Endress+Hauser FQG61 Series Manual

Source container with source insert for manual or pneumatic switch-ON/switch-
OFF
Application
The FQG61 and FQG62 source containers are designed to hold the radioactive source
during radiometric point level measurement, continuous level measurement and
density measurement. The radiation is emitted almost unattenuated in one direction
only, and is damped in all other directions. FQG61 and FQG62 differ from each other
in terms of size and screening effect.
Your benefits
• Lightweight device provides best possible screening thanks to almost spherical
design
• Safe and easy source replacement
• Highest safety classification for the source supplied (DIN 25426/ISO 2919, typical
classification C66646)
• Compact device that is easy to mount
• Various angles of emission for optimum adaptation to the application
• Manual or pneumatic switch-ON/switch-OFF
• Padlock, cylinder lock or locking bolt for fixing the switch position
• Switch state easily identified
• Fire-resistant version +821 °C (+1510 °F) / 30 minutes
Products Solutions Services
Technical Information
Source container FQG61,
FQG62
Radiometric level measurement
Technical Information and Operating Instructions
TI00435F/00/EN/19.19
71456915
2019-10-22

Source container FQG61, FQG62
2 Endress+Hauser
Table of contents
Product identification ........................ 3
About this document ........................ 4
Symbols used ................................ 4
Documentation ............................... 4
Safety instructions .......................... 8
Designated use ............................... 8
Basic instructions for use and storage ................ 8
Hazardous areas .............................. 8
General instructions on radiation protection ............ 9
Legal regulations for radiation protection ............. 9
Supplementary safety instructions ................. 10
Function and system design .................. 11
Function .................................. 11
Attenuation factor and half-value layers ............. 11
Maximum activity of the radiation source ............ 11
Dose rate diagrams ........................... 11
Mechanical construction .................... 14
Version ................................... 14
Design, dimensions ........................... 14
Radiation emission channel ...................... 18
Weight ................................... 18
Materials .................................. 19
Safety equipment ............................ 24
Pneumatic drive ............................. 24
Environment .............................. 25
Ambient temperature range ..................... 25
Ambient pressure ............................ 25
Vibration resistance ........................... 25
Fire ...................................... 25
Degree of protection .......................... 25
Identification ............................. 26
Nameplates ................................ 26
RFID TAG .................................. 30
Installation ............................... 32
Incoming acceptance .......................... 32
Transportation .............................. 32
Mounting instructions ......................... 33
Orientation for level measurement ................. 34
Orientation for point level detection ................ 35
Orientation for density measurement ............... 36
Orientation of the fireproof version ................. 36
Mounting device (supplied by customer) ............. 37
Toothed lock washers .......................... 37
Tightening torque for mounting screws .............. 38
Post-installation check ......................... 38
Connecting the pneumatic actuator ............ 39
Compressed air connection ...................... 39
Connecting the proximity switches ................. 39
Commissioning .............................. 40
Reading the switch state ........................ 40
Technical data of the pneumatic actuator ............. 41
Operation ................................ 42
FQG61/FQG62; order code 020, option A ............ 42
FQG61/FQG62; order code 020, option B ............. 43
FQG61/FQG62; order code 020, option C ............. 45
FQG61/FQG62; order code 020, option D ............. 46
Maintenance and inspection ................. 48
Cleaning .................................. 48
Maintenance and inspection ..................... 48
Routine tests of the shutter mechanism .............. 48
Routine leak testing ........................... 49
What to do in an emergency .................. 51
Emergency action ............................ 51
Notifying the competent authority ................. 51
Procedures after termination of the application ... 52
Internal measures ............................ 52
Return .................................... 52
Ordering information ....................... 54
Ordering Information .......................... 54
Scope of delivery ............................. 54
Delivery ................................... 54
Accessories ............................... 55
Clamping device FHG61 ........................ 55
Measurement section FHG62 .................... 56

Source container FQG61, FQG62
Endress+Hauser 3
Product identification
Order code:
Ext. ord. cd.:
Ser. no.:
www.endress.com/deviceviewer Endress+Hauser
Operations App
XXXXXXXXXXXX
XXXXX-XXXXXX
XXX.XXXX.XX
Serial number
1.
3.
2.
A0023555

