Endress+Hauser Stamolys CA71SI Series User manual

Quality made by
Endress+Hauser
ISO 9001
BA 364C/07/en/07.03
51512332
Valid of:
Software version 5.2
StamoLys CA 71 SI
Silicate Analyzer
Operating Instructions

StamoLys CA 71 SI
Endress+Hauser 3
Table of contents
1 Safety instructions . . . . . . . . . . . . . . 4
1.1 Designated use . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Installation, commissioning and operation . . . 4
1.3 Operational safety . . . . . . . . . . . . . . . . . . . . . . 5
1.4 Return . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.5 Notes on safety icons and symbols . . . . . . . . . 5
2 Identification . . . . . . . . . . . . . . . . . . . 6
2.1 Device designation . . . . . . . . . . . . . . . . . . . . . 6
2.2 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . 7
2.3 Certificates and approvals . . . . . . . . . . . . . . . . 7
3 Installation. . . . . . . . . . . . . . . . . . . . . 8
3.1 Incoming acceptance, transport, storage . . . . 8
3.2 Installation conditions . . . . . . . . . . . . . . . . . . . 8
3.3 Installation instructions . . . . . . . . . . . . . . . . . 11
3.4 Installation examples . . . . . . . . . . . . . . . . . . . 12
3.5 Post-installation check . . . . . . . . . . . . . . . . . . 13
4 Wiring . . . . . . . . . . . . . . . . . . . . . . . . 14
4.1 Electrical connection . . . . . . . . . . . . . . . . . . . 14
4.2 Signal connection . . . . . . . . . . . . . . . . . . . . . 16
4.3 Switching contacts . . . . . . . . . . . . . . . . . . . . . 17
4.4 Serial interface . . . . . . . . . . . . . . . . . . . . . . . . 18
4.5 Post-connection check . . . . . . . . . . . . . . . . . 19
5 Operation . . . . . . . . . . . . . . . . . . . . . 20
5.1 Operation and commissioning . . . . . . . . . . . . 20
5.2 Display and operating elements . . . . . . . . . . 20
5.3 Local operation . . . . . . . . . . . . . . . . . . . . . . . 20
5.4 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
6 Commissioning . . . . . . . . . . . . . . . . 30
6.1 Function check . . . . . . . . . . . . . . . . . . . . . . . 30
6.2 Switch-on . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7 Maintenance . . . . . . . . . . . . . . . . . . 32
7.1 Maintenance schedule . . . . . . . . . . . . . . . . . 32
7.2 Replacing reagents . . . . . . . . . . . . . . . . . . . . 33
7.3 Replacing pump hoses . . . . . . . . . . . . . . . . . 34
7.4 Replacing valve hoses . . . . . . . . . . . . . . . . . . 34
7.5 Replacing the static mixer . . . . . . . . . . . . . . . 35
7.6 Replacing the photometer optical cell . . . . . . 35
7.7 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
7.8 Placing out of service . . . . . . . . . . . . . . . . . . 36
8 Accessories . . . . . . . . . . . . . . . . . . . 37
8.1 Collecting vessel . . . . . . . . . . . . . . . . . . . . . . 37
8.2 Reagents, cleaner, standard solution . . . . . . 37
8.3 Hose cleaner . . . . . . . . . . . . . . . . . . . . . . . . . 37
8.4 Additional accessories . . . . . . . . . . . . . . . . . 37
9 Trouble-shooting . . . . . . . . . . . . . . . 38
9.1 Trouble-shooting instructions . . . . . . . . . . . . . 38
9.2 System error messages . . . . . . . . . . . . . . . . . 38
9.3 Process errors without messages . . . . . . . . . . 39
9.4 Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
9.5 Return . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
9.6 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
10 Technical data . . . . . . . . . . . . . . . . . 42
10.1 Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
10.2 Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
10.3 Power supply . . . . . . . . . . . . . . . . . . . . . . . . . 42
10.4 Performance characteristics . . . . . . . . . . . . . . 43
10.5 Environment . . . . . . . . . . . . . . . . . . . . . . . . . . 43
10.6 Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
10.7 Mechanical construction . . . . . . . . . . . . . . . . . 43
11 Appendix . . . . . . . . . . . . . . . . . . . . . . 44
11.1 Operating matrix . . . . . . . . . . . . . . . . . . . . . . . 44
11.2 Ordering forms . . . . . . . . . . . . . . . . . . . . . . . . 48
11.3 Analyzer settings . . . . . . . . . . . . . . . . . . . . . . 50
11.4 Maintenance schedule . . . . . . . . . . . . . . . . . . 52
Index . . . . . . . . . . . . . . . . . . . . . . . . . 53

