Endress+Hauser Proline Promag W 400 User manual

Products Solutions Services
Operating Instructions
Proline Promag W 400
EtherNet/IP
Electromagnetic flowmeter
BA01214D/06/EN/01.13
71218264
Valid as of version
01.00.zz (Device firmware)

Proline Promag W 400 EtherNet/IP
2 Endress+Hauser
• Make sure the document is stored in a safe place such that it is always available when
working on or with the device.
•To avoid danger to individuals or the facility, read the "Basic safety instructions" section
carefully, as well as all other safety instructions in the document that are specific to
working procedures.
• The manufacturer reserves the right to modify technical data without prior notice. Your
Endress+Hauser Sales Center will supply you with current information and updates to
these Instructions.

Proline Promag W 400 EtherNet/IP Table of contents
Endress+Hauser 3
Table of contents
1 Document information .............. 6
1.1 Document function ..................... 6
1.2 Symbols used .......................... 6
1.2.1 Safety symbols .................. 6
1.2.2 Electrical symbols ................ 6
1.2.3 Tool symbols .................... 7
1.2.4 Symbols for certain types of
information .................... 7
1.2.5 Symbols in graphics ............... 7
1.3 Documentation ........................ 8
1.3.1 Standard documentation ........... 8
1.3.2 Supplementary device-dependent
documentation .................. 8
1.4 Registered trademarks ................... 8
2 Basic safety instructions ............ 9
2.1 Requirements for the personnel ............ 9
2.2 Designated use ........................ 9
2.3 Workplace safety ...................... 10
2.4 Operational safety ..................... 10
2.5 Product safety ........................ 10
2.6 IT security ........................... 11
3 Product description ................ 12
3.1 Product design ........................ 12
4 Incoming acceptance and product
identification ..................... 13
4.1 Incoming acceptance ................... 13
4.2 Product identification ................... 14
4.2.1 Transmitter nameplate ........... 14
4.2.2 Sensor nameplate ............... 15
4.2.3 Symbols on measuring device ...... 16
5 Storage and transport ............. 17
5.1 Storage conditions ..................... 17
5.2 Transporting the product ................ 17
5.2.1 For measuring devices
≤ DN 300 (12") ................. 17
5.2.2 For measuring devices
≥ DN 350 (14") ................. 18
5.3 Packaging disposal ..................... 18
6 Installation ....................... 19
6.1 Installation conditions .................. 19
6.1.1 Mounting position ............... 19
6.1.2 Requirements from environment and
process ....................... 22
6.1.3 Special mounting instructions ...... 23
6.2 Mounting the measuring device ........... 24
6.2.1 Required tools .................. 24
6.2.2 Preparing the measuring device ..... 25
6.2.3 Mounting the sensor ............. 25
6.2.4 Mounting the transmitter of the
remote version ................. 30
6.2.5 Turning the transmitter housing .... 32
6.2.6 Turning the display module ........ 34
6.3 Post-installation check .................. 34
7 Electrical connection .............. 36
7.1 Connection conditions .................. 36
7.1.1 Required tools .................. 36
7.1.2 Requirements for connecting cable ... 36
7.1.3 Terminal assignment ............. 38
7.1.4 Pin assignment, device plug ........ 39
7.1.5 Preparing the measuring device ..... 39
7.1.6 Preparing the connecting cable for
the remote version .............. 40
7.2 Connecting the measuring device .......... 41
7.2.1 Connecting the transmitter ........ 41
7.2.2 Connecting the remote version ..... 42
7.2.3 Ensuring potential equalization ..... 44
7.3 Special connection instructions ............ 46
7.3.1 Connection examples ............. 46
7.4 Hardware settings ..................... 47
7.4.1 Setting the device address ......... 47
7.5 Ensuring the degree of protection .......... 48
7.5.1 Degree of protection IP66/67, Type
4X enclosure ................... 48
7.5.2 Degree of protection IP68, Type 6P
enclosure, with "Cust-potted" option .. 48
7.6 Post-connection check .................. 49
8 Operation options ................. 50
8.1 Overview of operation options ............ 50
8.2 Structure and function of the operating
menu .............................. 51
8.2.1 Structure of the operating menu .... 51
8.2.2 Operating philosophy ............ 52
8.3 Access to the operating menu via the local
display ............................. 53
8.3.1 Operational display .............. 53
8.3.2 Navigation view ................ 55
8.3.3 Editing view ................... 57
8.3.4 Operating elements .............. 58
8.3.5 Opening the context menu ......... 59
8.3.6 Navigating and selecting from list ... 61
8.3.7 Calling the parameter directly ...... 61
8.3.8 Calling up help text .............. 62
8.3.9 Changing the parameters ......... 63
8.3.10 User roles and related access
authorization .................. 64
8.3.11 Disabling write protection via access
code ......................... 64