Source container FQG61, FQG62
4 Endress+Hauser
About this document
Symbols used Safety symbols
DANGER
This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or
fatal injury.
WARNING
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or
fatal injury.
CAUTION
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in minor or
medium injury.
NOTICE
This symbol contains information on procedures and other facts which do not result in personal
injury.
Symbols for certain types of information
Symbol Meaning
Permitted
Procedures, processes or actions that are permitted.
Preferred
Procedures, processes or actions that are preferred.
Forbidden
Procedures, processes or actions that are forbidden.
Tip
Indicates additional information.
Reference to documentation
Reference to page
Reference to graphic
Visual inspection
Symbols in graphics
Symbol Meaning
1, 2, 3 ... Item numbers
,… ,
Series of steps
A, B, C, ... Views
A-A, B-B, C-C, ... Sections
-
Hazardous area
Indicates a hazardous area.
.
Safe area (non-hazardous area)
Indicates the non-hazardous area.
Documentation The following document types are available on the Internet at → www.de.endress.com

Source container FQG61, FQG62
Endress+Hauser 5
Returning source containers
Documentation Comment
SD00309F/00 Returning source containers FQG60, FQG61, FQG62,
FQG63, QG020, QG100
Returning source containers
Documentation Comment
SD00311F/00 Special Documentation Type A packaging
Gamma radiation source FSG60/FSG61
Documentation Comment
TI00439F/00 • Technical Information for gamma radiation source
FSG60/FSG61
• Returning source containers
• Type A packaging
Source container FQG60, FQG61, FQG62, FQG63, FQG66
Documentation Comment
SD00297F/00 Instructions for loading and changing the source. Label
set
Clamping device FHG61
Documentation Comment
SD01221F/00 Clamping device FHG61 For rectangular and diagonally
irradiated pipes with a diameter
50 to 420 mm (1.97 to 16.5 in)
Measurement section FHG62
Documentation Comment
SD00540F/00 Measurement section FHG62 for density measurements
Gamma modulator FHG65 Synchronizer FHG66
Documentation Comment
TI00423F/00 Technical Information for gamma modulator FHG65 and
synchronizer FHG66
BA00373F/00 Operating Instructions for gamma modulator FHG65 and
synchronizer FHG66
Source container FQG66
Documentation Comment
TI01171F/00 Technical Information for source container FQG66
BA01327F/00 Operating Instructions for source container FQG66

Source container FQG61, FQG62
6 Endress+Hauser
Gammapilot M FMG60
Documentation Comment
TI00363F/00 Technical Information for Gammapilot M FMG60
BA00236F/00 Operating Instructions for Gammapilot M FMG60
(HART)
BA00329F/00 Operating Instructions for Gammapilot M FMG60
(PROFIBUS PA)
BA00330F/00 Operating Instructions for Gammapilot M FMG60
(FOUNDATION Fieldbus)
Gammapilot FTG20
Documentation Comment
TI01023F/00 Technical Information for Gammapilot FTG20
BA01035F/00 Operating Instructions for Gammapilot FTG20
RFID TAG
Documentation Comment
SD01502F/00 document, which is supplied
separately
Special Documentation RFID TAG
ZE01020F/00 RFID TAG Certificate/Declaration of Conformity
Supplementary instruction manuals
Supplementary instruction manuals
Documentation Comment
SD00292F/00 Supplementary instruction manual for Canada
SD00293F/00 Supplementary instruction manual for the United States
XA01633F/00 Safety Instructions ATEX II 2 G

Source container FQG61, FQG62
Endress+Hauser 7
Certificate of suitability
A0037353