Safety instructions StamoLys CA 71 SI
4Endress+Hauser
1Safetyinstructions
1.1 Designated use
With 18% silicon is the second most frequent element of the earth crust. It occurs
chemically bonded as silicate or silicon dioxide in a variety of minerals. From these
minerals silicate or silicic acid is washed out in low quantities to waters.
There are no standard limits for drinking water since silicate is not known to be harmful
to health.
But in boiler feed water and boiler water, there may be only low silicate concentrations.
Under thermal charge or under high pressure insoluble silicon dioxide is formed. It
solidifies in boilers, heat exchangers and turbine blades and thus reduces the heat
exchanger’s efficiency or causes overheating.
The standard limit for boiler feed water is 0.02 ppm silicic acid (SiO2). For injection and
boiler water the standard limits are pressure dependent. For example, at an operational
pressure of 68 bar (986 psi), the concentration of silicic acid in boiler water must not
exceed 10 ppm.
The analyzer is a compact photometric analysis system.
It is designed for the almost continuous monitoring of the silicate content in ultrapure
water and boiler feed water.
In particular, the analyzer is intended for:
•steam and condensate analysis
•reversed osmosis
•demineralisers.
Any other use than the one described here compromises the safety of persons and the
entire measuring system and is, therefore, not permitted.
The manufacturer is not liable for damage caused by improper or non-designated use.
1.2 Installation, commissioning and operation
Please note the following items:
•Installation, electrical connection, commissioning, operation and maintenance of the
measuring system must only be carried out by trained technical personnel.
The technical personnel must be authorised for the specified activities by the system
operator.
•Technical personnel must have read and understood these Operating Instructions
and must adhere to them.
•Before commissioning the entire measuring point, check all the connections for
correctness. Ensure that electrical cables and hose connections are not damaged.
•Do not operate damaged products and secure them against unintentional
commissioning. Mark the damaged product as being defective.
•Measuring point faults may only be rectified by authorised and specially trained
personnel.
•If faults can not be rectified, the products must be taken out of service and secured
against unintentional commissioning.
•Repairs not described in these Operating Instructions may only be carried out at the
manufacturer’s or by the Endress+Hauser service organisation.

StamoLys CA 71 SI Safety instructions
Endress+Hauser 5
1.3 Operational safety
The analyzer has been designed and tested according to the state of the art and left the
factory in perfect functioning order.
Relevant regulations and European standards have been met.
As the user, you are responsible for complying with the following safety conditions:
•Installation instructions
•Local prevailing standards and regulations.
1.4 Return
If the analyzer has to be repaired, please return it cleaned to the Endress+Hauser sales
centre responsible.
Please use the original packaging, if possible.
Please enclose the completed Dangerous Goods sheet (copy the second last page of
these Operating instructions) with the packaging and also the shipping documents.
No repair without completed Dangerous Goods sheet!
1.5 Notes on safety icons and symbols
#
Warning!
This symbol alerts you to hazards. They can cause serious damage to the instrument or
to persons if ignored.
"
Caution!
This symbol alerts you to possible faults which could arise from incorrect operation.
They could cause damage to the instrument if ignored.
!
Note!
This symbol indicates important items of information.

