BA00282R/09/EN/13.14
71258848
SW version
1.00.zz
Operating Instructions
RID14
Field Indicator
with FOUNDATION Fieldbus™- protocol

How to find the documentation for your device RID14
2Endress+Hauser
How to find the documentation for your device
TAG No.: XXX000
Ser. No.: X000X000000
Order code 00X00-XXXX0XX0XXX
www.endress.com/deviceviewer Endress+Hauser Operations App
Serial number

RID14 Brief overview
Endress+Hauser 3
Brief overview
For quick and easy commissioning:
Safety instructions →ä7
▾
Installation instructions →ä11
▾
Wiring →ä14
▾
Display and operating elements →ä23
Information on configuration and operating programs from other
manufacturers.
Information about setting the hardware write protection, device
address, etc. for FOUNDATION Fieldbus communication
▾
Commissioning →ä28
Commissioning via the FOUNDATION Fieldbus interface - quick start
for device configuration for standard operation

RID14
4Endress+Hauser
Table of contents
1 Document information . . . . . . . . . . . . . . 5
1.1 Document function . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 Document conventions . . . . . . . . . . . . . . . . . . . . . . . 5
2 Safety instructions . . . . . . . . . . . . . . . . . 7
2.1 Requirements for the personnel . . . . . . . . . . . . . . . 7
2.2 Designated use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.3 Occupational safety . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.4 Operational safety . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.5 Product safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 Identification . . . . . . . . . . . . . . . . . . . . . . 9
3.1 Device designation . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.3 Certificates and approvals . . . . . . . . . . . . . . . . . . . . 9
3.4 Registered trademarks . . . . . . . . . . . . . . . . . . . . . 10
4 Installation . . . . . . . . . . . . . . . . . . . . . . . 11
4.1 Incoming acceptance, transport, storage . . . . . . 11
4.2 Installation conditions . . . . . . . . . . . . . . . . . . . . . 11
4.3 Mounting instructions . . . . . . . . . . . . . . . . . . . . . 12
4.4 Post-installation check . . . . . . . . . . . . . . . . . . . . . 13
5 Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.1 Connecting the cable to the field indicator . . . . 14
5.2 Connection to the FOUNDATION Fieldbus™ . . . 15
5.3 FOUNDATION Fieldbus™ cable specification . . 17
5.4 Degree of protection . . . . . . . . . . . . . . . . . . . . . . . 20
5.5 Post-connection check . . . . . . . . . . . . . . . . . . . . . 21
6 Operating the field indicator . . . . . . . . 22
6.1 Quick operation guide . . . . . . . . . . . . . . . . . . . . . 22
6.2 Display and operating elements . . . . . . . . . . . . . 23
6.3 FOUNDATION Fieldbus™ technology . . . . . . . . . 23
6.4 Configuration of the indicator and FF
functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.5 Hardware settings . . . . . . . . . . . . . . . . . . . . . . . . . 27
7 Commissioning . . . . . . . . . . . . . . . . . . . 28
7.1 Function check . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
7.2 Switching on the indicator . . . . . . . . . . . . . . . . . . 28
7.3 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
8 Maintenance . . . . . . . . . . . . . . . . . . . . . 32
9 Accessories . . . . . . . . . . . . . . . . . . . . . . . 32
9.1 Device-specific accessories . . . . . . . . . . . . . . . . . . 32
9.2 Communication-specific accessories . . . . . . . . . 32
10 Trouble-shooting . . . . . . . . . . . . . . . . . .33
10.1 Troubleshooting instructions . . . . . . . . . . . . . . . . 33
10.2 Status messages . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
10.3 Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
10.4 Return . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
10.5 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
10.6 Software history and overview of compatibility . 37
11 Technical data. . . . . . . . . . . . . . . . . . . . .38
12 Operation via FOUNDATION™ Fieldbus .
45
12.1 Block model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
12.2 Resource Block (device block) . . . . . . . . . . . . . . . . 45
12.3 Transducer Blocks . . . . . . . . . . . . . . . . . . . . . . . . . . 52
12.4 PID function block (PID controller) . . . . . . . . . . . . 59
12.5 Input Selector function block . . . . . . . . . . . . . . . . 59
12.6 Arithmetic function block . . . . . . . . . . . . . . . . . . . 59
12.7 Integrator function block . . . . . . . . . . . . . . . . . . . . 59
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . .60