Source container FQG61, FQG62
8 Endress+Hauser
Safety instructions
Designated use The FQG61 and FQG62 source containers described in this document contain the radioactive source,
which is used for radiometric measurement of level, interface and density. They screen the radiation
from the surrounding environment and allow it to be emitted almost unattenuated in the direction of
measurement only. In order to guarantee the screening effect and rule out damage to the radiation
source, it is essential to comply strictly with all the instructions provided in this Technical
Information document for mounting and operating the unit, as well as all legal regulations
surrounding radiation protection. Endress+Hauser does not accept any responsibility for damage
caused by incorrect use.
Basic instructions for use and
storage
• Observe the applicable regulations and national/international standards.
• Comply with radiation protection regulations when using, storing and working with the
radiometric measuring system.
• Heed warning signs and observe safety zones.
• Install and operate the device according to the instructions in this document and as specified by
the regulatory authority.
• Never operate or store the device outside the specified parameters.
• When operating and storing the device, protect it against extreme influences (i.e. chemical
products, weather, mechanical impacts, vibrations etc.).
• Always secure the OFF position of the source insert using the padlock
• Before switching on the radiation, make sure that no-one is in the radiation zone (or inside the
product vessel). The radiation may only be switched ON by properly instructed staff.
• Do not operate damaged or corroded devices. Notify the competent radiation safety officer as soon
as damage or corrosion occurs, and follow his/her instructions.
• Conduct the required leak testing procedure according to the applicable regulations and
instructions
LWARNING
Vibrations and mechanical impacts
‣If the device is exposed to strong vibrations or mechanical impacts, the safety pin can become
abraded. This may cause the source insert to fall out of the container.
‣Therefore, the source holder must be checked at regular intervals to ensure that it is secure and
stable
LCAUTION
Condition of the system
‣If there are any doubts about the proper condition of the system, check the area around the
device for leakage radiation and notify the competent radiation safety officer.
Hazardous areas General instructions
LCAUTION
Suitability
‣The suitability of the radiometric measurement method and of the device for applications in
hazardous areas must be checked by the plant operator according to the national rules and
regulations that apply.
The following must be observed:
• Avoid electrostatic charge at the device. Do not rub dry.
• The device must be integrated in the potential equalization system of the plant. In order to ensure
electrical contact between the radiation source container and the mounting support, the supplied
toothed lock washers must be used.→  37
If an RFID tag is used, comply with the instructions in the
SD01502F/00 document, which is supplied separately

Source container FQG61, FQG62
Endress+Hauser 9
Additional instructions for pneumatically operated radiation source containers
LCAUTION
Hazardous areas
‣For applications in hazardous areas categorized as ATEX II 2 G, the associated Safety Instructions
(XA) must be observed.
‣The pneumatic drive may not be operated in locations where the ambient conditions may lead to
corrosion in or at the pneumatic drive.
General instructions on
radiation protection
When working with radioactive sources, avoid any unnecessary exposure to radiation. All
unavoidable radiation exposure must be kept to a minimum. Three basic concepts apply to achieve
this:
ABC
A0016373
A Screening
B Time
C Distance
Screening
Ensure the best possible screening between the radiation source and yourself and all other persons.
Source containers (e.g. FQG60, FQG61/FQG62, FQG63, FQG66) and all high-density materials (lead,
iron, concrete etc.) can be used for effective screening purposes.
Time
The time spent in the exposed area should be kept to a minimum.
Distance
Keep as far away from the radiation source as possible. The local radiation dose rate decreases in
proportion to the square of the distance from the radiation source.
Legal regulations for
radiation protection
The handling of radioactive emitters is legally controlled. The radiation protection regulations of the
country in which the plant is operated are of overriding importance and must be strictly observed. In
the Federal Republic of Germany, the current version of the Radiation Protection Ordinance applies.
The following points derived from this Ordinance are particularly important for radiometric
measurement:
Handling permit
A handling permit is required for operating a plant which uses gamma radiation. Permit applications
are made to the local state government or the authority responsible (State Offices for Environmental
Protection, Trade Inspection Offices, etc.). The Endress+Hauser sales organization will be happy to
help you obtain the handling permit.
Radiation safety officer
The plant operator must appoint a radiation safety officer (RSO) who has the necessary specialist
knowledge and who is responsible for observing the Radiation Protection Ordinance and all radiation
protection procedures. Endress+Hauser offers training courses in which individuals can acquire the
necessary specialist knowledge.

Source container FQG61, FQG62
10 Endress+Hauser
Control zone
Only persons who are exposed to radiation during the course of their job and are subject to official
personal dose monitoring procedures may work in control zones (i.e. areas where the local dose rate
exceeds a specific value). The limit values for the control zone are specified in the current Radiation
Protection Ordinance applicable for your area. The Endress+Hauser sales organization will be
pleased to provide further information on radiation protection and regulations in other countries.
Supplementary safety
instructions
Observe the associated safety instructions contained in the following documents:
SD00292F/00 (for Canada)
SD00293F/00 (for the United States)
This document, together with the nameplates, constitutes the documentation for highly
radioactive radiation sources as stipulated in Section 94 (3) of the Radiation Protection
Ordinance in Germany.
LCAUTION
This device contains more than 0.1% lead with CAS No. 7439-92-1.
‣The lead is not accessible in vessels that are free from damage. If the vessel is damaged, national
regulations surrounding the handling of lead must be observed.