Table of contents Proline Promag W 400 EtherNet/IP
4 Endress+Hauser
8.3.12 Enabling and disabling the keypad
lock ......................... 64
8.4 Access to the operating menu via the Web
browser ............................. 65
8.4.1 Function range ................. 65
8.4.2 Prerequisites ................... 65
8.4.3 Establishing a connection ......... 66
8.4.4 Logging on .................... 66
8.4.5 User interface .................. 67
8.4.6 Disabling the Web server .......... 68
8.4.7 Logging out .................... 68
8.5 Access to the operating menu via the
operating tool ........................ 68
8.5.1 Connecting the operating tool ...... 69
8.5.2 FieldCare ..................... 69
9 System integration ................ 71
9.1 Overview of device description files ......... 71
9.1.1 Current version data for the device ... 71
9.1.2 Operating tools ................. 71
9.2 Overview of system files ................. 71
9.3 Integrating the measuring device in the
system ............................. 71
10 Commissioning .................... 73
10.1 Function check ....................... 73
10.2 Switching on the measuring device ......... 73
10.3 Configuring the device address via software .. 73
10.4 Setting the operating language ............ 73
10.5 Configuring the measuring device .......... 74
10.5.1 Defining the tag name ............ 74
10.5.2 Setting the system units .......... 75
10.5.3 Configuring the local display ....... 76
10.5.4 Configuring the communication
interface ...................... 78
10.5.5 Configuring the low flow cut off ..... 79
10.5.6 Configuring empty pipe detection ... 80
10.6 Advanced settings ..................... 82
10.6.1 Carrying out a sensor adjustment .... 82
10.6.2 Configuring the totalizer .......... 83
10.6.3 Carrying out additional display
configurations .................. 84
10.6.4 Performing electrode cleaning ...... 86
10.7 Simulation ........................... 87
10.8 Protecting settings from unauthorized
access .............................. 88
10.8.1 Write protection via access code ..... 88
10.8.2 Write protection via write protection
switch ........................ 89
11 Operation ......................... 90
11.1 Read out and modify current Ethernet
settings ............................. 90
11.2 Reading device locking status ............. 90
11.3 Adjusting the operating language .......... 91
11.4 Configuring the display ................. 91
11.5 Reading measured values ................ 91
11.5.1 Process variables ................ 91
11.5.2 Totalizer ...................... 92
11.6 Adapting the measuring device to the process
conditions ........................... 92
11.7 Performing a totalizer reset .............. 93
11.7.1 Function scope of "Control Totalizer "
parameter ..................... 93
11.7.2 Function scope of "Reset all totalizers"
parameter ..................... 93
11.8 Showing data logging ................... 93
12 Diagnostics and troubleshooting ... 96
12.1 General troubleshooting ................. 96
12.2 Diagnostic information via light emitting
diodes .............................. 97
12.2.1 Transmitter .................... 97
12.3 Diagnostic information on local display ...... 99
12.3.1 Diagnostic message .............. 99
12.3.2 Calling up remedial measures ..... 101
12.4 Diagnostic information in the Web browser .102
12.4.1 Diagnostic options .............. 102
12.4.2 Calling up remedy information .... 102
12.5 Diagnostic information in FieldCare ....... 103
12.5.1 Diagnostic options .............. 103
12.5.2 Calling up remedy information .... 104
12.6 Diagnostic information in FieldCare ....... 104
12.6.1 Diagnostic options .............. 104
12.6.2 Calling up remedy information .... 105
12.7 Diagnostic information via communication
interface ........................... 105
12.7.1 Reading out diagnostic information 105
12.8 Adapting the diagnostic information ...... 106
12.8.1 Adapting the diagnostic behavior ... 106
12.9 Overview of diagnostic information ....... 107
12.10 Pending diagnostic events .............. 110
12.11 Diagnostic list ....................... 111
12.12 Event logbook ....................... 111
12.12.1 Event history .................. 111
12.12.2 Filtering the event logbook ....... 112
12.12.3 Overview of information events .... 112
12.13 Resetting the measuring device .......... 113
12.14 Device information ................... 113
12.15 Firmware history ..................... 114
13 Maintenance .................... 116
13.1 Maintenance tasks .................... 116
13.1.1 Exterior cleaning ............... 116
13.1.2 Interior cleaning ............... 116
13.1.3 Replacing seals ................ 116
13.2 Measuring and test equipment ........... 116
13.3 Endress+Hauser services ............... 116
14 Repair ........................... 117
14.1 General notes ....................... 117
14.2 Spare parts ......................... 117
14.3 Endress+Hauser services ............... 117

