Important information June 2018
1 Important information
1.1 General provisions
The Enelion charger (further called the device, the charger or the charging terminal) is a charging station dedi-
cated for charging electric cars as defined in the Act of 11 January 2018 on Electromobility and Alternative Fuels,
in Art. 2, subsections 5, 12, 13 and 27 of the above mentioned Act.
Before installing and using the device read this instruction.
Installing and servicing the device must be done by qualified individuals with proper certification, and repair works
may only be carried by the manufacturer or by entities authorized by the manufacturer.
Tampering with the mechanical, electrical and electronic elements as well as the software of the device is forbid-
den under the pain of forfeiting the guarantee. The actions defined in this instruction and the actions which were
agreed upon with the manufacturer in writing are an exception.
The manufacturer shall not be liable for property damage resulting from the above mentioned incidents of tam-
pering with the product.
The electric wiring system which will be used by the device when in operation must meet the requirements de-
scribed in the fitting manual. The manufacturer is not responsible for the improper installation and/or inadequate
security of the wiring system used by the device.
The manufacturer is not responsible for the improper operation of the wiring system used by the device.
The electric wiring system which will be used by the device when in operation must be in compliance with the
legal norms binding for the place where the wiring system is installed and the device is used. The manufacturer
is not responsible for any damage caused by the wiring system which does not meet the legal norms.
The device is not equipped with an inbuilt switch. It starts operating once power supply is accessed. Isolation from
power supply must be done through proper instruments described in the fitting manual. Except for emergency
situations the device may not be switched off while charging.
It is forbidden to provide power supply when the device casing remains open.
It is forbidden to use a charger which has mechanical damages or which signals critical error.
It is forbidden to place in the charger socket any objects which are not intended for this purpose. The only object
intended to be placed in the charger socket is a working wire which has the right section for the capacity of the
device and the type of vehicle, with a working type 2 plug according to EC 62196-2.
The manufacturer is not responsible for health or life loss resulting from not following the above mentioned rec-
ommendations.
The nameplate on the device is its integral part and cannot be removed or damaged under the pain of forfeiting
the manufacturer’s guarantee.
1.2 Protection guidelines
• The outdoor installation should not be carried in the rain, snow or strong wind, if there is any risk that water
or dirt could get inside the device.
• All actions described in this instruction should be carried after you make sure there is no voltage on the
charging cable.
1.3 Criteria for choosing the location
• Enelion Wallbox may be installed both outdoors and indoors. The suggested height at which the socket
should be is 140 cm – 160 cm. You should remember that the national regulations may define a specific
height at which the device may be installed.
Wallbox — Installation guide Page 4 of 22