Identification StamoLys CA 71 SI
6Endress+Hauser
2 Identification
2.1 Device designation
2.1.1 Nameplate
Check the order code on the nameplate (at the analyzer) with the product structure (see
below) and your order.
C07-CA71SIx-18-08-00-xx-001.EPS
Fig. 1: Example of a nameplate
2.1.2 Product structure
Measuring range
A Measuring range 1.0 ... 200 µg/l Si
B Measuring range 100 ... 5000 µg/l Si
Y Special version acc. to customers specification
Sample transfer
1 Sample transfer from one measuring point (one-channel version)
2 Sample transfer from two measuring points (two-channel version)
Power supply
0 Power supply 230 V AC / 50 Hz
1 Power supply 115 V AC / 60 Hz
Collecting vessel for up to 3 analyzers
A Without collecting vessel
B With collecting vessel without level measurement
C With collecting vessel with level measurement (one-channel version only)
D With two collecting vessels without level measurement (two-channel version)
Housing version
1 Without housing
2 With GFK housing
3 With stainless steel 1.4301 (AISI 304) housing
Communication
A 0/4 ... 20 mA, RS 232
Additional equipment
1 Quality certificate
2 Quality certificate + set of inactive reagents
3 Quality certificate + three sets of inactive reagents
CA 71 SI - complete order code

StamoLys CA 71 SI Identification
Endress+Hauser 7
2.2 Scope of delivery
The scope of delivery comprises:
•an analyzer with mains plug
•a cleaning injector
•a tin of silicone spray
•a Nopren hose, length 2.5 m (8.2 ft), ID 1.6 mm (0.06")
•a C-flex hose, length 2.5 m (8.2 ft), ID 6.4 mm (0.25")
•a C-flex hose, length 2.5 m (8.2 ft), ID 3.2 mm (0.12")
•two hose fittings of each size:
– 1.6 x 1.6 mm (0.06 x 0.06")
– 1.6 x 3.2 mm (0.06 x 0.12")
– 6.4 x 3.2 mm (0.25 x 0.12")
•two T-hose fittings of each size:
– 1.6 x 1.6 x 1.6 mm (0.06 x 0.06 x 0.06")
– 3.2 x 3.2 x 3.2 mm (0.12 x 0.12 x 0.12")
•an interference suppressor for the current output
•4 edge covers
•a quality certificate
•Operating Instructions (english).
!
Note!
Reagents, please order separately with analyzer version CA 71 XX-XXXXXX1.
With versions CA 71 XX-XXXXXX2 and CA 71 XX-XXXXXX3 inactive reagents are in the
scope of delivery. You have to mix them before using the reagents. Please, read the
mixing instructions attached to the reagents.
2.3 Certificates and approvals
2.3.1 4 approval
Declaration of conformity
The product meets the legal requirements of the harmonised European standards.
Endress+Hauser confirms compliance with the standards by affixing the
4 symbol.
2.3.2 Manufacturer certificate
Quality certificate
With the certificate Endress+Hauser confirms compliance with all technical regulations
and the successful testing individually for your product.

Installation StamoLys CA 71 SI
8Endress+Hauser
3Installation
3.1 Incoming acceptance, transport, storage
•Make sure the packaging is undamaged!
Inform the supplier about damage to the packaging.
Keep the damaged packaging until the matter has been settled.
•Make sure the contents are undamaged!
Inform the supplier about damage to the delivery contents.
Keep the damaged products until the matter has been settled.
•Check that the scope of delivery is complete and agrees with your order and the
shipping documents.
•The packaging material used to store or to transport the product must provide shock
protection and humidity protection. The original packaging offers the best protection.
Also, keep to the approved ambient conditions (see "Technical data").
•If you have any questions, please contact your supplier or your Endress+Hauser
sales centre responsible (see back page of these Operating Instructions).
3.2 Installation conditions
3.2.1 Design, dimensions
C07-CA71xxx-06-08-00-en-001.eps
Fig. 2: CA 71 dimensions, stainless steel version

StamoLys CA 71 SI Installation
Endress+Hauser 9
C07-CA71xxx-06-08-00-en-002.eps
Fig. 3: CA 71 dimensions, GFK version
3.2.2 Connecting the sample line
C07-CA71xxx-11-08-00-xx-001.eps
Fig. 4: Collecting vessel at analyzer (optionally)
1 Ventilation
2 Sample inlet from sampling
3 Collecting vessel
4 Electrical connections
5 Analyzer sample inlet
C07-CA71xxx-06-08-02-en-003.eps
Fig. 5: Collecting vessel dimensions
* variable, freely adjustable dimensions
6 Sampling for analyzer
7 Analyzer outlet
8 Sample overflow
1
2
3
4
5
6
7
8

