Eneo NXD-2030PTZ1080IR User manual

EN
User Manual
1/2.8” Network Dome, PTZ,
30x, Day&Night, 4.3~129mm,
Infrared,1920x1080,Outdoor
NXD-2030PTZ1080IR

WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EX-
POSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY
METALLIC OBJECT THROUGH THE VENTILATION GRILLS OR OTHER
OPENNINGS ON THE EQUIPMENT.
CAUTION
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an equilateral triangle, is in-
tended to alert the user to the presence of dangerous voltage within the products
enclosure that may be of sufficient magnitude to constitute a risk of electric shock
to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the product.
2

FCC COMPLIANCE STATEMENT
FCC INFORMATION: This equipment has been tested and found to
comply with the limits for a Class A digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commer-
cial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the in-
struction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful in-
terference in which case the user will be required to correct the interference
at his own expense.
CAUTION: Changes or modifications not expressly approved by the party
responsible for compliance could void the users authority to operate the
equipment.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numrique de la classe A est conforme la norme NMB-003 du
Canada.
CE COMPLIANCE STATEMENT
WARNING
This is a Class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures..
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
3

IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings, Install in accordance with the manufacturers in-
structions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug, A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong are provided for your safety, If
the provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, conve-
nience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus. When a cart is used.
Use caution when moving the cart/apparatus combination to avoid in-
jury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for
long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is re-
quired when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or moisture, does not operate nor-
mally, or has been dropped.
15. CAUTION −THESE SERVICING INSTRUCTIONS ARE FOR USE BY QUALIFIED
SERVICE PERSONNEL ONLY. TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT
PERFORM ANY SERVICING OTHER THAN THAT CONTAINED IN THE OPERATING IN-
STRUCTIONS UNLESS YOU QRE QUALIFIED TO DO SO.
16. Use satisfy clause 2.5 of IEC60950-1/UL60950-1 or Certified/Listed Class 2 power
source only.
17. ITE is to be connected only to PoE networks without routing to the outside plant.
4

Contents
1 Introduction 6
1.1 Components .................................... 6
1.2 KeyFeatures .................................... 7
2 Installation 8
2.1 Installation ..................................... 8
2.1.1 Installation - Wall Mount . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.1.2 Installation - Ceiling Mount . . . . . . . . . . . . . . . . . . . . . . . . 10
2.2 Basic Configuration of Camera System . . . . . . . . . . . . . . . . . . . . . 11
2.3 Micro-SD Card Insertion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.4 Connections .................................... 13
2.4.1 Network Connection & IP assignment . . . . . . . . . . . . . . . . . . 14
3 Operation 15
3.1 Accessfromabrowser .............................. 15
3.2 Access from the internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.3 Setting the admin password over a secure connection . . . . . . . . . . . . . 16
3.4 LiveViewPage................................... 17
3.5 Playback ...................................... 19
3.6 NetworkCameraSetup .............................. 21
3.6.1 Basic Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.6.2 LiveView .................................. 25
3.6.3 Video&Image ............................... 26
3.6.4 Audio .................................... 35
3.6.5 Event .................................... 37
3.6.6 DomeConfiguration ............................ 59
3.6.7 System ................................... 68
3.7 Help......................................... 89
3.8 Resetting to the factory default settings . . . . . . . . . . . . . . . . . . . . . 90
4 Appendix 91
4.1 Troubleshooting................................... 91
4.2 AlarmConnection ................................. 92
4.3 Preventive Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
4.4 ProductSpecification................................ 93
4.5 System Requirement for Web Browser . . . . . . . . . . . . . . . . . . . . . . 95
4.6 General Performance Considerations . . . . . . . . . . . . . . . . . . . . . . 95
5

1 Introduction
The network camera supports the network service for a sensor image with progressive scan,
which can be monitored on a real-time screen regardless of distances and locations. By us-
ing its dedicated program, many users are able to have an access to the network camera
at once or a single user can monitor various network cameras at the same time. It also
enables users to play, store and retrieve a monitoring image by using a PC. All the settings
and real-time monitoring screens are also provided through an access to the web.
The network camera is fully featured for security surveillance and remote monitoring needs.
It is based on the DSP compression chip, and makes it available on the network as real-time,
full frame rate Motion JPEG and H.264 video streams.
1.1 Components
This system comes with the following components;
Dome Camera ························ 1
Installation Guide/CD ························ 1
RJ-45 Coupler ························ 1
2P screw type Connector ························ 1
5P screw type Connector ························ 1
12VDC Adaptor ························ 1 (Optional)
PoE Injector ························ 1 (Optional)
Install Adaptor ························ 1
6