Proline Promag W 400 EtherNet/IP Table of contents
Endress+Hauser 5
14.4 Return ............................. 117
14.5 Disposal ........................... 117
14.5.1 Removing the measuring device .... 117
14.5.2 Disposing of the measuring device .. 118
15 Accessories ...................... 119
15.1 Device-specific accessories .............. 119
15.1.1 For the transmitter ............. 119
15.1.2 For the sensor ................. 119
15.2 Communication-specific accessories ....... 119
15.3 Service-specific accessories .............. 120
15.4 System components ................... 120
16 Technical data ................... 121
16.1 Application ......................... 121
16.2 Function and system design ............. 121
16.3 Input .............................. 121
16.4 Output ............................ 124
16.5 Power supply ........................ 127
16.6 Performance characteristics ............. 128
16.7 Installation ......................... 130
16.8 Environment ........................ 130
16.9 Process ............................ 131
16.10 Mechanical construction ............... 132
16.11 Operability ......................... 144
16.12 Certificates and approvals .............. 144
16.13 Application packages .................. 146
16.14 Accessories ......................... 146
16.15 Documentation ...................... 147
17 Appendix ........................ 148
17.1 Overview of the operating menu .......... 148
Index ................................. 162

Document information Proline Promag W 400 EtherNet/IP
6 Endress+Hauser
1 Document information
1.1 Document function
These Operating Instructions contain all the information that is required in various phases
of the life cycle of the device: from product identification, incoming acceptance and
storage, to mounting, connection, operation and commissioning through to
troubleshooting, maintenance and disposal.
1.2 Symbols used
1.2.1 Safety symbols
Symbol Meaning
DANGER
A0011189-EN
DANGER!
This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in
serious or fatal injury.
WARNING
A0011190-EN
WARNING!
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
serious or fatal injury.
CAUTION
A0011191-EN
CAUTION!
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
minor or medium injury.
NOTICE
A0011192-EN
NOTICE!
This symbol contains information on procedures and other facts which do not result in
personal injury.
1.2.2 Electrical symbols
Symbol Meaning
A0011197
Direct current
A terminal to which DC voltage is applied or through which direct current flows.
A0011198
Alternating current
A terminal to which alternating voltage is applied or through which alternating current flows.
A0017381
Direct current and alternating current
•A terminal to which alternating voltage or DC voltage is applied.
• A terminal through which alternating current or direct current flows.
A0011200
Ground connection
A grounded terminal which, as far as the operator is concerned, is grounded via a grounding
system.
A0011199
Protective ground connection
A terminal which must be connected to ground prior to establishing any other connections.
A0011201
Equipotential connection
A connection that has to be connected to the plant grounding system: This may be a potential
equalization line or a star grounding system depending on national or company codes of practice.