Installation StamoLys CA 71 SI
10 Endress+Hauser
One-channel version
Two-channel version
•Due to the ordered version are oneor two collecting vessels (with or without level
measurement) in the scope of delivery.
•Level measurement is only for one channel possible.
•Only one collecting vessel can be mounted at housing. The second is to be placed
nearby the analyzer.
Adjusting the level measurement (one-channel version only)
Adjust the conductive level measurement due to the number of connected analyzers.
1. In dependence of the application, mount the right adjusting pin or no adjusting pin
(Fig. 6 and Fig. 7, position 2).
2. Pull the marked pipe (position 3) downwards due to your application (1, 2 or 3
analyzers).
E+H Collecting vessel (at CA 71, with or without level measurement)
Connection hose ID 3.2 mm (0.13")
Customer collecting vessel
Connection hose ID 1.6 mm (0.06")
Max. distance from collecting vessel to analyzer 1 m (3.28 ft)
Max. height difference from collecting vessel to
analyzer
0.5 m (1.64 ft)
C07-CA71xxx-11-08-00-xx-004.eps
Fig. 6: One Analyzer
1 M 3x12 (0.47")
2 M 3x35 (1.38")
3 Mark 1
C07-CA71xxx-11-08-00-xx-003.eps
Fig. 7: Two analyzers
1 M 3x12 (0.47")
2 M 3x20 (0.79")
3 Mark 2
C07-CA71XXx-11-08-02-xx-001.eps
Fig. 8: Three analyzers
1 M 3x12 (0.47")
3Mark3
1
2
3
1
2
3
1
3

StamoLys CA 71 SI Installation
Endress+Hauser 11
3.3 Installation instructions
To install the analyzer at the intended location, proceed as follows:
1. Place the analyzer in position and secure it to a wall using M6 screws, if necessary.
For the installation dimensions, please see previous chapter.
2. Use a spirit level to check that the cabinet is standing or hanging level. This is the
only way to ensure that any air bubbles that occur can escape from the cell.
3. Place the edge covers on the analyzer edges (with GFK housing only).
4. Lay the drain pipe for the reaction products. Where possible, use fixed pipes (PVC
or PE, internal diameter ¾ " with 3% incline).
5. Insert the valve hoses according to Fig. 9. This prevents the hoses becoming stuck
or being pressed against the same position for a long period of time.
C07-CA71xxx-00-08-00-xx-007.eps
Fig. 9: Valves and valve hoses
V1 Valve 1
V2 Valve 2
1 To the pump
2 Y-piece, connecting hose to valve 1, behind it
3 Hose valve 2, front, standard
4 Hose valve 2, back, cleaning agent
5 Hose valve 1, front, sample
6. Secure the hose cassettes in the pump brackets:
Sample pump on the left, reagent pump on the right. Here, the flow direction of
sample and reagent must be anticlockwise.
7. Connect the sample transfer.
!
Note!
The sample can be obtained as follows:
– Directly or after a reversible flow filter or a cross current filter by means of a small
pump (rating approx. 300 ml/min), suitable for clear media, e.g. in the discharge
channel of a sewage treatment plant
– From a sedimentation tank or after microfiltration; this is practical for media
containing flocculants,
e.g. in an activated sludge basin
– Sample conditioning using ultrafiltration for heavily soiled media,
e.g. from the primary settling tank
For questions regarding sample conditioning and its automation, please contact
Endress+Hauser Service or the
Endress+Hauser Sales Centre responsible for your region.
12
3
4
5
V1 V2

