Eneo MNR-18N04000A User manual

EN
User Manual
Hybrid HD Video Recorder,
HD-TVI, AHD, HDMI,
SATA, w/o HDD
MNR-18N04000A
MNR-18N16000A
Learn more about eneo IN series
on our YouTube channel. 

DVR USER MANUAL
1
CONTENT
SAFETY INSTRUCTION .......................................................................................................................................................... 6
CHAPTER 1: PRODUCT OVERVIEW ....................................................................................................................................... 7
1.1 REAR PANEL ................................................................................................................................................................... 7
1.2 REMOTE CONTROL (FOR REFERENCE ONLY,SUBJECT TO MATERIAL OBJECTS)..................................................................................... 8
CHAPTER 2 DVR INSTALLATION & CONNECTION .................................................................................................................. 8
2.1 HDD INSTALLATION ......................................................................................................................................................... 8
2.2 CONNECTION DIAGRAM .................................................................................................................................................... 9
2.3 POWER SUPPLY CONNECTION ........................................................................................................................................... 10
CHAPTER 3 DVR COMMON OPERATIONS ........................................................................................................................... 10
3.1 USING THE SUPPLIED MOUSE ........................................................................................................................................... 10
3.2 USING THE VIRTUAL KEYBOARD ........................................................................................................................................ 10
3.3 PASSWORD .................................................................................................................................................................. 11
CHAPTER 4 DVR STARTING UP ........................................................................................................................................... 13
4.1 STAR T WIZARD ............................................................................................................................................................. 13
4.1.1 Start Wizard.................................................................................................................................................... 13
4.1.2 Network configuration..................................................................................................................................... 13
4.1.3 Date/Time........................................................................................................................................................ 14
4.1.4 IP Camera...................................................................................................................................................... 15
4.1.5 Disk................................................................................................................................................................. 16
4.1.6 Resolution....................................................................................................................................................... 16
4.1.7 Mobile............................................................................................................................................................. 16
4.1.8 Summary........................................................................................................................................................ 16
4.2 INTRODUCTION OF THE REAL-TIME VIEW INTERFACE................................................................................................................ 17
4.2.1 Camcorder Quick Toolbar ............................................................................................................................. 18
4.2.2 Taskbar........................................................................................................................................................... 18
4.2.3 The Start Menu.............................................................................................................................................. 19
4.2.3.1 Unlock and Lock the screen............................................................................................................................................19
4.2.3.2 Equipment shutdown.....................................................................................................................................................19
CHAPTER 5: DVR SYSTEM SETTINGS...................................................................................................................... 20
5.1 CHANNEL .................................................................................................................................................................... 20
5.1.1 Channel.......................................................................................................................................................... 21
5.1.1.1 Channel setup ...............................................................................................................................................................21
5.1.1.2 IP Channels....................................................................................................................................................................21
5.1.2 Live ................................................................................................................................................................. 23
5.1.3 Image control ................................................................................................................................................. 24
5.1.4 PTZ................................................................................................................................................................. 25
5.1.4.1 PTZ control ....................................................................................................................................................................26
5.1.5 The Privacy Area............................................................................................................................................ 29
5.1.6 Motion............................................................................................................................................................. 30
5.1.7 PIR.................................................................................................................................................................. 31
5.1.8 White Light ..................................................................................................................................................... 31
5.1.9 Intelligent (Intelligent Analytics) .................................................................................................................... 33