1.2 Key Features
•Brilliant video quality
The network camera offers the highly efficient H.264 video compression, which drasti-
cally reduces bandwidth and storage requirements without compromising image qual-
ity. Motion JPEG is also supported for increased flexibility.
•Dual or Triple Streams
The network camera can deliver dual or triple video streams simultaneously at full
frame rate in all resolutions up to Full-HD (1920 x 1080p) using Motion H.264 and
JPEG. This means that several video streams can be configured with different com-
pression formats, resolutions and frame rates for different needs.
•Image setting adjustment
The network camera also enables users to adjust image settings such as contrast,
brightness and saturation to improve images before encoding takes place.
•Intelligent video capabilities
The network camera includes intelligent capabilities such as VCA(Video Content Anal-
ysis). The network camera’s external inputs and outputs can be connected to devices
such as sensors and relays, enabling the system to react to alarms and activate lights
or open/close doors.
•Improved Security
The network camera logs all user access, and lists currently connected users. Also, its
full frame rate video can be provided over HTTPS.
•Built-in Synchronized IR LED & Fixed IR LED
The camera is equipped with two built-in IR LEDs, fixed one for wide view and zoom
synchronized adjustable one for distant view.
•PoE (Power over Ethernet)
This network camera can be powered through PoE, which simplifies installation since
only one cable is needed for carrying power, as well as video controls.
•ONVIF Certificate
This is a global interface standard that makes it easier for end users, integrators, con-
sultants, and manufacturers to take advantage of the possibilities offered by network
video technology. ONVIF enables interoperability between different vendor products,
increased flexibility, reduced cost, and future-proof systems.
•Micro-SD Recording support
The network camera also supports a Micro-SD memory slot for local recording with
removable storage.
•Audio support
The network camera also supports two-way audio.
7

2 Installation
2.1 Installation
You need one optional mount kit of the wall mount and the ceiling mount to install.
The wall or ceiling mount must be attached to a structural object such as hard wood, con-
crete that will support the weight of the mount and dome camera.
The use of a solid backboard is recommended when attaching to gypsum walls.
1. Remove the Protection pad and the tape from attached the dome camera.
2. Attach the mounting base to wall using the supplied M8 tapping screw and plastic
bushing. (Ceiling using the supplied M6 tapping screw and bushing)
3. Wind the both thread of the pipe end with Teflon tape about 20 times for sealing. Then
use a silicone rubber sealant to seal the area where the wall (ceiling) mount and the
pipe meet.
4. Place a bead of silicone sealant around the wall and ceiling mount mounting flange,
press it to the surface and line up the flange hole with drilled holes.
CAUTION 1: A silicone rubber sealant must be applied to seal the housing to secure water-
proofing.
CAUTION 2: When installing, a bracket must be applied.
8

2.1.1 Installation - Wall Mount
The wall mounting plate must be attached to a structural object such as concrete that will
support the weight of the mount and Dome Camera.
1. Select a suitable mounting location and verify there is sufficient cable to reach the
middle of the Wall Mount.
2. Mark and drill mounting holes in the surface using the Wall Mount Flange.
3. Pull out cables required to connect to the dome camera from the wall or route cables
through a section of 0.75 in. (19 mm) conduit pipe.
4. Remove the access plate from the wall mount bracket.
5. Attach the wall mount bracket using screws routing cables through the access plates
hole.
6. Attach the housings safety wire to the wall mounts latch.
7. Fix the housing to the wall mount bracket using the locking nut after routing cables
through the wall mount bracket and tighten the housing set screw with the supplied
wrench.
8. After connecting cables, attach the access plate.
9

2.1.2 Installation - Ceiling Mount
The ceiling mounting plate must be attached to a structural object such as concrete that will
support the weight of the mount and Dome Camera.
1. Select a suitable mounting location
and verify there is sufficient cable to
connect with cables from the housing.
2. Mark and drill mounting holes in
the surface using the ceiling mount
flange.
3. Pull out cables required to connect
to the dome camera from the ceiling.
4. Attach the ceiling mount bracket
using screws routing cables through
the locking nut.
5. Tighten the housing with the pipe
using the socket after routing cables
through the pipe.
6. Attach the housing’s safety wire
to the ceiling mount’s m6X35 tapping
screw.
7. After connecting cables, fix the
pipe to the ceiling mount using the
locking nut.
8. Tighten set screws of the socket
and locking nut with the supplied
wrench.
10