Installation StamoLys CA 71 SI
12 Endress+Hauser
8. Connect the tubes from canisters containing reagents, standard and cleaning
agents to the following nozzles:
!
Note!
The pressure of the hose cassette is set at the factory such that the sample and reagent
are fed in without bubbles.
Only change the pressure if the factory setting does not meet your requirements. The
setting is changed by turning the adjustment screw using a 2.5 mm Allen key.
3.4 Installation examples
3.4.1 CAT 430 or customer-specific ultra filtration and two
CA 71 analyzers
Canister Hose designation (mark)
Sample
Reagent 1
Reagent 2
Reagent 3
Standard solution
Cleaner
P
SI1
SI2
SI3
S
R
•Permeate can contain air bubbles
(CAT 430) or is free of bubbles
(customer-supplied ultrafiltration)
•Distance between the analyzers as short
as possible: sampling line between
T-piece and the second analyzer
(Fig. 10, item 2) shorter than 1.5 m
•Cross-section of sampling line
ID 3.2 - 4 mm
•only one sample receiver required
!
Note!
Ensure that there is always sufficient
sample available for both analyzers.
Observe this when selecting maintenance
intervals for CAT 430 and when setting the
buffer volume on the collecting vessel.
C07-CA71xxx-11-08-00-xx-007.eps
Fig. 10: Installation example
1 Sample from CAT 430
2 Sampling line
3 Sample receiver overflow
4 T-piece
5 Collecting vessel
14
5
CA 71 CA 71
23

StamoLys CA 71 SI Installation
Endress+Hauser 13
3.4.2 CAT 411, CAT 430 and two CA 71 analyzers (two-channel
version)
3.5 Post-installation check
•After installation, check that all connections are fitted tightly and are leakage resistant.
•Ensure that the hoses can not be removed without effort.
•Check all hoses for damage.
•Permeate not free of air bubbles
•Distance between the analyzers as short
as possible: sampling line between
T-piece and the second analyzer
(Fig. 11, item 5) shorter than 1.5 m
•Cross-section of sampling line ID
3.2 - 4 mm
•one sample receiver each (without
level measurement) for CAT 411 or
CAT 430
!
Note!
Ensure that there is always sufficient
sample available for both analyzers.
Observe this when selecting maintenance
intervals for CAT 411 and CAT 430.
C07-CA71xxx-11-08-00-xx-006.eps
Fig. 11: Installation example
1 Sample from CAT 430
2 Sample from CAT 411
3 Collecting vessel
4 Collecting vessel overflow
5 Sampling lines
6 T-pieces
1
CA 71
CA 71
2
6
3
4
5

Wiring StamoLys CA 71 SI
14 Endress+Hauser
4Wiring
4.1 Electrical connection
#
Warning!
•The electrical connection must only be carried out by authorised technical personnel.
•Technical personnel must have read and understood the instructions in this manual
and must adhere to them.
•Ensure that there is no voltage at the power cable before beginning the connection
work.
4.1.1 Quick wiring guide
!
Note!
The device does not have a mains switch. Therefore, it is advantageous to have a fused
socket near to the device.
C07-CA71xxxx-04-08-00-a2-001.eps
Fig. 12: Connection sticker CA 71

StamoLys CA 71 SI Wiring
Endress+Hauser 15
4.1.2 Terminal assignment
!
Note!
•Alarm values 1 and 2 do not need to be connected if the PLC sets its own alarm values
at the analog output.
•When using a sample conditioning system:
Connect terminals 57 and 53 on the CA 71 to the corresponding terminals on the
sample conditioning system. For the allocation of these terminals, please see the
sample conditioning system operating instructions.
•If there is a 24 V voltage at terminal 57, the analyzer will not begin measurement
(sample not ready). To start measurement, the voltage must stay at 0 V for at least
5 seconds.
Function Designation Terminal
one channel
Terminal
two channels
Mains
L33
N22
PE 1 1
Alarm value 1, channel 1
COM 25 25
NC 24 24
NO 23 23
Alarm value 2, channel 1
COM 28 28
NC 27 27
NO 26 26
Alarm value 1, channel 2
COM – 13
NC – 12
NO – 11
Alarm value 2, channel 2
COM – 16
NC – 15
NO – 14
Fault
COM 19 19
NC 18 18
NO 17 17
Reserve (unassigned terminals)
COM 22 22
NC 21 21
NO 20 20
Analog output 1
0/4 ... 20 mA
+3636
–3535
Screen PE1PE1
Analog output 2
0/4 ... 20 mA
+–39
––38
Screen – PE1
1) Brass screw with bolt top right in the connection compartment (marked with
*
)
Sample conditioning
remote control
Input 57 57
0 V 53 53
Channel switch-over Input – 55
0 V – 53