DVR USER MANUAL
2
5.1.9.1 PID (Perimeter intrusion detection)................................................................................................................................33
5.1.9.2 LCD (Line Crossing Detection).........................................................................................................................................35
5.1.9.3 SOD (Stationary Object Detection) .................................................................................................................................36
5.1.9.4 PD&VD（pedestrian and vehicle type detection）.........................................................................................................38
5.1.9.5 FD (face detection) ........................................................................................................................................................39
5.1.9.6 CC (Cross-Counting) .......................................................................................................................................................40
5.1.9.7 Sound Detection............................................................................................................................................................42
5.1.9.8 Video Tampering（Video Tampering）..........................................................................................................................43
5.1.9.9 Schedule（Smart Schedule）........................................................................................................................................43
5.1.9.10 Cross Counting Statistics（crossing statistics）............................................................................................................44
5.2 RECORDING ................................................................................................................................................................. 45
5.2.1 Encoding......................................................................................................................................................... 45
5.2.1.1 Mainstream...................................................................................................................................................................45
5.2.1.2 Substream.....................................................................................................................................................................46
5.2.1.3 Mobilestream................................................................................................................................................................47
5.2.1.4 Audio ............................................................................................................................................................................48
5.2.2 Video recording.............................................................................................................................................. 48
5.2.2.1 Video recording Settings ................................................................................................................................................48
5.2.2.2 Video recording schedule...............................................................................................................................................49
5.2.3 Capture........................................................................................................................................................... 49
5.2.3.1 Capture settings 1..........................................................................................................................................................49
5.2.3.2 Capture Schedule table 2 ...............................................................................................................................................50
5.3 ALARM ....................................................................................................................................................................... 51
5.3.1 Mobile detection and alarm........................................................................................................................... 51
5.3.2 PIR alarm........................................................................................................................................................ 52
5.3.3 I/O Alarm......................................................................................................................................................... 53
5.3.4 Intelligent analysis and alarm........................................................................................................................ 55
5.3.4.1 PID（Perimeter intrusion Detection）...........................................................................................................................55
5.3.4.2 LCD（Line Cross detection and alarm）.........................................................................................................................56
5.3.4.3 SOD ((Stationary Object Detection)) ...............................................................................................................................57
5.3.4.4 PD&VD (Pedestrian Detection & Vehicle Detection)........................................................................................................58
5.3.4.5 FD（face detection）....................................................................................................................................................59
5.3.4.6 CC (Cross-Counting) .......................................................................................................................................................60
5.3.4.7 Sound Detection............................................................................................................................................................61
5.3.4.8 Video Tampering ...........................................................................................................................................................62
5.3.5 Combined alarm............................................................................................................................................. 63
5.3.6 PTZ linkage.................................................................................................................................................... 65
5.3.7 Exception........................................................................................................................................................ 65
5.3.8 Alarm Schedule.............................................................................................................................................. 66
5.3.9 Voice broadcast ............................................................................................................................................. 66
5.3.9.1 Document management ................................................................................................................................................66
5.3.9.2 loop management .........................................................................................................................................................68
5.4 AI ............................................................................................................................................................................. 68
5.4.1 Setup............................................................................................................................................................... 68
5.4.1.1 Face detection...............................................................................................................................................................68
5.4.1.2 Pedestrian and vehicle detection ...................................................................................................................................69
5.4.1.3 Perimeter invasion detection .........................................................................................................................................70
5.4.1.4 Line Crossing detection..................................................................................................................................................72

DVR USER MANUAL
3
5.4.1.5 Cross Counting statistics ................................................................................................................................................73
5.4.1.6 Heat map ......................................................................................................................................................................75
5.4.1.7 Crowd Detection............................................................................................................................................................76
5.4.1.8 Queueing length detection.............................................................................................................................................77
5.4.1.9 License plate detection ..................................................................................................................................................78
5.4.1.10 RSD .............................................................................................................................................................................79
5.4.1.11 Schedule .....................................................................................................................................................................79
5.4.2 Recognition .................................................................................................................................................... 80
5.4.2.1 Model configuration ......................................................................................................................................................80
5.4.2.2 Face Database Management ..........................................................................................................................................80
5.4.2.3 License plate database management..............................................................................................................................82
5.4.3 Alarm settings................................................................................................................................................. 85
5.4.3.1 Face recognition alarm...................................................................................................................................................85
5.4.3.2 Face attribute alarm ......................................................................................................................................................87
5.4.3.3 License plate recognition ...............................................................................................................................................87
5.4.3.4 Pedestrian and vehicle detection ...................................................................................................................................89
5.4.3.5 Pedestrian intrusion.......................................................................................................................................................90
5.4.3.6 Line Cross Detection ......................................................................................................................................................92
5.4.3.7 CC .................................................................................................................................................................................93
5.4.3.8 CD.................................................................................................................................................................................94
5.4.3.9 QD Alarm ......................................................................................................................................................................95
5.4.3.10 LPD .............................................................................................................................................................................96
5.4.3.11 RSD .............................................................................................................................................................................97
5.4.4 Statistics......................................................................................................................................................... 98
5.4.4.1 Face recognition statistics ...........................................................................................................................................98
5.4.4.2 Pedestrian and vehicle detection statistics......................................................................................................................98
5.4.4.3 CC .................................................................................................................................................................................99
5.4.4.4 Heat map .................................................................................................................................................................... 100
5.5 NETWORK ............................................................................................................................................................... 101
5.5.1 General......................................................................................................................................................... 101
5.5.1.1 General configuration.................................................................................................................................................. 101
5.5.1.2 PPPo E......................................................................................................................................................................... 101
5.5.1.3 SNMP.......................................................................................................................................................................... 102
5.5.1.4 Wireless configuration.................................................................................................................................................102
5.5.1.5 Port Configuration .......................................................................................................................................................103
5.5.2 DDNS （ Dynamic Domain name server ） ................................................................................................. 104
5.5.3 Email............................................................................................................................................................. 104
5.5.3.1 Email Configuration .....................................................................................................................................................105
5.5.3.2 Email Schedule ............................................................................................................................................................ 105
5.5.4 FTP............................................................................................................................................................... 106
5.5.5 IP Filter.......................................................................................................................................................... 107
5.5.6 Voice Assistant............................................................................................................................................. 107
5.5.6.1 Amazon.......................................................................................................................................................................107
5.5.6.2 Google ........................................................................................................................................................................112
5.5.7 Platform Access........................................................................................................................................... 118
5.5.7.1 Onvif ........................................................................................................................................................................... 118
5. 6DEVICE .................................................................................................................................................................... 118