Proline Promag W 400 EtherNet/IP Document information
Endress+Hauser 7
1.2.3 Tool symbols
Symbol Meaning
A0013442
Torx screwdriver
A0011219
Phillips head screwdriver
A0011222
Open-ended wrench
1.2.4 Symbols for certain types of information
Symbol Meaning
A0011182
Allowed
Indicates procedures, processes or actions that are allowed.
A0011183
Preferred
Indicates procedures, processes or actions that are preferred.
A0011184
Forbidden
Indicates procedures, processes or actions that are forbidden.
A0011193
Tip
Indicates additional information.
A0011194
Reference to documentation
Refers to the corresponding device documentation.
A0011195
Reference to page
Refers to the corresponding page number.
A0011196
Reference to graphic
Refers to the corresponding graphic number and page number.
,… ,
Series of steps
Result of a sequence of actions
A0013562
Help in the event of a problem
1.2.5 Symbols in graphics
Symbol Meaning
1, 2, 3,... Item numbers
,… ,
Series of steps
A, B, C, ... Views
A-A, B-B, C-C, ... Sections
A0013441
Flow direction
-
A0011187
Hazardous area
Indicates a hazardous area.
.
A0011188
Safe area (non-hazardous area)
Indicates a non-hazardous area.

Document information Proline Promag W 400 EtherNet/IP
8 Endress+Hauser
1.3 Documentation
The following document types are available:
•On the CD-ROM supplied with the device
• In the Download Area of the Endress+Hauser Internet site: www.endress.com →
Download
For a detailed list of the individual documents along with the documentation code
(→  147)
1.3.1 Standard documentation
Document type Purpose and content of the document
Technical Information Planning aid for your device
The document contains all the technical data on the device and provides
an overview of the accessories and other products that can be ordered for
the device.
Brief Operating Instructions Guide that takes you quickly to the 1st measured value
The Brief Operating Instructions contain all the essential information
from incoming acceptance to initial commissioning.
1.3.2 Supplementary device-dependent documentation
Additional documents are supplied depending on the device version ordered: Always
comply strictly with the instructions in the supplementary documentation. The
supplementary documentation is an integral part of the device documentation.
1.4 Registered trademarks
EtherNet/IPTM
Trademark of ODVA, Inc.
Microsoft®
Registered trademark of the Microsoft Corporation, Redmond, Washington, USA
Applicator®, FieldCare®, Field XpertTM, HistoROM®, Heartbeat TechnologyTM
Registered or registration-pending trademarks of the Endress+Hauser Group

Proline Promag W 400 EtherNet/IP Basic safety instructions
Endress+Hauser 9
2 Basic safety instructions
2.1 Requirements for the personnel
The personnel for installation, commissioning, diagnostics and maintenance must fulfill
the following requirements:
‣Trained, qualified specialists must have a relevant qualification for this specific function
and task
‣Are authorized by the plant owner/operator
‣Are familiar with federal/national regulations
‣Before beginning work, the specialist staff must have read and understood the
instructions in the Operating Instructions and supplementary documentation as well as
in the certificates (depending on the application)
‣Following instructions and basic conditions
The operating personnel must fulfill the following requirements:
‣Being instructed and authorized according to the requirements of the task by the
facility's owner-operator
‣Following the instructions in these Operating Instructions
2.2 Designated use
Application and media
The measuring device described in these Instructions is intended only for flow
measurement of liquids with a minimum conductivity of 5 μS/cm.
Depending on the version ordered, the measuring device can also measure potentially
explosive, flammable, poisonous and oxidizing media.
Measuring devices for use in hazardous areas, in hygienic applications or in applications
where there is an increased risk due to process pressure, are labeled accordingly on the
nameplate.
To ensure that the measuring device remains in proper condition for the operation time:
‣Only use the measuring device in full compliance with the data on the nameplate and
the general conditions listed in the Operating Instructions and supplementary
documentation.
‣Based on the nameplate, check whether the ordered device is permitted for the
intended use in the hazardous area (e.g. explosion protection, pressure vessel safety).
‣Use the measuring device only for media against which the process-wetted materials
are adequately resistant.
‣If the measuring device is not operated at atmospheric temperature, compliance with
the relevant basic conditions specified in the device documentation provided (on the
CD-ROM) is absolutely essential.
Incorrect use
Non-designated use can compromise safety. The manufacturer is not liable for damage
caused by improper or non-designated use.
!WARNING
Danger of breakage of the sensor due to corrosive or abrasive fluids!
‣Verify the compatibility of the process fluid with the sensor material.
‣Ensure the resistance of all fluid-wetted materials in the process.
‣Observe the specified pressure and temperature range.
Verification for borderline cases:
‣For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance
in verifying the corrosion resistance of fluid-wetted materials, but does not accept any