Source container FQG61, FQG62
Endress+Hauser 11
Function and system design
Function Function of the radiation source container
In the FQG61/FQG62 source container, the radioactive source is surrounded by a steel casing filled
with lead which screens off gamma radiation. The radiation can be emitted, almost unattenuated, in
one direction only through a channel (focused narrow beam path). This radiation is used for
radiometric measurement.
Switching the radiation ON and OFF
• By turning the insert 180°, the radiation source is positioned in the radiation emission channel
(radiation is switched on) and removed from the channel (radiation is switched off).
• The current switch position (ON or OFF) is clearly visible from the outside.
• The OFF position can be secured by a cylinder lock or padlock (depending on the version; see
product structure: order code 020, "Version").
• The ON position can be secured by a cylinder lock, a padlock or a locking bolt (depending on the
version; see product structure: order code 020, "Version").
Remote control/remote indication of the switch state
Device versions with a pneumatic drive are available, which enable the radiation to be switched on
and off remotely (product structure: order code 020, "Version K, L, M, N"). These versions have
proximity switches for remote indication of the switch state (ON or OFF).
Fire-resistant version
A fire-resistant version of the radiation source containers is available (product structure: order code
670 "Additional function"). This version has a compensation compartment, which is welded onto the
housing. In the event of a fire, the liquefied lead is collected in the compensation compartment, thus
ensuring the enhanced fire-resistance of the source container.
Attenuation factor and half-
value layers FQG61
60Co
FQG61
137CS
FQG62
60Co
FQG62
137CS
Attenuation factor FS37 294 181 3100
Number of half-value layers 5.2 8.2 7.5 11.6
The table contains typical values, which do not take into account production-related variations
in the source activity and tolerances of the measuring devices.
Maximum activity of the
radiation source Source container 60Co 137CS
FQG61 max. 0.74 GBq (20 mCi) max. 18.5 GBq (500 mCi)
FQG62 max. 3.7 GBq (100 mCi) max. 111.0 GBq (3000 mCi)
LCAUTION
Maximum admissible activity
‣The maximum admissible activity can be further restricted by country-specific approvals.
Dose rate diagrams A dose rate diagram specifies the local dose rate at a specified distance from the surface of the
radiation source container. Examples of dose rate diagrams for FQG61 and FQG62 are presented
below. They apply for a distance of 1 m (3.3 ft)and for selected activities of a 60Co or 137Cs radiation
source. All the dose rate diagrams indicated refer to the OFF switch position and to order code 020
"Version", option A "Cylinder lock fixation ON/OFF + cover". The maximum values apply outside the
path of the beam. Dose rate diagrams for other distances and activities are available on request. The

Source container FQG61, FQG62
12 Endress+Hauser
dose rate diagram for the real loading and version can be ordered with order code 580 "Test,
Certificate".
For the allocation of the device version, see the Product Configurator on the Endress+Hauser
website: www.endress.com → Select your country → Products → Select measuring technology,
software or components → Select the product (picklists: measurement method, product family
etc.) → Device support (right-hand column): Configure the selected product → The Product
Configurator for the selected product opens
Dose rate diagrams for 60Co
90° 90°
30° 30°
60° 60°
120° 120°
300° 300°
330° 330°
0° 0°
270° 270°
210° 210°
240° 240°
180° 180°
150° 150°
A B
60% 100% 60% 100%
A0018270
A FQG61
B FQG62
Option in order code 100
"Prepared for source
activity"
FQG61
Activity in MBq
FQG62
Activity in MBq
FQG61
Max. value (100%)
in μSv/h
FQG62
Max. value (100%)
in μSv/h
AA 3.7 3.7 0.04 0.01
AB 7.4 7.4 0.08 0.02
AC 18.5 18.5 0.21 0.05
AD 37 37 0.42 0.10
AE 74 74 0.85 0.20
AF 111 111 1.27 0.30
AG 185 185 2.12 0.50
AH 370 370 4.24 1.01
AK 740 740 8.49 2.02
AL - 1110 - 3.03
AM - 1850 - 5.04
AN - 3700 - 10.09