DVR USER MANUAL
4
5.6.1 Disk............................................................................................................................................................... 118
5.6.1.1 Disk Group .................................................................................................................................................................. 119
5.6.1.2 S.M.A.R.T..................................................................................................................................................................120
5.6.2 Cloud............................................................................................................................................................. 120
5.7 SYSTEM .................................................................................................................................................................... 121
5.7.1 General...................................................................................................................................................... 121
5.7.1.1 General Configuration..................................................................................................................................................121
5.7.1.2 Date and Time .............................................................................................................................................................122
5.7.1.3 Output Configuration...................................................................................................................................................123
5.7.2 Multi-user...................................................................................................................................................... 125
5.7.2.1 Changing Password and Add New Users .......................................................................................................................126
5.7.2.2 Add New Users............................................................................................................................................................ 126
5.7.2.3 Setting User Permissions..............................................................................................................................................127
5.7.3 Maintenance................................................................................................................................................. 128
5.7.3.1 Log........................................................................................................................................................................... 128
5.7.3.2 Load Default................................................................................................................................................................129
5.7.3.3 Reset setting................................................................................................................................................................130
5.7.3.4 Upgrade ...................................................................................................................................................................... 130
5.7.3.4.1 USB Upgrade...................................................................................................................................................130
5.7.3.4.2 Online upgrade................................................................................................................................................. 130
5.7.3.5 Parameter Management .............................................................................................................................................. 131
5.7.3.6 Auto Reboot................................................................................................................................................................131
5.7.3.7 Developer Mode.......................................................................................................................................................132
5.7.4 IP Camera Maintain..................................................................................................................................... 132
5.7.4.1Upgrade IP Camera.......................................................................................................................................................132
5.7.4.2 Load Default Settings for IP Camera.............................................................................................................................. 133
5.7.4.3 Reboot IPC .................................................................................................................................................................. 133
5.7.4.4 Manage IPC parameters ............................................................................................................................................... 133
5.7.4.5 Format IPC .................................................................................................................................................................. 134
5.7.5 System Information...................................................................................................................................... 134
5.7.5.1 Information ..............................................................................................................................................................134
5.7.5.2 Channel Information.................................................................................................................................................... 134
5.7.5.3 Record Information...................................................................................................................................................... 135
5.7.5.4 Network State ..........................................................................................................................................................135
CHAPTER 6: AI SCENARIO-BASED APPLICATION............................................................................................... 136
6.1 FACE ATTENDANCE ....................................................................................................................................................... 136
6.2 CC SCENARIO ............................................................................................................................................................. 139
6.2.1 channel......................................................................................................................................................... 139
6.2.2 Groups.......................................................................................................................................................... 140
6.2.3 Search .......................................................................................................................................................... 141
6.2.4 Settings......................................................................................................................................................... 141
6.3 NON-HUMAN MACHINE STATISTICS .................................................................................................................................. 143
CHAPTER 7 SEARCH, PLAYBACK & BACKUP...................................................................................................... 144
7.1 USING SEARCH FUNCTION ............................................................................................................................................. 144
7.1.1 Search & Play Video in General................................................................................................................. 146
7.1.1.1 Video Clip Backup........................................................................................................................................................ 146