Basic safety instructions Proline Promag W 400 EtherNet/IP
10 Endress+Hauser
warranty or liability as minute changes in the temperature, concentration or level of
contamination in the process can alter the corrosion resistance properties.
Residual risks
The external surface temperature of the housing can increase by max. 10 K due to the
power consumption of the electronic components. Hot process fluids passing through the
measuring device will further increase the surface temperature of the housing. The surface
of the sensor, in particular, can reach temperatures which are close to the fluid
temperature.
Possible burn hazard due to fluid temperatures!
‣For elevated fluid temperature, ensure protection against contact to prevent burns.
2.3 Workplace safety
For work on and with the device:
‣Wear the required personal protective equipment according to federal/national
regulations.
For welding work on the piping:
‣Do not ground the welding unit via the measuring device.
If working on and with the device with wet hands:
‣It is recommended to wear gloves on account of the higher risk of electric shock.
2.4 Operational safety
Risk of injury.
‣Operate the device in proper technical condition and fail-safe condition only.
‣The operator is responsible for interference-free operation of the device.
Conversions to the device
Unauthorized modifications to the device are not permitted and can lead to unforeseeable
dangers.
‣If, despite this, modifications are required, consult with Endress+Hauser.
Repair
To ensure continued operational safety and reliability,
‣Carry out repairs on the device only if they are expressly permitted.
‣Observe federal/national regulations pertaining to repair of an electrical device.
‣Use original spare parts and accessories from Endress+Hauser only.
Environmental requirements
If a plastic transmitter housing is permanently exposed to certain steam and air mixtures,
this can damage the housing.
‣If you are unsure, please contact your Endress+Hauser Sales Center for clarification.
‣If used in an approval-related area, observe the information on the nameplate.
2.5 Product safety
This measuring device is designed in accordance with good engineering practice to meet
state-of-the-art safety requirements, has been tested, and left the factory in a condition in
which it is safe to operate.
It meets general safety standards and legal requirements. It also complies with the EC
directives listed in the device-specific EC Declaration of Conformity. Endress+Hauser
confirms this by affixing the CE mark to the device.

Proline Promag W 400 EtherNet/IP Basic safety instructions
Endress+Hauser 11
2.6 IT security
We only provide a warranty if the device is installed and used as described in the
Operating Instructions. The device is equipped with security mechanisms to protect it
against any inadvertent changes to the device settings.
IT security measures in line with operators' security standards and designed to provide
additional protection for the device and device data transfer must be implemented by the
operators themselves.
Endress+Hauser can be contacted to provide support in performing this task.

Product description Proline Promag W 400 EtherNet/IP
12 Endress+Hauser
3 Product description
3.1 Product design
1
2
3
5
6
8
7
4
A0017218
 1 Important components of the compact version
1 Display module
2 Smart sensor electronics module
3 HistoROM DAT (plug-in memory)
4 Main electronics module
5 Terminals (screw terminals, some available as plug-in terminals)
6 Transmitter housing, compact version
7 Cable glands
8 Sensor, compact version

Proline Promag W 400 EtherNet/IP Incoming acceptance and product identification
Endress+Hauser 13
4 Incoming acceptance and product
identification
4.1 Incoming acceptance
A0015502
1
+
2
1
+
2
A0013843
Is the order code on the delivery note (1) identical to the order code on the product sticker
(2)?
A0013695
A0015502
A0013698
Are the goods undamaged?
A0015502
A0013699
Do the nameplate data match the ordering information on the delivery note?
A0015502
A0013697
Is the CD-ROM with the Technical Documentation and documents present?

