ENERGY SISTEM urban box 3 User manual

1/8 energysistem.com
ENGLISH
Introduction 3 .....................................................................................................................................................................
Care and maintenance 3 ...................................................................................................................................................
Features 3 ...........................................................................................................................................................................
Technical specifications 4 ...............................................................................................................................................
Product content 4 ...............................................................................................................................................................
Buttons and ports 5 ...........................................................................................................................................................
Main functions 5 .................................................................................................................................................................
Switching on and off the device 5 ..................................................................................................................................
Charging the battery 6 ...................................................................................................................................................
Battery life 6 ...................................................................................................................................................................
Bluetooth pairing 6 ............................................................................................................................................................
Auto power off 6 .............................................................................................................................................................
Wireless playback control 6 .............................................................................................................................................
Call control 6 ..................................................................................................................................................................
Audio input 7 .......................................................................................................................................................................
Warranty 7 ...........................................................................................................................................................................
Warranty procedure 7 .......................................................................................................................................................
Trademarks 7 .................................................................................................................................................................
Declaration of conformity 7 ..............................................................................................................................................

2/8 energysistem.com

3/8 energysistem.com
Introduction
Thank you for your trust in our company and for buying the new Headphones BT Urban 3. We hope you enjoy
them.
We recommend you to read this manual in order to enjoy your device safely and with maximum performance.
Care and maintenance
Do not expose your Headphones BT Urban 3 to impacts, dust, humidity or high temperatures.
Do not use neither corrosive nor abrasive cleaning products.
Keep the headphones clean and free of dust using a soft dry cloth.
Do not disassemble your headphones. All reparation works should be carried out exclusively by qualified staff of
Energy Sistem Technology, S.A.
Do not leave the battery completely discharged for a long period of time.
Features
Deep and powerful bass that will make you vibrate with each song.
Wireless headphones with Bluetooth 4.2 technology.
Turn the volume up or down. Switch to the next or previous track. Playback control from the device.

4/8 energysistem.com
If you run out of battery use the audio cable to plug your headphones into your music player. Don't let the music
stop.
Metal finishes and comfortable ear pads.
Lithium-polymer battery with up to 13 hours of battery life.
Technical specifications
DESIGN:
Comfortable ear pads
Metal finishes
CONNECTIVITY
Bluetooth: 5.0
Range: 10 m
Supported Bluetooth protocols: HSP / HFP / A2DP / AVRCP
Operating frequencies: 2.4 GHz
Maximum output signal: < 20 dBm
DRIVERS:
Frequency response: 20 - 20,000 Hz
Driver diameter: 40 mm
SPL: 116 ± 3 dB
Maximum power: 30 mW
Closed design
Type: dynamic
Impedance: 32 ohms
THD < 1%
CABLE
Length: 120 cm
Connector: 3.5 mm mini jack
MICROPHONE:
Sensitivity: -42 dB ± 3 dB (@1 KHz)
BATTERY:
Capacity: 300 mAh / 3.7 V
Type: Li-Po
Battery life:
Battery life if volume is at 50%: 13 hours*
Charging port: microUSB Type-B
Charging time: 3 hours
OTHER FEATURES
Audio cable
MicroUSB charging cable
*Approximate battery life. This value depends on the selected volume level and the type of music you play.
Compatible with most popular smartphones on the market.
Product content
Headphones BT Urban 3
MicroUSB cable
Audio cable
Quick guide

5/8 energysistem.com
Buttons and ports
MULTIFUNCTION BUTTON1.
BACK2.
VOLUME -3.
NEXT4.
VOLUME +5.
STATUS INDICATOR6.
CHARGING PORT7.
AUDIO-IN8.
MICROPHONE9.
Main functions
Switching on and off the device
To switch on your Headphones BT Urban 3, press and hold the Multifunction button (1) for 3 seconds. You will hear a
confirmation sound. The Status indicator (6) lights up blue and keeps flashing while your Headphones BT Urban 3 are
on. To switch off your Headphones BT Urban 3, press and hold the Multifunction button (1) for 3 seconds. You will hear a
sound when switching off the headphones.