RID14 Document information
Endress+Hauser 5
1 Document information
1.1 Document function
These Operating Instructions contain all the information that is required in various phases
of the life cycle of the device: from product identification, incoming acceptance and storage,
to mounting, connection, operation and commissioning through to troubleshooting,
maintenance and disposal.
1.2 Document conventions
1.2.1 Safety symbols
1.2.2 Electrical symbols
Symbol Meaning
A0011189-EN
DANGER!
This symbol alerts you to a dangerous situation. Failure to avoid this situation
will result in serious or fatal injury.
A0011190-EN
WARNING!
This symbol alerts you to a dangerous situation. Failure to avoid this situation
can result in serious or fatal injury.
A0011191-EN
CAUTION!
This symbol alerts you to a dangerous situation. Failure to avoid this situation
can result in minor or medium injury.
A0011192-EN
NOTE
This symbol contains information on procedures and other facts which do not
result in personal injury.
Symbol Meaning
A0011197
Direct current
A terminal to which DC voltage is applied or through which direct current flows.
A0011198
Alternating current
A terminal to which alternating voltage is applied or through which alternating current flows.
A0017381
Direct current and alternating current
• A terminal to which alternating voltage or DC voltage is applied.
• A terminal through which alternating current or direct current flows.
A0011200
Ground connection
A grounded terminal which, as far as the operator is concerned, is grounded via a grounding
system.
A0011199
Protective ground connection
A terminal which must be connected to ground prior to establishing any other connections.
A0011201
Equipotential connection
A connection that has to be connected to the plant grounding system: This may be a potential
equalization line or a star grounding system depending on national or company codes of practice.
A0012751
ESD - electrostatic discharge
Protect the terminals from electrostatic discharge. Failure to observe this may result in destruction
of parts of the electronics.

Document information RID14
6Endress+Hauser
1.2.3 Symbols for certain types of information
1.2.4 Symbols in graphics
Symbol Meaning
A0011182
Permitted
Indicates procedures, processes or actions that are permitted.
A0011183
Preferred
Indicates procedures, processes or actions that are preferred.
A0011184
Forbidden
Indicates procedures, processes or actions that are forbidden.
A0011193
Tip
Indicates additional information.
A0011194
Reference to documentation
Refers to the corresponding device documentation.
A0011195
Reference to page
Refers to the corresponding page number.
A0011196
Reference to graphic
Refers to the corresponding graphic number and page number.
A0015662
Series of steps
Result of a sequence of actions
A0013562
Help in the event of a problem
Symbol Meaning
1, 2, 3, … Item numbers
A0015662
Series of steps
A, B, C, etc. Views
A-A, B-B, C-C,
etc.
Sections
A0013441
Flow direction
A0011187
Hazardous area
Indicates a hazardous area.
A0011188
Safe area (non-hazardous area)
Indicates the non-hazardous area.
,… ,
,… ,
-
.

RID14 Safety instructions
Endress+Hauser 7
2 Safety instructions
2.1 Requirements for the personnel
The personnel for installation, commissioning, diagnostics and maintenance must fulfill the
following requirements:
‣Trained, qualified specialists must have a relevant qualification for this specific function
and task
‣Are authorized by the plant owner/operator
‣Are familiar with federal/national regulations
‣Before beginning work, the specialist staff must have read and understood the
instructions in the Operating Instructions and supplementary documentation as well as
in the certificates (depending on the application)
‣Following instructions and basic conditions
The operating personnel must fulfill the following requirements:
‣Being instructed and authorized according to the requirements of the task by the facility's
owner-operator
‣Following the instructions in these Operating Instructions
2.2 Designated use
‣The device is a configurable field indicator with fieldbus connection.
‣The device is designed for installation in the field.
‣The manufacturer does not accept liability for damage caused by improper or non-
designated use.
‣Safe operation is only guaranteed if the Operating Instructions are observed and adhered
to.
‣Only operate the device in the permitted temperature range.
2.3 Occupational safety
For work on and with the device:
‣Wear the required personal protective equipment according to federal/national
regulations.
2.4 Operational safety
Risk of injury!
‣Operate the device in proper technical condition and fail-safe condition only.
‣The operator is responsible for interference-free operation of the device.
Conversions to the device
Unauthorized modifications to the device are not permitted and can lead to unforeseeable
dangers.
‣If, despite this, modifications are required, consult with Endress+Hauser.
Repair
To ensure continued operational safety and reliability,
‣Carry out repairs on the device only if they are expressly permitted.
‣Observe federal/national regulations pertaining to repair of an electrical device.
‣Use original spare parts and accessories from Endress+Hauser only.