Source container FQG61, FQG62
Endress+Hauser 13
Dose rate diagrams for 137Cs
A B
90° 90°
30° 30°
60° 60°
120° 120°
300° 300°
330° 330°
0° 0°
270° 270°
210° 210°
240° 240°
180° 180°
150° 150°
60% 100% 10% 15%5%
A0018384
A FQG61
B FQG62
Option in order code
100 "Prepared for
source activity"
FQG61
Activity in MBq
FQG62
Activity in MBq
FQG61
Max. value (100%) in
μSv/h
FQG62
Max. value (100%) in
μSv/h
AA 3.7 3.7 < 0.01 < 0.01
AB 7.4 7.4 < 0.01 < 0.01
AC 18.5 18.5 0.01 < 0.01
AD 37 37 0.01 0.01
AE 74 74 0.02 0.01
AF 111 111 0.04 0.02
AG 185 185 0.06 0.03
AH 370 370 0.12 0.06
AK 740 740 0.24 0.12
AL 1110 1110 0.36 0.18
AM 1850 1850 0.60 0.30
AN 3700 3700 1.20 0.60
AP 7400 7400 2.39 1.19
AR 11100 11100 3.59 1.79
AT 18500 18500 5.98 2.98
AW - 29600 - 4.77
BB - 37000 - 5.96
BC - 55500 - 8.94
BD - 74000 - 11.91
BF - 111000 - 17.87

Source container FQG61, FQG62
14 Endress+Hauser
Mechanical construction
Version Order code 020 in the product structure Properties
A • Source insert for manual switch-ON/switch-OFF
• Cylinder lock to secure the ON/OFF switch position
• Cover
B • Swivel bracket for manual switch-ON/switch-OFF
• Locking bolt to secure the ON switch position
• Padlock to secure the OFF switch position
C • Swivel bracket for manual switch-ON/switch-OFF
• Padlock to secure the ON/OFF switch position
D • Higher protection against dust and humidity
• Swivel bracket for manual switch-ON/switch-OFF
• Padlock to secure the ON/OFF switch position
K
L
• Pneumatic switch-ON/switch-OFF
• Padlock to secure the OFF switch position
M
N
• Higher protection against dust and humidity
• Pneumatic switch-ON/switch-OFF
• Padlock to secure the OFF switch position
Design, dimensions FQG61/FQG62; order code 020, option A→  54
C
20 (0.79)
D
ø220 (8.66)
B
A
E
A0018385
 1 Dimensions: mm (in)
Dimensions Version mm (in) Comment
A FQG61 251 (9.88)
FQG62 272 (10.7)
B FQG61 The mounting flange of FQG61 and FQG62 is compatible with:
DN 100 PN16 (ø 180 mm (7.09 in)) and ANSI 4" 150 lbs (ø 190 mm (7.48 in))
FQG62
C FQG61 279 (11)
FQG62 360 (14.2)
D FQG61 75 (2.95) Clearance for cover removal
FQG62

Source container FQG61, FQG62
Endress+Hauser 15
Dimensions Version mm (in) Comment
E FQG61 479 (18.9) Clearance required to replace the radiation source
FQG62 560 (22)
FQG61/FQG62; order code 020, option B→  54
B
C
20 (0.79)
ø220 (8.66)
A
A0018386
 2 Dimensions: mm (in)
Dimensions Version mm (in) Comment
A FQG61 251 (9.88)
FQG62 272 (10.7)
B FQG61 287 (11.3)
FQG62 368 (14.5)
C FQG61 450 (17.7) Clearance required to replace the radiation source
FQG62 580 (22.8)
FQG61/FQG62; order code 020, option C→  54
B
C
20 (0.79)
ø220 (8.66)
A
A0018387
 3 Dimensions: mm (in)

Source container FQG61, FQG62
16 Endress+Hauser
Dimensions Version mm (in) Comment
A FQG61 251 (9.88)
FQG62 272 (10.7)
B FQG61 287 (11.3)
FQG62 368 (14.5)
C FQG61 450 (17.7) Clearance required to replace the radiation source
FQG62 570 (22.4)
FQG61/FQG62; order code 020, option D→  54
B
C
20 (0.79)
ø220 (8.66)
A
1
A0018388
 4 Dimensions: mm (in)
1 Reference O-ring
Dimensions Version mm (in) Comment
A FQG61 251 (9.88)
FQG62 272 (10.7)
B FQG61 297 (11.7)
FQG62 378 (14.9)
C FQG61 497 (19.6) Clearance required to replace the radiation source
FQG62 578 (22.8)