DVR USER MANUAL
5
7.1.2 Event Search, Playback & Backup............................................................................................................. 147
7.1.2.1 Event Playback Control ................................................................................................................................................ 149
7.1.3 Sub-periods Playback.................................................................................................................................. 149
7.1.4 Smart............................................................................................................................................................ 150
7.1.5 TAG............................................................................................................................................................... 151
7.1.6 External File................................................................................................................................................. 152
7.1.7 Picture Search & View................................................................................................................................. 152
7.1.7.1 Picture Preview Control ............................................................................................................................................ 154
7.1.8 SPLIT PLAYBACK....................................................................................................................................... 155
7.1.9 AI................................................................................................................................................................... 155
7.1.9.1 Face ............................................................................................................................................................................155
7.1.9.1.1 Face track chart................................................................................................................................................156
7.1.9.2 License plate detection ................................................................................................................................................ 157
7.1.9.3 Pedestrian and Vehicle................................................................................................................................................. 158
7.1.9.4 PID&LCD......................................................................................................................................................................159
7.1.9.5 Repeat Visitors ............................................................................................................................................................159
7.1.9.6 Face attendance ..........................................................................................................................................................160
CHAPTER 8 REMOTE ACCESS VIA WEB CLIENT................................................................................................. 161
8.1 BASIC SYSTEM ENVIRONMENT REQUIREMENTS ................................................................................................................... 161
8.2 WEB PLUGIN DOWNLOAD AND INSTALLATION..................................................................................................................... 162
8.3 WEB CLIENT MANAGER ................................................................................................................................................ 163
8.3.1 Live Interface................................................................................................................................................ 163
8.3.2 Playback....................................................................................................................................................... 167
8.3.2.1 Playback Control Buttons ............................................................................................................................................. 168
8.3.2.2 Picture playback ..........................................................................................................................................................169
8.3.2.3 Tag playback................................................................................................................................................................ 170
8.3.2.4 Smart Playback............................................................................................................................................................ 171
8.3.2.5 AI Playback.................................................................................................................................................................. 171
8.3.3 Remote Setting............................................................................................................................................ 172
8.3.4 Local Setting................................................................................................................................................. 172
CHAPTER 9 VIEWING BACKED UP VIDEO ON PC/MAC...................................................................................... 173
CHAPTER 10 REMOTE ACCESS VIA MOBILE DEVICES...................................................................................... 176
CHAPTER 11 APPENDIX............................................................................................................................................ 178
.11.1 FAQ QUESTIONS ...................................................................................................................................................... 178
11.2 USAGE MAINTENANCE ............................................................................................................................................... 179
11.3 ACCESSORIES (FOR REFERENCE ONLY) ............................................................................................................................. 180