Incoming acceptance and product identification Proline Promag W 400 EtherNet/IP
14 Endress+Hauser
If one of the conditions is not satisfied, contact your Endress+Hauser Sales Center.
4.2 Product identification
The following options are available for identification of the measuring device:
• Nameplate specifications
• Order code with breakdown of the device features on the delivery note
• Enter serial numbers from nameplates in W@M Device Viewer
(www.endress.com/deviceviewer): All information about the measuring device is
displayed.
For an overview of the scope of the Technical Documentation provided, refer to the
following:
• The "Additional standard documentation on the device" (→  8) and "Supplementary
device-dependent documentation" (→  8) sections
• The W@M Device Viewer: Enter the serial number from the nameplate
(www.endress.com/deviceviewer)
4.2.1 Transmitter nameplate
Order code:
i
Ext. ord. cd.:
Ser. no.:
Patents
i
Date:
1
2
3 4 5 6 7
8
9
10
111213
A0017346
 2 Example of a transmitter nameplate
1 Manufacturing location
2 Name of the transmitter
3 Order code
4 Serial number
5 Extended order code
6 Permitted ambient temperature range (Ta)
7 Firmware version (FW) and device revision (Dev.Rev.) from the factory
8 Degree of protection
9 Permitted temperature range for cable
10 2-D matrix code
11 Manufacturing date: year-month
12 CE mark, C-Tick
13 Electrical connection data, e.g. available inputs and outputs, supply voltage

Proline Promag W 400 EtherNet/IP Incoming acceptance and product identification
Endress+Hauser 15
4.2.2 Sensor nameplate
i
Patents
i
Material:
Tm:
Ext. ord. cd.:
Order Code:
Ser.No.:
Date:
21
3
4
5
6 7
8
9
10
11
13 12
14
15
A0017186
 3 Example of sensor nameplate
1 Name of the sensor
2 Manufacturing location
3 Order code
4 Serial number (Ser. no.)
5 Extended order code (Ext. ord. cd.)
6 Nominal diameter of sensor
7 Test pressure of the sensor
8 Fluid temperature range
9 Material of lining and electrodes
10 Degree of protection: e.g. IP, NEMA
11 Permitted ambient temperature (Ta)
12 2-D matrix code
13 CE mark, C-Tick
14 Flow direction
15 Manufacturing date: year-month
Order code
The measuring device is reordered using the order code.
Extended order code
• The device type (product root) and basic specifications (mandatory features) are
always listed.
• Of the optional specifications (optional features), only the safety and approval-
related specifications are listed (e.g. LA). If other optional specifications are also
ordered, these are indicated collectively using the # placeholder symbol (e.g. #LA#).
• If the ordered optional specifications do not include any safety and approval-related
specifications, they are indicated by the + placeholder symbol (e.g. XXXXXX-ABCDE
+).

Incoming acceptance and product identification Proline Promag W 400 EtherNet/IP
16 Endress+Hauser
4.2.3 Symbols on measuring device
Symbol Meaning

WARNING!
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious
or fatal injury.
A0011194
Reference to documentation
Refers to the corresponding device documentation.
A0011199
Protective ground connection
A terminal which must be connected to ground prior to establishing any other connections.

Proline Promag W 400 EtherNet/IP Storage and transport
Endress+Hauser 17
5 Storage and transport
5.1 Storage conditions
Observe the following notes for storage:
• Store in the original packaging to ensure protection from shock.
• Do not remove protective covers or protective caps installed on process connections.
They prevent mechanical damage to the sealing surfaces and contamination in the
measuring tube.
• Protect from direct sunlight to avoid unacceptably high surface temperatures.
• Select a storage location where moisture cannot collect in the measuring device as
fungus and bacteria infestation can damage the lining.
• Store in a dry and dust-free place.
• Do not store outdoors.
• Storage temperature(→  130)
5.2 Transporting the product
5.2.1 For measuring devices ≤ DN 300 (12")
!WARNING
Center of gravity of the measuring device is higher than the suspension points of the
webbing slings.
Risk of injury if the measuring device slips.
‣Secure the measuring device from rotating or slipping.
‣Observe the weight specified on the packaging (stick-on label).
‣Observe the transport instructions on the stick-on label on the electronics compartment
cover.
A0015606
Observe the following notes during transport:
•Transport the measuring device to the measuring point in the original packaging.
• Lifting gear
– Webbing slings: Do not use chains, as they could damage the housing.
– For wood crates, the floor structure enables these to be loaded lengthwise or broadside
using a forklift.
• Use the webbing slings to lift the measuring device at the process connections; do not lift
at the transmitter housing or the connection housing of the remote version.
• Do not remove protective covers or protective caps installed on process connections.
They prevent mechanical damage to the sealing surfaces and contamination in the
measuring tube.

