Eneo PXD-1110F39 Installation instructions

Full Manual
1/2.7“ Full HD Network Dome Camera
PXD-1110F39
PXD-1210Z03

1
Table of Contents
1. Overview ................................................................................................................................2
1.1 Features ......................................................................................................................2
1.2 Package Contents .......................................................................................................3
1.3 Dimensions..................................................................................................................4
1.4 Connectors ..................................................................................................................6
2. Camera Cabling.....................................................................................................................7
2.1 Connect Power ............................................................................................................7
2.2 Connect Ethernet Cable...............................................................................................7
2.3 Connect Alarm I/O .......................................................................................................7
3. System Requirements ..........................................................................................................8
4. Access Camera ..................................................................................................................... 9
4.1 Camera Login ......................................................................................................................9
5. Setup Video Resolution...................................................................................................... 10
6. Configuration Files Export / Import ................................................................................... 11
Appendix A: Technical Specifications ...................................................................................... 12
Appendix B: Delete the Existing DC Viewer.............................................................................. 16
Appendix C: Setup Internet Security ......................................................................................... 17
Appendix D: Video Resolution................................................................................................... 18
Quad Streams.......................................................................................................................18
Triple Streams....................................................................................................................... 22
Dual Streams ........................................................................................................................25
Single Stream .......................................................................................................................26

2
1. Overview
The Full HD Multi-Streams Compact Dome IP Camera is a compact camera
with an easy setup design. High Power PoE is supported to reduce complicated
cabling without sacrificing performance. Moreover, 5 Megapixel Resolution is
offered for providing high definition images. Quad Streams Compression (H.264
Baseline / Main / High Profile + MJPEG) are supported for efficient bandwidth
and storage management. For dark environments, the camera has incorporated
WDR, 3DNR and Day/Night ICR technologies to capture clear images in
lowlight conditions.
1.1 Features
•2M Progressive Scan CMOS Sensor
•Dual Streaming- Full HD 1080P Real Time + D1 Real Time
•Quad Streams Compression- H.264 Baseline / Main / High Profile + MJPEG
•Multi-language Support
•Tampering Alarm
•Remote Zoom & Focus (Motorized Lens)*
•Wide Dynamic Range
•Motion Detection
•Privacy Masks
•Smart Picture Quality / 3D Noise Reduction
•Vertical View Mode (image rotation by 90 degrees)
•Smart IR Mode
•Network Failure Detection
•Day/Night (ICR)
•IR LED Module (working distance up to 25m)*
•microSD Support
•BNC Analog Output
•Weatherproof (IP66 International)
•High Power PoE (PoE+)
•ONVIF Support
(*) Optional

3
1.2 Package Contents
Please check the package contains the following items listed below.
Full HD Multi-Streams
Compact Dome IP Camera
Power Terminal Block
Self Tapping Screws (×2) Plastic Screw Anchors (×2)
Quick Guide
CD
(bundled software and documentation)

4
1.3 Dimensions
The dimensions of the IP Camera are shown below.

5

6
1.4 Connectors
The connectors of the IP Camera are shown in the below diagram. Definition for
each connector is also given as follows.
No.
Connector
Pin
Definition
Remarks
1
RJ-45
-
10/100 Mbps Ethernet / PoE
2 Power
AC 24V
1
AC 24_1
Power connection
2
AC 24_2
DC 12V
3
GND
4
DC 12V (+)
3
BNC
-
For analog Video Output
4 Alarm & Audio I/O
1
Alarm In (–)
Alarm connection
2
Alarm In (+)
3
Alarm Out (–)
4
Alarm Out (+)
5
Audio Out (R)
Line Out
6
Audio Out (L)
7
Audio GND
8
Audio In (R)
Line In
9
Audio In (L)
5
microSD Card Slot
-
For video recording storage
6 Default Button -
Press the button with one finger to restore the
system.
NOTE: Please insert the SD card into the microSD Card Slot before
power on the camera. If the camera is already powered on, reboot the
camera after the SD card is inserted.

