1. INTRODUCTION
Thank you for purchasing this Energy™TV Player 150. First of all, welcome to the
Energy portable multimedia world. The following sections provide an overview of
your new device and its basics features. Please read everything carefully before
start using the product.
2. IMPORTANT SAFETY INSTRUCTIONS
To ensure your safety and the safety of others, please ensure that you read all the
safety information before operating this product.
Keep this information in a safe place for future reference.
This symbol indicates that this product incorporates double insulation
between hazardous mains voltage and user accessible parts.
WARNING: To reduce the risk of fire or electric shock, do not expose this appara-
tus to rain or moisture.
Safety Considerations.
≥ Position the cables so that they cannot be walked on or pinched by items placed on
or against them.
≥Do not use the set top box in humid or damp conditions.
≥Do not allow the set top box to get wet.
≥Do not expose the set top box to dripping or splashing.
≥Do not place water filled objects such as vases on top of the set top box.
≥Do not place naked flame sources, such as candles, on the top of the set top box.
Ventilation
The slots and openings on the set top box are for ventilation. Do not cover or block
them as it may cause overheating.
NEVER let children push anything into the holes or slots on the case.
Servicing
There are no user serviceable parts in this set top box.
Battery Disposal
Please ensure batteries are disposed of safely.
Never dispose of batteries in a fire or with other household waste.
Check with your local authority for disposal regulations.

30
Cleaning
ALWAYS unplug the set top box before you clean it.
Do not use liquid or aerosol cleaners.
Clean the set top box with a soft, damp (not wet) cloth.
ENERGY TV PLAYER 150 HANDLING AND CARE
Place the product in a well-ventilated area. Don’t install it in the cold or under direct sunlight.
Leave a minimum 10cm gap all around the product Do not disassemble, repair,
or reorganize the product
Don’t place cups with water or other liquids
on the top of the product Don’t place objects on the top of the product

31
ENGLISH
3. FEATURES
The Energy™TV Player 150 is a product of family high-definition home video player that
turns your TV into a multimedia center easily and without complicated connections.
Through USB port you can connect hard drives, pen drives, digital cameras, and
through the card reader memory cards included SD/SDHC/MMC and any device that
can be recognized as mass storage devices.
The Energy™TV Player 150 compatibility with SBS and anaglyphic 3D formats turns it
into the perfect match of your high definition TV, thanks to play the most popular HD
files in 1080p resolution in pictures and movie
3.1. Front panel
1 2
1. POWER LED: Turns blue while switched on, turns red light while stand-by.
2. IR RECEIVER: To receive the remote control signal.
3.2. Side panel
1. USB PORT: Supports multiple external USB storage devices.
2. 2-in-1 card reader: Supports SD/SDHC/MMC cards.

32
MEMORY CARDS USAGE
The Energy™TV Player 150 has an built-in multimedia card reader supporting memory
cards including SD/SDHC/MMC. Gently insert the memory card into the reader with the
arrow side upward until there goes completeley inserted into the slot.
3.3. Rear panel
1 2 3 4
1. DC IN: 5V power input.
2. HDMI: High Definition input.
3. AV Port (composite): composite output audio/video.
4. Digital Audio S/PDIF: audio output“S/PDIF” through optical port.

33
ESPAÑOL
4. REMOTE CONTROL
4.1. Buttons description
1. POWER: Turn on and off in the stand by mode
2. MUTE : Turn on or shut audio output
3. TV SYSTEM: Press to switch between NTSC, PAL, 480P, 576P,
720P 50HZ, 720P 60HZ, 1080I 50HZ y 1080I 60HZ, 1080P, 24HZ,
1080P 50HZ, 1080P 60HZ.
4. 0-9: Press to select channels or numbers.
5. GOTO: Jump to the appointed time/ page when playing video.
6. DISPLAY: Press to display time, title, information of chapter when
play video and photo.
7. HOME: Switch to the main menu.
8. FR: Press to fast rewind from current play and again to select the speed.
9. FF: Press to fast forward from current play and again to select the speed
10. RETURN: Return to the previous menu
11. OPTION: Press this button to enter setup menu
12. ◄ Press shortly to move cursor left
13. ▲ Press shortly to move cursor up
14. ► Press shortly to move cursor right
15. ▼ Press shortly to move cursor down
16. OK: Confirms a selection and starts the playback of a media file.
17. |◄◄ PREV: Press to return to previous file
18. ►►| NEXT: Press to go to next file
19. VOL-: Press to decrease the volume
20. VOL+: Press to increase the volume
21. SUBTITLE: Press to set the type, color, the text encoding format ,size of
subtitle, when playing the video
22. PLAY: Press to play media file and to autoplay the picture
23. STOP: End the playback of a media file
24. PAUSE/STEP: Pause the playback
25. SETUP: Press to enter to corresponding setting menu
26. AUDIO: Switch the audio format output
27. ZOOM: Zoom in/out.
28. REPEAT: Press to set repeat option: sequence, random, only once, rotate
one, rotate all.
29. RED KEY: Press this button, the list of all files in storage media will
display.
30. BLUE KEY: Press this button, the list of audio files in storage media
will display
31. GREEN KEY: Press this button, the list ofimage files in storage media
will display.
32. YELLOW KEY: Press this button, the list of video files in storage media
will display.
3
4
7
9
11
20
24
14
19
23
28
27
32
31
13
16
1
5
10
12
18
17
21
6
15
22
25
26
29
30
8
2