Safety instructions RID14
8Endress+Hauser
Environmental requirements
If a plastic transmitter housing is permanently exposed to certain steam and air mixtures,
this can damage the housing.
‣If you are unsure, please contact your Endress+Hauser Sales Center for clarification.
‣If used in an approval-related area, observe the information on the nameplate.
Hazardous area
Measuring systems for use in hazardous areas are accompanied by separate "Ex
documentation", which is an integral part of these Operating Instructions. Strict compliance
with the installation instructions and connection data as stated in this supplementary
documentation is mandatory!
2.5 Product safety
This measuring device is designed in accordance with good engineering practice to meet
state-of-the-art safety requirements, has been tested, and left the factory in a condition in
which it is safe to operate.
It meets general safety standards and legal requirements. It also complies with the EC
directives listed in the device-specific EC Declaration of Conformity. Endress+Hauser
confirms this by affixing the CE mark to the device.

RID14 Identification
Endress+Hauser 9
3 Identification
3.1 Device designation
3.1.1 Nameplate
The right device?
Compare the order code on the nameplate of the device to that on the delivery papers.
a0012565
Fig. 1: Nameplate of the field indicator (example)
1 Designation, order code and serial number of the device
2Powersupply
3 Ambient temperature
4 Firmware version and device revision
5 Degree of protection and approvals
6Approvals
3.2 Scope of delivery
The scope of delivery of the field indicator comprises:
• Field indicator
• Brief operating instructions as hardcopy
• ATEX Safety Instructions for deploying a device permitted for use in hazardous areas,
optional
• Accessories (eg. pipe mounting kit), see chapter ’Accessories’
3.3 Certificates and approvals
CE mark, declaration of conformity
The field indicator is designed to meet state-of-the-art safety requirements, has been tested
and left the factory in a condition in which it is safe to operate.
The device meets the relevant standards and directives as per EN 61 010 "Safety
requirements for electrical equipment for measurement, control and laboratory use".
The device described in these Operating Instructions thus meets the legal requirements of
the EU directives. The manufacturer confirms that the device has been tested successfully by
affixing the CE mark.
CSA General Purpose.
Made in Germany 2013
D-87484 Nesselwang
Order code: RID14-XXXX/X
Ser. no.: XXXXXXXXXXX
Ext. ord. cd.: RID14-XXXXX
9 - 32 V
Ta = -40 ...+55/70/80°C
FW: 1.00.00-[1...1] DevRev: X
4
IP66/67 Type 4X
RID14
1
2
3
4
5
6

Identification RID14
10 Endress+Hauser
3.3.1 Certification Foundation Fieldbus™
The field indicator has successfully passed all the tests and is certified and registered by the
Fieldbus Foundation. The device meets all the requirements of the following specifications:
• Certified in accordance with FOUNDATION Fieldbus™ specification
• FOUNDATION Fieldbus™ H1
• Interoperability Test Kit (ITK), revision status 5.1.0 (device certification number available
on request): the device may also be operated using certified devices from other
manufacturers
• Physical Layer Conformance Test of the Fieldbus FOUNDATION™ (FF-830 FS 1.0)
3.4 Registered trademarks
FOUNDATION FieldbusTM
Registered trademark of the Fieldbus Foundation Austin, Texas, USA

RID14 Installation
Endress+Hauser 11
4Installation
4.1 Incoming acceptance, transport, storage
The permitted ambient and storage conditions must be observed. The precise specifications
can be found in Section "Technical data".
4.1.1 Incoming acceptance
On receipt of the goods, check the following points:
• Are the packaging or contents damaged?
• Is anything missing from the delivery? Compare the scope of delivery with the information
you specified in the order. See also section 2.2 "Scope of delivery".
4.1.2 Transportation and storage
Note the following points:
• Pack the device so that is protected against impact for storage and transportation. The
original packaging provides optimum protection.
• The permitted storage temperature range is -40 to +80°C (-40 to +176 °F); it is possible to
store the device in the limit temperature ranges for a limited period (maximum 48 hours).
4.2 Installation conditions
The process indicator is designed to be used in the field.
The orientation is determined by the readability of the display. Cable entries are located on
the bottom of the device.
Operational temperature range:
-40 to +80 °C (-40 to +176 °F)
NOTICE
Shorter display operating life at higher temperatures
‣Where possible do not operate the device in the higher temperature range.
4.2.1 Dimensions
a0011152
Fig. 2: Installation dimensions; dimensions in mm (dimensions in inches in brackets)
The display may react slowly at temperatures below -20 °C (-4 °F).
Readability of the display cannot be guaranteed at temperatures below
-30 °C (-22 °F).
132 (5.2)
135 (5.3)
112 (4.4)
166 (6.5)
106 (4.2) 121 (4.8)
121 (4.8)
6.4
(0.25)