DVR USER MANUAL
6
SAFETY INSTRUCTION
Please carefully read the following safety instruction so as to avoid personal injuries and prevent the
equipment and other connection devices from being damaged.
1. Power sources (note: please use the power supply attached or specified by the manufacturer)
Never operate the equipment by using unspecified power supply.
2. Never push objects of any kind through openings of DVR so as to avoid electric shock or other accidents.
3. Do not put the equipment in the dusty field
4. Do not place the equipment under rain or humid environment. If the equipment is accidentally in
contact with water, please unplug the power cable and immediately contact your local dealer.
5. Keep the surface of the equipment clean and dry. Use soft damp cloth to clean the outer case of DVR
(do not use liquid aerosol cleaners)
6. Do not operate if any problems are found. If there are any strange smell or sound from DVR, unplug
the power cable and contact the authorized dealer or service center.
7. Do not try to remove the upper cover
Warning: Do not remove the cap of DVR so as to avoid electric shock.
8. Handle with care
If DVR does not work normally because of hitting on the hard object, please contact the authorized
dealer for repair or replacement.
9. Use standard lithium battery (Note: Use the batteries attached or specified by the manufacturer)
After cutting off the power supply, if the system clock cannot continue to work, please replace the
standard 3V lithium battery on the main board.
Warning: Turn off DVR before replacing the batteries, or you may be suffered from seriouselectric shock.
Please properly dispose of the used batteries.
10. Put the equipment in a place with good ventilation
The DVR system includes HDD, which produces large amount ofheat during operation.As a result, do
not block the ventilation openings (on the top, bottom, both sides and the reverse side) for cooling the system
during operation. Install or put the equipment in the place with good ventilation.
11. The attached power adapter can only be used for 1 set of DVR. Do not connect more equipment, or
DVR may be restarted repeatedly because of insufficient power.
12. Prevent the equipment from water dropping or splashing. Do not place objects containing water, such
as flower vase, on the equipment.
13. Do not ingest battery, Chemical Burn Hazard,
This product contains a coin / button cell battery.
If the coin / button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can
lead to death.
Keep new and used batteries away from children.
If the battery compartment does not close securely, stop usingthe product and keep it away from children.
If you think batteries might have been swallowed or placed inside any part of the body, seek immediate
medical attention.
Notice:
Do not ingest battery, Chemical Burn Hazard,
This product contains a coin / button cell battery.
If the coin / button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can
lead to death.
Keep new and used batteries away from children.
If the battery compartment does not close securely, stop using the product and keep itaway from
children.
If you think batteries might have been swallowed or placed inside any part of the body, seek immediate
medical attention

DVR USER MANUAL
7
Chapter 1: Product Overview
1.1 Rear Panel
Item Description
VIDEO INPUT Connect with video input devices, standard BNC port
AUDIO INPUT Connect with audio input signals, RCAport
AUDIO OUTPUT Audio signal output, RCAport
USB port Connect the supplied mouse or USB flash memory
VGA Connect to your TV or a monitor with VGA input.
HDMI Connect to your digital TV or monitor with HDMI input
LAN
Connect to your home network
e-SATA
Optional. Connect to e-SATA HDD for recording & backup
RS-485 Connect to PTZ devices
Sensor & Alarm Optional. Connect to external sensor & alarm devices
Power Connect to the supplied power adaptor
Power Switch Turn on /off power supply
Audio input (1-4) & Video input (25-32)
Some 32 channel DVR models can be connected to the audio input using the include connector（25 CH
Audio input (5-16)
Some 16-32-channel DVR models can be connected to the audio input using the included connector

DVR USER MANUAL
8
1.2 Remote control (for reference only, subject to material objects)
Chapter 2 DVR Installation & Connection
2.1 HDD Installation
Depending on the package you have purchased, the hard disk drive may be included in the full package.
If it is not pre-installed, follow the installation instructions on this user manual.
Caution: DONOT install or remove the hard disk drive while the device power is turned ON.
HDD Installation:
（1）Cut power firstly, and then remove screws on both sides & rear panel, and open DVR upper cover.
No.
Icon
Description
1 1-8
Numeric keys
Press to display channel 1~8
2 9、0 Numeric keys
3 ALL
Press to display all channels
Multiple display mode
4
Menu
Press to enter or exit the Main Menu
5
Mute
Mute On/off
6
Submenu
Go to submenu
7
Up arrow key; Volume increase
8 SEL
Press to enter the selected menu item and
edit the setting
9
Left/Right key; Decrease/increase parameter
value of control bar.
10
Down arrow key; Volume decrease
11
Press to rewind during video playback
12
Press to fast forward during video playback
13
Press to play recorded video or enter the
recording search menu
14
Press to start manual recording
15
Press to stop manual recording or stop the
video playback
16
Press to pause the video playback or enter
frame-playback mode
Table 2-1
1
2
3 4
5 6
7
8
9
10
9
11 12
13
14 15
16

DVR USER MANUAL
9
（2）Connect the data and power cables to the HDD and place the HDD on the DVR case. Carefully flip
the DVR case and secure the HDD to the DVR with the screws.
(3) Put the upper cover back carefully, and fix the cover with screws.
Note:Above procedures are for reference only. The practical operation may be different depending on
the DVR you purchased.
2.2 Connection Diagram
Note:Above diagram is for reference only. The practical connection may be different depending on the
DVR you purchased.