Storage and transport Proline Promag W 400 EtherNet/IP
18 Endress+Hauser
5.2.2 For measuring devices ≥ DN 350 (14")
Also observe the following notes during transport:
•Lift the measuring device by the flange using the metal brackets.
• If transporting by forklift, do not lift the sensor by the metal casing. This would buckle
the casing and damage the internal magnetic coils.
A0016257
5.3 Packaging disposal
All packaging materials are environmentally friendly and 100% recyclable:
• Measuring device secondary packaging: polymer stretch film that conforms to EC
Directive 2002/95/EC (RoHS).
• Packaging:
– Wood crate, treated in accordance with ISPM 15 standard, which is confirmed by the
affixed IPPC logo.
or
– Carton in accordance with European Packaging Directive 94/62EC; recyclability is
confirmed by the affixed RESY symbol.
• Seaworthy packaging (optional): Wood crate, treated in accordance with ISPM 15
standard, which is confirmed by the affixed IPPC logo.
• Carrying and mounting hardware:
– Disposable plastic pallet
– Plastic straps
– Plastic adhesive strips
• Dunnage: Paper cushion

Proline Promag W 400 EtherNet/IP Installation
Endress+Hauser 19
6 Installation
6.1 Installation conditions
No special measures such as supports are necessary. External forces are absorbed by the
construction of the device.
6.1.1 Mounting position
Mounting location
Preferably install the sensor in an ascending pipe, and ensure a sufficient distance to the
next pipe elbow: h ≥ 2 × DN
h
A0017061
To prevent measuring errors arising from accumulation of gas bubbles in the measuring
tube, avoid the following mounting locations in the pipe:
•Highest point of a pipeline.
• Directly upstream of a free pipe outlet in a down pipe.
Installation in down pipes
Install a siphon or a vent valve downstream of the sensor in down pipes whose length h ≥
5 m (16.4 ft). This precaution is to avoid low pressure and the consequent risk of damage
to the measuring tube. This measure also prevents the system losing prime, which could
cause air pockets.
For information on the liner's resistance to partial vacuum (→  131)
h
2
1
A0017064
 4 Installation in a down pipe
1 Vent valve
2 Pipe siphon
h Length of down pipe

Installation Proline Promag W 400 EtherNet/IP
20 Endress+Hauser
Installation in partially filled pipes
A partially filled pipe with a gradient necessitates a drain-type configuration. The empty
pipe detection (EPD) function offers additional protection by detecting empty or partially
filled pipes.
•Do not install the sensor at the lowest point in the drain: risk of solids accumulating.
• It is advisable to install a cleaning valve.
³5 × DN ³2 × DN
A0017063
For very heavy sensors
If the nominal diameter DN ≥ 350 (14 in), mount the sensor on a foundation of adequate
load-bearing strength.
NOTICE
Very heavy!
Risk of damaging the metal casing and the internal magnetic coils.
‣Do not support the weight of the sensor on the metal casing.
A0016276
Orientation
The direction of the arrow on the sensor nameplate helps you to install the sensor
according to the flow direction (direction of medium flow through the piping).
An optimum orientation position helps avoid gas and air accumulations and deposits in
the measuring tube.
The measuring device also offers the empty pipe detection function to detect partially filled
measuring pipes in the event of outgassing fluids or variable process pressures.
Vertical
This is the optimum orientation for self-emptying piping systems and for use in
conjunction with empty pipe detection.
