
230
220
210
200
190
180
9
8
7