DVR USER MANUAL
10
2.3 Power Supply Connection
Caution: Use only the supplied power adapter that came with the DVR
Connect one end of the power adapter to the power connector on the back of the DVR. Plug the other
end of the power adapter into the wall outlet.
For some specific models, you may need to press the Power switch to turn on the power.
Chapter 3 DVR Common Operations
3.1 Using the Supplied Mouse
1、Left Button:
Click to select menu options.
During live viewing in split-screen view, double-click on
a channel to view it in full-screen. Double-click
the channel again to return to split-screen viewing.
Click upon a channel on Live Viewing screen to open
Camera Quick Toolbar.
Click and hold to drag sliders and scales on menu mode
2、Scroll Wheel:
In menus, scroll to move up / down through the menu content.
While hovering over the volume control wheel, scroll to turn system volume up / down.
3.2 Using the Virtual Keyboard
You will see the virtual keyboard automatically on the screen when you need to enter data
Move cursor to left
Click to delete a
character
Click to complete
the enter
Move the cursor to left
Move the cursor to right
Click to toggle the keyboard to
upper case and more punctuation

DVR USER MANUAL
11
3.3 Password
The first time you run a DVR, you must immediately set your password to protect your privacy.Be sure to
record your user name and password and keep it in a secure place.
Device ID: Select the language of the interface
Device ID: Enter the device ID in parentheses.The default ID is 000000. Fordetailson the device ID, see
1.1 General configuration 5.7.1 General Configuration.
New Admin name: Set up the administrator.Version 8.2.2 cannot modify the administrator user name.
New Admin Password: Setup the administrator password.Password should be 8 to 15 characters, not
the same as the user name, letters, numbers, special symbols to at least two combinations.
Confirm Password: Enter the password for the logged-in user again.
Unlock Pattern Enable: Enable the gesture password.Click the edit icon on the right to start setting the
gesture password.After two confirmation, you can successfully set the gesture password.
Click Apply to confirm the Settings and enter the password recovery Settings page. You can open the
corresponding password recovery method by checking the line, or click the Cancel button directly without
checking, and do not open the password recovery function.

DVR USER MANUAL
12
①Security Question Configuration：Question check and modifythe main user password function.After
opening, you need to choose 3 out of15 common questions, and set the answer required to retrieve the
password. The maximum length of the answer is 64 characters.
②Certificate of authorization：Use the key to modify the master user password function, and click
Export to download the key file certificate. The txt goes to the U disk.
③Super code(Not recommended)：Use the super verification code to modify the master user password
function, using the currentDVRMac address and DVR system time, to calculatea superverification code that
can modify the master user password. However, the Mac address of DVR is broadcast in the network, and
the DVR system can be directly obtained when using Super code to modify the main user password during
login, so there are certain security risks, so it is not recommended for users to open it.
Then go to the login interface. Enter your username and password Click on Login to log in to the DVR
system.
Pattern：Enter the gesture and password login interface
Notice:
If you forget two kinds of password, you will not be able to login the system. Please check Forgot
Password to reset password. System will send the temporary password to the setting email. This password
is used on login interface and User setting to change password. If you didn’t set the email, please contact
your reseller to resetpassword. (Some models didn’t support FORGOT PASSWORD function.)

DVR USER MANUAL
13
Chapter 4 DVR Starting up
4.1 Start Wizard
Startup Wizard will help to configure the system and get the DVR works quickly.
4.1.1 Start Wizard
Click the Start Wizard to proceed to the next step
4.1.2 Network configuration
If you connect to a router allows to use DHCP, please check the DHCP box. The router will assign
automatically all the network parameters for your DVR. Unless the network is manually addressed below
parameters:
IPAddress: The IP address identifies the DVR in the network. It consists of four groups of numbers
between 0 to 255, separated by periods. For example, “192.168.001.100”.
Subnet Mask: Subnet mask is a network parameter which defines a range of IP addresses that can be
used in a network. If IP address is like a street where you live then subnet mask is like a neighborhood. The
subnet address also consists of four groups of numbers, separated by periods. For example,
“255.255.000.000”.
Gateway: This addressallows the DVR to access the Internet. The format of the Gateway address is the
same as the IPAddress. For example, “192.168.001.001”.
DNS1/DNS2: DNS1 is the primary DNS server and DNS2 is a backup DNS server. Usually should be
enough just to enter the DNS1 server address.
Web Port: This is the port that you will use to log in remotely to the DVR (e.g. using the Web Client). If
the default port80 is already taken by other applications,please change it.
Client Port: This is the port thatthe DVR will use to send information through (e.g. using the mobile app).
If the defaultport 9000 is already taken by other applications, please change it.
RTSP Port: This is the port that the DVR will be allowed to transmit real-time streaming to other device
(e.g. using a streaming Media player.).
UPNP: If you want to log in remotely to the DVR using Web Client, you need to complete the port
forwarding in your router. Enable this option if your router supports the UPnP. In this case, you do not need to
configure manually port forwarding on your router. If your router does not support UPnP, make sure the port
forwarding is completed manually in your router.