34
4.2. Installing the Batteries
Remove the battery cover from the remote control and put 2xAAA size batteries
inside the compartment.
The following diagram shows the correct way to insert batteries.
OP EN
CL OSE
1. Open the cover 2. Install batteries 3. Close the cover
≥Keep batteries out of reach of children. If someone swallows a coin cell or battery
must receive immediate medical attention.
≥Do not attempt to reactivate the batteries using heat, loading, or by other means.
Never dispose of batteries in fire, or disassemble or short circuit. Replace batte-
ries at least once a year to avoid spillage.
≥Replace both batteries at the same time and replace them with the same type.
≥When not using the remote control for a long time, remove the batteries.
4.3. Using the remote control
To use the remote control, point it towards to the front of the multimedia player.
The remote control has a range of 5 metres from the receiver at an angle of 40
degrees.
20º 20º

35
ENGLISH
The remote control will not work if the way to the receiver is blocked.
Sunlight or other very strong light will decrease the sensitivity of the remote
control.
5. CONNECTIONS
5.1. Power connection
Take out power adapter from the package and connect to the device.
5.2. Connection of TV audio and video output
The Energy™TV Player 150 is designed with multi-output, including composite (AV),
Optical and HDMI. Individuals can select different interface according various need.
It can detect video output automatically, making that the Energy™TV Player 150 ope-
ration becomes friendly and convenient. Please refer to the following instruction for
connection to avoid any problem.
5.3. Composite output connection (AV)
Plug the yellow connector into the AV output of the Energy™TV Player 150 and AV input
of TV, and plug the red and white connector into the audio input of TV or HIFI. Turn on
the TV and select AV mode. Turn on the device and TV displays the initiation interface.

36
5.4. Optical output connection
Connect the optical connector of the Energy™TV Player 150 with the optical connector
of other video or audio device by optical cable. Then enter the device audio output
format interface, select the Digital Output option "SPDIF”. It is available to enjoy 5.1
high quality sounds through a multi channel decoder/amplifier with optical input.
Note: when selecting the “normal” output, there is no video by optical output, and if
select the “SPDIF” output there is no video by HDMI and AV have no audio output.
5.5. HDMI output connection
HDMI offers the best audio and video effect. Connect HDMI cable to output of product
and display device with HDMI input. Select HDMI mode in TV until it displays the user
interface.
When selecting the "HDMI" output, there is no video output by AV. When selecting the
"AV" output, there is no video by "HDMI".

37
ENGLISH
5.6. USB connection
The Energy™TV Player 150 has an USB port that can read external HDD, digital
cameras, memory cards (SD/SDHC/MMC) and other data storage devices.
You can connect external storage devices through the USB HOST interface. To direct
play a variety of high-definition formats high-fidelity audio and video files stored in
external storage devices.
5.7. Firmware upgrade
TV Player 150 can be upgraded to allow system improvements in the future.
Download the latest firmware version from http://www.energysistem.com.
Unzip the file and copy it to a USB storage device. Make sure that the USB device is
empty and in FAT32 format.
Use the file browser to select the firmware file and press ‘Ok’. Confirm that you want
to upgrade and don’t power off the TV Player 150 until the process finishes. When its
completed the unit will automatically reboot.
WARNING: Do not switch off the device while the firmware upgrading is taking place,
in this case the TV Player 150 will become unstable and the official warranty will be
cancelled.

38
6. USER INTERFACE
Please read the following instructions carefully to understand the function of each
option.
When connecting the power supply for the first time, press the “power” key on the
remote control and the device will power on automatically and display the main menu.
6.1. Main menu
There are three function options in the main menu.
You can enter this main menu by pressing “HOME” key on the remote control. Under
the main interface, you may select the USB Device, Smart Card, Setup icon by
pressing ▲ and ▼ key on the remote control, then press “OK” key to browse
or play the corresponding files stored in the external USB, device or memory card.
In addition to, you can go to the setup menu directly and configure the “System”,“Video”
“Audio”, “Photo” and adjust the device options according to your needs.

39
ENGLISH
6.2. Setup menu
Select “Setup” option to enter the setup menu. Then select any option you want by
pressing “up” and “down” on the remote controll, and press OK to confirm or press
“Return” to exit.
6.2.1. System setup
≥Language: Select to choose the OSD (On Screen Display) language. Press ▲
and ▼ to select the language. Press OK to confirm.
≥Auto Play: Turns the Auto Play function on or off. If is ON, when you are playing a
file the next one will automatically played after the current video ends.