Installation RID14
12 Endress+Hauser
4.2.2 Installation location
Information on conditions that must be present at the installation location to mount the
device correctly can be found in Section 'Technical data'. These include the ambient
temperature, degree of protection, climate class etc.
4.3 Mounting instructions
The device can be mounted directly on the wall. A mounting bracket is available for pipe
mounting (→å4). The illuminated display can be mounted in four different positions
(→å3).
4.3.1 Rotating the display
a0011256
Fig. 3: Field indicator wall mounting, 4 display positions, can be plugged in in stages of 90°
The display can be turned in stages of 90°. First remove the cover clamp (1) and the housing
cover (2). Then remove the display (3) from the electronics unit (4). For configuration
purposes, the ribbon cable between the display and electronics unit has to be plugged in.
Turn the display to the desired position and then attach it to the electronics unit.
4.3.2 Direct wall mounting
Proceed as follows to mount the device directly on the wall:
• Drill 2 holes
• Attach the device to the wall with 2 screws (∅ 5 mm).
4.3.3 Pipe mounting
The mounting bracket is suited for pipes with a diameter between 1.5" - 3.3".
Proceed as follows to mount the device on a pipe:
• Attach the mounting bracket to the pipe
• The additional mounting plate must be used for pipes with a diameter of 1.5" to 2.2".
• Fix the device to the mounting bracket with the two screws supplied. The mounting plate
is not needed for pipes with a diameter of 2.2" - 3.3".
90°
90° 90°
Pos. 2 Pos. 3 Pos. 4
Pos. 1
2
3
1
4

RID14 Installation
Endress+Hauser 13
a0011258
Fig. 4: Mounting the field indicator on a pipe with mounting bracket for pipe diameter 1.5-2.2"
Mounting kit, consisting of:
1: Mounting plate
2: Mounting bracket
3: 2 nuts M6
4.4 Post-installation check
After installing the device, always run the following final checks:
Device condition and specifications Notes
Is the device damaged? Visual check
Is the sealing ring undamaged? Visual check
Is the device fixed securely to the wall or mounting plate? -
Is the front cover fixed tightly? -
Does the device comply with the measurement point specifications, e.g.
ambient temperature etc.?
See Section 'Technical data'

Wiring RID14
14 Endress+Hauser
5 Wiring
WARNING
!
Danger of explosion if unit is connected incorrectly in hazardous area
‣When connecting Ex-approved devices please take special note of the instructions and
connection schematics in the Ex-specific supplement to these Operating Instructions.
The local E+H representative is available for assistance if required.
NOTICE
Electronics can be destroyed if unit is connected incorrectly
‣Switch off power supply before installing or connecting the device. Failure to observe this
may result in destruction of parts of the electronics.
‣The 4-pin post connector is only designed for connecting the associated display.
Connecting other devices can destroy parts of the electronics.
Devices can be connected to the FOUNDATION Fieldbus™ in two ways:
• Connection via conventional cable gland (→ä16)
• Connection via fieldbus connector (optional, can be purchased as an accessory) (→ä16)
5.1 Connecting the cable to the field indicator
For wiring a field indicator, proceed as follows:
a0012568
Fig. 5: Opening the housing of the field indicator
1. Open the cable entry.
2. Remove cover clamp.
3. Remove housing cover.
4. Remove display.
5. Remove screws from electronics unit.
6. Remove electronics unit.
7. Feed cables through cable entry.
8. Connect cable to terminal block according to →å6.
9. Assembly of device in reverse order.
1.
2.
3. 6.
5.
4.
5.