Wiring StamoLys CA 71 SI
16 Endress+Hauser
4.2 Signal connection
4.2.1 Screening of the analog outputs
The interference suppressor attenuates electromagnetic effects on control, power and
signal lines.
After the connection of the data transfer cables clip the interference suppressor (in
scope of delivery) on the cable cores (not on the outer insulation of the cable!). Place
the cable screen out of the interference suppressor and connect it to PE (brass screw
with bolt, top right in the connection compartment) (→Fig. 13).
!
Note!
With the two-channel version, place the cable cores of all cables (data cables to analog
output 1 and to analog output 2) through the interference suppressor.
4.2.2 One-channel version
C07-CA71xxx-03-08-00-xx-001.eps
Fig. 13: Interference protection of the signal cable
1 Cable screen (to PE )
2 Signal cable
3 Interference suppressor
4 Cable cores of the signal cable
Connection Designation Function
Signal inputs
Leak Liquid has collected in the drip pan
No sample No sample available, measurement is not started,
display flashes
Signal outputs
AV 1 Alarm value 1 exceeded or undershot
AV 2 Alarm value 2 exceeded or undershot
Fault Retrieves error message using operation menu
Analog output l-1 channel 1 0 or 4 mA = measuring range start
20 mA = measuring range end

StamoLys CA 71 SI Wiring
Endress+Hauser 17
4.2.3 Two-channel version
4.3 Switching contacts
One-channel version
Connection Designation Function
Signal inputs
Leak Liquid has collected in the drip pan
No sample No sample available, measurement is not started,
display flashes
Signal outputs
AV 1 - 1 Alarm value 1, channel 1 exceeded or undershot
AV 1 - 2 Alarm value 2, channel 1 exceeded or undershot
AV 2-1 Alarm value 1, channel 2 exceeded or undershot
AV 2 - 2 Alarm value 2, channel 2 exceeded or undershot
Fault Retrieves error message using operation menu
Channel ½ or
measurement end1
1) Alternative selection
Displays active channel
Displays "Measurement finished" (5 s)
Analog output
l-1 channel 1 0 or 4 mA = measuring range start
20 mA = measuring range end
l-2 channel 2 0 or 4 mA = measuring range start
20 mA = measuring range end
Channel selection Meas. 2 0 V = channel 1
24 V = channel 2
Connection Terminal connection for
condition fulfilled
Terminal connection for
condition not fulfilled
Terminal connection for
power off
AV 1 A:
R:
25
25
-
-
23
24
A:
R:
25
25
-
-
24
23
25 - 24
AV 2 A:
R:
28
28
-
-
26
27
A:
R:
28
28
-
-
27
26
28 - 27
Fault A:
R:
19
19
-
-
17
18
A:
R:
19
19
-
-
18
17
19 - 18
Unassigned 22
16
13
-
-
-
20
14
11
22
16
13
-
-
-
21
15
12
22
16
13
-
-
-
21
15
12