DVR USER MANUAL
14
PPPoE（Ethernet-based Point-Point Communication Protocol) dialing: PPPoE (English:
Point-to-Point Protocol Over Ethernet), peer-to-peer protocol on Ethernet, is a network tunneling protocol that
encapsulates Point-to-Point Protocol (PPP) in an Ethernet (Ethernet) framework.Due to the integration of
PPP protocol in the protocol, the functions of authentication, encryption and compression that cannot be
provided by traditional Ethernet can also be used for ethernet protocol such as cable modem (cable modem)
and digital user line (DSL).
4.1.3 Date/Time
This menu allows you to configure the Date,Time, Date Format,Time Format,Time Zone, NTPand DST.
Date and Time：Click on the calendar icon to set the current system date.
Date: Click on the calendar icon to set the system date.
Time: Click to set the system time.
Date Format: Choose from the dropdown menu to set preferred date format.
Time Format: Choose time format between 24Hour and 12Hour.
Time Zone: Set the correct time zone.
NTP：NTP stands for Network Time Protocol. This feature allows you to synchronize the date and time
automatically on the DVR over Internet. Therefore, the DVR needs to be connected to the Internet.
Check the “NTP” box, and select the NTP server.
Choose the server address ：time.windows,com,/time.nist.gov/pool.ntp.org/User-Defined
DST：DST stands for Daylight Savings Time.
DST:Enable if Daylight Saving Time (DST) is observed in your region
Time Offset: Select the amount of time to offset for DST
Time Mode: Choose to set the daylight-saving time in weeks or in days
Start Time/End Time: Set the start time and end time for daylight saving

DVR USER MANUAL
15
4.1.4 IP Camera
Click Search to search IP cameras in the same
network. Choose the IPcamera(s) you want to add, and
then click icon to add to the DVR
Enter the camera’s user name &
password to add the camera(s).
You can also click button to add
individual IP camera to a single channel.
Click Search button to search IP
cameras, and then click one of the IP camera
in the device list.
IP Address/Domain: IP address or
domain name of the IP camera
Alias: Name of the IP camera
Port: Port of the IP camera
Protocol: Choose the protocol of the IP
camera from the dropdown menu
User Name: User Name of the IP
camera
Password: Password of the IP camera
Camera Mode: Select the IP camera
mode in the drop-down menu

DVR USER MANUAL
16
4.1.5 Disk
If the HDD is installed in the
DVR for the first time, it must be
formatted. Select the HDD and
then click Format HDD button to
format the HDD.
Overwrite: Use this option to
overwrite the old recordings on
the HDD when the HDD is full.
For example, if you choose the
option 7 days then only the last 7
days recordings are kept on the
HDD. To prevent overwriting any
old recordings, select Disable.
If you have disabled this function, please check the HDD status regularly, to make sure the HDD is not
full. Record On ESATA: If your DVR comes with an e-SATA port on the rear panel, you can enable to record
the video to e-SATAHDD.
4.1.6 Resolution
Choose an output resolution matches to your monitor.
The DVR supports to adjust the output resolution
automatically to match the best resolution of your monitor
when the system is starting up.
4.1.7 Mobile
If your DVR come with a P2P ID, you can scan
the QR code with your mobile app to view the DVR
remotely.
4.1.8 Summary
You can check the system summary information
you had set in the start wizard and finish the wizard.
Tick “Don't show this window next time" if you don’t
want to display Start Wizard when system reboot next
time. Click Finish button to save & exit.