40
≥Screen: Turns on or off the function of screen saver. Press the navigation keys
to select. Screen saver mode will automatically start after 2, 5 or 10 minutes of
non activity.
≥Restore Default: To restore the factory’s default settings
≥System Info: display software version information
6.2.2. Audio setup
Select to choose the audio output:
≥Normal: signal is directly outputted through Energy™TV Player 150.
≥SPDIF Digital: audio signal is decoded by theTV Player through optical output.
(SPDIF/PCM/RAW)
6.1.3. Video setup
≥Video Output: Select to adjust TV system NTSC,PAL,480P,576P,720P, 50HZ,
720P 60HZ, 1080i 50HZ, 1080i 60HZ, 1080P 24HZ,1080P 50HZ, 1080P 60HZ.
≥Resume Play: On/Off. If ON, the device will record the current time when the
playback is stopped. Next time you access to the video file the device will ask if
you want to resume the playback from the last pause point or if you want to re-
start the playback from the beginning.
≥Auto Detect: when a file is being played automatically detects the video
configuration.

41
ENGLISH
6.2.4. Photo setup
≥Slide Show Timing: Set time interval of slide show. 3/5/10/20s.
≥Transition Effect: Select a picture transformation effect, there are eight
different effects to choose.
≥Background Music: If you choose the Folder option, the audio files stored on the
folder of the pictures you are displaying will become the Background Music. If you
do not want to use the Background Music function just select the option close.

42
6.3. Picture view mode
Enter a storage device, and the pictures files under the current directory will be set
out. Press ▲ and ▼ to select the folder containing your photo files. You also can
press green or red key on remote, if you press green key, all folders and supported
picture files will be displayed, if you press red key, all folders and supported video,
audio and picture files will be displayed.
Note : If you press the other two buttons (blue, yellow) on the remote control there
will no photo files display.
6.4. Audio play mode
Enter a storage device and the audio files under the current directory will be set out.
Press ▲ and ▼ to select the folder containing your audio files. You also can press
blue or red key on remote, if you press blue key, all folders and supported music files
will be displayed, if you press red key, all folders and supported video, audio and
picture files will be displayed.
Note: If you press the other two buttons (green or yellow) on the remote control
there will no audio files display.

43
ENGLISH
6.5. Video play mode
Enter a storage device, and the video files under the current directory will be set out.
Press ▲ and▼ to select the folder containing your video files. You also can press
yellow or red key on remote, if you press yellow key, all folders and supported movie
files will be displayed, if you press red key, all folders and supported video, audio and
picture files will be displayed.
Note: If you press the other two buttons (green or blue) on the remote control there
will no video files display.
Enter the folder press ▲and▼ to select the video file you want to view and press OK
and the playback will start in full screen. The device supports multiple video formats,
including RM, RMVB, AVI, MPG, VOB, DAT, MKV, MP4, FLV, DIVx.
In addition, the device also supports breakpoint movie play. Next time you play the
movie, there will be a prompt: “ from the breakpoint”. If you choose to “YES”, the movie
will start from where it stops last time.

44
6.6. Subtitle
The Energy™TV Player 150 supports subtitle file formats including SSA, SUB, SRT.
Make sure the subtitle file and the video file are stored in the same folder and have the
same name. When playing the file, press SUBTITLE button to show / hide the subtitle
setup menu and realize subtitles settings.
If using external subtitles in a movie, press the arrow keys on the remote control to
select the option to adjust and press OK to confirm. Then you can set several options
by pressing UP/DOWN arrow key on remote control to adjust the subtitles to your needs
or preferences:
≥Encode format,
≥Font size,
≥Font color of the subtitle
For example, to change the color of subtitle, firstly select the color option by pressing
right arrow keys, then press OK key to enter, finally press up/down arrow key to select
the option you need and press OK key to confirm the setting.

45
ENGLISH
7. TROUBLESHOOTING
If you experience problems with this receiver or its installation, in the first instance
please read carefully the relevant sections of this User Manual and this Troubleshooting
section.
Problem Possible cause What to do
Standby LED not lit.
Your TV Player 150 is
unplugged.
Check the connections and
ensure that the TV player is
plugged.
No picture.
The Connection of TV
audio and video output is not
correct.
Check that you have
connected the correct cable
for the output of the video
signals.
No response to
remote control.
Receiver off Plug in and turn on receiver.
Front panel obstructed Check for obstructions.
Remote control batteries are
inserted incorrectly
Check batteries direction.
Remote control batteries
exhausted.
Replace remote control
batteries.
No Sound.
Volume is too low.
Check if the volume ofyour
TV Player or TV is set to an
adequate level.
Mute is active.
By pressing the mute button
on the remote control you
can desactivate the mute
function.