7
2. Camera Cabling
Please follow the instructions below to complete IP Camera connection.
2.1 Connect Power
For power connection, please refer to the Connectors section of the previous
chapter. Alternatively, connect the Ethernet Cable to the camera’s PoE port and
plug the other end of the cable into a PoE switch.
NOTE: If PoE is used, make sure Power Sourcing Equipment (PSE) is
in used in the network.
2.2 Connect Ethernet Cable
Use of Category 5 Ethernet Cable is recommended for network connection; to
have best transmission quality, cable length shall not exceed 100 meters.
Connect one end of the Ethernet Cable to the RJ-45 connector of the IP
Camera, and the other end of the cable to the network switch or PC.
NOTE: In some cases, Ethernet Crossover Cable might be needed
when connecting the IP Camera directly to the PC.
Check the status of the link indicator and activity indicator LEDs. If the LEDs are
unlit, please check the LAN connection.
Green Link Light indicates good network connection.
Orange Activity Light flashes for network activity indication.
2.3 Connect Alarm I/O
The camera equips one alarm input and one relay output for alarm application.
Refer to the alarm pin definition below to connect alarm devices to the IP
Camera if needed.
PIN 1: GND (Input-)
PIN 2: Input+
PIN 3: Output-
PIN 4: Output+

8
3. System Requirements
To perform the IP Camera via web browser, please ensure the PC is in good
network connection, and meet system requirements as described below.
Items System Requirement
Personal Computer
1. Intel®Pentium®M, 2.16 GHz or
Intel®CoreTM2 Duo, 2.0 GHz
2. 2 GB RAM or more
Operating System Windows VISTA / Windows XP / Windows 7
Web Browser Microsoft Internet Explorer 6.0 or later
Firefox
Chrome
Safari
Network Card 10Base-T (10 Mbps) or 100Base-TX (100 Mbps) operation
Viewer ActiveX control plug-in for Microsoft IE

9
4. Access Camera
For initial access to the IP Camera, users can search the camera through the
installer program: eneo Scan Device Tool, which can be found in “Scan Device
Tool” folder in the supplied CD.
For further information, please refer to the eneo Scan Device Tool Guide
included in the same folder.
4.1 Camera Login
The network Speed Dome Camera’s default IP address is: 192.168.1.10.
Therefore, to access the camera for the first time, set the PC’s IP address as:
192.168.1.XXX; for example:
IP Address: 192.168.1.20
Subnet Mask: 255.255.255.0
Login ID & Password
•Key in the camera’s IP address in the URL bar of the Web browser window and
press “Enter.”
•Enter the default user name (admin) and password (admin) in the prompt
request dialogue.
Note that user name is case sensitive.
Install the ActiveX Control
•After connecting to the network Speed Dome Camera, the request for installing
the ActiveX control will appear just below the URL bar.
•Right Click on the information bar, and press “Install ActiveX Control…” to permit
ActiveX control installation.
•In the pop-up security warning window, click on “Install” to start downloading
DC Viewer software on the PC.
•Click on “Finish” after DC Viewer installation is complete.

10
5. Setup Video Resolution
Users can setup Video Resolution on Video Format page of the user-friendly
browser-based configuration interface.
Video Format can be found under this path: Streaming> Video Format.
The default value of Video Resolution is as below.
2M
H.264- 1920 x 1080 (30 fps) + H.264- 720 x 480 (30 fps)
For more Video Resolution combination details, please refer to chapter
Appendix D: Video Resolution.

11
6. Configuration Files Export / Import
To export / import configuration files, users can access the Maintenance page
on the user-friendly browser-based configuration interface.
The Maintenance setting can be found under this path: System> Maintenance.
Users can export configuration files to a specified location and retrieve data by
uploading an existing configuration file to the IP Camera. This is especially
convenient to make multiple cameras having the same configuration.
Export
Users can save the system settings by exporting the configuration file (.bin) to a
specified location for future use. Click on the <Export> button, and the popup
File Download window will come out. Click on <Save> and specify a desired
location for saving the configuration file.
Upload
To upload an configuration file to the IP Camera, please first click on <Browse>
to select the configuration file, and then click on the <Upload> button for
uploading.