DVR USER MANUAL
17
4.2 Introduction of the real-time view interface
Camera name
Display the camera name
A-: This indicates that the connected camera is an AHD camera
T-: This indicates that the connected camera is a TVI camera
C-: This indicates that the connected camera is a CVI camera
IP: This indicates that the connected camera is an IP camera
Status icon
：A Smart alert is triggered
：It means that the human body infrared sensing alarm is triggered
:This indicates that the channel is being video-recorded
:This indicates triggering the move detection
Show the triggered input and output IO alarm and video recording
:This icon indicates that the hard drive is not working properly
The icon indicates that the hard disk is unformatted
The icon indicates that the hard drive is full
The icon indicates that the hard drive is of a read-only status
Off -line: The analog camera is disconnected.
No Camera: No IP camera is connected.
Decoding Failed: This IP camera compression standard is not supported by DVR, please change to
H.264 Compression standard.
Resource Not Enough：Insufficient resource, the main code stream does not support and all drawing /
mjpeg format can only display one channel.
Band Not Enough：Insufficient bandwidth for the channel to go online
Failed to connect to camera：The IPC connection has failed
User name or passwword error: Wrong IPC username or password
Click to open the Quick Add menu to add an IP camera
Click to edit the current channel parameters

DVR USER MANUAL
18
4.2.1 Camcorder Quick Toolbar
In the preview screen, left-click on the attached camera to display the Quick Toolbar.
Video recording: Click to manually record the channel immediately. If a manual recording is ongoing,
the icon is in red.Click Stop Manual recording again
Grab: Click to save a snapshot of the current camera image.
Instant playback: Click to play the last 5-minute video of this channel
PTZ: Click to enter the PTZ control panel
Click to put the channel. Scroll the mouse wheel to zoom the picture and drag the screen.
Click to adjust the image color of the channel. You can adjust the tone, brightness, contrast, and
saturation of the image.
Switch the live video streams between the primary and subcode streams.HD is the main code outflow
diagram, and SD is the subcode outflow diagram.
Click to manually turn / off the channel white light alarm, see 5.1.8 White Light.Also, this menu does not
change the parameters within the white light settings.
Click to manually turn / off the channel alarm, see section -5.1.8 White Light。Also, this menu does not
change the parameters within the white light settings.
Label click to add labels
Statistics When AI is turned on, hover over the icon to viewAI statistics
4.2.2 Taskbar
Click to Open the Start menu
Click to select a different layout to preview the display
Click to select more layouts to preview the display
Round tour, click to start preview the channel in sequence
Quick playback, you can replay all the channels from the start of the day, or click on the lower right
triangle to select from the nearest 5s, 10s, 30s, 1Min, 5Min to start the play.
Click to adjust the volume
Click to switch all IP channels to primary or substreams for a preview
Click to switch between the original scale screen or the stretch screen.
Click to switch between the balanced or smooth views. Preview mode affects preview video quality only
through bit and frame rates, but not the recording quality.
There is no connection network
This icon appears if the network is disconnected.
The network connection was successful
Turn the lights and alarms on or off for all channels
Start or stop the manual video recording and the manual alarm.
View system information, channel information, record information, and network status.

DVR USER MANUAL
19
4.2.3 The Start Menu
With the Start menu, you can switch between users, search and playback, enter the System Settings
menu, lock and unlock the screen, close, restart and log out the system.
4.2.3.1 Unlock and Lock the screen
4.2.3.2 Equipment shutdown
Switch users.To enable multiple users, please see 5.7.2.2 Add a new use。
Search and play.For more details, please seeChapter 7 Search, playback, and backup
Lock and unlock the screen. For details, please see 4.2.3.1Unlock and lock the screen。
Close, restart, and deregister the system. For details, please visit 4.2.3.2 Equipment shutdown。
NVR system Settings. For details, please see Chapter 5 DVR System Setting
If the NVR is not operated on the Menu for a long time, the screen is locked to
protectunauthorized
OSD
operations. For details, see Menu Timeout (min) in5.7.1.1
General Configuration
You can also manually lock the screen if necessary. To do this, go to the Start
menu and then click the Lock screen icon to lock the system immediately.
If the system is locked, you can click the icon If the system is locked, you
can click the icon
Click the Shutdown button from Star Menu, and the check the further action
you want to move. Click OK button, system will require to input the admin password
to authenticate
Click the
Shutdown
button from Star
Menu, and the check the further action you
want to move. Click OK button, system will
require to input the admin password to
authenticate