RID14 Wiring
Endress+Hauser 15
5.1.1 Quick wiring guide
Terminal assignment
a0012569
Fig. 6: Terminal assignment
5.2 Connection to the FOUNDATION Fieldbus™
Devices can be connected to the FOUNDATION Fieldbus™ in two ways:
• Connection via conventional cable gland (→ä16)
• Connection via fieldbus connector (optional, can be purchased as an accessory) (→ä16)
NOTICE
Damage to part of the electronics and the fieldbus cable through electrical voltage
‣Switch off power supply before installing or connecting the field indicator.
‣Grounding via one of the grounding screws is recommended.
‣If the shielding of the fieldbus cable is grounded at more than one point in systems
without additional potential matching, power supply frequency equalizing currents can
occur that damage the cable or the shielding. In such cases the shielding of the fieldbus
cable is to be grounded on only one side, i.e. it must not be connected to the ground
terminal of the housing (terminal head, field housing). The shield that is not connected
should be insulated!
ESD - electrostatic discharge
Protect the terminals from electrostatic discharge. Failure to observe this may result
in destruction or malfunction of parts of the electronics.
FOUNDATION FieldbusTM
-
+
Terminal Terminal assignment
+FOUNDATION Fieldbus™ connection (+)
-FOUNDATION Fieldbus™ connection (-)

Wiring RID14
16 Endress+Hauser
5.2.1 Cable glands or entries
a0012571
Fig. 7: Connection to the FOUNDATION Fieldbus™ fieldbus cable - installed in the field housing on the left, and in the terminal
head on the right
A FF terminals - fieldbus communication and power supply
B Inner ground terminal
COutergroundterminal
D Shielded fieldbus cable (FOUNDATION Fieldbus™)
5.2.2 Fieldbus connector
Optionally, a fieldbus connector can be installed in field housing instead of a cable gland.
Fieldbus connectors can be ordered from Endress+Hauser as an accessory (see Section 8
'Accessories').
The connection technology of FOUNDATION Fieldbus™ allows measuring devices to be
connected to the fieldbus via uniform mechanical connections such as T-boxes, junction
boxes, etc.
This connection technology using prefabricated distribution modules and plug-in connectors
offers substantial advantages over conventional wiring:
• Field devices can be removed, replaced or added at any time during normal operation.
Communication is not interrupted.
• Installation and maintenance are significantly easier.
• Existing cable infrastructures can be used and expanded instantly, e.g. when constructing
new star distributors using 4-channel or 8-channel distribution modules.
Please also observe the general procedure on →ä14.
‣The terminals for the fieldbus connection (1+ and 2-) are not polarity sensitive.
‣Conductor cross-section:
– Max. 2.5 mm2for screw terminals

RID14 Wiring
Endress+Hauser 17
a0012573
Fig. 8: Connectors for connecting to the FOUNDATION Fieldbus™
AFieldbusconnector
–1Bluewire:FF–(terminal2)
– 2 Brown wire: FF+ (terminal 1)
– 3 Gray wire: shielding
– 4 Green/yellow wire: ground
B Field indicator
Connector technical data:
• Degree of protection IP 67 (NEMA 4x)
• Ambient temperature range: –40 to +105 °C (–40 to +221 °F)
5.3 FOUNDATION Fieldbus™ cable specification
5.3.1 Cable type
Twin-core cables are required for connecting the device to the FOUNDATION Fieldbus™ H1.
Following IEC 61158-2 (MBP), four different cable types (A, B, C, D) can be used with the
FOUNDATION Fieldbus™, only two of which (cable types A and B) are shielded.
• Cable types A or B are particularly preferable for new installations. Only these types have cable
shielding that guarantees adequate protection from electromagnetic interference and thus the
most reliable data transfer. In the case of cable type B, several field buses (same degree of
protection) may be operated in one cable. No other circuits are permissible in the same cable.
• Practical experience has shown that cable types C and D should not be used due to the lack of
shielding, since the freedom from interference generally does not meet the requirements
described in the standard.
The electrical data of the fieldbus cable have not been specified but determine important
characteristics of the design of the fieldbus, such as distances bridged, number of users,
electromagnetic compatibility, etc.
Type A Type B
Cable structure Twisted pair, shielded One or more twisted pairs, fully
shielded
Wire size 0.8 mm2(AWG 18) 0.32 mm2 (AWG 22)
Loop-resistance (direct current) 44 Ω/km 112 Ω/km