12
Appendix A: Technical Specifications
Camera
PXD-1110F39
Image Sensor
1/2.7” Progressive CMOS
Effective Pixels
1920 (H) x 1080 (V)
Minimum Illumination
0.2 lux (Color) / 0.02 lux (B/W)
Shutter Speed
1 ~ 1/10000 sec.
Lens
Lens
Vari-focal
Focal Length
3.0 ~ 9.0 mm
F Number
F1.2
FOV
103.5º (Wide); 34.3º (Tele)
Operation
Multiple Languages
English / French / German / Italian / Japanese / Korean / Portuguese /
Russian / Simplified Chinese / Spanish / Traditional Chinese
Image Setting
Backlight Compensation
On / Off
White Balance
Auto / Manual / ATW
3D Noise Reduction
On / Off
Wide Dynamic Range
On / Off
Privacy Mask
On / Off
Brightness
Manual
Exposure
Auto / Manual
Sharpness
Manual
Contrast
Manual
Saturation
Manual
Hue
Manual
Digital Zoom
Support
Motion Detection
On / Off / By Schedule
Privacy Mask Type
Color
ICR
Auto / On / Off / Smart
ICR + IR LED*
Auto / LED On / LED Off / Smart IR / Light Sensor
Tampering Alarm
On / Off / By Schedule
Audio
Two-way Audio
Line In / Line Out
Compression
G.711 / G.726
Network
Interface
RJ-45, 10/100 Mbps Ethernet
Video Compression
H.264 / MJPEG
Video Streaming
Dual Streams- H.264 + MJPEG / H.264 + H.264
Quad Streams- H.264 x 3 + MJPEG / H.264 x 4
Video Resolution
H.264- Full HD 1080P / SXGA / HD 720P / XGA / SVGA / D1 / VGA / CIF
MJPEG- Full HD 1080P / SXGA / HD 720P / XGA / SVGA / D1 / VGA / CIF
Frame Rate
Single Stream
1080P (30/25 fps)
Dual Streams
1080P (30/25 fps) + D1 (30/25 fps)
Protocol
IPv4/v6, TCP/IP, UDP, RTP, RTSP, HTTP, HTTPS, ICMP, FTP, SMTP,
DHCP, PPPoE, UPnP, IGMP, SNMP, QoS, ONVIF
Security
HTTPS / IP Filter / IEEE 802.1x
Alarm
Input
1 Set, 5V 10kΩ pull up
Output
1 Set, Photo Relay Output 300V DC/AC
Event Notification
HTTP / FTP / SMTP
microSD
microSDHC 32GB support
Supported Web Browser
Internet Explorer (6.0+) / Chrome / Firefox / Safari
User Account
20
Password Levels
User and Administrator

13
Mechanical
LED Indicator
Power / Link / ACT
Connectors
Alarm
4 of 9 Pin Terminal Block
Power
4 Pin Terminal Block
Ethernet
RJ-45
Analog Video
1.0 Vp-p / 75Ω, BNC
Audio*
5 of 9 Pin Terminal Block
General
Operating Temperature
TBD
Humidity
TBD
Weatherproof Standard
NA
Dimension
∅149 x 99.5 mm
Weight
TBD
Power Source
DC 12V / AC 24V / PoE+
Power
Consumption
Sys
tem Max. 5W
Regulatory
CE / FCC / RoHS
(*) Optional