6/8 energysistem.com
Charging the battery
When the battery level is below 10%, the Status indicator (6) flashes red. You will also hear a sound to remind you to
charge the battery.
The Status indicator (6) glows red while charging the device and turns blue once the charging process has been
completed. Plug the microUSB end of the USB cable provided to your headphones' Charging port (7) and the other USB
end to any device with an USB charging port that provides energy (PC, USB wall charger, car charger, etc) to charge the
battery. The charging time is approximately 3 hours.
Battery life
Volume Low (25%) Medium (50%) High (75%) Maximum (100%)
15 hours 13 hours 12.5 hours 12 hours
Important considerations:
Do not store or leave your device unused or completely discharged for a long period of time.
Bluetooth pairing
Once your Headphones BT Urban 3 are off, press and hold the Multifunction button (1) for approximately 4 seconds,
until the Status indicator (6) starts flashing red and blue. At this point, your headphones and your Bluetooth device can
be paired. Once "Headphones BT Urban 3" appears on your source devide screen, press "connect". You will hear a
sound to confirm that both devices have been paired correctly.
If you previously paired your Headphones BT Urban 3 with a source device, they will synchronize with it automatically. If
you want to pair them again, press the Multifunction button (1) twice. You will hear a confirmation sound and the lights
will flash red and blue. At this point, your device can be paired once again.
Auto power off
Your Headphones BT Urban 3 Bluetooth will automatically turn off in the following situations:
After 5 minutes in search mode, if they are not synchronized with another device.
After 30 minutes, if they are synchronized and music is paused.
Wireless playback control
Once your Headphones BT Urban 3 are syncronized, you will be able to control basic playback functions such as turning
up and down the volume and switching to the next or previous song directly from your headphones.
Press Volume + (5) or Volume - (3) to turn the volume up or down. You will hear a sound when reaching the maximum
and minimum volume levels.
Press Next (4) to switch to the next song. You can also press and hold Back (2) to go back to the previous song.
Press the Multifunction button (1) once to pause or resume playback.
If you are using the audio cable instead of the Bluetooth connection, you will have to use your music player to
control music playback and not the headphones.
Call control
Once your Headphones BT Urban 3 and smartphone are synchronized, you will be able to answer calls thanks to the
headphones' built-in Microphone (9).
Press the Multifunction button (1) to answer an incoming call. If you are listening to music when you receive a call,
playback will pause and you will hear an incoming call sound. You can also press and hold this button for 2 seconds to
reject an incoming call.
Press the Multifunction button (1) once again to end a call. Playback will resume from the point when the music
stopped.

7/8 energysistem.com
Audio input
If you don't want to use the Bluetooth connection, you can also connect your Headphones BT Urban 3 to your music
player using the audio cable provided. You don't need to switch on your headphones if you want to use them in this
mode.
Simply plug one cable end into the Audio input (8) and the other end to your music player to enable this mode.
If you are using the audio cable instead of the Bluetooth connection, you will have to use your music player to
control music playback and not the headphones.
Warranty
Energy Sistem Technology, S.A. is liable for any lack of conformity that exists at the time the goods are purchased
during a period of 36 months. Batteries are excluded from the 36 month warranty, having a warranty period of 24
months. This warranty covers any defects in workmanship or materials and does not cover any product failure due to
accidents, misuse or alteration made by an unauthorized person.
The special 36 month warranty is valid for the European Union. For other countries please refer to your specific
legislation or your local distributor.
Warranty procedure
Please visit www.energysistem.com/en/support and select your product to view the FAQ (Frequently Asked Questions),
user manual, quick guide, drivers and updates available as well as to submit a query to our Technical Support or
manage the warranty. You may also contact the distributor that sold the product by presenting the purchase receipt or
invoice.
Trademarks
All company, brand and product names are trademarks or registered trademarks of their respective companies.
Specifications are subject to change without notice.
© 2018 by Energy Sistem Technology, S.A. All rights reserved.
Declaration of conformity
Issuer?s name: Energy Sistem Technology, S.A.
Address: C/ Calpe, 1 - 03509 Finestrat, Alicante (Spain)
Tel: [phone]
CIF: A53107488
We declare under our own exclusive responsibility that the product:
Description: Wireless earphones
Brand: Energy Sistem
Model: Headphones BT Urban 3
Manufacturer: Energy Sistem Technology, S.A.
Manufacturing country: China
referred to in this declaration is in compliance with the essential norms and standards
EN 62368-1:2014 + A11:2017
EN 62479:2010
EN 50663:2017
ETSI EN 301 489-1 V2.2.3 (2019-11)
ETSI EN 301 489-17 V3.2.4(2020-09)
EN 55032:2015
EN 55035:2017
ETSI EN 300 328 V2.2.2 (2019-07)

8/8 energysistem.com
in conformity with the provisions of the Directive 2014/53/EU of the European Parliament and of the Council of 16th
April 2014.
Finestrat, 1st December 2020
Miguel Ángel Aragüez García
Innovation and Technology Director