Wiring RID14
18 Endress+Hauser
Suitable fieldbus cables (type A) from various manufacturers for non-hazardous areas are
listed below:
• Siemens: 6XV1 830-5BH10
• Belden: 3076F
• Kerpen: CeL-PE/OSCR/PVC/FRLA FB-02YS(ST)YFL
5.3.2 Maximum overall cable length
The maximum network expansion depends on the type of protection and the cable
specifications. The overall cable length combines the length of the main cable and the length
of all spurs (>1 m/3.28 ft). Note the following points:
• The maximum permissible overall cable length depends on the cable type used.
• If repeaters are used, the maximum permissible cable length is doubled. A maximum of three
repeaters are permitted between user and master.
5.3.3 Maximum spur length
The line between the distribution box and field device is described as a spur.
In the case of non-Ex applications, the max. length of a spur depends on the number of spurs
(>1 m/3.28 ft):
5.3.4 Number of field devices
In accordance with IEC 61158-2 (MBP), a maximum of 32 field devices can be connected per
fieldbus segment. However, this number is restricted under certain conditions (explosion
protection, bus power option, field device current consumption). A maximum of four field
devices can be connected to a spur.
Characteristic impedance at
31.25 kHz
100 Ω± 20% 100 Ω± 30%
Attenuation constant at 39 kHz 3 dB/km 5 dB/km
Capacitive asymmetry 2 nF/km 2 nF/km
Envelope delay distortion (7.9 to
39 kHz)
1.7 ms/km *
Shield coverage 90% *
Max. cable length (incl. spurs >1
m)
1900 m (6233 ft) 1200 m (3937 ft)
* Not specified
Number of spurs 1 to 12 13 to 14 15 to 18 19 to 24 25 to 32
Max. length per spur 120 m
(393 ft)
90 m
(295 ft)
60 m
(196 ft)
30 m
(98 ft)
1 m
(3.28 ft)
Type A Type B

RID14 Wiring
Endress+Hauser 19
5.3.5 Shielding and grounding
Optimum electromagnetic compatibility (EMC) of the fieldbus system can only be
guaranteed if the system components and, in particular, the lines are shielded and the shield
forms as complete a cover as possible.
• To ensure an EMC protective effect, connect the shield as often as possible to the reference
ground.
• For reasons of explosion protection, you should refrain from grounding however.
To comply with both requirements, the FOUNDATION Fieldbus™ basically allows three different
types of shielding:
• Shielding at both ends
• Shielding at one end on the feed side with capacitance connection to the field device
• Shielding at one end on the feed side
Experience shows that the best results with regard to EMC are achieved in most cases in
installations with one-sided shielding. Appropriate measures with regard to input wiring
must be taken to allow unrestricted operation when EMC interference is present. These
measures have been taken into account for this device. Operation in the event of disturbance
variables as per NAMUR NE21 is possible with one-sided shielding.
Where applicable, national installation regulations and guidelines must be observed during
the installation!
Where there are large differences in potential between the individual grounding points, only
one point of the shielding is connected directly with the reference ground. In systems
without potential equalization, therefore, cable shielding of fieldbus systems should only be
grounded on one side, for example at the fieldbus supply unit or at safety barriers, →å9
a0012570
Fig. 9: Shielding and one-sided grounding of the fieldbus cable shielding
1Supply unit
2Distribution box (T-box)
3Bus terminator
4Grounding point for fieldbus cable shielding
5Optional grounding of the field device, isolated from cable shielding.
NOTICE
Damage of the bus cable or shielding through equalizing currents
‣If the shielding of the cable is grounded at more than one point in systems without
potential matching, power supply frequency equalizing currents can occur that damage
the bus cable or shielding or have a serious effect on signal transmission. In such cases
the shielding of the fieldbus cable is to be grounded on only one side, i.e. it must not be
connected to the ground terminal of the housing (terminal head, field housing). The
shield that is not connected should be insulated!

Wiring RID14
20 Endress+Hauser
5.3.6 Bus termination
The start and end of each fieldbus segment are always to be terminated with a bus
terminator. With various junction boxes (non-Ex), the bus termination can be activated via
a switch. If this is not the case, a separate bus terminator must be installed. Note the
following points in addition:
• In the case of a branched bus segment, the device furthest from the Fieldbus power supply
represents the end of the bus.
• If the fieldbus is extended with a repeater, then the extension must also be terminated at both
ends.
5.3.7 Further information
General information and further points on wiring can be found on www.fieldbus.org, the
Web site of the Fieldbus Foundation.
5.4 Degree of protection
The devices fulfill all the requirements for IP 67 degree of protection. Compliance with the
following points is mandatory following installation or servicing in order to ensure that IP
67 protection is maintained:
• The housing seal must be clean and undamaged when inserted into the seal groove. The
seal may have to be cleaned, dried or replaced.
• The cables used for connection must be of the correct specified outside diameter (e.g. M16
x 1.5, cable diameter from 5 to 10 mm).
• Replace any unused cable entries with dummy plugs.
• The grommet used should not be removed from the cable entry.
• The housing cover and the cable entry must be well tightened.
• Install the device upright in such a way that the cable entries point downwards.