14
Camera
PXD-1210Z03
Image Sensor
1/2.7” Progressive CMOS
Effective Pixels
1920 (H) x 1080 (V)
Shutter Speed
1 ~ 1/10000 sec.
Lens
Lens
3x Optical Zoom, Auto Focus
FOV
108º (Wide); 41º (Tele)
Operation
Multiple Languages
English / French / German / Italian / Japanese / Korean / Portuguese /
Russian / Simplified Chinese / Spanish / Traditional Chinese
Image Setting
Iris Control*
P-Iris / DC Iris
Backlight Compensation
On / Off
White Balance
Auto / Manual / ATW
3D Noise Reduction
On / Off
Wide Dynamic Range
Gamma WDR
Privacy Mask
On / Off
Brightness
Manual
Exposure
Auto / Manual
Sharpness
Manual
Contrast
Manual
Saturation
Manual
Hue
Manual
Digital Zoom
Support
Motion Detection
On / Off / By Schedule
Privacy Mask Type
Color
ICR
Auto / On / Off / Smart
ICR + IR LED*
Auto / LED On / LED Off / Smart IR / Light Sensor
Tampering Alarm
On / Off / By Schedule
Audio
Two-way Audio
Line In / Line Out
Compression
G.711 / G.726
Network
Interface
RJ-45, 10/100 Mbps Ethernet
Video Compression
H.264 / MJPEG
Video Streaming
Dual Streams- H.264 + MJPEG / H.264 + H.264
Quad Streams- H.264 x 3 + MJPEG / H.264 x 4
Video Resolution
H.264- Full HD 1080P / SXGA / HD 720P / XGA / SVGA / D1 / VGA / CIF
MJPEG- Full HD 1080P / SXGA / HD 720P / XGA / SVGA / D1 / VGA / CIF
Protocol
IPv4/v6, TCP/IP, UDP, RTP, RTSP, HTTP, HTTPS, ICMP, FTP, SMTP,
DHCP, PPPoE, UPnP, IGMP, SNMP, QoS, ONVIF
Security
HTTPS / IP Filter / IEEE 802.1x
Alarm
Input
1 Set, 5V 10kΩ pull up
Output
1 Set, Photo Relay Output 300V DC/AC
Event Notification
HTTP / FTP / SMTP
microSD
microSDHC 32GB support
Supported Web Browser
Internet Explorer (6.0+) / Chrome / Firefox / Safari
User Account
20
Password Levels
User and Administrator
Mechanical
LED Indicator
Power / Link / ACT
Connectors
Alarm
4 of 9 Pin Terminal Block
Power
4 Pin Terminal Block
Ethernet
RJ-45
Analog Video
1.0 Vp-p / 75 Ω, BNC
Audio*
5 of 9 Pin Terminal Block

15
General
Operating Temperature
TBD
Humidity
10% ~ 90%, No Condensation
Weatherproof Standard*
NA
Dimension
∅149 x 99.5 mm
Weight
TBD
Power Source
DC 12V / AC 24V / PoE+
Power
Consumption
System
Max. 5W
3x AF
Max. 3W
Regulatory
CE / FCC / RoHS
(*) Optional

16
Appendix B: Delete the Existing DC Viewer
For users who have installed the DC Viewer in the PC previously, please remove the
existing DC Viewer from the PC before accessing to the IP Camera.
Deleting the DC Viewer
In the Windows <Start Menu>, activate <Control Panel>, and then double click on <Add or
Remove Programs>. In the <Currently installed programs> list, select <DCViewer> and
click on the button <Remove> to uninstall the existing DC Viewer.
Deleting Temporary Internet Files
To improve browser performance, it is suggested to clean up the all the files in the
Temporary Internet Files. The procedure is as follows.
Step 1: Click on the <Tools> tab on the menu bar and select <Internet Options>.
Step 2: Click on the <Delete> button under <Browsing history> section. In the appeared
window tick the box beside the <Temporary Internet files>.
Step 3: Click on <Delete> to start deleting the files.

17
Appendix C: Setup Internet Security
If ActiveX control installation is blocked, please either set Internet security level to default or
change ActiveX controls and plug-ins settings.
Internet Security Level: Default
Step 1: Start the Internet Explorer (IE).
Step 2: Click on the <Tools> tab on the menu bar and select <Internet Options>.
Step 3: Click on the <Security> tab, and select <Internet> zone.
Step 4: Down the page, click on the <Default Level> button and click on <OK> to confirm
the setting. Close the browser window, and restart a new one later to access the IP
Camera.
ActiveX Controls and Plug-ins Settings
Step 1: Repeat Steps 1 ~ 3 of the previous section above.
Step 2: Down the page, click on the <Custom Level> button to change ActiveX controls
and plug-ins settings. The Security Settings window will pop up.
Step 3: Under <ActiveX controls and plug-ins>, set ALL items (as listed below) to
<Enable> or <Prompt>. Please note that the items vary by IE version.
ActiveX controls and plug-ins settings:
1. Binary and script behaviors.
2. Download signed ActiveX controls.
3. Download unsigned ActiveX controls.
4. Allow previously unused ActiveX controls to run without prompt.
5. Allow Scriptlets.
6. Automatic prompting for ActiveX controls.
7. Initialize and script ActiveX controls not marked as safe for scripting.
8. Run ActiveX controls and plug-ins.
9. Only allow approved domains to use ActiveX without prompt.
10.Script ActiveX controls marked safe for scripting*.
11.Display video and animation on a webpage that does not use external media player.
Step 4: Click on <OK> to accept the settings. A prompt window will appear for confirming
the setting changes, click <Yes(Y)> to close the Security Setting window.
Step 5: Click on <OK> to close the Internet Options screen.
Step 6: Close the browser window, and restart a new one later to access the IP Camera.