Wiring StamoLys CA 71 SI
18 Endress+Hauser
Two-channel version
!
Note!
Condition fulfilled means:
•AV 1: concentration > Alarm value 1
•AV 2: concentration > Alarm value 2
•Fault: error occurred
Contacts AV 1, AV 2 and fault are only affected during automatic operation.
4.4 Serial interface
Terminal assignment:
The results (measured value+unit of measure+CR) are output in the "Data memory
Measured values" menu.
The calibration results (measured value+unit of measure+CR) are output in the "Data
memory-Calibration factors" menu.
!
Note!
•A null modem cable is required (not a crossed one).
•The analyzer does not have to be configured for the interface.
The following commands can be sent from the PC, in order to read out data:
•"D" = Data memory-Measured values
•"C" = Data memory-Calibration factors
•"S" = Setup (parameter entry, configuration...)
•"F" = Frequency (current)
Connection Terminal connection for
condition fulfilled
Terminal connection for
condition not fulfilled
Terminal connection for
power off
AV 1 - 1 A:
R:
25
25
-
-
23
24
A:
R:
25
25
-
-
24
23
25 - 24
AV 1 - 2 A:
R:
13
13
-
-
11
12
A:
R:
13
13
-
-
12
11
13 - 12
AV 2 - 1 A:
R:
28
28
-
-
26
27
A:
R:
28
28
-
-
27
26
28 - 27
AV 2 - 2 A:
R:
16
16
-
-
14
15
A:
R:
16
16
-
-
15
14
16 - 15
Fault A:
R:
19
19
-
-
17
18
A:
R:
19
19
-
-
18
17
19 - 18
Channel ½
measurement end
A:
R:
22
22
-
-
20
21
A:
R:
22
22
-
-
21
20
22 - 21
A = NO current configured
R = NC current configured
RS 232 of CA 71 COM 1/2 at PC
SUB-D, nine-pin Function Function SUB-D, nine-pin
3TxD RxD2
2RxD TxD3
8CTS RTS7
CTS 8
5GND GND5
Software protocol: 9600, N, 8, 1
Output format: ASCII

StamoLys CA 71 SI Wiring
Endress+Hauser 19
4.5 Post-connection check
Carry out the following checks after electrical connection:
Current output simulation:
1. Hold both arrow keys down (see "Display and operating elements" chapter) and
connect the analyzer to the mains or switch the mains switch on (if available). Wait
until the display "0 mA" appears.
2. Check on your PLC, PCS or you data logger whether the current value is the same.
3. Press the
F
key. Browse to the next current values (4, 12, 20 mA, depending on
the setting).
4. Check that the respective current values are also on your PLC, PCS or your data
logger.
5. If the values are not there, check the terminal assignment for analogue output
1 or 2.
Device status and specifications Note
Is the analyzer or cable externally undamaged? Visual inspection
Electrical connection Note
Does the supply voltage correspond to the data on the nameplate? 230 V AC / 50 Hz 115 V AC / 60 Hz
Are current outputs screened and connected?
Are the mounted cables relieved of tension?
Cable type properly disconnected? Guide power supply and signal lines
separate over the entire travel
distance. Separate cable channels
are ideal.
Cable routing without scuffing or cross-overs?
Are power supply and signal lines connected correctly according
to wiring diagram?
Are all screw terminals tightened?
Are all cable entries mounted, tightened and leak-resistant?
Interference suppressor at the analogue output?
Current output simulation See procedure below

Operation StamoLys CA 71 SI
20 Endress+Hauser
5Operation
5.1 Operation and commissioning
The following chapters provide you with information on the analyzer’s operating
elements and explain how to make settings.
In chapter “Commissioning” you will find the procedure for initial start-up and for daily
analyzer operation.
5.2 Display and operating elements
C07-CA71xxx-19-08-00-xx-005.eps
Fig. 14: CA 71 display and operating elements
1 LED (measured value)
2 LC display (measured value and status)
3 Serial interface RS 232
4 Operating keys and control LEDs
5.3 Local operation
The operating keys and the integrated indicator LEDs have the following functions:
RS 232
ENDRESS+HAUSER
STAMOLYS CA 71
M CE EK
12
43
Key Key function Indicator LED function
H
– “Auto measuring” option
– back to the main menu from all sub-menus
Alarm value 1 exceeded
K
– backwards in the sub-menu
(horizontal, see Appendix,)
Alarm value 2 exceeded
V
– backwards in the main menu (vertical)
– Increase value
Measuring range exceeded
W
– forwards in the main menu (vertical)
– Reduce value
Measuring range undershot
F
– Select option
– Adopt value, forwards in the sub-menu (horizontal)
Retrieve error message
J
– Selection in the sub-menu unassigned