Source container FQG61, FQG62
Endress+Hauser 17
FQG61/FQG62; order code 020, option K, L, M or N→  54
B
C
20 (0.79)
ø220 (8.66)
A
1
A0018389
 5 Dimensions: mm (in)
1 Reference O-ring
Dimensions Version mm (in) Comment
A FQG61 251 (9.88)
FQG62 272 (10.7)
B FQG61 427(16.8)
FQG62 508 (20.0)
C FQG61 483 (19.0) Clearance required to replace the radiation source
FQG62 602 (23.7)
"Fire-resistant" additional feature (FQG61/FQG62; order code 670, option WE)→  54
A
A0018390
 6 Dimension A
Dimensions Version mm (in) Comment
A FQG61 305 (12)
FQG62 362 (14.3)

Source container FQG61, FQG62
18 Endress+Hauser
Radiation emission channel
9.5 (0.37)
45°
22.5°
5°
20° 40°
A/B
A0018391
 7 Dimensions: mm (in)
A FQG61: 123 mm (4.84 in)
B FQG62: 166 mm (6.54 in)
Position The emission channel is located at a distance of 9.5mm (0.37 in) from the center of
the mounting flange. It has the same direction as the lifting eye of the radiation
source container. The radiation emission channel is indicated by a mark on the
covering plate of the mounting flange.
Angle of emission According to feature 240 of the product structure:
• 5°
• 20°
• 40°
Width of emission • FQG61: 10 mm (0.39 in)
• FQG62: 12 mm (0.47 in)
Attenuation of the
useful beam
Approx. 0.3 half-value layers (FS = 1.2)
Weight Source container With manual switch-ON/switch-OFF With pneumatic switch-ON/switch-OFF
FQG61 Approx. 42 kg (92.59 lb) Approx. 46 kg (101.41 lb)
FQG62 Approx. 86 kg (189.60 lb) Approx. 90 kg (198.42 lb)

Source container FQG61, FQG62
Endress+Hauser 19
Materials FQG61/FQG62; order code 020, option A→  54
2
7
4
56
3
1
8
9
10
A0018393
 8 List of materials
Item Component part Material
1 Housing 316Ti (1.4571); S235JR (1.0038)
Flange 316L (1.4404)
2 Housing ring 316L (1.4404); 304 (1.4301)
3 Nameplate 316L (1.4404)
4 Cover 304 (1.4301)
O-ring FKM
5 Screw/groove pin A2
6 Warning sign Acrylate foil
7 Nameplate for radiation source 304 (1.4301)
8 Tag 304 (1.4301)
Cable 316 (1.4401)
9 Tag 304 (1.4301)
Cable 316 (1.4401)
10 Ring eyelet C15; A4
Item Component part Varnish
1 Housing, flange PUR 2K texture paint RAL1003
4 Cover

Source container FQG61, FQG62
20 Endress+Hauser
FQG61/FQG62; order code 020, option B→  54
9
10
8
11
12
14
15
13
1
16
2
3
4
5
6
7
A0018394
Item Component part Material
1 Housing 316Ti (1.4571); S235JR (1.0038)
Flange 316L (1.4404)
2 Indication plate 316L (1.4404)
3 Rotating pin 316L (1.4404)
4 "AUS/OFF" sign 304 (1.4301)
5 "Source" nameplate 304 (1.4301)
6 Rotary element 316L (1.4404)
7 Screw A4
8 Screw A4
Nut A4
9 Bracket A4
10 Padlock: body Brass
Padlock: shackle Hardened steel
11 "EIN/ON" sign 304 (1.4301)
12 "CAUTION!" warning sign Acrylate foil
13 Additional national sign 304 (1.4301)
"Container" nameplate 304 (1.4301)
14 "Caution radiation" sign 304 (1.4301)
15 Ring eyelet C15; A4
16 Tag 304 (1.4301)
Cable 316 (1.4401)
Item Component part Varnish
1 Housing, flange PUR 2K texture paint RAL1003