18
Appendix D: Video Resolution
Quad Streams
H.264 + H.264 + H.264 + H.264 / MJPEG
H.264-1
H.264-2
H.264-3
H.264-4 / MJPEG
1920 x 1080 (15 fps)
1280 x 1024 (15 fps)
1280 x 720 (15 fps)
720 x 480 (15 fps)
640 x 480 (15 fps)
352 x 240 (30 fps)
800 x 600 (15 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
800 x 600 (30 fps)
352 x 240 (30 fps)
720 x 480 (15 fps)
720 x 480 (30 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
640 x 480 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
1280 x 720 (15 fps)
1280 x 720 (15 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
800 x 600 (30 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
720 x 480 (30 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
640 x 480 (30 fps)
640 x 480 (30 fps)
1280 x 720 (30 fps)
720 x 480 (30 fps)
352 x 240 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
1024 x 768 (15 fps)
800 x 600 (30 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
720 x 480 (30 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
640 x 480 (30 fps)
640 x 480 (30 fps)
1024 x 768 (30 fps)
800 x 600 (30 fps)
352 x 240 (30 fps)
720 x 480 (30 fps)
352 x 240 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
800 x 600 (30 fps)
800 x 600 (30 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
720 x 480 (30 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
640 x 480 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
720 x 480 (30 fps)
720 x 480 (30 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
640 x 480 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
640 x 480 (30 fps) 640 x 480 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
1920 x 1080 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)

19
H.264 + H.264 + H.264 + H.264 / MJPEG
H.264-1
H.264-2
H.264-3
H.264-4 / MJPEG
1280 x 1024 (15 fps)
1280 x 1024 (15 fps)
1280 x 720 (15 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
1280 x 720 (30 fps)
352 x 240 (30 fps)
800 x 600 (30 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
720 x 480 (30 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
640 x 480 (30 fps)
640 x 480 (30 fps)
1280 x 1024 (30 fps)
720 x 480 (30 fps)
352 x 240 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
1280 x 720 (15 fps) 1280 x 720 (30 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
1280 x 720 (30 fps)
800 x 600 (30 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
720 x 480 (30 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
640 x 480 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
1024 x 768 (30 fps)
800 x 600 (30 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
720 x 480 (30 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
640 x 480 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
800 x 600 (30 fps)
800 x 600 (30 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
720 x 480 (30 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
1280 x 1024 (30 fps)
1024 x 768 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
800 x 600 (30 fps)
800 x 600 (30 fps)
352 x 240 (30 fps)
720 x 480 (30 fps)
352 x 240 (30 fps)
640 x 480 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
720 x 480 (30 fps)
720 x 480 (30 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
640 x 480 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
640 x 480 (30 fps) 640 x 480 (30 fps)
640 x 480 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
352 x 240 (30 fps)
1280 x 720 (15 fps)
1280 x 720 (15 fps) 1280 x 720 (30 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
1280 x 720 (30 fps)
1280 x 720 (30 fps)
352 x 240 (30 fps)
800 x 600 (30 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
720 x 480 (30 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
640 x 480 (30 fps)
640 x 480 (30 fps)
1024 x 768 (30 fps) 800 x 600 (30 fps)
720 x 480 (30 fps)
640 x 480 (30 fps)
